Sharp KC-930EUW User manual

日本語
R
* Plasmacluster is a trademark of Sharp
Corporation.
KC-930EU
ČISTIČKA VZDUCHU
s funkcí zvlhčování
NÁVOD K OBSLUZE
ČISTIČKA VZDUCHU
s funkciou zvlhčovania
NÁVOD NA POUŽITIE
LÉGTISZTÍTÓ
párásító funkcióval
HASZNÁLATI ÚTMUTATÓ
ОЧИСНИК ПОВІТРЯ
з Функцією Зволожування
ПОСІБНИК З ЕКСПЛУАТАЦІЇ
Free standing type
Freistehendes Modell
Type mobile
Vrijstaand type
Тип установки: отдельностоящий
Volně stojící
Voľne stojaca
Különálló típus
Вільностоячий тип
床置き・卓上兼用型
AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
LUFTREINIGER
mit Befeuchtungsfunktion
BEDIENUNGSANLEITUNG
Puricateur d’air avec
fonction d’humidication
MANUEL D’UTILISATION
LUCHTREINIGER
met luchtbevochtiger
GEBRUIKSAANWIJZING
NEDERLANDS
РУССКИЙ
Воздухоочиститель с
функцией увлажнения
РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ
FRANÇAIS
SLOVENSKY
УКРАЇНСЬКА
日本語
加湿空気清浄機
取扱説明書
Printed in China
TINS-A385KKRZ 09J-
CN 1
MAGYAR ČESKY
DEUTSCH
ENGLISH
OSAKA, JAPAN
SHARP CORPORATION
Free standing type
Freistehendes Modell
Type mobile
Vrijstaand type
Тип установки: отдельностоящий
Volně stojící
Voľne stojaca
Különálló típus
Вільностоячий тип
床置き・卓上兼用型
KC-930EU-jan.indd 1 09.9.17 11:34:18 AM

Please read before operating your new Air Purifier
Some odour ingredients absorbed by the filter may become separated and
may be discharged through the air outlet and result in additional odour. De-
pending on the usage environment, especially when the product is used in
a condition significantly more severe than household use, this odour may
become strong in a shorter period than expected.
In this case we recommend purchasing the optional replacement filter.
NOTE
• The air purifier is designed to remove air-suspended dust and odour, but not harmful gases (for
example, carbon monoxide contained in cigarette smoke.) If the odour sources still exist, it cannot
completely remove the odour(for example, odours from construction materials and pet odours).
• It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.
pollen, dust, particles of
cigarette smoke, pet dander
Dust Collection / Deodorizing Filter
Elements removed by filter
cigarette smoke odour,
household odour (toilet /
raw garbage / pet, etc.)
Odour
Dust
KC-930EUeng.indd2KC-930EUeng.indd2 2009/09/1111:10:592009/09/1111:10:59

