Sealey GSA26 User manual

Ø75MM AIR CUT-OFF TOOL - STRAIGHT
MODEL NO: GSA26
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Follow all workshop Health & Safety rules, regulations and conditions when using tool.
WARNING! Disconnect from air supply before changing cutting disc or servicing.
9Maintain tool in good condition and replace any damaged or worn parts. Use genuine parts only. Unauthorised parts may be dangerous
and will invalidate the warranty.
WARNING! Check correct air pressure is maintained and not exceeded. We recommend 90psi.
9Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and
ensure that all connections are secure.
WARNING! Before each use check cutting disc is secure and the disc is not worn or damaged. If damaged replace immediately.
9Ensure replacement discs are not damaged in any way such as cracks, deformations or splinters etc. Also check the mounting washer
to ensure it is not deformed, burred or notched. Damaged washer must not be used as it may cause irregular pressure on the disc
which may cause the disc to break. DO NOT over tighten a disc and never tamper with a disc in order to adapt it to a different
size holder.
9Always use the correct disc suitable for the material being cut. Ensure the maximum speed specification of the cutting disc is higher
than that indicated on the machine data plate.
WARNING! Keep disc guard in place, tight and in good working order. The safety guard is a mandatory tting where tool is used in
premises covered by the Health & Safety at Work Act.
WARNING! Always wear approved eye or face protection when operating the tool.
9Use breathing protection in accordance with COSHH regulations if fumes or dust pose a hazard.
9Wear ear defenders and gloves if necessary.
9Keep hands and body clear of the workpiece when operating the tool.
9Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9Secure unstable workpiece with a clamp, vice or other adequate holding device.
9Keep children and non essential persons away from the working area.
9Avoid subjecting disc to excessive strain, always ease disc down against workpiece (a harsh impact may break the disc). DO NOT use
force in order to cut workpiece. Maintain a controlled progression.
8DO NOT get the tool wet or use in damp or wet locations.
8DO NOT hold the workpiece by hand. Use clamps or a vice to secure the workpiece.
8DO NOT use the tool for a task it is not designed to perform.
WARNING! DO NOT use tool if damaged or faulty. Contact your local service agent.
8DO NOT use tool unless you have been instructed in its use by a qualified person.
8DO NOT position your body in line with the disc whilst cutting, and DO NOT remove the safety guard whilst in use.
8DO NOT carry the tool by the air hose, or yank the hose from the air supply.
8DO NOT direct air from the air hose at yourself or others.
WARNING! DO NOT cut any materials containing asbestos.
8DO NOT switch the tool on whilst the disc is in contact with the workpiece.
8DO NOT allow workpiece to overheat. Cool using an oil lubricant.
8DO NOT use tool where there are flammable liquids, solids or gases such as paint solvents, including waste wiping or cleaning rags etc.
as any sparks generated may be dangerous.
8DO NOT touch the workpiece close to the ground surface as it will be very hot. Allow to cool. The workpiece may also be very sharp.
8DO NOT operate tool if you are tired or under the influence of alcohol, drugs or intoxicating medication.
9When not in use disconnect from air supply and store in a safe, dry, childproof location.
GSA26 Issue 2 (HF) 04/11/20
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear ear
protection
Wear a mask
Danger of Fire/Explosion Hazard
WARNING! The grinding process can produce streams of sparks (especially when grinding metal), which are a potential source of
ignition.
8DO NOT use the grinder where there are flammable liquids, solids or gases.
8DO NOT allow grinder sparks to make contact with the operator’s clothing or any other fabric such as cleaning rags. Fabrics
contaminated with inflammable materials such as petrol, oil, grease, paint and solvents are a particular fire hazard.
9To reduce the risk of clothing catching fire the operator should wear wool or cotton outer garments treated with a fire retardant in
preference to man-made fibres.

