Sealey Bt91/7pf.v2 User manual

6/12V PROFESSIONAL BATTERY DROP

TESTER - POLARITY FREE

MODEL NO: BT91/7PF.V2

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

▲DANGER! Be aware, lead acid batteries generate explosive gases during normal battery operation, for this reason, it is very

important to read and follow these instructions carefully each time you use the battery tester. Follow these instructions in

conjunction with those of the battery and vehicle manufacturer, and the maker of any equipment you intend to use in the vicinity of

the battery. Remember to review warning marks on all products and on engines.

WARNING! Modern vehicles contain extensive electronic systems. You are required to check with the vehicle Manufacturer, for any

 specicinstructionsregardingtheuseofthistypeofequipmentoneachvehicle.Noliabilitywillbeacceptedfordamage/injury, 

where this product is not used in accordance with all instructions.

1.1. PERSONAL PRECAUTIONS

9Ensure there is another person within hearing range of your voice and close enough to come to your aid, should a problem arise when

working near a lead-acid battery.

9Wear safety eye protection and protective clothing. Avoid touching eyes while working near battery.

9Have fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes.

9Wash immediately with soap and water if battery acid contacts skin or clothing. If acid enters eye, flush eye immediately with cool, clean

running water for at least 15 minutes and seek immediate medical attention.

9Remove personal metallic items such as rings, bracelets, necklaces and watches. A lead-acid battery can produce a short-circuit current

which is high enough to weld a ring or the like to metal, which would cause severe burns.

9Ensure hands, clothing (especially belts) are clear of fan blades and other moving or hot parts of engine, remove ties and contain long

hair.

8DO NOT smoke or allow a spark or flame in the vicinity of battery or engine.

1.2. GENERAL SAFETY

8DO NOT operate the load test switch for more than 10 seconds at a time. (Failure to release the switch after 10 seconds may

result in the switch burning out and invalidating your warranty.)

9Familiarise yourself with the application and limitations of the tester as well as the potential hazards. Also refer to the vehicle

manufacturer’s hand book. IF IN ANY DOUBT CONSULT AN ELECTRICIAN.

9Ensure the tester is in good order and condition before use. If in any doubt DO NOT use the unit and contact an electrician.

9Only use recommended attachments and parts. To use unapproved items may be dangerous and will invalidate your warranty.

9 Ensurethetesterloadswitchis‘Off’beforeattaching/detachingthepowerclampsto/fromthebatteryterminals.

9Keep tools and other items away from the engine and ensure you can see the battery and working parts of engine clearly.

9Confirm that the battery to be tested is either 6 or 12 volt before attaching clamps to battery terminals.

9Should the unit suffer excessive shock, it must be checked by a qualified service agent before further use.

8DO NOT disassemble the tester for any reason. The tester must only be checked by qualified service personnel.

9If the battery terminals are corroded or dirty clean them with a solution of water and baking soda before attaching the clamps.

9Keep children and unauthorised persons away from the working area.

WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow

them to touch the battery terminals.

8DO NOT pull the cables or clamps from the battery terminals.

8DO NOT use the tester outdoors, or in damp, or wet locations and DO NOT use within the vicinity of flammable liquids or gases.

9Ensure there is effective ventilation to prevent a build-up of explosive gases, and DO NOT cover or obstruct tester ventilation louvres.

8DO NOT use the tester for a task for which it is not designed.

9When not in use, store the tester carefully in a safe, dry, childproof location.

2. INTRODUCTION

American-style drop tester. Polarity protected cables - impossible to damage unit by incorrect connection. Load applied by internal switchgear

- no sparking! Suitable for 6 and 12V batteries. Applies load across cells and measures output on meter. Accurate indication of battery voltage

and faulty or short circuited cell.

BT91/7PF.V2Issue113/10/2020

Original Language Version

Refer to

instructions

NoopenamesWear eye

protection

Wear protective

gloves

Wear protective

clothing

Warning

corrosive

substance

Warning:

explosive

material

Use in well

ventilated areas

3. OPERATION

  WARNING! Ensure you read, understand and apply the safety and operational instructions before connecting the tester

clamps to the battery. Only when you are sure that you understand the procedures is it safe to proceed with the testing process.

3.1. PREPARATION

3.1.1. Check the battery casing for cracks or leakage and confirm whether 6 volts or 12 volts.

3.1.2. Clean the battery terminals.

3.1.3. If practical, check the electrolyte levels and top up with distilled water as required.

3.2. CONNECTION

WARNING! Ensure the vehicle or battery is in a well ventilated area before starting to test.

3.2.1. Attach the clamps to the battery terminals. Use the extended clamps if necessary. To ensure good electrical contact twist the clamps

on the terminals two or three times. Correct connection indication will sweep the pointer clockwise across the voltage scale. If there is

no movement from the pointer, it is either a bad connection or a dead battery.

3.2.2. Ensure that the clamp cables are clear of hot or moving engine parts, especially if a starter or charging test is required. Ventilation

slots in the tester casing should not be obstructed and the meter scale easily visible with access to the load switch.

3.3. BATTERY LOAD TEST

NOTE! On the first load test, smoke may be emitted from the louvres in the tester casing, this is normal and temporary.

