Sharp Plasmacluster KC-6400E User manual

ENGLISH
KC-6400E
KC-6500E
AIR PURIFIER
OPERATION MANUAL
R
Free standing type
*Plasmacluster is a trademark of
Sharp Corporation.
KC-6400E
KC-6500E

MODEL

Please read before operating your new Air Purifier
The air purifier draws in room air from its air intake, lets the air pass through a
Active Carbon Filter (deodorization filter) and a HEPA Filter (dust collection
filter) inside of the unit, then discharges the air from its air outlet. The air
purifier unit repeats this process by moving its internal fan.
As air passes through, a new HEPA Filter can remove 99.97% of dust parti-
cles, of as small as 0.3 microns. The Active Carbon Filter gradually absorbs
odour elements as they repeatedly pass through the filter. (Odour elements
are absorbed by HEPA Filter as well.)
Some odour ingredients absorbed by the filters may become separated and
may be discharged through the air outlet and result in additional odour. De-
pending on the usage environment, especially when the product is used in a
condition significantly more severe than household use, this odour may be-
come strong in a shorter period than expected.
If the odour persists, then the filters are fully expended and it is necessary to
purchase the optional replacement filter.
NOTE
• The air purifier is designed to remove air-suspended dust and odour, but not harmful gases (for
example, carbon monoxide contained in cigarette smoke). If the odour sources still exist, it cannot
completely remove the odour. (for example, odours from construction materials and pet odours).
• It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.
(Common illustration has used “KC-6500E”)

ENGLISH
FEATURES
E-1
ENGLISH
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .... E-2
• WARNING ............................................. E-2
• CAUTIONS CONCERNING OPERATION .... E-3
• INSTALLATION GUIDELINES .............. E-3
• FILTER GUIDELINES ........................... E-3
PART NAMES .................................... E-4
• ILLUSTRATIVE DIAGRAM ................... E-4
• BACK .................................................... E-5
• INCLUDED ............................................ E-5
• MAIN UNIT DISPLAY ............................ E-6
PREPARATION.................................. E-8
• FILTER INSTALLATION ........................ E-8
• POUR WATER INTO THE TANK ........ E-10
OPERATION ..................................... E-11
• POWER ON/OFF BUTTON .................E-11
• ION SHOWER MODE OPERATION ....E-11
• MODE SELECTION BUTTON ............ E-12
• HUMIDIFY AND CLEAN AIR MODE ...... E -12
• RUNNING CLEAN AIR MODE ONLY ... E-13
• PLASMACLUSTER ION MODE ......... E-13
• LIGHTS ON/OFF ................................ E-13
CARE AND MAINTENANCE ........... E-14
• MAIN UNIT .......................................... E-14
• TANK ................................................... E-14
• SENSORS .......................................... E-14
• FILTER CLEANING ............................. E-15
• WASHABLE ACTIVE CARBON FILTER CARE . E-15
• MIST TRAY ......................................... E-16
• MIST FILTER ...................................... E-17
• FILTER REPLACEMENT
GUIDELINES ...................................... E-18
TROUBLE SHOOTING.................... E-19
SPECIFICATIONS ........................... E-20
INFORMATION ON PROPER DISPOSAL ..... E-21
Thank you for purchasing the SHARP Air Pu-
rifier. Please read this manual carefully for
the correct usage information. Before using
this product, be sure to read the section: “Im-
portant Safety Instructions.”
After reading this manual, retain it in a con-
venient location for future reference.
New Air Purifier with "Humidifying"
ability beyond the "Two-in-one"
effect
"Synergy" of humidification and Plasmacluster
ion realize the more powerful deodorization
and eliminating of airborne dust, mold, or
microbes.
1.Simultaneously generating the
Plasmacluster ions and vaporized mist
realize the longer life of ions and higher
performance of purification.
(Not available to get this effect from
separate Humidifier and Air Purifier.)
2. Powerfully decompose and remove the
airborne microbes or house dust.
3. Effectively eliminating of static electricity
which tend to be caused in a dry
environment.
4. Powerful deodorizing - not only the
airborne odour but the adherent one which
is inside of the fabric of clothes.
5. Provide the appropriate humidity in the
room, and controls the activity of viruses in
the dry room.
6. Usual air purifying operation is available
by selecting humidify off mode.
Powerful Humidifying Ion Shower
Operation
Enhanced Ion Shower operation with
humidification releases concentrated
Plasmacluster ions by repeating its airflow
cycles between strong and gentle, effectively
removes the airborne dust, pollen, mold, and
allergen.
Dual Filtering System
1) Washable Active Carbon Filter
Collect the large dust particles at the
surface, and absorbes odour elements.
Washable to maintain optimum
deodorization performance.
2) HEPA (High Efficiency Particulate
Air) Filter with Microbial control.
High efficiency filter can remove the dust
particles as small as 0.3 microns.

