INTRODUCTION
Thank you for choosing the SENA SMH5, Bluetooth Stereo Headset and
Intercom for scooters and motorcycles. With the SMH5, you can call handsfree
on your Bluetooth mobile phone, listen to stereo music or voice instructions of
GPS navigation by Bluetooth wirelessly, and have intercom conversations in full
duplex with a passenger or other riders.
The SMH5 is compliant with the Bluetooth Specification v3.0 supporting the
following profiles: Headset Profile, Handsfree Profile (HFP), Advanced Audio
Distribution Profile (A2DP), and Audio Video Remote Control Profile (AVRCP).
Please check with the manufacturers of other devices to determine their
compatibility with this headset.
Please read this user’s guide carefully before using the headset. Also check
www.senabluetooth.com/support forthelatestversionoftheuser’sguideand
additional information related to SENA Bluetooth products.
The SMH5 features:
t#MVFUPPUIIBOETGSFFGPS#MVFUPPUINPCJMFQIPOFT
tBluetooth stereo headset for Bluetooth stereo devices such as MP3 players
tBluetooth stereo headset for Bluetooth GPS navigations
tBluetooth intercom up to 400 meters (430 yards)*
tMulti-pair Bluetooth intercom to pair with 3 other headsets
tFirmware upgradeable
Key Specifications:
tBluetooth v3.0
t Supporting profiles: Headset Profile, Hand-Free Profile (HFP), Advanced
Audio Distribution Profile (A2DP), Audio Video Remote Control Profile (AVRCP)
--------------------------------
*in open terrain

English
SMH5
5
PACKAGE CONTENTS &ODPS8QLW
+HOPHW6SHDNHUV
$WWDFKDEOH%RRP0LFURSKRQH
86%3RZHU&DEOH
*OXHG6XUIDFH0RXQWLQJ3ODWH
+HDGVHW0DLQ8QLW
-RJ'LDO
/('
&KDUJLQJ/('
3KRQH%XWWRQ
'&3RZHU&KDUJLQJ)LUPZDUH8SJUDGH3RUW

SMH5
6
0LFURSKRQH6SRQJHV
9HOFUR3DGVIRU6SHDNHUV
9HOFUR3DGIRU%RRP0LFURSKRQH
$WWDFKDEOH%RRP0LFURSKRQH+ROGHU
6SHDNHU3DGV
$OOHQ:UHQFK
INSTALLING THE SMH5 ON YOUR HELMET
1. Loosen the two screws on the back plate of the clamp using the enclosed
Allen Wrench. Insert the back plate of the clamp unit between the internal
padding and external shell of the helmet, and tighten the two screws.
Insert

English
SMH5
7
2. Attach the headset main unit to the clamp. Insert the main unit in the clamp
until you feel the click that signals a secure attachment.
3. If you have any problem mounting the clamp unit on the helmet for any
reason, you may use the glued surface mounting plate which can be attached
to the external surface of the helmet.
- Locate a proper surface on the helmet to attach the unit, clean the helmet
surface location with a moistened towel, and allow to dry thoroughly.
- Peel off the cover of the adhesive tape of the plate and attach the unit on the
proper surface of your helmet.
Note:
Sena recommends the clamp unit over the glued surface mounting plate. Even though the glued
surface mounting plate is provided for convenience, Sena does not assume any responsibility for
use of it. Users may have to use the glued plate at their own risk and responsibility.
4. Place the helmet speakers along with the velcro pads, centered to your ear,
in the ear pockets of the helmet. If the helmet has deep ear pockets, you can
use the speaker pads to place the speakers closer to your ears.
5. Attach the boom microphone between the internal padding and the external shell. The
boom microphone should be mounted on the inside surface of the external shell so it is
facing properly towards your mouth. Please make sure that the microphone is located

SMH5
8
close to your mouth when you wear the helmet. You can use the enclosed velcro pad
and holder for the boom microphone to ensure secure placement.
6. Please make sure that the fin side of the microphone is facing outward; away from your
lips. You can easily recognize it by touching the fin with your fingers.
fin
7. To remove the headset main unit from the clamp, please make sure to pull out the
speaker cable connector from the main unit first. Then, remove the main unit from the
clamp.

