Seizmik RZR PRO XP User manual

RZR PRO XP 2 Seat Seizmik Skid Plate Manual
Part # 76-10167
1
Always observe the warnings and precautions in this manual when using your Seizmik products. For best results, carefully
follow the instructions in this manual and make no modifications.
If you have any questions, comments, need assistance, or are missing parts, please call 1-866-838-3366 between 9:00AM
and 5:00PM EST. You can email us at [email protected]

View looking up at the underside of the vehicle
2
Front
Rear

Parts List
1.5” Wrap Around Clamp
2.0” Wrap Around Clamp
Skid Plate Washer
M6 Clip Nut
Tapered Hex Screw M6x25mm
1.75” Snap Over Clamp
Skid Plate Insert Washer
76-10183
76-10184
76-10185
76-10186
76-10187
76-10188
76-10189
76-10190
76-10191
99-10001
99-10002
99-10003
99-10006
99-10005
3
10

ALL GREEN holes use M6x25mm tapered bolt and washer
Into factory threaded holes unless called out otherwise.
ALL YELLOW holes use M6x25mm tapered bolt and
washer into clip nuts attached to metal brackets unless
called out otherwise.
BLUE holes use M6x40mm with wrap around
clamp or M6x16mm with snap over clamp.
(Next page specifies clamp locations)
ALL ORANGE holes use M6x40mm flange head bolt and
insert washer placed into factory hole in sheet metal
unless called out otherwise.
ALL RED holes use Self Tapping Screws- Some locations may
or may not require predrilling of 1/8” pilot hole.
Wrap around Snap over
4

Uses OEM Threaded holes
Threads into brackets with clip nuts
Uses Clamps
Uses insert washer or nut
Self Tapping Screws-May or may not require predrilling of 1/8” pilot hole
M8x16mm bolt
5

Uses OEM Threaded holes
Threads into brackets with clip nuts
Uses Clamps
Uses insert washer or nut
Self Tapping Screws-May or may not require predrilling of 1/8” pilot hole
6

Threading should face upwards, toward vehicle.
7
Attach all clip nuts to specified holes in metal brackets.

8
Attach bash plate to front panel
Thread the two M8x16mm bolts through
the bash plate and into the front panel
Attach clamp to side panels
Thread M6x16mm bolts through the side
panels and into the snap over clamps

1.5” Wrap Around Clamp
M6x30mm Bolt
2.0” Wrap Around Clamp
M6x35mm Bolt
9
To start, remove stock skid plate.
Then, snap clamps around chassis in
general locations shown (Shown in
BLUE). The threading on the clamps
should face outward.
Place insert washers in Sheetmetal
holes in vehicle (Shown in ORANGE).
This side of insert washer
faces upward, toward vehicle.

To start, loosely install the center 3 bolts and washers
(Shown in GREEN) so that the middle panel is held in
place on its own.
Next, loosely attach the metal brackets to the middle
panel using 4 bolts and washers (Shown in YELLOW)
into the clip nuts that you attached to the metal
brackets. The metal brackets go between the panels
and the vehicle frame. The panels will sandwich the
brackets to the underside of the vehicle frame.
10
M6x25mm Tapered Bolt

Loosely install the bolts and washers (Shown in GREEN)
so that the rear panel is held in place on its own.
Place the rear spacer between the rear panel and the
vehicle underbody. Install M6x30mm bolts (Shown in
GREEN and ORANGE) through rear panel and rear
spacer to secure. 11
1.5” Wrap Around Clamp
M6x30mm Bolt
M6x30mm Bolt
M6x25mm Tapered Bolt

Slide bash plate onto front piece of Sheetmetal
(as shown), loosely install two bolts and
washers (Shown in GREEN). Install M6x30mm
bolt into insert washer (Shown in ORANGE).
12
M6x30mm Bolt and Insert washer
M6x25mm Tapered Bolt
Bash Plate attached to Sheetmetal

Snap the snap over clamp (pg. 8) onto the tubing and
then loosely install all tapered bolts and washer
(Shown in GREEN). Then install M6x35mm bolts and
washer (Shown in BLUE) and bolts and washers into
clip nuts (Shown in YELLOW).
LASTLY, install the self drilling screw (shown in RED)
Repeat for other side. Tighten all bolts.
13
2.0” Wrap Around Clamp
M6x35mm Bolt
M6x35mm Bolt
Self Tapping Screw
M6x25mm Tapered Bolt
M6x25mm Tapered Bolt
