Seville Classics UltraHD Cabinet Stacker User manual

Mounts on top of 16238 UltaHD Mega Cabinet
TR160527
ASSEMBLY INSTRUCTIONS
UltraHD Cabinet Stacker (Model No. WEB347)
48in. W x 24in. D x 18.5in. H
(1.21m x 60.9cm x 46.9cm H)
Reference page 9 for special care
and maintenance of stainless steel

(pg 1 of 10)
#61
#41
#54
#55
#42

(#60) Mounting Strap x 2 PCS
(#6) Left Door x 1 PC
(#7) Right Door x 1 PC
(#8-A) Back Panel x 1 PC
(#3) Top Panel x 1 PC
(#4) Bottom Panel x 1 PC
PARTS LIST (pg 2 of 10)
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our
customer service department. (please refer to page 10 of 10) .
(#1) Left Panel x 1 PC
(#2) Right Panel x 1 PC

(#19-A) Right Back Bottom Corner Protection x 1 PC
(#20-A) Left Back Bottom Corner Protection x 1 PC
(#21) Screw Driver x 1 PC
(#22) KEY x 2 PCS
PARTS LIST (pg 3 of 10)
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our
customer service department. (please refer to page 10 of 10) .
(#17-A) Left Front Bottom Corner Protection x 1 PC
(#18-A) Right Front Bottom Corner Protection x 1 PC
(#15) Corner Protection A x 2 PCS
(#16) Corner Protection B x 2 PCS

(#55) Screw M (M6 x 50L) x 2 PCS
(#55-A) Wall Anchor x 2 PCS
(#61) Screw O (M4 x 12L) x 2 PCS
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our
customer service department. (please refer to page 10 of 10) .
(#42) Screw G (M4 x 30L) x 8 PCS
(#54) Screw N (M4 x 10L) x 46 PCS
PARTS LIST (pg 4 of 10)
(#23) Magnet x 2 PCS
(#27) WASHER (M4) x 2PCS
(#27-B) WASHER（M8）x 2 PCS
(#41) Screw F (M4 x 8L) x 30 PCS
M8X20 pcs

Step 1:
Step 2:
Step 3:
Install Bottom Panel (#4).
Attach the Bottom Panel (#4) to the Left and Right
Side Panels (#1 and #2). Make sure the front of the
panel faces downward. Use 8 pcs Screws G (#42) to
assemble the panels.
Install Left Panel (#1)
Place the Top Panel (#3) and Left Panel (#1)
vertically. Line up the screw holes, use 4 pcs of
Screw F (#41) to tighten.
ASSEMBLY INSTRUCTIONS (pg 5 of 10)
UltraHD Cabinet Stacker (Model No. WEB347)
Place the Right Panel (#2) on the ground vertically.
Make sure the front of the panel faces downward.
Place the Top Panel (#3) next to the Right Panel (#2).
Line up the screw holes, use 4 pcs of Screw F (#41)
to tighten.
Install Right Panel (#2) to the Top Panel (#3)
TIP: A magnetic screwdriver is included for your
convenience. If a power screwdriver is used, keep on a low
torque setting.
WARNING: For your safety, 2 people are recommended to
assemble and attach this product.
Back
Front
Back
Front
Front

Step 4:
Step 5:
Step 6:
ASSEMBLY INSTRUCTIONS (pg 6 of 10)
UltraHD Cabinet Stacker (Model No. WEB347)
Place the Back Panel (#8-A) onto both Left and
Right Side Panels (#1 and # 2) and Top and
Bottom Panel (#3 and 4). Use the 12 pcs of
Screw F (#41) to tighten.
Install Magnet (#23)
Use 4 pcs of Screw F (#41) to install the Magnet
(#23) on the Top Panel (#3) and the Bottom
Panel (#4).
Install Back Panel (#8-A).
Install Left Door (#6)
Attach the Left Door (#6) to the Left Panel (#1).
Use 3 pcs Screw F (#41) to tighten the Door
Panel.
Note: The screw holes on the door hinge have
tolerance, enabling the door to be adjusted and
centered in the door frame.
#1
#6
#41

Step 7:
Step 8:
Note
Step 9:
Remove the top Corner Protection brackets
from Model No. 16238 Mega Cabinet as the
left photo shows.
Install the Corner Protection A&B (#15&16)
Use 20 pcs of Screws N (#54) to install the
Corner Protection A and B (#15 and #16) onto
the top of the cabinet.
Fully tighten the screws after all the corner
protections are attached.
ASSEMBLY INSTRUCTIONS (pg 7 of 10)
UltraHD Cabinet Stacker (Model No. WEB347)
Install Right Door (#7)
Attach the Right Door (#7) to the Right Panel
(#2). Use 3 pcs Screw F (#41) to tighten the
Door Panel.
Note: The screw holes on the door hinge have
tolerance, enabling the door to be adjusted
and centered in the door frame.
#2

Step 10:
Step 11:
A. Place Cabinet Stacker Model No. WEB347 on
top of 16238.
B. Attach the Left Front Bottom Corner Protection
(#17-A), Right Front Bottom Corner Protection
(#18-A), Right Back Bottom Corner Protection
(#19-A), Left Back Bottom Corner Protection (#20-
A on the bottom of the cabinet, use 26 pcs of
Screw N (#54) to tighten.
Attach Cabinet Stacker Model No. WEB347
ASSEMBLY INSTRUCTIONS (pg 8 of 10)
UltraHD Cabinet Stacker (Model No. WEB347)
Remove the 6 corner screws from the top
back panel of 16238.

Step 12:
A. Remove 1 pc Screw N (#54) from the back
corner protection.
B. Attach the Mounting Strap (#60) to the
back Corner Protection brackets as the left
photo shows using Screw O (#61) and
Washer (#27).
C. Drill a hole in the wall with a 5/16" drill
bit, insert the Wall Anchor (#55-A) into the
hole.
D. Attach the other end of the Mounting
Strap (#60) to the wall using Screw M (#55)
and Washer (#27-B).
Repeat steps A through D to install the
other mounting strap.
Warning: To prevent possible tipping, it is suggested
that the Mounting Straps be installed. For safety,
secure the mounting straps to wood studs whenever
possible.
Stainless Steel Maintenance:
These parts have an UltraGuard™ fingerprint resistant
finish. Do not use traditional stainless steel cleaners on
this unit. Lightly wipe off once a month with clean
warm water and a soft cloth (preferably a micro fiber
cloth). This is the safest formula to prevent new stains
from appearing over time and manage unwanted
fingerprints or grease marks. Remember to always wipe
in the direction of the surface grain (NEVER ACROSS)
and always use a lint-free cloth. Once the surface is
clean,thoroughly wipe dry with a soft absorbent cloth.
ASSEMBLY INSTRUCTIONS (pg 9 of 10)
UltraHD Cabinet Stacker (Model No. WEB347)
Install Mounting Strap (#60)

***Please visit our website or call and inquire about our additional UltraHD Line***
Website & Online Store: www.sevilleclassics.com
CONTACT INFORMATION (pg 10 of 10)
*If you are missing any parts, have any questions, or need additional assistance in assembly, please contact
our bilingual (English and Spanish) customer service department at:
Seville Classics, Inc.
19401 South Harborgate Way
Torrance, CA 90501
USA
Telephone: [phone] within USA
Hours: 9:00am - 4:30pm (Pacific Standard Time)
Fax: [phone]
E-mail: [email protected]