English
SMH5
9
To power on and off the headset, you don’t need to press and hold any
button for several seconds. Just short press the Jog Dial and the Phone Button
simultaneously, and you will get quick on-and-off convenience.
3RZHULQJ2Q
Press the Jog Dial and the Phone Button at the same time for about 1 second
to power on. The blue LED turns on and you will hear ascending beeps.
3RZHULQJ2II
Just short press the Jog Dial and the Phone Button simultaneously, you don’t
need to press and hold for a few seconds. The red LED turns on for a while until
it turns off completely and you will hear descending beeps.
&KDUJLQJ
- To charge the SMH5, use the USB Power Cable included in the package
by plugging into computer’s USB port or USB wall charger. USB wall charger
is not included in the package. Any 3rd party USB wall charger can be used
with the SMH5 if the charger is approved by either FCC, CE, IC or other locally
approved agencies that Sena accepts.*
- The USB Power Cable is also used for firmware upgrade of the SMH5.
- The Charging LED beside the charging port turns on red while charging, and
turns to blue when the headset is fully charged. It takes about 2.5 hours to be
fully charged.
- You can use the SMH5 while charging. It is especially helpful when you use a
cigarette charger for a long road trip.
- A cigarette charger for the SMH5 is separately available as an optional
accessory.
/RZ%DWWHU\:DUQLQJ
When the battery is low, the blinking blue LED in stand-by mode turns to
red and you will hear mid-tone triple beeps and a voice prompt saying
“Low battery”.
POWERING ON/OFF AND CHARGING
--------------------------------
*please contact Sena regarding locally approved agencies Sena accepts.

SMH5
10
CHECKING THE BATTERY LEVEL
You can check the battery level in two different ways when the headset is
powering on.
/(',QGLFDWRU
When the headset is powering on, the red LED flashes rapidly indicating the
battery level.
4 flashes High, 70~100%
3 flashes Medium, 30~70%
2 flashesLow, 0~30%
9RLFH3URPSW,QGLFDWRU
When you power on the headset, keep pressing the Jog Dial and Phone
Button simultaneously for about 3 seconds until you hear three high tone
beeps. Then you will hear a voice prompt indicating the battery level. However,
if you release the buttons as soon as the headset turns on, you will not hear the
voice prompt for the battery level.
Before using the SMH5 Bluetooth headset with any of Bluetooth devices for the
first time, you need to do the pairing operation. It can be paired with Bluetooth
mobile phones, Bluetooth stereo devices such as MP3, or motorcycle specific
Bluetooth GPS, and with other SENA Bluetooth headsets. This pairing operation
is only required once for each Bluetooth device. The headset will remain paired
with the devices and automatically connects to the paired devices again when
they are within range. You will hear a high tone single beep and a voice prompt
when the headset connects to the paired device automatically: “Phone
connected” to a mobile phone, “Media connected” to a Bluetooth stereo
device.
0RELOH3KRQH3DLULQJ
1. Turn on the SMH5 and press the Phone Button for 5 seconds until the LED
flashes red and blue alternately and you hear multiple beeps. You will hear a
voice prompt saying “Phone pairing”.
2. Search for Bluetooth devices on your mobile phone. Select the Sena SMH5
in the list of the devices detected on the mobile phone.
PAIRING THE SMH5 WITH BLUETOOTH DEVICES

English
SMH5
11
3. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN.
4. The mobile phone confirms that pairing has completed and the SMH5
is ready to use. You will hear a voice prompt from the SMH5 saying “Your
headset is paired”.
5. If the pairing process is not completed within three minutes, the SMH5 will
return to stand-by mode.
%OXHWRRWK6WHUHR'HYLFH3DLULQJ
1. If the Bluetooth stereo device is integrated with the mobile phone such as
smartphones, you don’t need to pair the SMH5 with it separately. When the
SMH5 is paired with the mobile phone, it is also paired as a stereo music
device.
2. If you have a stand alone Bluetooth stereo device, follow the paring procedure
separately. The procedure is the same as the procedure of “Mobile Phone
Pairing”.
Note:
1. If Bluetooth connection between the headset and a mobile phone is disconnected, tap the
Phone Button to recover the Bluetooth connection immediately.
2. If Bluetooth connection between the headset and a media player is disconnected, press the
Jog Dial for 1 second to recover the Bluetooth connection and play.
%OXHWRRWK*361DYLJDWLRQ3DLULQJ
1. You can listen to Bluetooth voice instructions from a Bluetooth GPS
navigation.
2. The GPS paring procedure is the same as the procedure of “Mobile Phone
Pairing”.
3. Some GPS's use mobile phone profile (HFP, Handsfree Profile) and others
use stereo music profile (A2DP, Advanced Audio Distribution Profile). If you
want to use a mobile phone with a GPS which uses mobile phone profile, you
have to pair the SMH5 with the GPS, and the GPS with the mobile phone. Most
motorcycle specific GPSs use mobile phone profile. Please refer to the manual
of the Bluetooth GPS navigation for details.
Note:
You have to use a motorcycle specific GPS which transmits turn-by-turn voice instruction to the
headset by Bluetooth. Most automotive GPS systems don’t have this feature.