ENGLISH
E-1
ENGLISH
Thank you for purchasing the SHARP Air Puri-
fier. Please read this manual carefully for the
correct usage information. Before using this
product, be sure to read the section: “Important
Safety Instructions.”
After reading this manual, retain it in a conven-
ient location for future reference.
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
• WARNING ....................................................E-2
• CAUTIONS CONCERNING OPERATION ...E-3
• INSTALLATION GUIDELINES......................E-3
• FILTER GUIDELINES ..................................E-3
PART NAMES...............................................E-4
• MAIN UNIT DISPLAY ...................................E-4
• ILLUSTRATIVE DIAGRAM..........................E-4
• INCLUDED ...................................................E-5
• BACK............................................................E-5
PREPARATION ............................................E-6
• FILTER INSTALLATION ...............................E-6
• REFILLING THE WATER TANK...................E-7
OPERATION .................................................E-8
• MAIN UNIT OPERATION .............................E-8
CARE AND MAINTENANCE .....................E-9
• FILTER INDICATOR LIGHT .........................E-9
• BACK PANEL AND SENSORS ....................E-9
• WATER TANK.............................................E-10
• UNIT ...........................................................E-10
• HUMIDIFYING TRAY ................................. E-11
• HUMIDIFYING FILTER...............................E-12
• FILTER REPLACEMENT GUIDELINES.....E-13
TROUBLESHOOTING ..............................E-14
SPECIFICATIONS......................................E-15
CONTENTS
FEATURES
Plasmacluster technology uses plas-
ma discharge to produce and release
the same positive and negative ions
as those found in nature ("Plasma-
cluster ions").
This is a unique air cleaning technol-
ogy of the SHARP CORPORATION
for breaking down and inactivating
such potential allergens as the feacal
matter or corpses of aerial mites*1,
viruses *2and mold and bacteria *3
suspended in the air, and has been
substantiated by third-party organiza-
tions both in Japan and overseas.
When there is a high density of Plas-
macluster ions in the air, the smell of
cigarette smoke trapped in curtains
or sofas is removed in about 80 min-
utes*4, and when clothing is hung in
a place exposed to the direct air ex-
pelled from the unit generating Plas-
macluster ions, the smell of sweat is
reduced to a virtually imperceptible
level in one night (about 6 hours).
"Plasmacluster" technology
*1 Graduate School of Advanced Sci-
ences of Matter, Hiroshima University,
Japan
Measurement of action on the poten-
tial allergens of aerial mites in (13m²)
*2 Retroscreen Virology, Ltd., London, UK
Measurement of ratio of viruses elimi-
nated from the air in a 1m³ box
*3 Ishikawa Health Service Association,
Japan
Measurement of aerial mold and bac-
teria with an air sampler (13m²)
*4 Japan Spinners Inspecting Foundation,
Japan
Evaluation of deodorizing effect on
odor-imbued fragments of cloth
KC-930EUeng.indd3KC-930EUeng.indd3 2009/09/1111:10:592009/09/1111:10:59

When using electrical appliances, basic safety precautions should be followed, including the
following:
E-2
IMPORTANT SAFETY INSTRUCTIONS
WARNING - To reduce the risk of electrical shock, fire or injury to persons:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet
is loosened.
• Periodically remove dust from the power plug.
• Do not insert fingers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or fire from short circuit may occur as a result.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or fireplaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not using the
unit.
Electrical shock from bad insulation and/or fire from short circuit may occur as a result.
• When refilling the Water Tank, cleaning the unit, or when the unit is not in use, be sure to
unplug the unit. Electrical shock and/or fire from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent,
Sharp Authorised Service Centre or similarly qualified person in order to avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air or in very high humidity conditions, such as a
bathroom.
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
• Only Sharp Authorised Service Centre should service this air purifier. Contact the nearest Service
Centre for any problems, adjustments, or repairs.
• When carrying the unit, remove the Water Tank and Humidifying Tray first and hold the unit by han-
dles on both sides.
• Do not drink the water in the Humidifying Tray or Water Tank.
• Change the water in the Water Tank daily with fresh tap water and regularly clean the Water Tank
and Humidifying Tray. (See E-11 and E-12). When unit is not in use, dispose of the water in the
Water Tank and Humidifying Tray. Leaving water in the Water Tank and/or Humidifying Tray may
result in mold, bacteria, and bad odours.
In rare cases, this bacteria may cause harmful physical effects.
• This appliance is not intended for use by persons (including children) with reduced physical, sen-
sory or mental capabilities, or lack of experience and knowledge, unless they have been given su-
pervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
NOTE - Radio or TV Interference
If this air purifier should cause interference to radio or television reception, try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
KC-930EUeng.indd4KC-930EUeng.indd4 2009/09/1111:10:592009/09/1111:10:59

ENGLISH
E-3
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Always operate the unit in an upright position.
• Always hold the handle on both sides of the unit when moving it.
Holding the back panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not operate the unit without the filters, Water Tank, and Humidifying Tray properly in-
stalled.
• Do not wash and reuse the filter .
Not only does it not improve filter performance, it may cause electrical shock or malfunction.
• Clean the exterior with a soft cloth only.
Do not use volatile fluids and/or detergents.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
INSTALLATION GUIDELINES
• During the operation of the product, please place the unit at least 2 m away from equipment
utilizing electrical waves such as televisions, radios or wave clocks.
• Avoid use in locations where furniture, fabrics or other items may come in contact with and
restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or rapid temperature
changes. (Use under appropriate conditions between 0 and 35˚C in the room.)
(If it is unavoidable please allow unit to stand for 1 hour before switching on.)
• Place on a stable surface with sufficient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
• Avoid use in locations where grease or oily smoke is generated (such as in a kitchen, etc.).
The unit surface may crack or the sensor may malfunction as a result.
• Place the unit about 30 cm~60 cm(1~2 ft) away from the wall in order to ensure proper air-
flow.
The wall directly behind the air outlet may become dirty over time. When using the unit for an ex-
tended period of time in the same location, periodically clean the wall and protect the wall with a
vinyl sheet, etc. to prevent the wall from becoming dirty.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the filters.
Use only filters designed for this product.
KC-930EUeng.indd5KC-930EUeng.indd5 2009/09/1111:10:592009/09/1111:10:59

