Server CP-MEC3 User manual

Stainless Steel Pump
with Aluminum Lid
MODEL: CP-MEC3
85451
...for purchasing our Stainless Steel Pump with
gold colored aluminum lid. This quality pump delivers
precise portions and lasts for years of service.
CONSISTENT PORTIONS—SERVE BETTER
Thank You

Page 2
PUMP PARTS
PLUNGER
LID (GOLD)
85454
DISCHARGE TUBE
85452
DISCHARGE
TUBE NUT
82027 (not used on every pump)
O-RING
2.5 cm
05127
CYLINDER ASSEMBLY
82336
O-RING
3.3 cm
82323
VALVE BODY CONNECTOR
85891
KNOB
82023-000
LOCKING COLLAR
82021
HEAD TUBE
82017
HEAD INSERT
82018
SPRING
82016
WASHER
82015
PISTON
82013
SEAL ASSEMBLY
83003
To reduce portion, add
GAGING COLLAR(S)
83529 Smaller collar: 3.7 mL reduction
82022 Larger collar: 7.4 mL reduction
PUMP DELIVERS
30 mL PORTIONS
FOOD
EQUIPMENT
LUBRICANT
40179
BRUSH
2/5” WIDE BRISTLES 82526
1/2” WIDE BRISTLES 84257
BRUSH
82049
If your pump
has threads on the
discharge tube,
use:

Page 3
To reduce portion, add
GAGING COLLAR(S)
83529 Smaller collar: 3.7 mL reduction
82022 Larger collar: 7.4 mL reduction
SAFETY
According to food and safety regulations, most
foods must be stored and/or served at certain
temperatures or they could become hazardous.
Check with local food and safety regulators for
specific guidelines.
Be aware of the product you are serving and the
temperature the product is required to maintain.
Server Products, Inc. cannot be responsible for the
serving of potentially hazardous product.
IMPORTANT
Clean, rinse, sanitize, and dry parts daily or regularly
to comply with local sanitization requirements.
DISASSEMBLY
REMOVE PUMP
from container of product. Pump out any
remaining product from inside pump.
1
REMOVE BOTH O-RINGS
from the valve body and bottom of
discharge tube.
5
REMOVE LOCKING COLLAR
REMOVE GAGING COLLAR(S) (if used)
REMOVE HEAD INSERT from inside head tube.
REMOVE SPRING & WASHER from piston
REMOVE SEAL ASSEMBLY from piston.
DISASSEMBLE PLUNGER:
6
During disassembly, collect small parts
in a container to prevent loss.
DISASSEMBLE AND WASH ALL
PARTS PROPERLY BEFORE USE.
See page 4.
REMOVE O-RING from inside seal.
REMOVE KNOB
Prevent knob from springing off:
Press head tube towards piston base
while twisting knob off.
WASH & FLUSH PUMP
Rinse pump thoroughly, inside and out.
Place lower end of pump into container
of hot water and operate pump until all
remaining product is expelled and only
water is discharged.
2
REMOVE PLUNGER & LID
Turn locking collar (and discharge tube nut if
used) counterclockwise to loosen and remove.
3
REMOVE CYLINDER &
DISCHARGE TUBE
Twist each counterclockwise to release
from slots in valve body.
4

Page 4
HAND WASH ONLY
with mild detergent solution.
Finish of gold lid may fade if exposed to
harsh chemicals.
GOLD LID CLEANING
PUMP CLEANING
Use dishwashing
soap, hot water
and nylon brush.
YES!
Pump is dishwasher safe.
Lid: Hand Wash Only.
Do not use caustic cleaners or cleansing agents
with high concentrations of acid, alkaline or
chlorine. These agents can cause the finish to fade.
FLUSH & RINSE
all pump surfaces with hot water.
Place lower end of pump into container
of hot water and operate pump until all
remaining product is expelled and only hot
water is discharged.
1
DISASSEMBLE & CLEAN
all washable parts with soap and hot water.
(See DISASSEMBLY on page 3.)
2
USE SUPPLIED BRUSH
to thoroughly clean inside discharge
tube and any confined areas.
RINSE
fully with clean water.
3
SANITIZE
all parts according to local sanitization
requirements. All parts in contact with food
must be sanitized.
4
AIR DRY
all parts fully.
5