SMH5
12
If you have a MP3 stereo music phone such as a smartphone, sometimes you
may need to selectively use the SMH5 for A2DP stereo music only or for mobile
phone handsfree only. This instruction is for advanced users who want to pair
the SMH5 to their smartphones only with one selective profile: A2DP for stereo
music or HFP for phone call.
If you have previously paired a mobile phone to the SMH5, you must clear the
previous paring list on both devices; the mobile phone and SMH5. To clear
the pairing list on SMH5, please do a factory reset described on the page
19.To clear the pairing list on the mobile phone, please refer to the mobile
phone manual. For most smartphones, delete the Sena SMH5 from the list of
Bluetooth devices in setting menu.
$'36WHUHR0XVLF2QO\
1. Turn on the headset and press the Phone Button for 5 seconds until the LED
flashes red and blue alternately and you hear multiple beeps.
PAIRING WITH SELECTIVE PROFILE: A2DP STEREO
OR HANDSFREE
2. Within 2 seconds, tap the Jog Dial again, then the LED turns to red flashing
and the beeps turn to double mid-tone beeps. You will hear a voice prompt
saying “Media selective pairing”.
3. Search for Bluetooth devices on your smartphone. Select the Sena SMH5
in the list of devices detected on your phone.
4. Enter 0000 for the PIN. Some smartphones may not ask for PIN.
+)3IRU3KRQH&DOO2QO\
1. Turn on the headset and press the Phone Button for 5 seconds until the LED
flashes red and blue alternately and you hear multiple beeps.
2. Within 2 seconds, tap the Phone Button again, then the LED turns to blue
flashing and the beeps turn to multiple mid-tone beeps. You will hear a voice
prompt saying “Phone selective pairing”.
3. Search for Bluetooth devices on your smartphone. Select the Sena SMH5
in the list of devices detected on your phone.
4. Enter 0000 for the PIN. Some smart phones may not ask for PIN.

English
SMH5
13
The SMH5 can be paired with up to three other headsets for Bluetooth
Intercom conversation.
1. Turn on the two SMH5 headsets (A and B) that you would like to pair with
each other.
2. Press and hold the Jog Dial of the headset A and B for 5 seconds until red
LEDs of the both units start to flash rapidly. You will hear a voice prompt saying
“Intercom pairing”.
3. Simply tap the Jog Dial of any one of the two headsets A or B (It doesn’t
matter that you choose A or B) and wait until the LEDs of both headsets turn
to blue and intercom connection is automatically established. The two SMH5
headsets A and B are paired with each other for intercom conversation. If the
pairing process is not completed within one minute, the SMH5 will return to
stand-by mode.
PAIRING WITH OTHER SMH5 HEADSETS FOR
INTERCOM CONVERSATION
&
'
A
B
Pairing A & B
A
B'
Pairing A & C
A
B'
Pairing A & D
4. You can make other pairings between the headset A and C, and between
the headset A and D by following the same procedure as above.
&&

SMH5
14
5. The intercom pairing queue is ‘Last-Come, First-Served’. If a
headset has multiple paired headsets for intercom conversations, the last
paired headset is set as first intercom friend. The previous Intercom friend
becomes second intercom friend, and third intercom friend.
Note:
For example, after the pairing procedures listed above, headset D is the first intercom friend of
headset A. Headset C is the second intercom friend of headset A, and headset B is the third
intercom friend of headset A.
PAIRING WITH OTHER SENA HEADSET MODELS FOR
INTERCOM CONVERSATION
The SMH5 can be paired with all other SENA headset models such as the
SMH10 and the SPH10 for intercom conversation. Please follow the same
procedure as above to pair with these headset models.