When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electrical shock, fire or injury to persons:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet is
loosened.
•Periodically remove dust from the power plug.
• Do not insert fingers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or fire from short circuit may occur as a result.
• Do not remove the power plug when your hands are wet.
• Do not use this unit near gas appliances or fireplaces.
• When pouring the water into the Tank, when cleaning the unit and when not using the unit, be
sure to unplug the power cord.
Electrical shock from bad insulation and/or fire from short circuit may occur as a result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent,
Sharp authorized Service Centre or similarly qualified person in order to avoid a hazard.
•Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air or in very high humidity condition, such as a
bathroom.
•Be cautious when cleaning the unit. Strong corrosive cleansers may damage the exterior.
•Only Sharp Authorized Service Centre should service this air purifier. Contact the nearest Service
Centre for any problems, adjustments, or repairs.
•When carrying the Main Unit, please remove the Tank and MIST Tray and hold the Handles on both
sides.
•Do not drink in jest the water in the MIST Tray or Tank.
It may cause illness.
•Change the Tank water every day with fresh tap water.
Keep inside the Tank clean. (See Tank maintenance E-10)
Leaving water in the Tank will result in mold, bacteria, and bad odours.
In rare cases, this bacteria cause harmful physical effects.
•When not in use, dispose the water in the Tank and MIST Tray.
Leaving water in the Tank and MIST Tray will cause mold and bacteria.
NOTE - Radio or TV Intreference
If this air purifier should cause interference to radio or television reception, try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation distance between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
E-2
IMPORTANT SAFETY INSTRUCTIONS

ENGLISH
E-3
CAUTIONS CONCERNING OPERATION
• Do not block the intake and air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting in
bodily injury.
• Do not operate the unit without the filter.
• Do not wash and reuse HEPA filter .
Not only does it not improve filter performance, it may cause electric shock or malfunction.
• Clean the exterior with a soft cloth only.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
INSTALLATION GUIDELINES
• During the operation of the product, please place the unit at least 2m away from equipments
which involve electric wave such as televisions, radios or wave clocks, in case electrical
interference occurs to such equipments.
• Avoid a location where the sensor is exposed to direct wind.
The unit may not operate properly.
• Avoid locations where curtains, etc., come into contact with the intake or air outlet.
Curtains, etc., may become dirty or a malfunction may occur.
• Avoid locations where the unit is exposed to condensation, due to drastic temperature changes.
(Use under appropriate conditions between 5 and 35˚C in the room.)
• Place on a stable surface with sufficient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
When placing the unit on an uneven surface, the water may leak from the Tank.
• Do not install when there is generation of lampblack, such as in a kitchen, etc.
The unit surface may crack or the sensor may malfunction as a result.
• Leave about 60cm of space from the ceiling and wall.
The wall behind the air outlet may become dirty as time passes. When using the unit for extended
period of time in the same location, use a vinyl sheet, etc., to prevent the wall from becoming dirty. In
addition, periodically clean the wall.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the filters.
• The frequency of maintenance (descaling) will depend on the hardness or the impurities of
the water that you use; the harder the water the more often descaling will be necessary.

