Sealey LP290 User manual

Cable
Restraint
Brown
Live
Connection
1.1. PLUG & MAINS POWER SUPPLY.
 WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also
recommend that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual
Current Device by contacting your Sealey dealer.
YOU MUST also read and understand the following instructions concerning electrical safety.
NOTE: 110 volt heaters are usually operated by connecting to a transformer or a generator. Check to ensure all supply equipment is compatible
with the rating of the heater.
1.1.1. The Electricity at Work Act 1989 requires all portable electrical appliances, if used on business
premises, to be tested by a qualified electrician, using a Portable Appliance Tester (PAT), at least
once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for
the safe condition of those appliances and the safety of the appliance operators. If in any doubt
about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the
power supply. See 1.1.1 and 1.1.2 and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all connections
to ensure that none are loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply to be
used and that the plug is fitted with the correct fuse - see fuse rating on right.
1.1.7. Important: For use with a 110 volt supply - ensure that the 110 volt transformer or generator
is adequately rated.
1.1.8. DO NOT pull or carry the appliance by the power cable.
1.1.9. DO NOT pull the plug from the socket by the cable.
1.1.10. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item repaired
or replaced by a qualified electrician. When an ASTA/BS approved UK 3 pin 13 amp plug or 110 volt
plug is damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only - see diagrams on right).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly
connected, that the cable outer insulation extends beyond the cable restraint and that
the restraint is tight.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance plugged
into it will be protected. The cable core section is important and should be at least 1.5mm2, but to be absolutely sure that the capacity of
the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use of 2.5mm2
section cable.
1.2. GENERAL SAFETY.
 WARNING! Disconnect heater from mains supply before servicing or performing maintenance. Replace or repair damaged parts. Use genuine
parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
 WARNING! NOT to be used for the heating of habitable areas of domestic premises: for use in public buildings, refer to national regulations.
 Store gas cylinders in accordance with regulations applicable to such appliances.
 Ensure that nothing stands or passes in front of the heater. Mandatory minimum distance from the heater is 1 metre.
 Use the supplied pressure regulator only.
 Ensure continuous ventilation is provided to the heater operating area. A ventilation opening must run to the outside of the premises where the heater is
to be operated. The opening must be 100cm2for every kW and must also be set at an equal distance from the upper and lower parts of the heater operating area.
WARNING! If the heater is used for prolonged periods at maximum power, ice may form on the propane cylinder. This is due to excessive
evaporation. In such a case DO NOT use the heater to de-ice the cylinder.
 DO NOT use the heater if damaged. Take immediate action to repair or replace damaged parts. Use an authorised service agent only.
 DO NOT allow untrained persons to ignite the heater.
 DO NOT operate the heater without the cover.
 DO NOT exceed the 100W/m3limit considering the volume of the empty operating location.
 DO NOT use a naked flame to try and ignite the heater.
 DO NOT use the heater near inflammable, combustable or explosive materials - liquids, solids or gases.
 DO NOT leave the heater unattended whilst in use.
 DO NOT obstruct the air inlet and outlet sections of the heater. Keep immediate area clean and tidy.
 DO NOT point the heater towards the gas cylinder.
 Keep the heater clean and in good working order.
 Ensure that the heater is correctly turned off and the gas source isolated, when not in use.
 When not in use for any length of time, store heater in a safe, dry, childproof location.
