SGM Powerlight 1212D User manual

www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
1
General instructions
Read the instructions in this handbook carefully, as they give important information regarding
safety during installation, use and maintenance.
Be sure to keep this instruction manual with the unit, in order to consult it in the future.
If the unit is sold or given to another operator, make certain that it always has its manual, to
enable the new owner to read about its operation and relative instructions
• This unit is not for home use, only professional applications
• Do not dismantle or modify the unit.
• Make certain that no inflammable liquids, water or metal objects enter the unit.
• Should any liquid be spilled on the unit, disconnected the power supply to the unit immediately.
• In the event of serious operating problems, stop using the unit immediately and either contact
the nearest SGM sales point for a check or contact the manufacturer directly.
• Do not open the unit - there are no user serviceable parts inside
• Never try to repair the unit yourself. Repairs by unqualified people could cause damage or
faulty operation. Contact your nearest authorized service centre.
Always insist on original spare parts being fitted.
Safeguard the environment: don't throw batteries, accumulators or
packaging material into your waste bin - return them to your reseller or
take them to the nearest special waste collection point.
www.audiovias.com

2
Powerlight 1212 version1.01
General warranty conditions
• The unit is guaranteed for 12 months from the date of purchase against material and
manufacturing defects.
• Breakdown caused by carelessness and improper use of the unit is excluded.
• The guarantee is no longer valid if the unit has been tampered with or repaired by unauthorized
personnel.
• The replacement of the unit is not foreseen by the guarantee.
• External parts, knobs, switches, removable parts and lamps are excluded from the guarantee:
these are covered by their manufacturers' guarantee conditions.
• Transport costs and related risks are borne by the unit's owner.
• The guarantee is valid to all effects only on presentation of the guarantee certificate to the
manufacturer or the nearest SGM technical assistance centre.
Always quote the unit's serial number and model when contacting your reseller
for information or assistance.
How to contact SGM Elettronica
Our customer assistance service can be contacted as follows:
The offices are open from Monday to Friday, from 8.30am to 12.30pm and from 2.30pm to
6.30pm.
(Italian local time: GMT + 1 - Daylight-saving time from March to October (+1 hour))
Fax (24/24 ore): [phone]
Tel: [phone]
http:// www.sgm.it
E-Mail: [email protected]
www.audiovias.com

GGBB
appendix
1 General Instructions
2 General guarantee conditions
2 How to contact SGM Elettronica
3 Index
4 changes to this manual
5 1 - Main features
5 1.1 - Technical specifications
6
1.2 - Installation
6 1.2.1 - Packaging
6 1.2.2 - Contents
6 1.2.3 - Before installation
7
1.3 - P612 connections
7 1.3.1 - Connecting to the mains supply
8 1.3.2 - Rear panels
9 1.3.3 - DMX signal cable
9 1.3.4 - DMX line connection example
10 1.3.5 - DMX termination construction
10 1.3.6 - RS-232 connection
11 1.3.7 - Switching on
11 1.3.8 - Using the microcomputer
12 1.3.9 - Signaling of the display
13 1.3.10 - menu
14 2 - Description of the menu
14 2.1 - Soft Patch
14 2.2 - Set chn mode
15 2.3 - Set chn level
15 2.4 - Set pre heat
16 2.5 - Channel test
17 2.6 - Brightness
17 2.7 - Signal Monitor
18 2.8 - Version
18 2.9 - Run Autotest
19 2.10 - Edit chase
20 2.11 - Run chase
20 2.12 - EQ curves
21 2.13 - Set Default
22 2.14 - Resume default
22 2.15 - Fixture name
23 3 - Protections
23 3.1 - Overheating protection
23 3.2 - Short-circuit protection
23 3.3 - Protection against incorrect connections
24 4 - Error messages
Index
IDFE
Powerlight 1212 version1.01
3
www.audiovias.com