E-4
ILLUSTRATIVE DIAGRAM
Control Panel Air Outlet
Odour Sensor
Temperature / Humidity Sensor
Dust Sensor
Dust Sensor Filter
HEPA Filter (white)
Active Carbon Filter (black)
Filter Support
Main Unit
PART NAMES
Control Panel Air Outlet
Odour Sensor
Temperature / Humidity Sensor
HEPA Filter (white)
Active Carbon Filter (black)
Main Unit
Front Panel
(KC-6400E)
(KC-6500E)
Front Panel

ENGLISH
E-5
BACK
Handle
(2 locations left and right)
Tank
Tank Handle
Air Inlet
Tank Cap
Float
MIST Filter
MIST Tray
Air Outlet
Date Label
Power Cord
(Shape of plug depends on country.)
Power Plug
(left and right/bottom side)
INCLUDED • Operation manual
Handle
(2 locations left and right)
Air Inlet
(left and right/bottom side)
Tank Handle
Tank
Tank Cap
Float
MIST Filter
MIST Tray
Air Outlet
Date Label
Power Cord
(Shape of plug depends on country.)
Power Plug
(KC-6400E)
(KC-6500E)

Air of room
Colour
Cycle of light and shade
blue
the colour of CLEAN-SIGN
DETERMINING THE BASE IMPURITY RATE
red orange green Clean
Light off
Mode
Ion SHOWER
Plasmacluster ON
Plasmacluster OFF
E-6
PART NAMES
MAIN UNIT DISPLAY
Plasmacluster ON/OFF Indicator Light (green)
Plasmacluster ON/OFF Button
Plasmacluster Indicator Light
CLEAN-SIGN Light
ION SHOWER Indicator Light (blue.green)
Mode Selection Button
Clean Air Mode
Operation Indicator
Light(green)
ION SHOWER
Mode Button
(Humidification +
Plasmacluster)

ENGLISH
E-7
green) Humidity Indicator Light (green)
Humidify Mode
ION SHOWER
Mode Button
(Humidification +
Plasmacluster)
Mode Selection Button
MIST Filter Indicator Light (red)
Informs you when you must clean your
MIST Filter.
After cleaning
MIST Filter Reset Button
The Mist Filter Indicator Light turns off.
Power ON/OFF Button
Water Supply Indicator Light
(red)
Informs you when the tank needs to be
refilled with water.
Displays a rough measure of the current level of indoor
humidity. (Inputting your preferred humidity settings is not
allowed)
The unit will check the current level of humidity for one minute
immediately after the power is turned ON, during which time
numbers 30 - 70 flash sequentially.
(Ex.) At 50% humidity
Operation Indicator
Light(green)

E-8
Be sure to remove the power plug from the wall outlet.
PREPARATION
2
1
Please make sure that the HEPA
Filter is placed in proper orientation.
1
2
Remove the Front Panel.
Remove the Filter Support.
Install the filters
Place the HEPA Filter within
the main unit.
Do not install the
filter backwards or
the unit will not
operate properly.
To maintain the quality of the filters, they are installed in the main unit and packed in the
plastic bags. Be sure to remove the filters from the plastic bags before using the unit.
FILTER INSTALLATION
1
Push in the hooks,
then pull the Front
Panel.
Remove the filters
3
2
Push in the hooks
on top , then pull
the Filter Support.
Remove the Active Carbon
Filter(black) and HEPA Filter
(white) from the plastic
bags.
(At open)
Front Panel
Hook
Filter Support
HEPA Filter
Active Carbon Filter
HEPA Filter
The filter may sometimes discharge
deodorant powder, but such discharge does
not affect deodorizing performance.
Place the Active Carbon Filter
into the main unit.
Fit the Active Carbon Filter
to the tab on the top of the
main unit.
Fit the band to the tab facing toward
you in the direction indicated by the
arrow, and insert fully.
KC-6400E
band(blue)
(Only KC-6500E)

