Sealey PC35 User manual

INSTRUCTION MANUAL FOR:
MODELS: PC35 & PC40
Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT:PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLYAND WITH CARE FOR THE PURPOSE FOR WHICH
IT IS INTENDED. FAILURE TO DO SO MAYCAUSE DAMAGE AND/OR PERSONAL INJURYAND WILL INVALIDATE
THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
pWARNING! The blades used by these cutters are razor sharp and should be treated with due caution.
3Store the cutters in a safe childproof place when not in use.
3Use in a suitable, clean and tidy work area, free from unrelated materials. Ensure there is adequate lighting.
3Use the cutters for rubber and soft vinyl pipes only.
7DO NOT use cutters on hard reinforced pipe. If the blade does not penetrate the pipe, then the materials
used to make the pipe are too hard. Applying excessive pressure may cause the pipe to shatter.
7DO NOT continue to attempt cutting any pipe that withstands penetration.
7DO NOT insert a finger into the cutting area at any time.
7DO NOT turn the pipe whilst cutting.
7DO NOT allow untrained people to use the cutters.
7DO NOT allow children to use or play with the cutters.
7DO NOT use the cutters for tasks they are not designed to perform.
7DO NOT operate cutters if any parts are damaged or missing as this may cause failure and/or personal injury.
7DO NOT operate the cutters when you are tired, under the influence of alcohol, drugs or intoxicating
medication.
PC35, PC40 - 1 - 170504
PC35
Cutting capacity
6 - 35mm OD
2. INTRODUCTION
The PC35 & PC40 plastic pipe cutters have die cast aluminium bodies with heat treated AUS-8 grade stainless
steel blades. Both feature ratchet action cutting to avoid the crushing of pipes and push button blade retraction.
Suitable for cutting plastic pipes and extrusions.
PC40
Cutting capacity
6 - 42mm OD
PLASTIC PIPE AND EXTRUSION CUTTERS PLASTIC PIPE AND EXTRUSION CUTTERS
INSTRUCTION MANUAL FOR:
MODELS: PC35 & PC40
Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT:PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLYAND WITH CARE FOR THE PURPOSE FOR WHICH
IT IS INTENDED. FAILURE TO DO SO MAYCAUSE DAMAGE AND/OR PERSONAL INJURYAND WILL INVALIDATE
THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
pWARNING! The blades used by these cutters are razor sharp and should be treated with due caution.
3Store the cutters in a safe childproof place when not in use.
3Use in a suitable, clean and tidy work area, free from unrelated materials. Ensure there is adequate lighting.
3Use the cutters for rubber and soft vinyl pipes only.
7DO NOT use cutters on hard reinforced pipe. If the blade does not penetrate the pipe, then the materials
used to make the pipe are too hard. Applying excessive pressure may cause the pipe to shatter.
7DO NOT continue to attempt cutting any pipe that withstands penetration.
7DO NOT insert a finger into the cutting area at any time.
7DO NOT turn the pipe whilst cutting.
7DO NOT allow untrained people to use the cutters.
7DO NOT allow children to use or play with the cutters.
7DO NOT use the cutters for tasks they are not designed to perform.
7DO NOT operate cutters if any parts are damaged or missing as this may cause failure and/or personal injury.
7DO NOT operate the cutters when you are tired, under the influence of alcohol, drugs or intoxicating
medication.
PC35, PC40 - 1 - 170504
PC35
Cutting capacity
6 - 35mm OD
2. INTRODUCTION
The PC35 & PC40 plastic pipe cutters have die cast aluminium bodies with heat treated AUS-8 grade stainless
steel blades. Both feature ratchet action cutting to avoid the crushing of pipes and push button blade retraction.
Suitable for cutting plastic pipes and extrusions.
PC40
Cutting capacity
6 - 42mm OD
PARTNUMBERS FOR SPARE BLADES
PC35/B and PC40/B
PARTNUMBERS FOR SPARE BLADES
PC35/B and PC40/B
pc35, pc40.qxd 6/1/2004 11:29 Page 1

3. OPERATING INSTRUCTIONS FOR PC35 & PC40
fig. 1
3.1. ADJUSTING MODEL PC40 TO CUT
SMALLER PIPE SIZES UNDER 26MM
3.1.1 The PC40 has a switch on its top surface which
adjusts the starting position of the blade to more
conveniently cut pipe sizes of 26mm or less.
3.1.2 To select the 26mm position first retract the blade by
pressing the retraction button (See fig.1-R).
3.1.3 Now squeeze the handle/trigger fully six times, then
move the switch to the 26mm position. The blade will
only now retract sufficiently to allow a 26mm tube to
be inserted.
3.1.4 To return to the 42mm position first press the
retraction button which will partially retract the blade.
3.1.5 Now squeeze the handle/trigger fully three times,
then move the switch to the 42mm position. The
blade will now fully retract when the retraction button
is pressed.
PC35, PC40 - 1 - 170504