English
SMH5
15
9ROXPH$GMXVWPHQW
You can easily adjust the volume by rotating the Jog Dial. You will hear a beep
when the volume reaches maximum or minimum level. The volume is set and
maintained independently at different levels for each audio source even when
you turn off and on the headset. For example, once you set the volume for
mobile phone handsfree, it will not change even if you adjust the volume when
you hear Bluetooth MP3 music. So you can always maintain the preferred
optimum volume level for each audio source.
0RELOH3KRQH&DOO0DNLQJDQG$QVZHULQJ
1. When you have an incoming call, simply tap the Jog Dial or the Phone Button
to answer the call.
2. You can also answer the incoming call by loudly speaking any word of your
choice if Voice Activated Phone Answering, Phone VOX is enabled. (Refer to
the next section for details.)
3. To end a call, tap the Jog Dial or the Phone Button, or wait for the called
person to end the call.
USING THE SMH5
4. To reject a call, press the Jog Dial for 2 seconds until you hear a beep while
the phone is ringing.
5. To transfer a call between the mobile phone and the headset during the phone
conversation, press the Phone Button for 2 seconds until you hear a beep.
6. There are several ways to make a phone call:
- Enter numbers on your mobile phone keypad and make a call. Then the call
is automatically transferred to the headset.
- For some older mobile phones which do not automatically transfer calls to the
headset, press the Phone Button after entering phone numbers on the mobile
phone keypad.
- Tap the Phone Button in stand-by mode to activate the voice dialing of your
mobile phone. For this, the voice dialing feature must be available on the mobile
phone. Refer to your mobile phone manual for further instruction.
- To redial the last number, double tap the Phone Button in stand-by mode. You
will hear a voice prompt saying “Last number redial”.
(QDEOLQJ'LVDEOLQJ9RLFH$FWLYDWHG3KRQH$QVZHULQJ
3KRQH92;)DFWRU\'HIDXOW(QDEOHG
If this feature is enabled, you can answer incoming calls by simply saying a
word loudly enough. For example, when you hear a series of beeps for an

SMH5
16
incoming call, you can answer the phone by saying “Hello” or any other word
loudly. This is enabled from the factory but you can disable this. If this mode is
disabled, the only way to answer an incoming call is to tap the Phone Button.
1. Press and hold the Phone Button for 8 seconds until the red LED is rapidly
flashing. When you do this, after first 5 seconds you press the button, you will
see the headset enter into the Mobile Phone Pairing sequence, but you have
to keep pressing the button for another 3 seconds until the red LED flashes
rapidly. You will hear a voice prompt saying “VOX phone”.
2. To disable, tap the Jog Dial within 10 seconds, then you will hear a single
beep and the red LED flashes for 2 seconds. To enable VOX, tap the Phone
Button within 10 seconds, then you will hear a double beep and the blue
LED flashes for 2 seconds. If any button is not pressed within 10 seconds, it
remains unchanged and goes back to stand-by.
,QWHUFRP&RQYHUVDWLRQ
1. You can start an intercom conversation with any of intercom friends by
tapping the Jog Dial: single tapping to intercom with the first intercom friend,
double tapping with the second intercom friend, and triple tapping with the
third intercom friend.
2. To terminate an intercom conversation, single tap the Jog Dial. Any intercom
connection with any intercom friend will be terminated by a single tapping. A
double or triple tapping will do nothing in this case.
1st Intercom Friend 2nd Intercom Friend
3rd Intercom Friend

English
SMH5
17
,QWHUFRPDQG0RELOH3KRQH&DOO
1. When you have an incoming mobile phone call during an intercom
conversation, you will hear a ring tone. You can choose whether to 1) answer
the mobile phone call and stop the intercom conversation, or 2) reject the
phone call and stay on the intercom conversation.
- To answer the phone call and stop the intercom conversation, tap the Jog
Dial or the Phone Button. When you hang up the phone call, the intercom will
automatically be recovered.
- To reject the phone call and stay on the intercom conversation, press the Jog
Dial for 2 seconds until you hear a beep.
Unlike other motorcycle Bluetooth headsets, this prevents a user from being
dropped out of an intercom conversation by an incoming mobile call.
Terminate
2. When you have an incoming intercom call during a mobile phone call, you
will hear 4 high tone beeps, alerting you that there is an incoming intercom call.
You will also hear a voice prompt saying “Intercom requested”. In this case,
the intercom call does not override the mobile phone call because intercom
has lower priority than mobile call. You have to hang up the mobile phone call
to make or receive an intercom call.
,QWHUFRP)DLOXUH
When you try to start an intercom conversation with an intercom friend who is
already having an intercom conversation with other intercom friend or a mobile
phone call , you will hear a low tone double beep signifying a busy signal. You
will also hear a voice prompt saying “Intercom failed, try again later”. In this
case, you have to try again later. On the other hand, the intercom friend will
hear 4 high tone beeps alerting them that there is an incoming intercom call.
,QWHUFRP5HFRQQHFWLRQ
If your intercom friend goes out of range while having an intercom conversation,
you may hear static noise and eventually the intercom will be disconnected.
In this case, the SMH5 automatically tries to reconnect the intercom every
8 seconds. You will hear high tone double beeps until the intercom is