ENGLISH
E-9
4
Replace the Front Panel.
3
Fill in the usage start date
on the Date Label.
Use the date as a guide for the Fil-
ter Replacement schedule.
Date Label
Front Panel
Active Carbon Filter
Place the Filter Support
through the bands (2 places)
located at the corners of the
Active Carbon Filter.
Band(blue)
Filter Support
KC-6500E
Replace the Filter Support and
the Active Carbon Filter back
to the main unit.
Filter Support

Be sure to remove the power plug from the wall outlet.
PREPARATION
Pour water into the Tank
This product can be used as an air purifier
without putting water in the tank.
2
1
3
Hold the tank handle and remove the tank.
Remove the tank cap and pour water.
• Use drinkable tap water.
(Generally speaking, tap water is sterilized with chlo-
rine to suppress propagation of bacteria.)
• Change the tank water every day with fresh tap water.
After supplying water, securely tighten the
tank cap.
• Check to see that there is no water leak.
• Be sure to wipe off any excess water around the tank.
• When carrying the tank, hold it with both hands so
that the tank opening is facing up.
Mount the tank to the main unit.
• Insert the tank cap into the dented part of the unit.
• Make sure the tank is firmly attached by pushing it
in until you hear a click.
4
CAUTION
• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.
• Do not use hot water (of 40˚C or higher), chemical agents, aromatic substances, dirty water,
etc. Deformation and/or malfunction may occur as a result.
• Do not use mineral water, ionized alkaline water, well water, purified water, etc. Propagation of
mold fungus and bacteria may occur as a result.
• Securely tighten the tank cap. If the tank cap is difficult to tighten, loosen the cap one full turn
to properly set the cap to the tank.
Water Supply Indicator Light
Tank Handle
Tank
Tank Cap
Tank
(Ex.) When water runs out during
Automatic Humidify Mode
When the tank is dry and the water in the tray
begins to dry up, the Water Supply Indicator Light
will begin to flash.
Fill the tank with water.
When not operating in Humidify Mode, press the
Humidify Mode Selection Button to turn the mode
OFF; the Water Supply Indicator Light will turn off.
Flashing
E-10

ENGLISH
E-11
POWER ON/OFF BUTTON
2
1
Plasmacluster ON/OFF
Indicator Light
CLEAN-SIGN
Light
Plasmacluster Indicator
Light
ION SHOWER
Indicator Light
Clean Air Mode
Mode Selection
Button
Power ON/OFF
Button
Humidity
Indicator Light
Humidify Mode
Mode
Selection
Button
ION
SHOWER
Mode
Button
Operation Indicator
Light
Press the POWER ON/OFF Button on the main unit.
Press the POWER ON/OFF Button on the main unit.
When pushing the ION SHOWER Mode button, the ION SHOWER
operation will be activated. (Direct start is available even when the unit
is not turned on.)
The concentrated Plasmacluster Ions (ION SHOWER) will be generated
in the room like a shower for 15 minutes, repeating the airflow cycles
between strong and gentle. (The Plasmacluster Indicator Light repeats
its colour cycles between light and shade.), and effectively controls the
airborne dust, pollen, mold, and allergen.
• When the operation finishes, the unit will return to the prior operation.
• When pushing the ION SHOWER button while the ION SHOWER
operation mode is working, the unit will return to the prior operation.
ION SHOWER Mode Operation
• Mode activates after the short "beep".
• Unless unplug the power cord, the operation starts in the previous
mode the unit was operated in.
• When stop operation during ION SHOWER Operation, the unit
will back to the prior operation of ION SHOWER Operation.
• When the tank is dry, the Water Supply Indicator Light turns on.
When not operating in Humidify Mode, turn the mode OFF by
pressing the Humidify Mode Selection Button; the Water Supply
Indicator Light will turn off.
• Mode stops running after the long "beep".
Shower (Humidification + Plasmacluster Ion) Mode
OPERATION
Operation Indicator
Light