4
Powerlight 1212 version1.01
Designed and Manufactured in Italy by SGM Elettronica srl
Printed in January, 2002 • Rel. 1.01
Changes to this manual
SGM has an on-going product development policy, so the information printed in this manual may
not be completely up to date.
If any doubts arise regarding the topics covered in this manual or should any further help be
required, our online services (internet-server www.sgm.it ) are available 24 hours a day. In the
FAQ section of the technical assistance zona, answers can be found to numerous common
queries: fixtures, firmware and manuals can also be downloaded whenever required.
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
5
1. Main features
• Power supply: three phase 380V 3 PHASES + NEUTRAL, or single phase 110 - 220 V. Mains
frequency 50/60 Hz. The power supply for the electronics' logic part is taken from the T phase
+ NEUTRAL.
• Maximum absorption: 144 Amps
• Input signal: DMX 512 or RS232
• Cooling: forced ventilation by means of rear-mounted fans. Rotation speed is directly
proportional to the temperature on the cooling fins.
• Protections: output protection with thermal/magnetic circuit breackers (k curve)
• Microcomputer: located on the front of the P1212D, this comprises a display with six buttons
below it, enabling to carry out all settings necessary for correct installation, as well as testing
all the functions.
• Operating modes: can be controlled using a lighting control console or used a stand-alone
unit. In fact, it's possible to set the output level of the individual channels, or create 4 Chases
with up to 32 steps (scenes) in each Chase.
1.1 Technical specifications
power supply single phase 110/220 V
3-phase 3/N/PE 380V
The logic power supply is taken from the load power supply
Mains frequency 50/60 Hz
Output current 12 A / channel
rated output: 32Kw
output voltage: 110/230 V. 50/60 Hz
Type of load: resistive or inductive
Interference filter 32 mA/µsec
Inputs: DMX or RS232
Output connectors: SOCAPEX - CABUR - ILME (HARTING) - POWERCON NEUTRIK
Frame dimensions - three 19" rack units (L x H x D): 442 x 113 x 400 mm
Weight 18 kg.
SGM Elettronica reserves the right to improve or modify their products
at any time without prior notice.
Always consult the handbook of the unit being used to avoid errors and differences between the
actual functions and those shown in the manual.
www.audiovias.com

6
Powerlight 1212 version1.01
1.2 Installation
1.2.1 Packaging
KEEP THE PACKAGING MATERIAL. Packaging material (plastic bags, polystyrene foam, nails,
etc.) must not be left within children's reach, as it can be dangerous.
Use the original packaging if the unit has to be returned to the manufacturer for repair or
maintenance, as it has been specifically design to protect the unit during transport.
1.2.2 Contents
After opening the box, check that the packaging contains the items in the following list, and make
certain that the unit is in perfect condition.
If in doubt, do not use the unit and contact an authorized SGM Technical Assistance Centre and
the transport company. In fact, only the consignee can claim for any damage sustained by the
unit during transport
• Power Light P1212D
• Guarantee
• Instruction manual
• 1 XLR 5 P male connector
• 1 XLR 5 P female connector
1.2.3 Before installation
Read the following warnings before beginning installation.
•This unit is not intended for home use.
•Disconnect the power supply before carrying out any work on the unit.
•Electrical work necessary for installing the unit must be carried out by a qualified electrician or
experienced person.
•Before connecting the unit, make certain that the data on the plate correspond to the mains
power supply
•Avoid installing the units near sources of heat.
•Install the unit in a well-ventilated location. Avoid blocking the air intake and output vents.
• Never use the unit under the following conditions:
- In places subject to excessive humidity
- In places subject to vibrations or bumps.
- In places with a temperature of over 45°C or less than 2°C
• Protect the unit from excessive dryness or humidity (ideal conditions are between
35% and 80%).
Attention! The unit must be grounded. If this rule is not followed, the guarantee
will automatically be considered null. page 8 P612D
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
7
1.3 Connection the P1212
1.3.1 Connecting the power supply
• It must be connected to a circuit with a thermal-magnetic cut-off switch.(see appendix page 1,
2, 3)
• Make certain that the cross-section of the socket's cables is sufficient for the power absorbed
by the unit.
• Should it be necessary, replace the fuses with others of the same type and value.
• It's inadvisable to use adapters, in-line connectors or extension cables. Should their use be
indispensable, make certain they're in compliance with current safety norms regarding
component quality and cable length/cross-section.
Attention! Class 1 unit. The ground conductor must be part of the power cord
www.audiovias.com