3.3.1. Presstheloadswitchin;holduntilmeterreadingstabilises,orforamaximumof10seconds.Failure to release the switch inside

10 seconds may result in the switch burning out and your warranty being invalidated. Note the meter reading and then release

the load switch.

3.3.2. Comparethemeterreadingwithloadtestchart(3.4)todeterminebatterycondition.

NOTES: a) For 12 voltbatteriesthegreensector(fig.1A)borderismarkedwithnominalcrankingcurrentfrom300to500ampsand

 steppedin200ampintervals.Recordthisfigureandcomparewithbatterymanufacturer’squotedfiguretogiveanindicationofany

deterioration.

 b) Batteryperformancefallsatlowtemperaturesandquotedcrankingampsshouldbereducedby50ampsat20ºF(-7ºC)and

 100ampsat0ºF(-18ºC).

3.4. LOAD TEST CHART

g.1

Load Test Result Fig.1 Battery Condition

“OK”-Green Batterycapacityisgood.Mayormaynotbefullycharged.Checkelectrolytespecicgravitytodetermine

chargestate.Ifnotfullycharged,checkforchargingsystemfault(section3.6)orelectricaldrain.

“Weak” or “Bad” -yellow or red,

but pointer reading steady.

Battery capacity is unsatisfactory. Battery may be either:- (1) defective or (2) partly discharged.

Checkelectrolytespecicgravity.Ifover1.225,thebatteryisdefective.Ifunder1.225,rechargethe

batteryandretest.Ifcelltocellspecicgravityvariesbymorethan0.025acelldefectmayexist.If

chargingdoesnotbringspecicgravitytofullchargelevel,thebatteryiseithersulphatedorhaslost

active material.

“Weak” or “Bad” - yellow or red,

but pointer reading falling after

10secondsonload.

Battery may be defective. Release load switch and note the meter reaction. If the voltage recovers to 12

volts (6 volts for a 6 volt battery) or more in a few seconds, then the battery is probably defective. If the

voltagerecoversslowlythebatterymayonlybedischarged.Checktheelectrolytespecicgravityand

proceed as above

BT91/7PF.V2Issue113/10/2020

Original Language Version

3.5. BATTERY VOLTAGE/CHARGE LEVEL

3.5.1. If the load test result indicates a battery fault allow battery to stabilise for a few minutes and then read the open circuit voltage - meter

reading with load switch ‘Off’.

3.5.2. ComparethereadingwiththeVoltage/Chargetablebelowtogetanestimationofthechargelevel.

3.5.3. Thebatteryisconsideredchargedat75%ormore.Ifitfailedtheloadtestwiththischargeitshouldbereplaced.Ifthevoltageindicatesa

 chargelevelbelow75%thenchargethebatteryandloadtestagain.Ifbatteryfailsthissecondtestreplaceit.

3.6. CHARGING SYSTEM (12 VOLT)

3.6.1. Start engine and allow to reach normal operating temperature. Switch off all accessories.

3.6.2. Runengineat1200to1500rpmandnotemeterreading,whichshouldbeinthegreen‘OK’12 Volt sector (fig.1). DO NOT press the load

switch.

3.6.3. Switch on head lights and heater fan (highest speed), meter reading should remain in the green ‘OK’ sector.

3.6.4. A reading in the red sector above “CHARGING SYSTEM” (fig.1) indicates a fault in the charging system which will cause the battery to be

under charged. A reading in the red sector to the right (fig.1) indicates a fault which will cause the battery to be over charged.

NOTE: Although not marked on the meter scale the ‘OK’ range for a 6 voltchargingsystemis6.8to7.5volts.

3.7. STARTER MOTOR (12 VOLT)

NOTE: Thistestrequiresthatthebatteryisingoodconditionandischargedtoatleast75%capacity.

3.7.1. Disable ignition system; remove the fuse or similar so that engine will not start.

3.7.2. Carryoutaloadtest(section3.3.),ifnotalreadydoneandnotevoltagereading.

3.7.3. Usethetablegivenbeloworfig.1todeterminetheequivalentminimumcrankingvoltage.Notethatforenginesoflessthan3.25 

litres take the next higher figure. For example:-

 a)3.5litreengine-loadtestresult11.0volts,givesmin.crankingvoltageof9.7volts.

 b)1.5litreengine-loadtestresult11.0volts,givesmin.crankingvoltageof10.2volts

Table:-

 Loadvoltage  10.2 10.4 10.6 10.8 11.0 11.2 11.4

 Min.crankingvoltage 7.7 8.2 8.7 9.2 9.7 10.2 10.6

3.7.4. Operate the starter motor and note the voltage during cranking.

3.7.5. A reading below the minimum cranking voltage indicates that the starter motor is taking excessive current. This may be due to poor

connections, to a faulty motor or to the battery being too small for vehicle.

3.7.6. After test reinstate ignition system.

NOTE: For a 6 volt system test as above and note load test voltage. Double this value and determine equivalent minimum cranking voltage

 asinstage3.7.3.Halvethefiguretogiveminimumcrankingvoltageforthe6 voltsystemandthenproceedfromstage3.7.4.

Open Circuit Voltage Charge %

12 volt/6 volt battery

11.7/5.8orlower 0

12.0/6.0 25

12.2/6.1 50

12.4/6.2 75

12.6/6.3orhigher 100