E-12
Mode Selection Button
OPERATION
The operation mode can be switched, and the Indicator Light will turn on.
Clean Air
During operation During operation
Use the Clean Air Mode and Humidify Mode together to quickly remove house dust floating
in the air as well as eliminates odour. (for fresh air and those of saturated ones.)
During Normal Use
For Quiet Use at Bedtime, Etc.
When Air is Dry
4 sensors (a *Dust Sensor and an Odour Sensor for detecting
impurities in the air, and Temperature/Humidity Sensors for
detecting temperature and humidity) are used to automatically
control airflow volume in accordance with the state of your room.
2 sensors (a *Dust Sensor and an Odour Sensor for detecting
impurities in the air) are used to automatically control airflow
volume in accordance with the amount of impurities detected in
your room, while humidifying gently and quietly in "Humidify LOW"
Mode.
2 sensors (a *Dust Sensor and an Odour Sensor for detecting
impurities in the air) are used to automatically control airflow
volume in accordance with the amount of impurities detected in
your room, humidifying vigorously in "Humidify HIGH" Mode.
(Operation noise increases)
About Automatic Humidify Mode
The Temperature/Humidity
Sensors control humidity
automatically in accordance
with changes in room
temperature.
Depending on the size and dryness of your room, humidity
may not reach 55 - 65%. In such cases, it is recommended
to operate in "Humidify HIGH" Mode.
*
When operating Clean Air
Mode and Humidify Mode
together, Humidify Mode
takes priority.
Only KC-6500E is equipped with the Dust sensor.
*
Humidify and Clean Air Mode
Humidify
Clean Air : AUTO
Humidify : AUTO
Clean Air : AUTO
Humidify : LOW
Clean Air : AUTO
Humidify : HIGH

ENGLISH
E-13
Running Clean Air Mode Only
(when you wish to turn OFF
Humidifying)
2
1
AUTO operation
The fan speed is automatically
switched (HIGH*, MEDIUM, LOW)
depending on the amount of
impurities in the air. The sensors
detect the impurities for efficient
air purification.
MAX operation
The unit will operate at a fan speed
of MAX.
MEDIUM operation
The unit will operate at a fan speed
of MEDIUM.
LOW operation
The unit will operate quietly using
minimal air intake.
* HIGH fan speed is an interme-
diate speed between MEDIUM
and MAX.
Plasmacluster Ion Mode
LIGHTS ON/OFF
CAUTION
(Please press the Plasmacluster ON/OFF Button for 3 seconds
2 short beeps are generated.)
Switches the Plasmacluster Indicator Light and CLEAN-SIGN
Light either ON or OFF.
On rainy days, etc. when your room is reasonably humid, turn Humidify Mode OFF.
When the device is running, press the Humidify Mode Selection Button to turn Humidify
Mode OFF. ( )
Press the Clean Air Mode Selection Button to set your preferred purification mode.
Each time the Button is pressed during operation, the
Plasmacluster Ion Mode turns ON and OFF and the
Plasmacluster ON/OFF Indicator Light turns ON (green) and OFF.
Use when the Plasmacluster Indicator Light and the CLEAN-
SIGN Light are too bright.
When the Plasmacluster ON/OFF Button is released before the 2 short beeps,
The Plasmacluster Ion Mode switches between ON and OFF; the CLEAN-
SIGN Light does not turn ON/OFF because only the Plasmacluster Indicator
Light turns ON/OFF.