E-4
MAIN UNIT DISPLAY
ILLUSTRATIVE DIAGRAM
PART NAMES
POWER ON/OFF Button
Plasmacluster Ion ON/OFF Button
MODE Button
Fan Speed
Indicator Lights
Filter Indicator Light
Filter Reset Button
Humidify Mode
Indicator Light
Odour
Sensor
CLEAN SIGN
The odour sensor continuosly monitors
the air and changes colour depending
on air punity.
Green Orange Red
Clean Very Impure
Plasmacluster
Ion ON/OFF
Indicator Light
Handle
Main Unit
Main Unit Display
KC-930EUeng.indd6KC-930EUeng.indd6 2009/09/1111:10:592009/09/1111:10:59

ENGLISH
Handle
Tank Handle
Tank Cap
Power Cord
Plug
Float
Humidifying Tray
Humidifying Filter
Water Tank
(For humidifying)
Air Outlet
Filter
Tab
Back Panel
(Pre-Filter)
E-5
INCLUDED
• Operation manual
BACK
(Shape of plug depends on country.)
(Dust Collection /
Deodorizing Filter)
Air Inlet
Date Label
Air outlet
KC-930EUeng.indd7KC-930EUeng.indd7 2009/09/1111:10:592009/09/1111:10:59

PREPARATION
E-6
Be sure to remove the power plug from the wall outlet.
To maintain the quality of the filter, it is installed in the main unit and packed in
plastic bag. Be sure to remove the filter from the plastic bag before using the
unit.
Remove the filter
Remove the Back Panel.
Pull the tab at the top of the Back Panel.
Intall the filter
FILTER INSTALLATION
Remove the Filter from the
plastic bag.
Do not install the filter backwards or the unit
will not operate properly.
Place the Filter within the main unit.
1
2
2
1
1
Tab
Replace the Back Panel to the main
unit.
2
Fill in the usage start date on the
Date Label.
3
Use the date as a guide for the filter replace-
ment schedule.
Date Label
KC-930EUeng.indd8KC-930EUeng.indd8 2009/09/1111:11:002009/09/1111:11:00

ENGLISH
E-7
REFILLING THE WATER TANK
CAUTION
Tank Cap
• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.
• Do not use hot water (40 ºC), chemical agents, aromatic substances, dirty water, or other
damaging substances, deformation and/or malfunction may occur.
• Use only fresh tap water. Use of other water sources may promote the growth of mold, fun-
gus and/or bacteria.
The unit can be used in the Clean Air Mode without
putting water in the Water Tank. When using in the Hu-
midify Mode, the Water Tank should be filled with water.
1
Remove the Water Tank by unlatching the
top.
2
Remove the Water Tank Cap and carefully fill
the Water Tank with tap water.
3
After filling, securely tighten the Tank Cap.
• Check to see that there is no water leaking.
• Be sure to wipe off any excess water on the outside of
the Water Tank.
• When carrying the Water Tank, hold it with both hands
so that the Water Tank opening is facing up.
4
Replace the Water Tank in the unit.
Change the water in the Water Tank every day with
fresh tap water.
The top latch will “click” in place when the Water Tank is
properly installed.
KC-930EUeng.indd9KC-930EUeng.indd9 2009/09/1111:11:012009/09/1111:11:01

