Sealite NAUTILUS-2200 Supplement

Version 1.4
NAUTILUS-2200
Ocean Buoy
Installation & Service Manual

NAUTILUS-2200 Ocean Buoy

Latest products and information available at www.sealite.com
3
NAUTILUS-2200 Ocean Buoy
Table of Contents
Introduction..........................................................................................Page 4
Sealite Buoy Division..........................................................................Page 4
Why Choose Polyethylene Buoys? ...................................................Page 4
Mooring Requirements & Regulations ..............................................Page 4
NAUTILUS-2200 Ocean Buoy .............................................................Page 5
 ProductFeatures&TechnicalSpecications ..............................Page 6
Product Components...................................................................Page 8
Assembly Instructions .................................................................Page 9
Mooring Assembly Instructions..................................................Page 11
Mooring Diagram.......................................................................Page 12
Marine Buoy Maintenance ................................................................Page 13
Sealite Buoy Warranty ......................................................................Page 15
Version No. Description Date Approved
1.0 Manual Launch July 2009 K. Paton
1.1 Individual Manual Nov 2009 A. Dixon
1.2 Logo and Warranty Update July 2010 K. Paton
1.3 Update: Quality Logo May 2012 J. Dore
1.2 Breather Unit September 2013 P. Rainey

Latest products and information available at www.sealite.com
4
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
Introduction
Congratulations! By choosing to purchase a Sealite Buoy, you have become the
owner of one of the most advanced rotationally-moulded polyethylene marine buoys
in the world.
Sealite Pty Ltd has been manufacturing buoys for over 25 years, and particular care has been taken to
ensure your buoy gives years of service.
As a commitment to producing the highest quality products for our customers, Sealite has been
independentlycertiedascomplyingwiththerequirementsofISO9001:2008qualitymanagement
system.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of
your buoy, and be able to maximise its operating function.
Sealite Buoy Division
Sealite marine buoys are manufactured on-site from rotationally-moulded UV-stabilised polyethylene,
and are designed to offer a low-maintenance, high visibility solution to marine navigation.
The Sealite buoy division provides turn-key production of navigation buoys. From tooling development,
rawmaterialsselection,andproduction,tonaltestingandinspection,Sealiteguaranteessuperior
quality and fast turn-around times.
Sealite’sbuoyproductsareavailableinawiderangeofcongurationsandsizes,andcanbe
economically shipped worldwide.
Why Choose Polyethylene Buoys?
• Nopainting
• Inhibitsgrowth
• Increasedintervalbetweenservicing
• Routinemaintenanceonlocation
• Easilyrepairedintheunlikelyeventofdamage
• Lightweightforeaseofdeploymentandmaintenance
• Environmentallyfriendly–nouseoftoxicantifoulingpaint
4. Mooring Requirements & Regulations
Pleasecontactyourlocalauthorityforanyspecicrequirementsregardingthedeploymentofbuoys.
IALA also has guidelines and recommendations that should be followed.
All information given in this manual is advisory only. Please consult with your local authority before
deploying your buoy products.
Local conditions that need to be considered include:-
• Waterdepth
• Maximumcurrents
• Maximumwindspeeds
• Sinkersizeandweight

Latest products and information available at www.sealite.com
5
NAUTILUS-2200 Ocean Buoy
The NAUTILUS-2200 is a robust, rotationally-moulded polyethylene ocean buoy designed for
offshore port and coastal applications.
NAUTILUS-2200 Ocean Buoy
•Specications subject to change or variation without notice
*Subject to standard terms and conditions
SPECIFICATIONS•* NAUTILUS-2200
General Characteristics
Available Colours Red, Green,White,Yellow as per IALA Recommendations
Focal Plane Height (mm/inches) 3200 / 126
Total Float Volume (ltrs/US gallon) 4370 / 1154
Nominal Freeboard (mm/inches) 780 / 303/4
Nominal Draft (mm/inches) 690 / 271/8
Reserve Buoyancy (kgs/lbs) 1050 / 2315
Maximum Mooring Load (kgs/lbs) 1050 / 2315
Draft, Maximum (mm/inches) 960 / 373/4
Freeboard, Minimum (mm/inches) 510 / 201/8
Safe Working Load, 1pt (kg/lbs) 1950 / 4300
Safe Working Load, 2pt (kg/lbs) 5200 / 11460
Submergence (kg/cm, lb/inches) 39 / 218
Visual Area (m2/ft2) 3 / 32.3
Physical Characteristics
Material Rotationally-moulded UV-stabilized virgin polyethylene,
internal 316-grade stainless steel bracing, 316-grade stainless steel
grab rail and ladder
Wall Thickness (mm/inches) 18 / 3/4 (oat section)
Ballast (kg/lbs) 350 / 772 internal concrete
Filling Closed-cell polyurethane foam (oat section)
Height (mm/inches) 4120 / 1621/4
Width (mm/inches) 2200 / 862/3
Mass (kg/lbs) 830 / 1830
Radar Reector Echomax
Product Life Expectancy >20 years
Certications
Quality Assurance ISO9001:2008
Intellectual Property
Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd
Warranty * 5 years
Lantern Options Sealite SL-C310, SL-C410, SL-C420, APOLLO-155 or SL-125 series
Options Available • Mould-in graphics
• Day marks
• Rotationally-moulded side-panelling
• Monitoring Systems (AIS, GSM)

