SECO-LARM SD-927PWCQ User manual

®
SD-927PWCQ
Wave-to-Open Sensor
Manual
Features:
•
Range up to 2" (5cm)
•White plastic single-gang plate
•3A relay triggers minimum 0.5 sec or as
long as hand is near the sensor
•Quick connect screw-less terminal block
•
LED illuminated sensor area for easy
identification.
•Selectable LED colors (turns from red to
green or green to red) to show sensor
activated.
The ENFORCER Wave-to-Open
Sensor uses IR technology to request egress from a protected
area or activate a device with the simple wave of a hand.
Since no touch is required this sensor is
suitable for use in hospitals clinics labs cleanrooms (to reduce the risk of contamination
)
schools factories or offices.

ENFORCER Wave-to-Open Sensor
2SECO-LARM U.S.A., Inc.
1.
Run four wires through the wall to a single
-
gang back
-
box.
2. Connect the four wires from the back-box to the quick connect terminals according to Fig. 1.
3. Screw the plate into the back-box taking care not to crimp the wires.
4. Remove clear protective film from the sensor before use.
Operating voltage
12VDC
Current draw (max.)
50mA@12VDC
Relay type
Form C dry contact 3A@30
VDC
Response time
10m
s
LEDS
Standby
Red*
Triggered
Green*
Output time
M
inimum 0.5 sec or as long as hand is
near the sensor
Sensing range
2" (5
cm)
Operating t
emperature
-
4
°~
131
° F (
-
20
°~
55
° C)
Weight
2.5
-
oz (70g)
Specifications:
Installation:
Adjustin the LED Color:
1. The LED color factory default setting is red (standby) and
green (triggered).
2. To reverse the LED color visual indicator to green (standby)
and red triggered) remove the jumper located at the right
side of the terminal block as shown in Fig. 1.
Pasting the Decals
1. Select the appropriate decals in English French or Spanish*
according to your language requirements.
2. Remove the back sheet of the decal and then set it on the
desired location. Use the thin lines on the left and right sides
of the text on the decals for alignment see Fig. 2.
3. After the decal has been placed and set in the desired
location scratch the front of the decal to transfer the text onto
the faceplate.
NOTE: The decal needs at least 24 hrs. to fully dry & bond with
the surface. Do not touch or scratch until the decal is
fully dry.
1x
Wave
-
to
-
Open
Sensor
2x
Mounting screws
1x
Decal set
1x
Manual
Parts List:
*Default reversible by jumper
Jumper
(For LED color adjustment)
Fi . 2 Decal Alignment
2
1
/
8
"
(55mm)
1
1
/
8
"
(29mm)
* Decals for the lower part of the plate are provided for Spanish and French only.
Fi .
1
Connections
(under back cover)
NC
COM
N
O
(
–
)
(
+
)
Power Input
Relay output
(3A max.)
*

ENFORCER Wave-to-Open Sensor
SECO-LARM U.S.A., Inc. 3
12VDC
Power input
Relay output
(
–
)
(
+
)
COM
N
C
NO
NC
12VDC
Power input
Relay output
COM
NO
NC
(–) (
+
)
12VDC
Power input
Relay output
COM
NO
NC
12VDC
Power input
(
–
)
(
+
)
1.Installation with Electromagnetic Lock (Fail-Safe)
2. Installation with Electric Door Strike (Fail-Secure)
3. Installation with Electromagnetic Lock and Keypad
EAP
-
5D1Q
Access Control Power Supply
SK
-
1011SQ
Digital Keypad
Tamper
Output (N.C.)
EGRESS
NO
COM
NC
SECO
-
LARM
Series
Electromagnetic Lock
12VDC
Power input
Relay output
(–) (+)
EAP
-
5D1Q
Access Control
Power Supply
SECO
-
LARM
Series
Electromagnetic Lock
(
+
)
Sample
Installation
s
:
(
+
)
(
+
)
EAP
-
5D1Q
Access Control
Power Supply
SECO
-
LARM
Series
Electric Strike
WAVE TO OPEN
WAVE TO OPEN
WAVE TO OPEN

ENFORCER Wave-to-Open Sensor
4SECO-LARM U.S.A., Inc.
The SD
-
927P
WC
Q
is designed for
indoor
use to match most interiors. The sensor
and decals
require special care to ensure reliability and a long operating life.
1. Use a soft clean cloth for cleaning to avoid scratching the decals or sensor.
2. Use the mildest cleaner available. Strong cleaning chemicals may damage the decals.
3. When cleaning spray the cleaning solution onto the cleaning cloth instead of the unit.
4. Be sure to wipe off any excess liquid from the sensor. Wet spots or areas may affect the
sensor’s performance.
NOTICE
:
The SECO
-
LARM policy is one of continual development and improvement. For that reason SECO
-
LARM
reserves the right to change specifications without notice. SECO-LARM is also not responsible for misprints. All t
rademarks
are the property of SECO-LARM U.S.A. Inc. or their respective owners. Copyright © 2020 SECO-LARM U.S.A.
Inc. All
rights reserved.
WARRANTY:
This SECO
-
LARM product is warranted against defects in material and workmanship while
used in normal
service for one (1) year from the date of sale to the original customer. SECO-LARM’s obligation
is limited to the repair or
replacement of any defective part if the unit is returned transportation prepaid to SECO-LARM.
This Warranty is void if
damage is caused by or attributed to acts of God physical or electrical misuse or abuse neglect repair
or alteration
improper or abnormal usage or faulty installation or if for any other reason SECO-
LARM determines that such equipment
is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of
SECO-LARM and the purchaser’s exclusive remedy shall be limited to the replacement or repair only at SECO-LARM
’s
option. In no event shall SECO-
LARM be liable for any special collateral incidental or consequential personal or property
damage of any kind to the purchaser or anyone else.
WARNING
:
Incorrect
mounting which leads to exposure to rain or moisture inside the enclosure could cause a
dangerous electric sho
ck damage the device and void the warranty.
Care and Cleanin for the SD
-
927P
WC
Q
Wave
-
to
-
Open Sensor
:
SECO-LARM® U.S.A., Inc.
16842 Millikan Avenue Irvine CA 92606
Website:
www.seco
-
larm.com
Phone: (949)
261
-
2999 | (800) 662
-
0800
Email: sales@seco
-
larm.com
PITSW3
MI_SD
-
927PWCQ_201109.docx
IMPORTANT
:
Users and installers of this product are responsible for ensuring that the installation and configuration of this
product complies with all national state and local laws and codes related to locking and egress devices. SECO-
LARM will
not be held responsible for the use of this product in violation of any current laws or codes.
California Proposition 65 Warnin
:
These products may contain chemicals which are known to the State of California to
cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