Fan Speed Indicator Lights
Plasmacluster Ion Indicator Light
POWER ON/OFF
Button
MODE Button
Plasmacluster Ion
ON/OFF Button
LOW operation
The unit will operate quietly using
minimal air intake.
MEDIUM operation
The unit will operate at a fan speed
of MEDIUM.
MAX operation
The unit will operate at a fan speed
of MAX.
AUTO operation
The fan speed is automatically switched
(between HIGH and LOW) depending on the
amount of impurities in the air. The sensors
detect impurities for efficient air purfication.
OPERATION
MAIN UNIT OPERATION
E-8
Power ON/OFF Button
• Press to start operation (short beep) and stop operation
(long beep)
• Plasmacluster Indicator Light and Fan Speed Indicator
Light turn on/off.
• Unless the power cord has been unplugged, the opera-
tions starts in the previous mode it was operated in.
MODE Button
Plasmacluster Ion ON/OFF Button
• Press the MODE Button to select the desired fan speed.
Indicator Lights will show the fan speed currently select-
ed.
• The operation mode can be switched as below.
Press the Plasmacluster Ion ON/OFF Button to turn
Plasmacluster Ion Mode ON and OFF.
When Plasmacluster Ion is ON, the Plasmacluster Ion
Indicator Light will turn on. (blue)
Please select either Humidify mode or Clean air mode operation when operation when using.
Humidify mode : Fill Water Tank. (See E-7)
Clean Air mode : Drain Water Tank and Humidifying Tray.
KC-930EUeng.indd10KC-930EUeng.indd10 2009/09/189:08:252009/09/189:08:25

ENGLISH
E-9
CARE AND MAINTENANCE
FILTER INDICATOR LIGHT
The Filter Indicator Light will illuminate as a reminder to perform maintenance of the
Back Panel, Sensors, and Humidifying Filter. The Indicator Light will turn on after ap-
proximately 720 hours of use.
To maintain optimum performance of this air purifier, please clean the unit including
the sensor and filters periodically.
When cleaning the unit, be sure to first unplug the power cord, and never handle the
plug with wet hands. Electrical shock and/or bodily injury may occur as a result.
Care Cycle After 720 hours of use
(30days × 24hours = 720)
Care Cycle Whenever dust accumulates
on the unit or every 2 months
After performing maintenance, reset the Filter
Indicator.
1
Plug the unit in, turn power ON.
Press the RESET button for 3 seconds.
• The Filter Indicator Light will go off.
• Even if the Filter Indicator Light is already off, the RESET
button should be pressed to reset the maintenance timer.
2
Gently remove dust from the sensor opening and the back panel, using a vacuum
cleaner attachment or similar tool.
Back Panel
BACK PANEL and SENSORS
<When the back panel has stubborn dirt>
1
In case of heavy dirt, soak the back panel in water with a small amount of kitchen
detergent.
(Approx. 10min.)
(Avoid scrubbing the back panel hard when washing.)
2
Rinse the back panel repeatedly with clean water to remove
the solution residue.
3
Drip dry filter to remove excess water.
KC-930EUeng.indd11KC-930EUeng.indd11 2009/09/1111:11:012009/09/1111:11:01

E-10
CARE AND MAINTENANCE
WATER TANK
Rinse the inside of the tank by leaving a small amount of luke-
warm water inside, closing the tank cap firmly, and shaking
the tank. Mild household detergents may be used to clean the
inside of the tank, but detergent should be diluted and the tank
should be thoroughly rinsed to remove all detergent residue.
(Note the Water Tank is not dishwasher safe.)
Tank Cap
Water Tank
Care Cycle Every day when Humidifying
UNIT
Care Cycle Whenever dust accumulates on the unit or every 2 months
To prevent dirt or stains on the unit, clean regularly. If stains are allowed to remain, they may
become difficult to remove.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile fluids
Benzene, paint thinner, polishing powder, may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
KC-930EUeng.indd12KC-930EUeng.indd12 2009/09/1111:11:022009/09/1111:11:02