8
Powerlight 1212 version1.01
1.3.2 Rear panels
cod 004-1052 SOCAPEX
cod 004-1053 POWERCON NEUTRIK
cod 004-1054 ILME
cod 004-1055 CABUR
CH1CH2CH3CH4CH8 CH7 CH6 CH5CH9CH10CH12 CH11
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
MAX 12A/CH 110/220V
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
MAX 12A/CH 110/220V
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH11CH1
CH12
neutral out
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH11
CH12
MAX 12A/CH 110/220V
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
ALINE NEUTRAL GROUND B
CH7 1 2 13 CH1
CH8 3 4 14 CH2
CH9 5 6 15 CH3
CH10 7 8 16 CH4
CH11 9 10 17 CH5
CH12 11 12 18CH6
CHASSIS // // 19 //
MAX 12A/CH 110/220V
CH1-CH6CH7-CH12
A B
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
9
1.3.3 DMX signal cable construction
Power Light P1212 has a DMX 512 input that uses standard XLR 5-pin connectors.
When connecting, screened cable in compliance with EIA RS-485 specifications and with the
following characteristics must be used:
- 2 conductors plus screen
- 120 Ohm impedance
- low capacity
- maximum transmission rate 250Kbaud.
Connecting the cable:
see diagram, taking care to ensure that the screen is connected to Pin 1
Attention: the cable screen (braid) must NEVER be connected to the system's
ground, as this would cause faulty unit or controller operation.
1.3.4 Example of DMX line connection
To avoid the risk of faulty operation, follow the following indications:
Maximum cable length: 500m
Maximum N° of units connected: 32
Cable run: Avoid running the cable alongside power lines.
Termination: 120 ohm resistor across Pins 2 and 3 of the last unit.
inputoutput
see top cover for pin out
see top cover for pin out
DMX controller
DMX line
DMX Termination
(Last unit)
CH1CH2CH3CH4CH8 CH7 CH6 CH5CH9CH10CH12 CH11
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
MAX 12A/CH 110/220V
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
CH1CH2CH3CH4CH8 CH7 CH6 CH5CH9CH10CH12 CH11
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
MAX 12A/CH 110/220V
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
CH1CH2CH3CH4CH8 CH7 CH6 CH5CH9CH10CH12 CH11
CONSULTARE IL MANUALE PRIMA DI OGNI OPERAZIONE
TO CONSULT THE MANUAL BEFORE EVERY OPERATION
MAX 12A/CH 110/220V
apparecchio non per so domestico
fixt re not for domestic se
MAIN 3/N/PE 380V 50/60HZ -32Kw Max
OUT
IN
DMX 512
Disconnect fixt re before opening
Non aprire prima di avere tolto la tensione
Pilot
1 or 21 2 or 22 3 or 23 4 or 24 5 or 25 6 or 26 7 or 27 8 or 28 9 or 29 10 or 30 11 or 31 12 or 32 13 or 33 14 or 34 15 or 35 16 or 36 17 or 37 18 or 38 19 or 39 20 or 40
program chase psycho preset unit step
page store edit levels times
copy enter play extra lamp reset
smpte
rec
on off
universal dmx controller
0
10
20
30
40
50
60
70
80
90
100%
2000
2000
programming keyboard
multifunction keyboard
grand master
operations utility
memory obj
memory
1 - 20
21 - 40
setup
pan tilt
DIMMR
0
COLOR
0
GOBOS
0
SHUTT
0
ROTGB
0
FROST
0
- 0
- 0
1
2
3
4
5COMMON
DMX-
DMX+
www.audiovias.com

