RA-4961-MBQ
Wireless Mailbox/Tilt Sensor
Manual
•
For use with RA-4961 series receivers
•Wirelessly onitor ailboxes or any tilting
otion
•Up to 1,000ft (305 ) trans ission range*
•
Mounts to standard ailbox flaps or
other flat surfaces that ay tilt
•Adhesive ount - no screws required
•Adjustable sensing angle
*Trans ission range will vary depending on installation and operating environ ent.
®

CBA Wireless Mailbox/Tilt Sensor
2SECO-LARM U.S.A., Inc.
Specifications
:
Parts List:
1x
Wireless ailbox
/tilt
sensor
1x Adhesive
strip
Dimensions:
O er iew:
Model
n
umber
RA
-
4961
-
MB
Q
Frequen
cy
914.8MH
z
Transmission range*
Up to 1,000ft
(305 )
Channels
1
Power
supply
1
x
12V/23A
Battery
(included)
Current
draw
Standby
3.5µ
A
Max
22
A
Estimated battery life
365 days (3 triggers/day)
Low battery indicator
Zone LED on receiver blinks contin
uously
IP rating
IP45
Operating temperature
-
4
º~140º F (
-
2
0º~60º C)
Dimensions
5
"
x
1
"
x
3
/
4
"
(
126
x
25
x
1
8
)
1x Battery
1x Manual
R
eset
Button
Battery
Compartment Screw
Battery
Compartment
Front View
Sensor
Adjustment
Side View
Side View
Front View
RESET
*Trans ission range will vary depending on installation and operating environ ent.
5
"
(126 )
1
"
(25 )
3
/
4
"
(18 )
RESET

CBA Wireless Mailbox/Tilt Sensor
SECO-LARM U.S.A., Inc. 3
Installation:
1.
Select the l
ocation where the sensor will be ounted.
The sensor should be ounted to the
underside of a ailbox flap.
2. Use the included adhesive strip to ount the sensor.
3. When the ailbox flap is in its neutral/closed position, turn the sensor adjust ent until the arrow
is aligned with the white area.
4. Open the ailbox flap to the desired actuation angle and ensure that the arrow is pointing into
the red activation area.
P
airing
the Sensor
:
1.
Follow the
pairing
instructions for the RA
-
4961
-
K1Q receiver
or RA
-
4961
-
VPQ wireless receiver
to enter pairing ode. (Refer to the RA-4961-K1Q or RA-4961-VPQ anual for further pairing
instructions.)
2. Trigger the sensor for pairing by lifting the ailbox flap so that the arrow on the sensor
adjust ent oves out of the white area and into the red trigger area.
3. The receiver will beep once and cycle to the next channel to confir successful pairing.
Resetting the Sensor:
1.
To reset the receiver infor ation, press the reset button on the front of the sensor.
2. After the reset button has been pressed, the sensor will not be able to send a signal for five
seconds.
Simple Reset
1.
If a si ple reset does not resolve any issues, a hard reset ay be necessary.
2. Re ove the battery fro the sensor.
3. Place the battery back into the sensor while holding down the reset button for five seconds.
4. The LED on the receiver will flash five ti es and the sensor will be reset.
Note: A hard reset will reset the pairing code and the device will need to be paired again.
Hard Reset
The receiver (
RA
-
4961Q
or RA
-
4961
-
VPQ
) LED will re ain lit
after activation
until the
RA-4961-MBQ is reset.
Align arrow with white
area when sensor is
in neutral
Arrow is in the trigger
area when mailbox
flap is opened
nsure a
rrow is in
the trigger area for
pairing

CBA Wireless Mailbox/Tilt Sensor
4SECO-LARM U.S.A., Inc.
Installing Batteries
:
Also
A ailable from SECO
-
LARM:
NOTICE
:
The infor ation and specifications printed in this anual are current at the ti e of publication.
However, the
SECO-LARM policy is one of continual develop ent and i prove ent. For this reason, SECO-
LARM reserves the right to
change specifications without notice. SECO-LARM is also not responsible for isprints or typographical errors. Trade
arks
are the property of SECO-LARM USA Inc. or their respective owners.
Copyright © 2015 SECO-LARM U.S.A., Inc. All rights reserved.
This aterial ay not be reproduced or copied, in whole or
in part, without the written per ission of SECO-LARM.
LIMITED
WARRANTY:
This SECO-
LARM product is warranted against defects in aterial and work anship while
used in nor al service for one (1) year fro the date of sale to the original custo er. SECO-
LARM’s obligation is li ited to
the repair or replace ent of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty
is void if da age is caused by or attributed to acts of God, physical or electrical isuse or abuse, neglect, repair or
alteration, i proper or abnor al usage, or faulty installation, or if for any other reason SECO-
LARM deter ines that such
equip ent is not operating properly as a result of causes other than defects in aterial and work anship.
The sole
obligation of SECO
-
LARM and the purchaser’s exclusive re edy, sh
all be li ited to the replace ent or repair only, at
SECO-LARM’s option. In no event shall SECO-
LARM be liable for any special, collateral, incidental, or consequential
personal or property da age of any kind to the purchaser or anyone else.
SECO
-
LARM
®
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606 Website: www.seco-lar .co
PIHVK1
Phone: [phone] | [phone] E ail: sales@seco-lar .co
MiRA-4961-MBQ_150914.doc
1.
Using
a screwdriver, re ove the screw
fro the
front of the sensor and re ove the cover.
2. Place a 12V/23A battery (included) in the battery
co part ent, aking sure to observe correct
polarity.
3. Replace the cover and screw.
Battery
Compartment
Battery Compartment
Screw
RESET
Wireless
Alert System
RA-4961-K1Q
Wireless
Magnetic Contact
RA-4961-MCQ
Wireless
Indoor PIR Sensor
RA-4961-PRQ
Wireless
Vibrating Recei er
RA-4961-VPQ
Wireless
Pushbutton
RA-4961-PBQ
Wireless
Outdoor PIR Sensor
RA
-
4961
-
DS
Q
Note: Low battery is indicated on the receiver. Refer to the RA-4961-K1Q or RA-4961-VPQ anual for ore infor ation.
FCC COMPLIANCE STATEMENT:
FCC ID: YAHHAX
-
200
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION. Notice: The changes or odifications not expressly approved by the party responsible for co pliance
could void the user’s authority to operate the equip ent. IMPORTANT NOTE: To co ply with the FCC RF exposure
co pliance require ents, no change to the antenna or the device is per itted. Any change to the antenna or the device
could result in the device exceeding the RF exposure require ents and void user’s authority to operate the device.
