Scanstrut ROKK Bezel User manual

IMPORTANT SAFETY INSTRUCTIONS
The product must be installed in accordance with the instructions provided. Failure to do so
could result in personal injury, damage to your vessel and/or product failure.
Scanstrut recommends a professional builder/installer to install the product. No liability is accepted for damage
and/or injury caused by incorrect installation.
WARNING
•This product is designed to be tted to a 12/24V DC power source only.
•This product may contain high voltages. Do not tamper with the product.
•The power supply must be switched off before installing the product.
•An appropriately selected fuse or circuit breaker must be used in line between the battery and the product
•This product is NOT approved for use in hazardous/ammable atmospheres. Do NOT install in a hazardous/
ammable atmosphere (Such as engine room of near fuel tanks).
•To ensure proper heat dissipation of the product, ensure it is being tted with adequate space for proper
ventilation.
CAUTION
•The product has been designed specically for the charging of Qi compatible devices.
•The cable must be adequately retained.
•This product contains no user serviceable components. Do NOT attempt to repair or
alter the product in any way.
•The high friction top surface does not ensure the device will not slip during extreme operating environments
such as high acceleration and deceleration.
•If a phone case which is thicker than 3mm is used it may cause either the device to not charge at all or the
product to temporarily shut down, this is a safety feature which protects the electronics from over-heating.
•When used in a high ambient temperature the product may temporarily shut down, this is a safety feature
which protects the electronics from over-heating. This safety feature may also be seen on the phone where it
will stop accepting charge.
•The IP rating is only valid if installed onto specied surfaces and closely following the installation instructions.
READ THESE INSTRUCTIONS BEFORE
INSTALLING THE PRODUCT
17/08/18 Issue 1 IMPORTANT SAFETY INSTRUCTIONS

1
Drill hole 10mm (25/64”).
2Place charger and Bezel over hole
to mark screw centres. **Caution**
Do not remove self adhesive
backing from tape, dry t only.
4
Remove self adhesive backing from
charger.
5
7Install charger into bezel.
Connect wires to 12-24V
supply, ensuring a water-
proof connection. Fuze
appropriately according to
input voltage and current.
8
Screw Bezel to surface.
Remove and mark hole centres in
bezel.
Warning Switch O Power Supply
Ensure electrical power is turned o
before installing this product. Do not
connect or disconnect with power on.
Warning Switch O Power Supply
Ensure electrical power is
turned obefore installing
this product. Do not
connect or disconnect with
power on.
Tools Required
Power drill
10mm (3/8”) Drill
Alcohol Wipe 1.6mm (1/16”) Drill
Parts List
Charger x1
x1
Bezel & gasket
Input voltage range : 5-32V (12/24V system)
Input currant range: 0.5-1.5A
Output power: 5W (5V 1A)
Standby current draw: < 0.03W
Certications: Qi, CE, FCC, ROHS
Waterproof rating: IPX6 front and back
Techinical information
x3 x1
3
Drill 3x 1.6mm (1/16”)
pilot holes.
Installation Instructions
ROKK Wireless Charge Bezel (SC-CW-03)
08-08-18 Issue 5
®
No6 x 1/2” self tapping screw
6