10
Powerlight 1212 version1.01
1.3.5 DMX termination construction
The termination avoids the possibility of the DMX 512 signal being sent back along the cable
once it reaches the end: under certain conditions and with certain lengths, this could cause it
to over-ride the original signal and cancel it.
The termination is made by soldering a 120 1/4 W resistor across pins 2 and 3 of the 5-pole
male XLR connector (see diagram).
1.3.6 Connection RS-232
Good quality screened RG 58 50 co-ax cables must be used for connections to avoid faulty equipment
operation. Connectors used are always of the 5-pole XLR type. Refer to the diagram for wiring.
RS-232
COMPUTER
OUT
9 PIN
CONNECTOR
RS-232
COMPUTER
OUT
25 PIN
CONNECTOR 6
20
3
4
6
5
7
8
1
2
3
4
5
120Ω
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
11
1.3.7 Switching on
As soon as it's switched on, the Power Light P1212 display the SGM logo with the software
version, after which it begins an autotest (self test) routine to check for any irregularities in the
power supply and on the output.
Press ENTER to proceed to the Main Menu.
1.3.8 - Using the microcomputer
1 - The menus are scrolled using the UP/DOWN buttons
2 - Press ENTER to confirm the menu choice.
3 - The same set of square brackets can be moved between the various fields using the
RIGHT/LEFT buttons and their contents changed using UP/DOWN.
To return to the Main Menu, press ESC.
1
www.audiovias.com

12
Powerlight 1212 version1.01
1.3.9 Display view
Initial message:
Normal operation:
Warning messages (blinking writing):
NO SIGNAL
MISSING R PHASE
MISSING S PHASE
MISSING T PHASE
Dangerous message (writing and display blinking at the same time):
OVERTEMP= °C
HIGH TEMP= °C
FANS FAILURE
Fixture name
over vo tage
Fixture name
signa error
Fixture name
DMX signa
SGM E ectronics
P1212 ver. 1.00
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
13
1.3.10 menu
[Soft Patch ]
[Set Chn Mode ]
[Set Chn Leve ]
[Set Pre Heat ]
[Channe Test ]
[Brightness ]
[Signa Monitor]
[Version ]
[Run Autotest ]
[Edit Chase ]
[Run Chase ]
[Curve Equa iz ]
[Set Defau t ]
[Resume Defau t]
[Fixture Name ]
<Main Menu >
DMX SIGNAL
NO SIGNAL
SIGNAL ERROR
OVERVOLTAGE
FANS FAILURE
NO OVERVOLTAGE
FANS OK
R PHASE OK
S PHASE OK
T PHASE OK
T INT °C F
MISSING R PHASE
MISSING S PHASE
MISSING T PHASE
OVER TEMP= °C
HIGH TEMP= °C
LN ST CHN LEV
[1] 1 ALL 255
<FIXTURE NAME >
P1212
<RESUME DEFAULT>
NO [YES]
< SET DEFAULT >
NO [YES]
CHN CURVE N°
3 [4]
CHS CR SP LEV
[1] 99 99 255
< EDIT CHASE >
CHASE [4]
< AUTOTEST >
RS232 Signa
SGM E ectronics
P1212 ver. 1.00
CHN LEVEL LEV%
[ 1] 128 50
< BRIGHT >
[ [100%] ]
CHN LEVEL LEV%
1 128 [ 80]
CHN LEV%
[ALL] 0.0
CHN LEVEL LEV%
1 [255] 100
CHN MODE
[ALL] EXT
CHN ADDR
[1>>] 1
1>>:Set CHN1= ADDR; ch2 = ADDR+1;...;CHN12
= ADDR+11
ALL
ALL
ALL
ALL
ALL
ALL set all the channels
ALL
www.audiovias.com