E-14
CARE AND MAINTENANCE
To maintain optimum performance of this air purifier, please clean the unit including the
sensor and filters periodically.
When cleaning the unit, be sure to unplug the power cord, and never handle the plug with
wet hands. Electrical shock and/or bodily injury may occur as a result.
MAIN UNIT
Care Cycle 1 month
To prevent dirt or stains on the main unit, clean as often as necessary. If stains are allowed to
remain, they may become hard to clean.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile fluids
Benzene, paint thinner, polishing powder, etc., may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
Keep the unit away from water
TANK
Tank
With a small amount of water inside and the tank cap closed, wash
the tank set by shaking it.
When using a kitchen detergent, dilute the detergent with water and
rinse it thoroughly.
SENSORS (*DUST SENSOR, ODOUR SENSOR, TEMPERATURE/HUMIDITY SENSOR)
Sensor Cover
Opening of
Temperature/Humidity
Sensor
Opening of Dust
Sensor
Opening of Odour
Sensor
Care Cycle 2 months
Remove dust from the surface of the hole of
the sensors using a vacuum cleaner. SENSOR FILTER CARE
(The sensor Filter is in the sensor cover.)
Detach the sensor filter and tap it lightly with
your hand to remove the dust.
If it is very dirty, wash it with water and then
allow it to dry thoroughly.
Sensor Filter
It does not have a front
and a back.
Tank Cap
Care Cycle Every water supply
*
Opening of
Temperature/Humidity
Sensor
Opening of
Odour Sensor
(KC-6500E only)
KC-6500E
KC-6400E
Only KC-6500E is equipped with the Dust sensor.

ENGLISH
E-15
FILTER CLEANING
Care Cycle 2 months
Clean the top surface of the Active Carbon Filter
lightly with a vacuum cleaner.
WASHABLE ACTIVE CARBON FILTER CARE
1
2
3
4
5
6
Reinstall the filters as shown on
Page E-8,9.
CAUTION
CAUTION
•Some carbon may adhere to the
towel, but it is harmless.
•It is not allowed to wring out the
filter.
The filter will be saturated
with water after rinsing. To
decrease drying time, wrap
the filter in an old thick towel
so that excess water can be
removed.
Remove excess water.
If rinsing in a container, be sure to rinse 3 to 4 times
so that the odour is rinsed thoroughly from the filter.
Rinse thoroughly
with clean water.
Handle with care to prevent damage
to the activated carbon particles.
CAUTION
If the filter surface is very
dirty, scrub with an old
toothbrush.
Allow the filter to soak approximately
10 minutes before washing.
Dilute as indicated on
the detergent container.
Fill a large container with warm
water, add a mild kitchen
detergent and stir.
HAND WASH ONLY!
DO NOT TUMBLE DRY!
Dry the filter outdoors if pos-
sible in a well ventilated
area.
CAUTION
• The wet filter is heavy. Fix it securely for
drying to make sure it does not fall down.
• The filter takes longer to dry in winter,
on rainy days. Wash it on a day when
the weather is good and dry it in the sun.
Move it indoors at night to prevent freez-
ing.
• Dry the filter outdoors in a well ventilated
area. If dried indoors, the water dripping
off the filter may soil your floor.
• Make sure that the activated carbon has
not shifted to one side inside the filter. If
it has, distribute it evenly with your fin-
gers.
• Let the filter dry thoroughly.
If used while the filter is still moist, then
the air that is exhausted from the main
unit will have an odour. It may take 1 or
2 days to dry.
Reinstalling the Filters.
Active Carbon Filter
(The illustration has used “KC-6500E” )
Care Cycle
2 months
Towel