2. INTRODUCTION
Generation series air cut-off tool. Contoured handle insulates user from chill and vibration effects. Unlike conventional cut-off tools, the cutting
disc is in-line with the handle for easier directional control. Metal disc guard and rear air exhaust can be rotated 360° giving operator added
protection. Includes 4-position air valve and safety release trigger control to prevent accidental operation. Cutting disc not included.
3. SPECIFICATION
Model No:....................................................................................................................GSA26
Air Consumption:..............................................................................................................4cfm
Consumables
Cutting discs ........................................ Cutting Discs: PTC/3C (Single), PTC/3C5 (Pack of 5)
Disc size........................................................................................................ Ø75 x 2 x 10mm
Free speed...............................................................................................................20000rpm
Inlet size..................................................................................................................... 1/4”BSP
Noise power/pressure ............................................................................................97/86dB(A)
Operating pressure .........................................................................................................90psi
Vibration/uncertainty ............................................................................................2.2/0.05m/s²
4. PREPARATION FOR USE
4.1. AIR SUPPLY
4.1.1. Recommended hook-up procedure is shown in fig 1.
4.1.2. Ensure tool air control valve (or trigger) is in “Off” position before connecting to the air supply.
4.1.3. You will require an air pressure of 90psi, and an air flow according to specification.
WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the tool. Too high an air pressure and unclean
air will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
4.1.4. Drain the air tank daily. Water in the air line will damage the tool.
4.1.5. Clean air inlet filter weekly.
4.1.6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should be
1/4” I.D. and fittings must have the same inside dimensions.
4.1.7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are secure.
4.2. COUPLINGS
4.2.1. Vibration may cause failure if a quick change coupling is connected directly to the tool. To overcome this, connect a leader hose to
the tool. A quick change coupling may then be used to connect the leader hose to the air line recoil hose (see gs.1 & 2).
5. OPERATION
5.1. CHANGING THE CUTTING DISC
WARNING! Disconnect from the air supply before changing disc.
5.1.1. Check that replacement disc is not damaged (cracks, deformations or splinters etc).
5.1.2. Use spanner to secure the shank and unscrew central hex screw with hex key.
5.1.3. Remove the washer and old disc, place the new cutting disc onto the spindle.
5.1.4. Replace the washer and secure with hex screw, but do not over tighten.
5.1.5.
5.1.6. Also check the mounting washer to ensure it is not deformed, burred or notched.
5.1.7. A damaged washer must not be used as it may cause irregular pressure on the disc which may cause it to break. DO NOT tamper with
a disc in order to adapt it to a different size holder.
5.2. OPERATING
 WARNING!Ensure you have read, understood and apply safety instructions.
5.2.1. Connect the tool to the air supply.
5.2.2. To start the tool, hold firmly and push the trigger locking lever forward whilst depressing trigger.
5.2.3. The disc must be running at its maximum speed before attempting to cut the workpiece.
5.2.4. Slowly and smoothly bring the cutting disc toward the workpiece (avoid jerky movements).
5.2.5. Exert adequate pressure on the tool to allow cutting according to the type and size of the material you are working with. Avoid
subjecting disc to excessive strain, always hold tool firmly and ease disc against workpiece (a harsh impact may break the
disc). Maintain a controlled progression.
5.3. SAFETY
The GSA26 Air Cut-Off Tool has improved features including:
360° rotating metal guard, to protect the user from shards/debris during cutting.
360° rotating exhaust, this allows the user to direct airflow away from the body/hands. This is located at the base of the tool’s handle
Variable air-valve, allows 4 different degrees of air pressure into the unit.
g.1
g.2
Original Language Version
© Jack Sealey Limited GSA26 Issue 2 (HF) 04/11/20

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 24 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
8DO NOT allow tool to free run for an extended period of time as this will shorten its life.
6. MAINTENANCE
WARNING! Disconnect tool from air supply before changing accessories, servicing or performing maintenance. Replace or repair
damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
6.1. If the air supply does not have an oiler, lubricate the air tool daily with a few drops of Sealey air tool oil dripped into the air inlet to
prolong its life.
6.2. Clean the tool after use.
6.3. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air line. Moisture or restriction in the air pipe. Incorrect size or type of hose connectors. To remedy check the
air supply and follow instructions in chapter 4.
b) Grit or gum deposits in the tool may also reduce performance. If your model has an air strainer (located in the area of the air inlet),
remove the strainer and clean it. Flush the tool out with gum solvent oil or an equal mixture of SAE No 10 oil and paraffin. Allow to
dry before use.
6.4. For a full service contact your local Sealey service agent.
6.5. When not in use, disconnect from air supply, clean tool and store in a safe, dry, childproof location.
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a):.....................................2.2m/s²
Uncertainty value(k):....................................................................0.05m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission.
We recommend that a specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of
Hand Arm Vibration Syndrome.
Health surveillance.
We recommend a program of health surveillance to detect early symptoms of vibration injury so that management procedures can be modified
accordingly.
Personal protective equipment.
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the
uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and dry and
maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the Correct Use and
Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSC website www.
hse.gov.uk - Hand-Arm Vibration at Work.