14
Powerlight 1212 version1.01
2 - Menu descriptions
2.1 Soft Patch
In this Menu, it's possible to assign the POWER LIGHT's physical channels (CHN) to the digital
channels available (ADDR). This creates a correspondence between the Dimmer output channel
and the channel that has to be controlled.
There are 512 channels available for use, i.e., those provided for by DMX standard, and they don't
necessarily have to be in succession.
For access to the
Soft Patch function, proceed as follows:
1. Select SOFTPATCH in the main menu;
2. Press Enter to confirm the choice;
3. Move the square brackets to the CHN field and select the channel to be assigned;
selecting 1>> CHN1=ADDR; CHN2=ADDR+1;...;ADDR11=ADDR+11.
4. Move the square brackets to the ADDR field to assign the digital channel to the channel tha
has just been selected;
5. Repeat from point 3 to assign the other channels.
6. Press Esc to return to the main menu - the selected data are automatically updated.
2.2 Set Chn Mode (Channel Mode)
In this Menu, it's possible to choose the operating mode for each individual channel. It is in fact
possible to control the Power Light's channels independently or via a lighting control desk.
There are three operating modes available:
- FIX. The output of channels set in this mode isn't controlled by a lighting control desk and
remains fixed on a value which can be set later.
- OFF. The output of channels set in this operating mode stays off and cannot be controlled by a
lighting control desk
- EXT. (EXTERNAL) Output channels set in this mode can only be controlled by a lighting control
desk.
The standard factory setting is with all the channels in EXT.
For access to the Set Channel Mode function, proceed as follows:
1. Select the Channel Mode menu from the main menu;
<Main Menu >
[Set chn mode ]
CHN ADDR
[1] 1
<Main Menu >
[Soft Patch ]
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
15
2. Press Enter to confirm the choice;
3. Move the square brackets to the CHN field and select the channel to which the operating mode
has to be assigned;(AALLLLset all the channels)
4. Now move the square brackets to the MOD field to assign one of the three operating modes
available;
5. Repeat from point 3 to set the other channels.
6. Press Esc to return to the main menu:
2.3 Set Chn Level (Channel Level)
In this Menu it's possible to set the level of each individual channel configured in FIX mode in the
previous menu.
To access the
Set Channel Level function , proceed as follows:
1. Select the Set Channel Level menu from the main menu;
2. Press Enter to confirm the choice;
3. Move the square brackets to the CHN field and select the channel the output level has to be set
on;(AALLLLset all the channels)
4. Now move the square brackets to the LEV field to assign the output level. This is expressed as
a decimal value of between 000 and 255;
5. Repeat from point 3 to set the other channels.
6. Press Esc to return to the main menu: the selected data are automatically updated.
2.4 Set Pre Heat
In this Menu, it's possible to set the pre heat (warm-up) level of each individual channel.
Incandescent lamps' behaviour varies according to the power voltage they are supplied.
When they are cold, before voltage is applied, the filament has a very low resistance, so at the
moment in which the voltage is applied, a very high current will pass through the lamp.
This explains why frequent voltage changes can have a negative effect on lamp life: it's therefore
indispensable to set warm-up level.
This enables to set the minimum current which must pass through in the lamp when it is not lit,
in order for the absorption of current to be reduced and lamp life increased.
This is expressed as a percentage of between 0% and 9.9% and is usually left at zero for
inductive
loads (neon, par 36), whereas for resistive loads it varies according to the type of lamp used.
CHN LEV
2 [255]
<Main Menu >
[Set chn eve ]
CHN MOD
2 [FIX]
www.audiovias.com

