Yakima HangOut 2 User manual

1035818C - 1/27
HangOut 2&3
TM
BIKE SAFETY STRAP
IMPORTANT WARNING
ItIs crItIcal that all yakIma racks and accessorIes be properly and securely attached to your vehIcle. Improper attachment could result
In an automobIle accIdent, and could cause serIous bodIly Injury or death to you or to others. you are responsIble for securIng the
racks and accessorIes to your car, checkIng the attachments prIor to use, and perIodIcally InspectIng the products for adjustment,
wear, and damage. therefore, you must read and understand all of the InstructIons and cautIons supplIed wIth your yakIma product
prIor to InstallatIon or use. Ifyou do not understand all of the InstructIons and cautIons, or If you have no mechanIcal experIence and
are not thoroughly famIlIar wIth the InstallatIon procedures, you should have the product Installed by aprofessIonal Installer such as
aqualIfIed yakIma dealer.
HangOut 2
Maximum load is 2 bikes
(60 lbs./27kg total)
HangOut 3
Maximum load is 3 bikes (90 lbs./41kg total)
UPPER
STRAPS
SIDE
STRAPS
HUB
LOWER
STRAPS
CHAIN
STRAPS
STABILIZER
CRADLE
CRADLE
LOWER
FRAME
HUB—
(RED TRIGGER)
LOWER
HOOKS
UPPER
FRAME
LOAD
ARMS
SIDE
HOOKS
UPPER
HOOK
UPPER
HOOK
PURCHASE
SEPARATELY:
TubeTopTM
Required for bikes with step-
through/Ladies frames or
bikes with slanted top tubes.
Part #8002531
BEFORE
DRIVING
AWAY:
Read cautions and
warnings at end of
instructions.

1035818C - 2/27
— LOWER SUPPORT
FRAME
UPPER
FRAME
To move the frames, pull and turn both
red triggers on the outer hubs.
LOAD ARMS
RED TRIGGER—
ROTATE THE UPPER FRAME AWAY
FROM THE LOWER FRAME.
DANGER
DO NOT INSTALL THIS
CARRIER ON A VEHICLE
LISTED AS “NO FIT”.
FITTING YOUR CAR…
Rotate the trigger
until it remains
pulled out.
FIND YOUR MEASUREMENT
IN THE FIT SHEET.
See FITTING YOUR CAR (above).

edges of the tubes.
POSITION THE FRAMES.
OR
UNLISTED VEHICLES:
POSITION THE FRAMES. 
Follow these guidelines to position your frames on your car.
UPPER FRAME

upper frame until it rests on
the vehicle.

the lower frame and will
depend on vehicle shape.
LOWER FRAME


or below the numbers.

hand. If deformation occurs,
choose another location.
CAUTIONS:


that will dent under weight.
CAUTION: Some vehicles have a spoiler. If any
part of the carrier contacts the spoiler, do not
use this product.
When you see this icon, find
your vehicle at fitlookup.
yakima.com, or on the Yakima
Fit List for frame measurement,
strap positions, and critical
notes about your fit.
IF YOUR CAR IS NOT LISTED

and Canada, or see your dealer.
UNLISTED VEHICLES:
IF YOUR CAR CANNOT BE FOUND 
yakima.com, or on the Yakima Fit List, or through the dealer
or Yakima) it is “unlisted”. Install the carrier as directed in
these instructions where this icon appears.
CAUTION: Although your carrier is covered by a warranty
(see final page), Yakima cannot warranty any installation
onto any vehicle that is not listed in the Yakima Fit List or
fitlookup.yakima.com.



1035818C - 3/27
SECURE THE FRAME POSITION.
Lower support frame location is
extremely important to the load!
Read and follow the notes
for your vehicle.
POSITION UPPER HOOKS.
LOWER FRAME.

until they are seated in the hub.

slightly until the red triggers
snap.

the red triggers and try again.
Do not allow the frames
to move out of position.
Check your measurement
again if necessary.


Clean the contact points
on the vehicle, and keep
the pads free of debris.
CAUTIONS:

plastic, or thin metal.

supported metal that will dent under weight.
UNLISTED VEHICLES:



or below the numbers.
CARRIER IS
READY TO PLACE
ON CAR.
WARNING: DO NOT ATTACH THE UPPER HOOKS TO GLASS OR PLASTIC!
(If upper hooks must attach to glass or plastic, follow Anchor Strap installation on next page.)
UNLISTED VEHICLES:
UPPER HOOKS

the leading edge of the hatch
or trunk.
Refer to notes for
your vehicle to
see if you should
use the Glass
Hatch Hooks or
anchor strap.
NO GLASS OR PLASTIC? Continue to step 13.
CAUTIONS:

trunk has trim, you must use the


hatch or trunk. Opening the hatch
or trunk with hooks installed could
cause damage to the vehicle.