ENGLISH
2
Remove the Humidifying Filter from the
Humidifying Tray. Drain accumulated wa-
ter by tilting the Humidifying Tray slowly.
1
Remove the Water Tank and Humidifying
Tray.
E-11
Frequency of maintenance cycle will depend on the hardness
of the water. Avoid spilling water when removing or cleaning
the tray.
3
Rinse the inside of the Humidifying
Tray with lukewarm water to remove
impurities.
• Do not remove the Styrofoam float.
• Clean difficult-to-reach parts with a cotton-
tipped swab or tooth brush.
CAUTION
If the Styrofoam float comes off,
replace by inserting the tabs of
the Float into the holes in the
Humidifying Tray as shown in the
diagram.
When Water Deposits are Difficult to Remove
• Use only mild kitchen detergents to
clean the Humidifying Tray. Use of
non-designated chemicals or deter-
gents can cause deformation, tar-
nishing, cracking (water leakage).
Insert the float below
this tab.
Insert the tab on
the other side of the
float into the hole.
Insert the tab of the
float into the hole.
1
Fill Humidifying Tray half-
way with lukewarm water,
add a small amount of mild
kitchen detergent, and leave
to soak for about 30 min-
utes.
Dilute detergent according to
instructions on the container.
Clean difficult-to-reach parts
with a cotton swab or tooth
brush.
2
Rinse the Humidifying
Tray with lukewarm wa-
ter.
• Rinse until all detergent residue
is removed.
• Inadequate rinsing may cause
the detergent odour or changes
in the shape/colour of the main
unit.
HUMIDIFYING TRAY
Care Cycle 1 month
Unlatch the Water
Tank first, then re-
move the tray. Use
both hands when
pulling out the Hu-
midifying Tray to
avoid spilling water.
Humidifying Filter
Humidifying Tray
KC-930EUeng.indd13KC-930EUeng.indd13 2009/09/1111:11:022009/09/1111:11:02

E-12
Frequency of maintenance cycle will depend on the hardness or the impuri ties of the water that
you use; the harder the water the more often descaling will be necessary.
Pay attention not to spill water when cleaning the filter.
1
Remove the Water Tank and
Humidifying Tray.
(See E-11)
2
Remove the Humidifying Filter
from the Humidifying Tray.
Avoid spilling water from the Humidifying
Tray.
3
Preparing the descaling solu-
tion.
Citric acid, available at some drugstores,
or 100 % bottled lemon juice are used for
descaling. Choose either one to use, and
prepare the descaling solution.
<For using citric acid>
Dissolve 3 teaspoons of citric acid and 2
1/2 cups of lukewarm water in a suitable
container, and stir well.
<For using lemon juice>
100 % bottled lemon juice can be used
for descaling. Use only 100 % bottled
lemon juice with no pulp (strain juice if
necessary). Combine 1/4 cup lemon juice
and 3 cups of lukewarm water in a con-
tainer large enough to hold the Humidify-
ing Filter and stir well.
4
When using lemon juice, it is recommend-
ed to pre-soak longer than citric acid.
5
Rinse the Humidifying Filter re-
peatedly with lukewarm water
to remove all the solution resi-
due.
Inadequate rinsing may cause odour and
affect the performance and/or appear-
ance of the unit.
*Do not scrub the Hu-
midifying Filter, rinse
gently under lukewarm
water only.
6
Attach the Humidifying Filter
to the Humidifying Tray, and
replace the Humidifying Tray in
the unit.
•The Humidifying Filter dose not
need to be oriented in any particular
position(forward/backward, up/down)
7
Plug in the unit, turn power
ON, and press the Filter Reset
Button on the display for more
than 3 seconds to reset.
HUMIDIFYING FILTER
Care Cycle Once a month or when the Filter Indicator Light is on.
P re-soak the Humidifying Filter
in the solution for 30 minutes
before cleaning.
CARE AND MAINTENANCE
You may notice reddish-brown or
white deposits forming on the surface
of the Humidifying Filter. These impu-
rities (calcium, etc.) are due to the im-
purities contained in tap water; this is
not a defect. Replace the Humidifying
Filter when it is covered completely in
white deposits.
•When not using
the unit for a long
periods of time,
dry the Humidify-
ing Filter com-
pletely before
replacing.
When cleaning the unit, be sure to first unplug the power cord, and never handle the plug with
wet hands. Electrical shock and/or bodily injury may occur as a result.
KC-930EUeng.indd14KC-930EUeng.indd14 2009/09/1111:11:022009/09/1111:11:02