16
Powerlight 1212 version1.01
For a good warm-up, it's sufficient to increase the level until the filament becomes just visible.
Standard factory warm-up setting is 4%
For access to the Set Pre Heat function, proceed as follows:
1. Select the Set Pre Heat menu from the main menu;
2. Press Enter to confirm the choice;
3. Move the square brackets to the CHN field and select the channel whose pre-heat level has to
be set; (AALLLLset all the channels)
4. Now move the square brackets to the LEV% field to assign the pre-heat level.
This is expressed as a percentage with a value of between 0 and 9.9%;
5. Repeat from point 3 to set the other channels.
6. Press Esc to return to the main menu: the selected data are automatically updated.
2.5 Channel Test
In this Menu, it's possible to check if a channel has any problems. In fact, by selecting the
channel on which there are doubts, Power Light controls its efficiency, allowing to vary its value
from 0 to maximum output and switching off the channels not involved and ignoring any previous
assignments or the presence of an input signal. Only one channel can be checked at a time.
For access to the
Channel Test function , proceed as follows:
1. Select the Channel Test menu from the main menu
2. Press Enter to confirm the choice
3. Move the square brackets to the CHN field and select the channel to be checked
the ALL option executes the test on all the channels at the some time
4. Now move the square brackets to the LEV field to assign the output level
holding down the button, will bring the channel output to 255(full) in the event of
LEV field=0.
5. Repeat from point 3 to set the other channels
6. Press Esc to return to the main menu: the selected data are updated automatically.
CHN LEV
1 [0]
<Main Menu >
[Channe test ]
CHN LEV%
6 [4.0%]
<Main Menu >
[Set pre heat ]
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
17
2.6 Brightness
In this Menu, it's possible to vary the brightness of the LCD display on the front panel. This
brightness is expressed as a percentage and varies between 0 and 100%.
The standard factory setting of the LCD brightness is 75%
For access to the
Brightness function , proceed as follows:
1. Select the Brightness menu from the main menu;
2. Press Enter to confirm the choice;
3. The square brackets are positioned on the only field. Use the
UP/DOWN arrows to reach the brightness required.
4. Press Esc to return to the main menu: the selected data are updated automatically.
2.7 Signal Monitor
In this Menu, it's possible to check the level of the signal for controlling the channels on input.
Only one channel can be checked at a time.
For access to the
Signal Monitor function , proceed as follows:
1. Select the Signal Monitor menu from the main menu;
2. Press ENTER to confirm the choice;
3. The square brackets will be positioned on the CHN field to allow the channel to be selected.
4. Once the channel has been selected, the signal level will automatically appear in the LEV field.
This field cannot be modified as it only displays the signal level on input.
5. Press ESC to return to the main menu.
CHN LEV
[1] 0
<Main Menu >
[Signa monitor]
< BRIGHT >
[ [75
% ] ]
<Main Menu >
[Brightness ]
www.audiovias.com

18
Powerlight 1212 version1.01
2.8 Version
This Menu gives information on the software version installed in the Power Light.
Version is a menu only used for consultation, in which no parameters can be changed.
For access to this function, proceed as follows:
1. Select the Version menu from the main menu;
2. Press ENTER to confirm the choice;
3. At this point, the current version of the software will appear on the display.
4. Press ESC to return to the main menu.
2.9 Run Autotest
This Menu runs an autotest routine which enables irregularities to be found in some crucial points
of the Power Light. In fact. the following parameters are checked:
- the presence (or not) of DMX signal on input;
- any excess voltage on input,
- correct operation of both fans;
- the presence (or not) of RS-232 signal on input;
- the temperature on the cooling fins expressed in degrees Centigrade and Fahrenheit.
Run Autotest is only an executive menu - no parameters can be modified.
For access to this function, proceed as follows :
1. Select the Autotest Run menu from the main menu;
2. Press Enter to confirm the choice;
3. A this point, the results of the measurements made for all the abovementioned parameters will
appear one after another on the display.
4. Press Esc to return to the main menu.
AUTOTESTING
[OVERLOAD NO]
<Main Menu >
[Version ]
SGM E ectronics
P1212 ver. 1.00
<Main Menu >
[Version ]
www.audiovias.com

GGBB
appendix
IDFE
Powerlight 1212 version1.01
19
2.10 Edit Chase
The P1212 has been designed and built so that it can also be used as a free-standing unit, without
the aid of an external controller. It's possible to create 8 different sequences (Chases) with a
maximum of 32 scenes (Steps) each.
For access to the programming function of the
Edit Chase menu , proceed as follows:
1. Select the EDIT CHASE menu from the main menu;
2. Press ENTER to confirm the choice;
3. Now select the number of the Chase to be programmed, which can be between 1 and 8
4. Press ENTER to confirm the choice;
5. At this point, the following appears on the display:
LN: Maximum number of steps
ST: Current step
CHN: Channel (AALLLLset all the channels)
LEV: light output level assigned to the channel (0-255)
6. Firstly, set the maximum number of steps that the chase in the LN field must have
7. Move the square brackets to the ST field and select the first step to program.
8. Move the square brackets to the CHN field and select the channel whose output level has to
be adjusted.
9. Move the square brackets to the LEV field and change the output level to the required value.
10. Repeat points 7-8-9 for all the steps.
11. Press ESC to confirm the changes and return to the previous menu.
LN ST CHN LEV
[10] 1 1 255
<Edit chase >
Chase [1]
<Main Menu >
[Edit chase ]
www.audiovias.com