1035818C-4/27
B
A
E
D
C
TOP HOOKS: Anchor installation instructions
Confirmed your vehicle does not require
Anchors? Skip this page.
WARNING:
DO NOT REST
THE ANCHORS
AGAINST GLASS.
Make sure the anchor
is free from contact
between hatch door
and vehicle’s frame

1035818C - 5/27

Position the frame as determined in
step 6. The upper straps should hold
the carrier in place.
ADJUST UPPER
STRAPS.
Adjust upper straps by pulling on the ends. (Loosen by
pressing the metal buckles.)
PLACE LOWER STRAP HOOKS.

yakima.com, or Fit Notes.
CAUTIONS:



UNLISTED VEHICLES:
LOWER HOOKS

trunk/hatch.

bumper if there is a rigid, metal
attachment point.

underneath the vehicle or holes in
the vehicle’s frame.
WARNING: DO NOT ATTACH THE LOWER
HOOKS TO GLASS OR PLASTIC!
If lower hooks must attach to glass or plastic, follow
Anchor Installation Instructions on the next page.
Position hooks
at side mounting
points directed
by the Fit Sheet
Notes.

 UNLISTED VEHICLES:
SIDE HOOKS


slide up or down when tightened.
TIGHTEN SIDE STRAPS.
Pull the straps
tighter with two
hands.
TIGHTEN
UPPER
STRAPS.
Bundle the extra
strap ends into the
band.
Pull the straps
tighter with
two hands.
Note: If it is difficult to get the hook in, insert it at a
wider section and then slide it into place.
CONTINUE TO STEP 19

1035818C - 6/27
B
D
A
C
H
GF
E
BOTTOM HOOKS: Anchor installation instructions
Confirmed your vehicle does not require Anchors? Skip this page.
REMOVE THE CARRIER FROM THE CAR.
BEFORE CLOSING
THE TRUNK:
Be sure the anchors
are free from contact
between trunk door
and vehicle’s frame.

1035818C - 7/27
On the inner hubs,
pull and turn the
red triggers.

are seated in the hub!

they must snap into place!
Rotate load
arms to

horizontal.
EXTEND LOAD ARMS.
LOAD HEAVIEST BIKE FIRST
Always load first bike with
chain away from vehicle.
Always use the cradles
closest to the vehicle.
UNLISTED VEHICLES:
LOAD ARMS
CAUTIONS:


from the ground.
REPLACE RED TRIGGERS.
If the arms do not snap into
place, adjust triggers and move
arms until the arms are in place.
The straps can be routed
under the cables.
• Arrange bikes for best
stabilization.
• Pull straps tightly over bike
frame, and hook onto cradle
Stabilize the bike
frame in the cradle.
A Yakima TubeTop (see cover
page) may be required to carry
your bike safely.
Failure to load bikes
properly can result in
property damage, personal

Bikes should be as level as possible
to avoid ground clearance issues
and possible ejections.

1035818C - 8/27
BEFORE
DRIVING
AWAY WITH
YOUR BIKES:
READ ALL
WARNINGS ON
NEXT PAGE.
Tightly secure straps diagonally
over bike frame and seat tube.
The straps can be routed
under the cables.
Alternate bike directions
to avoid interference.
To slide cradles along the carrier
arms, close cradle and stabilizer.
Close cradles while loading bikes.
\
stabilizer
LOAD REMAINING BIKES.
Secure Bikes
The weight of the
bikes may cause
the straps to slack
or dislodge hooks.
TIGHTEN UPPER AND SIDE STRAPS
AGAIN AFTER BIKES ARE LOADED.
Each bike requires 3 chain straps.
Use the included safety
strap to secure your
bikes to the carrier.
Route the strap through
each wheel, around the
carrier. Feed the strap
through the buckle,
tighten it down, and
secure the loose end.