Page 5
• Fully rinsing and drying all parts can help
prevent corrosion. Elements and minerals in
tap water can accumulate on stainless steel
parts and create corrosion.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use products containing acids,
alkalines, chlorine, or salt. These agents can
corrode stainless steel.
• Do not use metal scrapers or cleaning pads
that could scratch surfaces.
• A mildly abrasive nylon or brass brush may
be used to remove any stubborn deposits.
This durable pump includes
stainless steel components.
If you notice corrosion beginning on any
stainless steel surface, you may need to
change the cleansing agent, sanitizing agent,
or the cleaning procedures you are using.
CARE OF STAINLESS STEEL
CLEAN-IN-PLACE PROCEDURE FOR PUMPS
RINSE
• Place lower end of pump into .5 L
(2 cups) of hot tap water (approximately
43°C/110°F) and pump until all tap
water is expelled.
2
RINSE
• Place lower end of pump into .24 L
(1 cup) of hot tap water (approximately
43°C/110°F) and pump until all tap
water is expelled.
4
SANITIZE
• Mix one 30 mL (1 oz) packet of KAY-5
Sanitizer/Cleaner (EPA REG No. 5389-
15) with 9.5 L (2.5 gallons) of tap water
(approximately room temperature).
• Place lower end of pump into this
sanitizing mixture and repeatedly operate
pump until .95 L (1 quart) sanitizing
mixture is pumped through pump.
3
CLEAN
• Pump out all (if any) remaining food
product from inside pump body.
• Wash and rinse off outside of pump body.
• Flush out and rinse inside of pump.
• Place lower end of pump into container
full of water and operate pump until all (if
any) remaining product is expelled
and only warm water flows from discharge
tube.
• Mix 5 mL (1 tsp) of dishwashing detergent
with .95 L (1 quart) of hot tap water
(approximately 43°C/110°F).
• Place lower end of pump into cleaning
mixture. Pump until all cleaning mixture
is expelled.
1

Page 6
ASSEMBLY WASH ALL PARTS PROPERLY
BEFORE EVERY USE. See page 4.
SLIDE HEAD INSERT
(beveled edge first) into head tube.
6
SLIDE LOCKING COLLAR
(thread side down) towards flared
end of head tube.
5
INSTALL SMALL O-RING
into seal. Apply food equipment
lubricant on o-ring.
1
INSTALL SEAL
onto piston head. Apply food equipment
lubricant inside seal.
TIP: Flared end of seal should
face away from piston head.
2
SLIDE WASHER
onto piston.
3
SLIDE SPRING
onto piston
4
INSERT PISTON ASSEMBLY
into head tube assembly.
7
INSTALL KNOB
Press head tube down to compress
spring and expose piston threads.
Rotate knob clockwise to secure.
8
OPTIONAL: ADD GAGING COLLARS
onto head tube to reduce portion size.
Smaller collar: 3.7 mL reduction
Larger collar: 7.4 mL reduction

Page 7
INSTALL LARGE O-RING
into valve body. Apply food equipment
lubricant on o-ring.
9
INSTALL MEDIUM O-RING
onto discharge tube.
Apply food equipment
lubricant on o-ring.
11
INSTALL LID
by sliding smaller lid hole
over discharge tube.
Align center hole with
threads on cylinder.
13
INSTALL PLUNGER ASSEMBLY
into pump.
Rotate locking collar clockwise
onto cylinder threads to secure.
14
INSTALL CYLINDER
onto valve body. Rotate cylinder
clockwise and press down firmly to
secure into slots on valve body.
10
INSTALL DISCHARGE TUBE
onto valve body. Rotate discharge tube
clockwise and press down firmly to
secure into slots on valve body.
12
IF DISCHARGE TUBE
HAS THREADS:
To secure lid, slide discharge tube nut
onto discharge tube.
Rotate nut clockwise to secure.

Page 8 Manual 01956-RevB 012721
NEED HELP?
Please be prepared with your Series Number and
Description located on the lid of the unit.
Please refer to page 2 for individual Part Numbers.
1.262.628.5600
[email protected]
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
SERVER PRODUCTS
LIMITED WARRANTY
GENERAL SERVICE,
REPAIR OR RETURNS
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
Before sending any item to Server Products
for service, repair, or return, contact Server
Products customer service to request a Return
Authorization Number. Merchandise must be
sent to Server Products with this number. Service
is extremely prompt. Typically, units are repaired
and ship out within 48 hours.
Merchandise being returned for credit must be in
new and unused condition and not more than 90
days old and will be subject to a 20% restocking
charge.
TROUBLESHOOTING
•Product may be too stiff or contain a solid
that will not pass through pump.
PROBLEMS WITH FLOW OR PORTIONS?
• If used: Ensure gaging collar(s) are undamaged
and properly installed on head tube.
• Clean pump.
PRODUCT OOZES OUT AROUND
LOCKING COLLAR?
• Ensure seal is properly installed on piston.
TIP: Seal has a slight taper.
Install with flat side towards
top, flared side down.
PLUNGER DOESN’T RETURN
TO TOP AFTER DISPENSING?
• Ensure that the spring is functional.
Replace broken spring if necessary.
• Ensure that the washer is installed
between the spring and piston head.
PUMP DRIPS?
• Clean discharge tube with supplied brush.
• Ensure product is not being heated by an
external source causing product to expand
and drip.
• Inspect all o-rings. Replace if damaged.