Blue Neutral
Connection
Yellow &
Green
Earth Wire
Connection
230V
110V
LP290, Issue No: 2(I) - 24/09/14
Original Language Version
©Jack Sealey Limited
Recommended Fuse Rating: 13Amp
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
1. SAFETY
INSTRUCTIONS FOR:
SPACE WARMER PROPANE HEATER
139,727-289,384BTU/HR 110/230V
MODEL NO: LP290

Model No: ....................................................... LP290
Output (kW): ......................................................40-84
Output (Btu/hr): .............................. ...........139,727-289,384
Airflow (cfm): .....................................................1,501
Fuel Consumption (kg/hr): .......................................2.46-5.53
Electrical Input (V):............................ .................. 110/230
Length x Width x Height (mm):...............................700 x 317 x 538
Fuel:...........................................................Propane
Heated Volume (ft3): ...............................................60,716
Heated Volume (mtr3):..............................................1,720
Weight (kg):..........................................................16
These propane heaters are fan assisted, tted with a piezoelectric ignition system for trouble-free starting, and feature a direct gas head assembly.
They feature a safety solenoid preventing the unit from leaking gas without rst being electrically started. Supplied with an approved propane gas
regulator and hose. All models are tested and certied to CE/EN standards by DVGW. Manufactured to BS EN 416.
LP290 Issue No: 2(I) - 24/09/14
Original Language Version
©Jack Sealey Limited
2. INTRODUCTION
3. SPECIFICATION
4. ASSEMBLY
5. INSTALLATION
Note: Fixings for assembly are located in the heater body.
4.1. Fit front legs, see g.1.1.
4.2. Fit rear leg, see g.1.2.
4.3. Fit handle supports, see g.1.3.
4.4. Fit handle in between the handle supports, see g.1.4.
fig.1 fig.2
Note: If a small gas cylinder is used, the heater may not operate at maximum efficiency. It is recommended to use two or more cylinders
linked in parallel, to achieve maximum continuous efficiency (fig.3).
5.1. Setting heater supply voltage.
5.1.1. Locate the voltage selection switch (fig.2.).
5.1.2. If the correct supply voltage is not selected, remove the cover, select the required voltage position (fig.5) and refit the cover panel (fig.2).
5.2. Connections.
5.2.1. Check heater and gas cylinder to ensure that they are both in good condition. If not, stop and contact your supplier immediately.
5.2.2. Site the heater and gas cylinder in the location to be heated.
5.2.3. Connect the heater to an electrical supply outlet, ensuring that the machine is correctly earthed. See Section 1 Safety Instructions.
5.2.4. Connect the gas supply hose to the excess flow valve (fig.4), connect the valve to the pressure regulator, and connect the regulator to the
gas cylinder. Note: Left hand threads. Connect the other end of the supply hose to the heater. Ensure all connections are tight.
5.2.5. Gradually open the tap of the gas cylinder. Check hose and all fittings for any gas leaks.
WARNING! DO NOT USE A NAKED FLAME! To check for leaks, the use of a foamy soap solution is recommended.
fig.3
fig.4

IMPORTANT: To ensure continuous ventilation to the heater area, a ventilation opening must connect to the outside of the premises where the heater is to
operate. The opening must be 100cm2for every kW of output, and must be set at an equal distance from the upper and lower parts of the heater
operating area.
6.1. Switching Heater On.
6.1.1. Switch the On/Off switch to the ON (I) position (fig.6) and check that the fan starts running.
6.1.2. Push in the gas valve button and hold it in (fig.6), at the same time, press (repeatedly) on the Piezo Ignition Button (fig.2) until the flame
ignites. When the flame has ignited and the heater has started, keep the gas valve button pushed in for a further 10 seconds, then release it.
6.1.3. If the heater stops when the gas valve button is released, leave the fan on, wait for one minute, before repeating the ignition
sequence. Hold the gas valve button in for 15-20 seconds this time, before releasing.
6.1.4. The heat output is controlled by adjusting the gas pressure via the regulator (fig.4). Turn the regulator knob anti-clockwise to reduce the
gas pressure and heat, and clockwise to increase the gas pressure and heat.
6.2. Switching Heater Off.
6.2.1. After use, shut off the gas cylinder tap. Allow the fan to continue running until the flame shuts down, then switch the On/Off switch to the
OFF (O) position and isolate the heater from the electrical supply.