ENGLISH
Date Label
Filter life vary depending on the room environment, usage, and location
of the unit.
If dust or odour persist, replace the filter.
(Refer to “Please read before operating your new Air Purifier”)
Guide for filter replacement timing
• The following filter life and replacement period is based on the condition of smoking 5
cigarettes per day and the dust collection/deodorization power is reduced by half compared
with that of new filter.
We recommend to replace the filter more frequently if the product is used in a condition sig-
nificantly severer than normal household use.
E-13
FILTER REPLACEMENT GUIDELINES
Dust Collection /
Deodorizing Filter
Humidifying Filter
•Dust Collection / Deodorizing Filter About 2 years after opening
•Humidifying Filter About 1 years after opening
REPLACING THE FILTER
1
See page E-6 and E-11,12 for
directions on how to install the
filter when replacing.
2
Fill in the usage start date of the
filter on the Date La
bel.
Replacement Filters
Model : FZ-Y30SFE
•Dust Collection / Deodorizing Filter : 1 unit
Model : FZ-Y30MFE
•Humidifying filter : 1 unit
Please consult your dealer for purchase of replacement filter.
Disposal of Filter
Please dispose of the replaced filter according to the local disposal laws and regulations.
Dust Collection / Deodorizing Filter materials :
•Filter : Polypropylene
•Frame : Polyester
•Deodorizer : Activated charcoal
Humidifying Filter materials :
•Rayon, Polyester
KC-930EUeng.indd15KC-930EUeng.indd15 2009/09/1111:11:032009/09/1111:11:03

E-14
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting chart below, since the problem may not
be a unit malfunction.
SYMPTOM REMEDY (not a malfunction)
Odours and smoke are not
removed. • Clean or replace the filters if they appear to be heavily soiled.
(See E-13)
The Clean Sign illuminates
green even when the air is
impure.
The Clean Sign illuminates
orange or red even when the
air is clean.
A clicking or ticking sound is
heard from the unit.
The discharged air has an
odour.
The unit does not operate
when cigarette smoke is in
the air.
Filter Indicator Light is
illuminated.
The Clean Sign are turned
off.
The Humidify Mode Indicator
Light does not illuminate
when the tank is not empty.
Water level in the tank does
not decrease or decreases
slowly.
The Clean Sign lights change
colour frequently.
Flashing of the Fan Speed
Indicator Light ' '.
• The air could be impure at the time the unit was plugged in.
Unplug the unit, wait one minute, and plug the unit in again.
• Sensor operation is affected if the odour sensor openings are dirty or
clogged. Gently clean the dust sensors.
(See E-9)
• Clicking or ticking sounds may be audible when the unit is generating
Plasumacluster ions.
• Check to see if the filter are heavily soiled.
• Clean or replace the filter.
• Plasmacluster Air Purifiers emit small traces of ozone which may
produce an odour.
• Is the unit installed in a location that is difficult for the sensor to de-
tect cigarette smoke?
• Are the dust sensor openings blocked or clogged?
(In this case, clean the openings.) (See E-9)
• After replacing filters, connect the power cord to an outlet and press
the Filter Reset Button.
(See E-9)
• Check to see if the Lights OFF Mode selected. If so, then press the
Lights Control Button to activate the indicator lights.
(See E-8)
• Check Styrofoam float for impurities. Clean the HumidifyingTray. En-
sure unit is located on a level surface.
• Check to see if the Humidifying Tray and Water Tank are correctly
installed. Check the Humidifying Filter.
• Clean or replace the filter when it is heavily soiled.
(See E-11, E-12, E-13)
• The Clean Sign lights automatically change colours as impurities are
detected by the dust sensor and odour sensor.
• Abnormal fan motor •
Turn power OFF to cancel the error
display, wait one minute, and then turn
power ON.
KC-930EUeng.indd16KC-930EUeng.indd16 2009/09/189:08:322009/09/189:08:32

