Installation & Operations Manual
Can Am Defender Folding Windshield
Installation Information:
This product does not require drilling or
modifications to the vehicle. Please familiarize
yourself with all the steps before beginning
assembly.
Compatibility Info:
This windshield is designed to work with other
Seizmik branded Accessories for the Can Am
Defender as well as OEM Can Am branded hard
tops. Please note Seizmik cannot guarantee fitment
with other branded aftermarket products. Please
research installation details on our products and
others when trying to combine different branded
accessories.
Seizmik makes Windshields, Mirrors, Cab Systems,
Light Bars, Storage Boxes, Hood Racks, and other
gr eat accessories for UTV’s to maximize the
vehicles usefulness. To help you do what you do
better.
If you have any questions, comments, need
assistance, or are missing parts, please call 1-866-
838-3366 between 9:00AM and 5:00PM EST. Or
email us at [e-mail]. Visit
www.seizmik.com for more information on our
products.
1
Part Numbers
25037/25038
1. Folding Windshield with stiffening rib
2. Bulb Gasket
3. Pro-fit Windshield Lever Assembly (2)
4. Windshield Holder Assembly (3)
5. Pro-fit Windshield Clamp assembly (2)
Kit Contents:
3
4
1
2 5

2
2. NOTE: The orientation of gasket and parts are very important.
See above. The hinge will ONLY allow the windshield to fold down flat in
one direction. You may find it helpful to place a piece of tape marking the
front side to avoid confusion in the following steps.
3. Attach the weather strip by pressing the channel in the gasket
onto the windshield with the bulb facing the BACK of the
windshield. The gasket will seal between the windshield and the
vehicle. Start the gasket at the middle of the bottom windshield.
Front
Start the gasket at the bottom
1. Peel the plastic film back from all edges and holes of
the windshield before beginning. Remove after windshield
is fully installed.
Front
4. Assemble a windshield lever in the upper corner of the windshield
using the two holes closest to the edge as shown. The levers will be on
the INSIDE of the windshield. Tighten the nut so that the levers require
a slight amount of force to turn them. Repeat for the other side.
5. Assemble the female portion of the windshield holder in the
upper corner hole next to the lever as shown on the FRONT of
the windshield. Repeat for the one in the center and other side.
6. Assemble the male portion of the windshield holder in the
lower corner hole as shown on the FRONT of the windshield.
Repeat for the one in the center and other side.

3
7. Attach the pro-fit roll cage clamps to the
vehicle in the approximate location shown. 8. Attach the windshield as shown. Before tightening the knobs, adjust
the position of the unfolded windshield in the roll cage so that the gaps
are the same on both sides and that there is enough gap at the tip for it
to fold easily. When you are happy with the position, tighten the knobs.
15. Rotate both levers perpendicular to the roll cage to lock
the windshield in place. To release the top section of the
windshield, rotate the lever 90º.
16. Push the top half of the windshield down and firmly press
the rubber plugs against each other to lock windshield in down
position. (Your vehicle may not be the same as the photo but
they work the same).
Lock
Unlock