Latest products and information available at www.sealite.com
6
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
Product Features & Technical Specications
Guard rail
Internal 10m2radar
reector
316-grade stainless steel
ladder & grab rail
Rotationally-moulded to
18mm wall thickness
Foam lled with
closed-cell polyurethane
IALA top mark
Optional
self-contained lantern
Convenient tether
points
Optional battery
compartment
Lifting points
Non-slip deck
Internal tie-bars to
interconnect lifting &
mooring points
Made from strong,
durable, UV-stabilized,
virgin polyethylene
Twin mooring points
Innovative
guidance
keel

Latest products and information available at www.sealite.com
7
NAUTILUS-2200 Ocean Buoy

Latest products and information available at www.sealite.com
8
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Product Components
No Description Qty
1Nautilus Float Section 1
2Nautilus Tower 1
3Ladder 1
4G316 S/S Bolt. M10x100mm Long 16
5G316 S/S Flat Washer 32
6G316 S/S Spring or Locking Washer 16
7G316 S/S Plain Nut 16
8Handrail 1
9Guardrail 1
10 Day Mark Mounting Plate 1
11 Nautilus Lug Bushes 4
12 Galvanised Grade M Shackle Ø38 with
Ø44 pin, inside width 70mm x 137mm
2
13 Galvanised Grade S Shackle, Ø32mm 2
14 Galvanised Grade S Shackle, Ø38mm 1
15 Bridle Plate 1
G316 S/S = Grade 316 Stainless Steel

Latest products and information available at www.sealite.com
9
NAUTILUS-2200 Ocean Buoy
Assembly Instructions
Check Components
• Unloadallcomponentsfromcrateorcontainer.
• Checkallcomponentsarecompleteandcorrect.Useassemblydiagramonfollowingpageforfull
list of components.
• PositiontheNautilusFloatSection(1)onatlevelground.
Prepare Tower Section
• Optional: Position the Lantern on the Tower section. For details on Lantern see Lantern
Installation Manual.
Note:CheckforcorrectLanternoperationbeforettingtothetowersection.
• Optional:PositiontheDayMarktotheMountingPlate(10)andsecureusing4xM10SocketHead
Cap Screws, washers and Nuts.
Connect Tower Section to Float Section
• PositiontheNautilusTower(2)ontopoftheFloatSection(1).
o Secure the Tower to the Float Section.
   - IfTowerSectionisttedwithSolarPanels,itwillrequire16xM10StainlessSteel
Bolts, Nuts and Washers.
   - IfTowerSectionisnotttedwithSolarPanelsthen18xM10StainlessSteel
Bolts, Nuts and Washers are required.
  o Placeaatwasherontothebolt,
o Insert bolt into hole through Tower and Float Section
o Secure a second Flat Washer, a Spring Washer and a Nut on to the Bolt.
o Tighten the Nut
• Fit2xØ38mmShacklestotheLiftingEyesontheFloatSection.
• LiftBuoyuptoaccesstheLugBushesatthebaseoftheBuoy.
• Cutoffthecabletieandt2xØ38mmShackles.Securetightly.
• ThebuoyisnowreadyfortheMooringAssemblytobetted.

Latest products and information available at www.sealite.com
10
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
Sealite Breather Unit
How it Works
Inside the breather unit, is an air channel which forms in the shape of an S-Bend which runs from the
M16 threaded hole to a small hole located on the other side.
Thischannel,llswithwaterandspillsoutthroughthesmallhole,allowingthewatertoeffectively
drain from the buoy and at the same time, preventing water from entering into the buoy through the
small hole.
Installation Instructions for Breather Units (For Products which Contain Sealite’s Power Packs)
1. Unscrew the white plug located at the side/base of the buoy
2. Apply a small amount of marine grade silicon adhesive to the thread of the breather valve
3. Carefully screw in the breather unit ensuring that the arrow’s direction is pointing down.