 WARNING! If the flame shuts down during operation, before repeating the ignition sequence, make sure that the fan is not jammed, and
the air inlet and outlet are completely free of obstructions. If it is due to overheating, the cause of the problem must be determined and
corrected before repeating the ignition procedure.
The heater may also be used as a cool air fan, as follows:
7.1. Remove the gas supply hose and plug the heater into the electrical power supply.
7.2. Switch on the fan. The unit will now blow out cool air only.
 WARNING! Before commencing service or maintenance, disconnect the heater from
the electrical and gas supplies. Use authorised parts only. Unauthorised parts may be
dangerous and will invalidate the warranty. Should the heater require service or
maintenance, a suitably qualified engineer should carry this out or contact your local
Sealey service agent.
8.1. Check the gas supply hose condition and change if necessary.
8.2. Carefully clean the fan blade and inside the heater unit with compressed air.
 Caution: Wear safety goggles to perform this operation.
8.3. Check the starting electrode gap (fig.7).
8.4. Check the ignition unit, safety thermostat, and thermocouple condition and ensure that
they are clean.
 WARNING! If for any reason, there is a sudden increase in gas flow (a ruptured supply pipe for instance), the Excess Flow Valve will shut
and cut off the gas supply. Close the tap on the gas cylinder and investigate the problem and resolve it. Re-open the tap on the gas cylinder
and reset the Excess Flow Valve by pressing on the push-button for a few seconds. Carry out the ignition sequence to re-light the heater.
fig.7
6. OPERATION
7. COOL AIR FAN
8. MAINTENANCE
fig.5
fig.6
LP290 Issue No: 2(I) - 24/09/14
Original Language Version
©Jack Sealey Limited

PROBLEM POSSIBLE CAUSE SOLUTION
The fan motor does not work 1. There is no electrical supply.
2. The motor has locked.
1. Check mains power supply, wire, plug, fuse.
2. Unlock the motor with an appropriate tool.
The ignitor does not spark 1. Electrode has the wrong gap.
2. Faulty connection.
1. Check and reset the electrode to the correct position (fig.7).
2. Check and connect correctly the ignitor and the electrode.
No gas flow to the burner 1. The cylinder gas tap is closed.
2. The cylinder is empty.
3. Gas leaks from the supply.
1. Open the gas tap.
2. Replace the cylinder.
3. Remove and clean the nozzle, check for leaks by using a
foamy soap only - DO NOT USE A FLAME to find a leak.
The burner starts, but it stops as
the gas valve is released.
1. The thermocouple is not warm enough.
2. The safety override has activated
because the fan does not work.
1. Repeat the starting operation, keeping the button pushed for
a slightly longer time.
2. See above “Fan motor does not work”.
The heater stops during operation 1. Excessive gas supply.
2. Insufficient air flow.
3. Insufficient gas due to ice formation
on the cylinder.
4. Excess flow valve has shut.
1. Check the pressure regulator, and replace if necessary.
2. Check that the motor is working correctly.
3. Check and if necessary use a larger gas cylinder or multiple
cylinders connected in parallel.
4. Investigate and rectify fault, reset valve before restarting.
WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Parts support is available for this product. To obtain a parts listing and/or diagram, please log on to www.sealey.co.uk,
email [e-mail] or phone [phone].
 WARNING! Regarding Air Contaminants.
Air contaminants taken into the heater will damage the unit, cause health problems and safety issues.
Example: Body shop filler dust and overspray dust will clog the burner diffuser, contaminate the combustion chamber and damage the
internal parts of the heater. If contaminants are present the heater must be supplied with ducted clean air.
Please note that any parts damaged by filler dust or overspray dust will not be covered by warranty. Additionally a cleaning
charge will be made for any heaters damaged by filler dust or overspray dust.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
LP290 Issue No: 2(I) - 24/09/14
Original Language Version
©Jack Sealey Limited
9. TROUBLESHOOTING
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
