Scosche StuckUp User manual

@ ,S'C'C,£FC:, IE .
STUCKUpVENT/DASH

(EN)
INCLUDED ELE MEN TS
A. Universal Wireless
Charging Mount
B. T-Notch/Ball Adapter
C. Dash Mount
D. Vent Mount 0
E. Car Adapter
F. Cable Routing Clips (2)
G. Cleaning Wipe
English .... . .... . ...... . ... . ...... 2-1 o
0
2
E]
0

DEVICE SE T UP
SECTION A- Universal Charging Phone Mount OveNiew
SECTION B- Dash Mount Assembly & Installation
SECTION C- Vent Mount Assembly & Installation
SECTION D- Mount Adjustment
SECTION E- Connection & Charging
3
(EN)

(EN}
SEC TI ONA
Universal Wireless
Charging Phone Mount
A. Side SupportArms
B. Wireless Charging Area
C. Bottom Support
D. Side Support Release Bu tt on
E. T- N otch Opening
F. Bottom Support Release Button
4

SECTION B
Dash Mount
Assembly
1. Remove collar from ball-joint socket
2. Place collar over ball end oft-notch/ball adapter,
then place ball end in socket.
3. Tighten collar onto socket.
4. Place t-notch hitch 1n opening
5. SI de up to lock in place
Removal
6. Press lever to release t-notch .
7. Slide down to remove.
Installation
Clean the mounting surface using supplied
wipe*. Remove backing from adhesive base,
place mount in position and press firmly.
*Supplied cleaning wipe may cause discoloration of
certain plastics, vinyls and painted surfaces . It is
recommended to test in an inconspicuous area first.
~0 ~P(Ji
5
(EN)

(EN) SECT IONC
Vent Mount
Assembly
Insert t- notch hitch on vent mount
into opening on back of mount head
(A} , and slide upward (B)
Slide vent mount down to remove (C) .
Installation
Rotate vent clips on mount (D}
to align with vent (E)
Note : Works with many vent
designs (F) . Not compatible with
curved or circular vents (G}
6
~
63
(1H)
-- '}

Press the side & bottom support
release buttons (A & B) to fully
open the Universal Mount.
Place the device in the mount and
manually press the side supports
inward to secure the device (C)
Note: The bottom support may also be
adjusted manually to raise the devi cein
the mount, if needed .
Press the side support release
button to remove the device .
Loosen the ball-joint collar on the
Dash Mount (D) to adjust mount
angle or rotate mount (E) ,
Note: Vent mount may be rotated only .
SECTION D
(EN)
8l
'~
0
7

(EN)
Wireless Charger*
Input: 12.0V =-== 2.0A
Output: 15.0W /1 0.0W I
7. SW/5.0W
*Actual charge rates may vary
depending on device software and
environmental conditions .
LED Status Indicators
Off. Standby
Blue: Charging
Flashing Red Foreign Object
Detected (FOD)
Car Adapter
Input. 12 . 0V 24 . 0V ~-- 6 OA
SECTION E
Type-C Output ·5 OV === 3 OA /9. 0V -:::: 2 22A
DC Output: 12 . OV :-::. 2. OA
20W USB-C Po w er Delivery Port
8
Cable Routing Clips (2)
12VOutput

FCC Compliance Statement
(EN}
This device complies with part 15 of the FCC Rules Operation is subiect to the following two conditions: (1} Th,s device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation .
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user 1s encouraged to try to correct the interference by one or more of the following
measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver 1s connected .
- Consult the dealer or an experienced radio/TV technician for help
Canadian Compliance Statement
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Soence and Economic
Development Canada's licence-exempt RSS(s) Operation 1s subject to the following two conditions ( 1) this device
may not cause interference and (2) this devJCe must accept any interference, including interference that may cause
undesired operation of the device
This Class [Bl digital apparatus complies with Canadian ICES-003
CAN ICES-3 (B)/NMB-3(8)
9

(EN)
StuckUp Ven t /Dash
Scosche Industries
1550 Pacific Avenue
Oxnard, Californra 93033
Phone· 800-J6-~-t1490 x1 / ROS-486-4450 xl
www.scosche.com
(~)2022 Scosc.nr.: lnoustr·es
Scosche 1s a tradeniarl of Scosche lndustnes
Other marh or brancis are tl'Je pror.1erty of their respective owners
D~:" ✓ 1Ce$ and or appearance rnay vary
Designed in Oxnard, California •
SI UQ3DV l /22
10

Please note that changes or modifications to this product not expressly approved by the party
r esponsible for c ompliance could void the user's authority to operate the equipment.
Th is equ i pment c omplies with FCC radiation exposure limits set forth for an uncontrolled
env i ronment. Th is equipment shall be installed and operated with minimum distance 15cm
between the radiator & body .
Th is equ i pment c omp li es with IC exposure li mits set forth for an uncontrolled environment.
This equ i pment shall be i nsta ll ed and operated with minimum distance 10cm between the
radiator & body .