ENGLISH
E-15
SPECIFICATIONS
Model
*1
*2
Size of a room which is appropriate for operating the unit at maximum fan speed.
•It indicates the space where a certain amount of dust particles can be removed in 30
minutes(JEM1467).
Size of a room in which approximately 7000 ions can be measured per cubic centimeter in the
center of the room (at a height of approximately 1.2 meters from the floor) when the product is
placed next to a wall and run at the MAX operation position.
Standby Power In order to operate the electrical circuits while the power plug is inserted in the
wall outlet, this product consumes about 0.9W of standby power.
For energy saving, unplug the power cord when the unit is not in use.
*3 The class of the HEPA filter by EN 1822 is H10.
Power supply
Fan Speed
operation
Fan Speed Adjustment
Rated Power
Fan Speed
Humidification
Recommended Room Size
High density Plasmacluster ion
recommended room size
Water tank capacity
Sensor
Filter type
Cord Length
Dimensions
Weight
KC-930EU
220-240V 50/60Hz
MAX MED LOW
27W 13W 4.5W
180m3/hour 126m3/hour 60m3/hour
350ml/hour 250ml/hour 140ml/hour
~21m2 *1
~17m2 *2
2.1L
odour sensor
Dust Collection (HEPA Filter *3)/ Deodorizing Filter
2.0m
375mm(W)x205mm(D)x535mm(H)
6.1kg
KC-930EUeng.indd17KC-930EUeng.indd17 2009/09/1111:11:032009/09/1111:11:03

A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust
bin!
Used electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and recycling of
used electrical and electronic equipment.
Following the implementation by member states, private households within the EU
states may return their used electrical and electronic equipment to designated
collection facilities free of charge*. In some countries* your local retailer may also
take back your old product free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators, please
dispose of these separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste undergoes
the necessary treatment, recovery and recycling and thus prevent potential negative
effects on the environment and human health which could otherwise arise due to
inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the
correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of
charge to the dealer, even if you don’t purchase a new product. Further collection
facilities are listed on the homepage of www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users.
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of the
product. You might be charged for the costs arising from take-back and recycling.
Small products (and small amounts) might be taken back by your local collection
facilities.
For Spain: Please contact the established collection system or your local authority for
take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for
the correct method of disposal.
Attention: Your product is
marked with this symbol. It
means that used electrical
and electronic products
should not be mixed with
general household waste.
There is a separate
collection system for these
products.
EN
KC-930EUeng.indd18KC-930EUeng.indd18 2009/09/1111:11:032009/09/1111:11:03

ENGLISH
Memo
KC-930EUeng.indd19KC-930EUeng.indd19 2009/09/1111:11:042009/09/1111:11:04

Bitte lesen Sie sich diese Bedienungsanleitung vor der ersten
Inbetriebnahme Ihres neuen Luftreinigers sorgfältig durch.
Einige Geruchsbestandteile, die von dem Filter absorbiert werden, könnten
gespalten und durch den Luftaustritt wieder ausgegeben werden, so
dass zusätzlich Geruch entstehen könnte. Je nach Betriebsumgebung
und insbesondere bei Verwendung des Gerätes unter so extremen
Bedingungen, dass sie denen in einem herkömmlichen Haushalt nicht mehr
entsprechen, kann sich diese Geruchsentwicklung in einer kürzeren Zeit als
ursprünglich angenommen verstärken.
In diesem Fall empfehlen wir Ihnen den Erwerb des optionalen Ersatzfilters.
HINWEIS
• Der Luftreiniger wurde für die Beseitigung von in der Luft enthaltenem Staub und Gerüchen
konzipiert; für eine Beseitigung schädlicher Gase (beispielsweise von in Zigarettenrauch
enthaltenem Kohlenmonoxid) ist er nicht geeignet. Wenn die Ursachen des Geruches weiterhin
vorhanden sind, kann der Geruch nicht vollständig entfernt werden (beispielsweise Gerüche von
Baumaterialien oder Haustieren).
• Wir empfehlen Ihnen, das Fenster etwas zu öffnen, wenn Sie rauchen, um den Luftaustausch zu
erleichtern.
Pollen, Staub, Partikel aus Zigarettenrauch,
Hautschuppen von Haustieren
Staubbeseitigung /
Geruchsbeseitigende Filter
Durch den Filter entfernte
Elemente
Zigarettenrauchgeruch,
Haushaltsgerüche
(Toilette / Kompost / Haustiere usw.)
Geruch
Staub
KC-930EUger.indd2KC-930EUger.indd2 2009/09/1111:11:302009/09/1111:11:30