1035818C - 9/27
This product is covered by YAKIMA’s “Love It Till You Leave It” Limited Lifetime Warranty
To obtain a copy of this warranty, go online to www.yakima.com
or email us at [email protected] or call [phone]
TECHNICAL ASSISTANCE OR
REPLACEMENT PARTS:
Contact your dealer or call
[phone]
Monday through Friday
7:00 am to 5:00 pm PST
KEEP THESE INSTRUCTIONS!
READ THESE WARNINGS…
Glass/Plastic Hatches

attach to glass or plastic, follow
instructions to use the Anchor
Strap (included).
Convertibles

of the carrier to rest on car
convertible top.

carrier is installed.
Tight Seams

seams may be too tight to easily
insert hooks. Slide hooks from
outside edge of trunk/hatch to
WARNING

LOADING BIKES.

CARRIER FRAME USING THE SAFETY
STRAP PROVIDED.

DURING TRAVEL.

BEFORE EACH USE, TIGHTEN IF
NECESSARY.

STRAPS CAN RESULT IN PROPERTY
DAMAGE, PERSONAL INJURY, OR DEATH.
Rear Window Wiper

carrier is installed. Do not allow
wiper to contact any part of this
carrier, at any time.
Vehicles with a Spoiler
If any part of the carrier contacts
the spoiler, do not use this
product.
Spoiler Gap
SUV’s, vans, and wagons with
a gap between the rear spoiler
and rear window or hatch must
route upper straps under the
spoiler when possible. Do not
allow straps to contact spoiler.
MAINTENANCE



entering an automatic car wash.
LOAD LIMITS

is: 60 lbs./27kg (2 bike limit).

load is: 90 lbs./41kg (3 bike limit).



bicycles.

READ THE INSTALLATION CAUTIONS THAT APPLY TO YOUR CAR…
appropriate location. If still to tight,
open trunk/hatch, insert hooks,
and close very carefully to avoid
damage.

securely closed before continuing
installation.
Soft Attachment Points

may cause damage to softer body
materials.
Although your carrier is covered by a warranty (see below), Yakima cannot warranty any
installation onto any vehicle that is not listed at fitlookup.yakima.com, or the the Yakima Fit List.
WARNING
THE DRIVE

installed. Opening the hatch or
trunk with carrier installed could
cause damage to the vehicle.

loaded.

hang near vehicle’s hot exhaust.

campers, or RVs.

appear worn or frayed (contact
your dealer, or Yakima customer
service).

1035818C - 10/27
HangOut 2&3
TM
AVANT DE
PRENDRE
LA ROUTE :



AVERTISSEMENT IMPORTANT
Ilest ImpératIf que les porte-bagages et les accessoIres yakIma soIent correctement et solIdement fIxés au véhIcule. unmontage mal réalIsé
pourraIt provoquer un accIdent d’automobIle, quI pourraIt entraîner des blessures graves ou même la mort, àvous ou àd’autres personnes.
vous êtes responsable de l’InstallatIon du porte-bagages et des accessoIres sur votre véhIcule, d’en vérIfIer la solIdIté avant de prendre
la route et de les Inspecter régulIèrement pour en contrôler l’état, l’ajustement et l’usure. vous devez donc lIre attentIvement toutes les
InstructIons et tous les avertIssements accompagnant votre produIt yakIma avant de l’Installer et de l’utIlIser. sIvous ne comprenez pas
toutes les InstructIons et tous les avertIssements, ou sI vous n’avez pas de compétences en mécanIque et ne comprenez pas parfaItement la
méthode de montage, vous devrIez faIre Installer le produIt par un professIonnel comme un déposItaIre yakIma qualIfIé.
KingJoe 2

vélos. (total de 27 kg/60 lb)
KingJoe 3

(total de 41 kg/90 lb)
SANGLES
SUPÉRIEURES
SANGLES
LATÉRALES
MOYEU
SANGLES
INFÉRIEURES
SANGLES À
TROUS
SANGLE DE
SÉCURITÉ
BERCEAU
STABILISATEUR
BERCEAU
CADRE
D’APPUI
MOYEU—
(BOUTON DE
VERROUILLAGE ROUGE)
CROCHETS
DES SANGLES
INFÉRIEURES
CADRE
SUPÉRIEUR
BRAS
CROCHETS
DES SANGLES
LATÉRALES
CROCHETS
DES SANGLES
SUPÉRIEURES
ACHETER À
PART :
TubeTop
Nécessaire pour les vélos
pour dames ou dont le tube
horizontal est fortement incliné
vers le bas ou présente un
angle. Article no 8002531.
