SECO-LARM Enforcer SD-997A User manual

7
7
/ 8 ” (200mm)
1” (25mm)
2
1
/ 4 ” (58mm)
1
1
/
2
”
(37.5mm)
3
7
/
8
” (98mm)
1
/
8
” (3mm)
1
1
/
4
”
(31.8mm)
Bolt
Bolt
5/8”
(16mm)
1
/
4
”
(5.6mm)
5
/ 8” (16mm) Throw
6
1
/ 8 ” (156mm)
3
/ 4 ”
(19mm)
12345
12345
12345
12345
12345
1”
(25.7mm)
39/16” (90mm)
15/16” (24.5mm)
11/16”
(18mm)
Sensor Magnet
Lock
knob
Key
ENFORCER
Access
ElectricDeadboltforFail-SecureApplications
®
Features:
Fail-secure operation (locks if power is lost).
Stainless steel bolt, 5/8” diameter, 5/8” throw.
Includes control wire which allows for releasing
without cutting unit’s power.
Door open/close monitor (NO/C/NC).
Magnetic switch senses door position for positive locking.
Solenoid attempts to lock several times and then shuts down if
door not closed properly to prevent solenoid from burning out.
Once door closed properly will automatically lock.
Adjustable door lock delay timer - (0, 3, 5, or 9 seconds).
1.5-Amp over-current protection.
Includes all necessary hardware.
SD-997B - Similar to SD-997A but for Fail Safe operation (also
does not include locking cylinder or second wire connector).
Model: SD-997A
Addsconcealeddeadboltsecurity
tomostwoodorhollowmetal
doors,withtheaddedconvenience
ofelectricaloperation.
SD-997A
Operation
Current Draw
Status Sensor
OperationVoltage
AdjustableDelay Timer
Weight(approx.)
Fail-Secure Fail-Safe
Standby: 320mA Standby: 360mA
Activated:880mA Activated: 900mA
SPDT,500mA @ 12VDC
(N.O./C./N.C.)
12VDC
0, 3, 5, 9 sec.s 0, 2.5, 5, 9 sec.s
2lbs.,5oz.(1kg) 1lb.,13oz.(0.82kg.)
SD-997B
*Note: Inches are closest
1/16”approximation.
Incorporatesmanuallock/unlockcylinderto
operatethe SD-997A ifpower is lost(turn lock
knobfrominsideprotectedpremisesand/or
usekeyfrom outside protected premises).
Notethatcylinder extends
pastlockonboth sides.
SECO-LARM®U.S.A., Inc., 16842 MillikanAvenue,Irvine, CA 92606 Tel: [phone](Domestic U.S.& Canada)
Tel: [phone](California &International) Fax: [phone] Email: [e-mail] Website: www.seco-larm.com
Specifications:
Dimensions:*
Connection
Diagram:
{
Card reader
or keypad
Orangewire
Brown wire
Redwire
Doorlock
delaytimer
COM
N.C.
N.O.
Green wire-door monitor, COM
Yellow wire-door monitor,N.C.
Blue wire -door monitor,N.O.
Push
button
12VDC
only
1Amp
Purple wire - manual N.C.
Graywire - manual COM
Blackwire - manual N.O.
For
SD-997A
only
SD997A.pmd
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