SMH5
18
- To play or pause music, press and hold the Jog Dial for 1 second until you
hear a double beep.
- To track forward or track back, rotate while pressing the Jog Dial clockwise
or counter clockwise.
)XQFWLRQ3ULRULW\
The SMH5 operates in the following order of priority:
(Highest) Mobile Phone,
Intercom, and
(Lowest) Bluetooth Stereo Music
reestablished. If you don’t want to make a reconnection, tap the Jog Dial to
stop the attempt.
6WHUHR0XVLF
You can listen to stereo music by Bluetooth wireless stereo. The Bluetooth
audio device must be paired with the SMH5 by following the Bluetooth Stereo
Device Pairing procedures described in the previous chapter. The SMH5
supports the Audio/Video Remote Control Profile(AVRCP), so if your Bluetooth
audio device also supports the AVRCP, you can use the SMH5 to remotely
control music playback. So, You not only can adjust the volume but also use
the functions such as play, pause, next track and previous track.
- To adjust the volume, rotate the Jog Dial.

English
SMH5
19
A lower priority function is always interrupted by a higher priority function.
For example, stereo music is interrupted by intercom call, and intercom
conversation is interrupted by incoming mobile phone call.
(QDEOLQJ'LVDEOLQJ9RLFH3URPSWV)DFWRU\'HIDXOW(QDEOHG
The voice prompt feature is enabled from the factory, and is enabled or
disabled by the following procedures.
1. Press and hold the Jog Dial for 8 seconds until the blue LED is rapidly
flashing and you hear a mid-tone double beep. You will also hear a voice
prompt saying “Voice prompt”.
2. To disable, tap the Jog Dial within 10 seconds, then you will hear a single
beep and the red LED flashes for 2 seconds. To enable the voice prompts, tap
the Phone Button within 10 seconds, then you will hear a double beep and the
blue LED flashes for 2 seconds. If any button is not pressed within 10 seconds,
it remains unchanged and goes back to stand-by.
(QDEOLQJ'LVDEOLQJ3/&3DFNHW/RVV&RQVHDOPHQW)DFWRU\
'HIDXOW(QDEOHG
The PLC (Packet Loss Concealment ) algorithm is enabled from the factory,
and is enabled or disabled by the following procedures. It is recommended
to enable this setting. The PLC algorithm improves the audio quality of the
intercom and mobile phone handsfree in the presence of data packet errors
within the Bluetooth link.
1. Press and hold the Jog Dial for 12 seconds until the LED shows sold blue
and you hear a high tone double beep. You will also hear a voice prompt saying
“PLC setting”.
2. To disable, tap the Jog Dial within 10 seconds, then you will hear a single
beep and the red LED flashes for 2 seconds. To enable the PLC algorithm, tap
the Phone Button within 10 seconds, then you will hear a double beep and the
blue LED flashes for 2 seconds. If any button is not pressed within 10 seconds,
it remains unchanged and goes back to stand-by.
5HVHWWR)DFWRU\'HIDXOW6HWWLQJV
1. To restore the SMH5 to factory default settings, press and hold the Phone
Button for 12 seconds until the LED shows solid red and you hear high tone
double beeps. You will also hear a voice prompt saying “Factory reset”.
2. Within 5 seconds, press the Jog Dial to confirm reset. The headset will be
restored to factory setting and switched off automatically. You will hear a voice

SMH5
20
FIRMWARE UPGRADE
The SMH5 supports firmware upgrade function. Please visit SENA Bluetooth
web site at www.senabluetooth.com to check the latest firmware
downloads.
prompt saying “Headset reset, good-bye”.
3. If you don’t press the Jog Dial within 5 seconds, the reset attempt is
canceled and the headset returns to stand-by mode. You will hear a voice
prompt saying, “Canceled”.
)DXOW5HVHW
When the SMH5 is not working properly or is in faulty status for any reason, you
may reset by pushing the pin-hole reset button at the back of the headset main
unit. Insert a paper clip into the reset pin-hole and press the reset button for 1
second with light pressure. The SMH5 will be switched off after which time, you
have to turn the system back on and try again. However, this will not restore the
headset to factory default settings.