Latest products and information available at www.sealite.com
11
NAUTILUS-2200 Ocean Buoy
Mooring Assembly Instructions
Check Components
• UnpackallMooringandcheckallcomponentsarecompleteandcorrect.
Prepare & Attach Chain
• Fitandsecure1xØ38mmShackleand1xØ38mmSwivelEyetothebaseofthebridle.
Note: All Shackles must be positively locked. For example use 3mm Stainless Steel wire to lock
the pin eye, or use a shackle pin with nut and split pin.
• FitandsecurealengthofchaintotheSwivelEyeusing1xØ38mmShackle.
Note:Pleaseusetheguidesbelowtodeterminethecorrectchainsizeandlength.
• FitandsecuretheBridletotheBuoyusing2xØ32mmShackles.PlaceØ36mmwasherstoeither
sideofthebridleplatetopacktheShackleforaneatt.
Attach Mooring Block
• FitandsecuretheChaintotheMooringBlock.
• TheBuoyisnowreadyfordeployment.
Water Depth Recommended Chain Size
(from swivel to mooring block)
Metres Feet
6 to 14 20 to 46 44mm
14 to 22 46 to 72 38mm
22 to 32 72 to 105 32mm
32 to 50 105 to 164 25mm
50 to 75 164 to 246 22mm
Chain Size Guide
Recommended
Length of Chain
Maximum
Water Depth
Best Practice
(Upto6ktscurrent) 3 x Water Depth 50m
For Reduced Water Circle
(Current2ktsto4kts) 2.5 x Water Depth 75m
For Minimum Water Circle
(useonlywherecurrent<2kts)
Not less thank
2 x Water Depth 75m
Chain Length Guide

Latest products and information available at www.sealite.com
12
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Mooring Diagram

Latest products and information available at www.sealite.com
13
NAUTILUS-2200 Ocean Buoy
Marine Buoy Maintenance
Sealite Marine Buoys are designed to require very little maintenance. We recommend the buoy be
inspected annually. Inspection may need to increase depending on the local conditions and the
position of the buoy.
IALARecommendationAISME-107suggestsmooringsareinspectedannually.
Marine Buoy – Annual Maintenance
• Visuallyinspectbuoyfordamage
• Inspectthetopmarkforanydamage.Repairanybrokenordamagedsection.
• Cleanbuoyofanimaldebris
Mooring – Annual Maintenance
• Checkandclearthetailandridechainsfromshellsandalgae.
• Checkforwearonanyshackleaxisandcheckthetaperedpins.Anywornshacklesmustbe
replaced.
• Checkthefreemovementofeachswivelarounditshead.Ifanyswivelheadsticksitmustbe
replaced.
• Checkeverylinkofthethrashlengthofthechain.Checkthediameterofthenipsandsidesand
also inspect the welds on every link.
• Ifdepthallows,awornridingchainmaybereversed.
• Changeachainwhenanylinkshowsexcessivewear.
• Chainmustbereplacedifanylinkwearstolessthan3/5oftheoriginaldiameter.
Mooring – Biannual Maintenance
• Inspectthegroundchainandsinker.
Lanterns – Maintenance
• PleaserefertotheInstallationManualforthespecicMarineLanternttedtotheBuoy.

Latest products and information available at www.sealite.com
14
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
Notes

Latest products and information available at www.sealite.com
15
NAUTILUS-2200 Ocean Buoy
Information in this manual is subject to change without notice and does not represent a commitment on the part of the vendor.
Sealite products are subject to certain Australian and worldwide patent applications.
Activating the Warranty
Uponpurchase,theSealitePtyLtdwarrantymustbeactivatedforrecognitionoffutureclaims.Todothisyouhavetwo(2)
options:
1. Postal Registration - please complete the Sealite Warranty Registration Card and return to Sealite within 30 days of your
purchase.
2. Online Registration-pleasecompletetheOnlineRegistrationFormat;www.sealite.com
Sealite Pty Ltd will repair or replace your buoy product in the event of failure for a period of up to twelve months (small
buoy products less than 1500mm diameter) & a period of up to ve years (large buoy products 1500mm diameter &
larger) from the date of purchase.
The unit must be returned to Sealite freight prepaid.
Warranty Terms
1. SealitePtyLtdwarrantsthatanyrotationally-mouldedbuoyproducts(“BuoyProducts”)willbefreefromdefectivematerials
andworkmanshipundernormalandintendeduse,subjecttotheconditionshereinaftersetforth,foraperiodoftwelve(12)
monthsforsmallbuoyproductsuptounder1500mmdiameter,andforaperiodofve(5)yearsforlargebuoyproducts
including and over 1500mm in diameter from the date of purchase by the original purchaser.
2. Sealite Pty Ltd will repair or replace, at Sealite’s sole discretion, any Buoy Products found to be defective in material and
workmanshipintherelevantwarrantyperiodsolongastheWarrantyConditions(setoutbelow)aresatised.
Warranty Conditions
ThisWarrantyissubjecttothefollowingconditionsandlimitations;
1. The warranty is applicable to buoys manufactured from 1/1/2009.
2. The warranty is void and inapplicable if:
a. the product has been used or handled other than in accordance with the instructions in the owner’s manual and any
otherinformationorinstructionsprovidedtothecustomerbySealite;
b. theproducthasbeendeliberatelyabused,ormisused,damagedbyaccidentorneglectorinbeingtransported;or
c. the defect is due to the product being repaired or tampered with by anyone other than Sealite or authorised Sealite
repair personnel.
3. The customer must give Sealite Pty Ltd notice of any defect with the product within 30 days of the customer becoming aware
of the defect.
4. NomodicationstotheoriginalspecicationsdeterminedbySealiteshallbemadewithoutwrittenapprovalofSealitePty
Ltd.
5. The product must be packed and returned to Sealite Pty Ltd by the customer at his or her sole expense. Sealite Pty Ltd
will pay return freight of its choice. A returned product must be accompanied by a written description of the defect and a
photocopy of the original purchase receipt. This receipt must clearly list model and serial number, the date of purchase, the
nameandaddressofthepurchaserandauthoriseddealerandthepricepaidbythepurchaser.Onreceiptoftheproduct,
Sealite Pty Ltd will assess the product and advise the customer as to whether the claimed defect is covered by this warranty.
6. Sealite Pty Ltd reserves the right to modify the design of any product without obligation to purchasers of previously
manufacturedproductsandtochangethepricesorspecicationsofanyproductwithoutnoticeorobligationtoanyperson.
Limitation of Liability
Totheextentpermittedbysection68AoftheTradePracticesAct1974(Cth),theliabilityofSealitePtyLtdunderthisWarrantywill
be, at the option of Sealite Pty Ltd, limited to either the replacement or repair of any defective product covered by this Warranty.
SealitewillnotbeliabletoBuyerforconsequentialdamagesresultingfromanydefectordeciencies.
Limited to Original Purchaser
ThisWarrantyisforthesolebenetoftheoriginalpurchaserofthecoveredproductandshallnotextendtoanysubsequent
purchaser of the product.
Miscellaneous
Apartfromthespecicwarrantiesprovidedunderthiswarranty,allotherexpressorimpliedwarrantiesrelatingtotheabove
productisherebyexcludedtothefullestextentallowableunderlaw.Thewarrantydoesnotextendtoanylostprots,lossofgood
will or any indirect, incidental or consequential costs or damages or losses incurred by the purchaser as a result of any defect
with the covered product.
Warrantor
Sealite Pty Ltd has authorised distribution in many countries of the world. In each country, the authorised importing distributor
has accepted the responsibility for warranty of products sold by distributor. Warranty service should normally be obtained from
the importing distributor from whom you purchased your product. In the event of service required beyond the capability of the
importer,SealitePtyLtdwillfulltheconditionsofthewarranty.Suchproductmustbereturnedattheowner’sexpensetothe
Sealite Pty Ltd factory, together with a photocopy of the bill of sale for that product, a detailed description of the problem, and any
information necessary for return shipment.
Sealite Buoy Warranty V2.1

Latest products and information available at www.sealite.com
16
NAUTILUS-2200 Ocean Buoy
NAUTILUS-2200 Ocean Buoy
Marine Lanterns
(1-12NM+)
Bridge & Barge Lights
Area Lighting
Monitoring
& Control Systems
Marine Buoys
(up to 3mt in diameter)
Mooring Systems
& Accessories
Other Sealite Products Available
Head Ofce
Sealite Pty Ltd
11 Industrial Drive
Somerville, Vic 3912
Australia
Tel: [phone]
Fax: [phone]
Email:[email protected]
Internet: www.sealite.com