E-16
CARE AND MAINTENANCE
MIST TRAY
The frequency of maintenance (descaling) will depend on the hardness of the water that
you use; the harder the water the more often descaling will be necessary.
Remove the Tank and MIST
Tray.
1
2
3
Wash inside the tray with water
to remove impurities.
• Do not remove the
float (Styrofoam).
• Clean difficult-to-
reach parts with a
cotton-tipped swab
or tooth brush.
Care Cycle 1 month
• The Tank is removed first, and the tray
is removed.
• Use both hands to pull out the MIST
Tray to avoid spilling of water.
Remove the Tank and MIST
Filter from the MIST Tray and
drain the water by tilting the
MIST Tray slowly.
1
Dilute as indicated
on the detergent
container.
2
CAUTION
MIST Tray
MIST Filter
Tank
Tank Handle
MIST Tray
Float
When Float comes off, please insert the
tabs of the Float into the holes of Mist Tray
as shown in the right diagram.
When Water Deposits are Difficult to Remove
• Be sure that no gaps are left between the
tray and the main unit when you load the
tray. The unit may not operate if the tray is
not securely fitted.
• Use only designated alkaline and acidic
cleansers. Using non-designated cleansers
can cause deformation, tarnishing,
cracking (water leakage).
Insert the float below
this protrusion.
Insert the tab on the
other side of the float
into the hole.
Insert the tab of the
float into the hole.
Fill MIST tray with warm water,
add a mild kitchen detergent
and stir.
Clean difficult-to-
reach parts with a
cotton swab or
tooth brush.
Rinse the MIST tray with water.
•Change the water and repeat this
procedure 2-3 times.
• Use clean water each time.
• Inadequate rinsing may
cause the detergent
odour or changes
in the shape/ colour
of the main unit.

ENGLISH
E-17
Remove the MIST Filter from the MIST
Tray.
• Be careful of the water drops that may fall.
MIST FILTER
The frequency of maintenance (descaling) will depend on the hardness or the impurities
of the water that you use; the harder the water the more often descaling will be necessary.
4
5
1
6
Preparing the descaling
solution.
Citric acid, available at some drugstores, or
100% bottled lemon juice are used for
descaling. Choose either one to use, and
prepare the descaling solution.
<For using citric acid>
Dissolve 3 teaspoons of citric acid and 600 ml of
luke-warm water in a suitable container, and stir well.
<For using lemon juice>
Use only bottled 100% lemon juice with no pulp
(please check before using and strain through a fine
strainer there seems to be some pulp). Pour 50 ml
of lemon juice and 600 ml of luke-warm water in a
suitable container, and stir well.
2
Presoak the mist filter in the
solution prior to cleaning.
When using lemon juice,
it is recommended to
presoak longer than
citric acid.
Rinse the MIST Filter with
water.
• Change the water and
repeat this procedure 2-
3 times.
• Use clean water each
time.
• Inadequate rinsing may
cause citric acid odour
or changes in the
shape/colour of the
main unit.
3
Attach the MIST Filter to the
MIST Tray.
Plug in the product and
press the MIST Filter Reset
Button on the main unit.
• The Mist Filter Indicator Light turns ON to remind you when it is
time to clean the MIST Filter.
• The Indicator Light will turn ON after approximately 1 month of
all-day, 24-hour use in Humidify Mode.
• Please clean the MIST Filter.
You will notice reddish-brown or
white deposits forming on the surface
of the MIST Filter. These impurities
(calcium, etc.) are due to the
impurities contained in tap water; this
is not a defect. Replace the MIST
Filter when it is covered completely
in white deposits.
• The MIST Filter does not need to
be oriented in any particular
position (forward/backward, up/
down)
• When not using the device for a
prolonged period of time, be sure
to dry the MIST Filter completely
before installing.
MIST Filter Indicator Light
* Do not wash the MIST Filter vigorously.
The Mist Filter might be damaged.
Care Cycle 1 month
The MIST Filter Indicator Light turns on.

E-18
CARE AND MAINTENANCE
FILTER REPLACEMENT GUIDELINES
The replacement period differs depending on the room environment, the usage hours
and location of the unit.
If dust or odours persists, replace the filters.
(Refer to “Please read before operating your new Air Purifier”)
HEPA Filter / Active Carbon Filter
Up to 5 years after opening
Guide for filter replacement timing
• Filter life can be greatly reduced in poor environments.
The presence of cigarette smoke, pet dander and other concentrations of airborne particles
will cause filters to become clogged in less time. Please check filters regularly and replace
as needed.
Replacement Filters
Part code PFIL-A134KKEZ(for KC-6500E)
• HEPA Filter : 1 unit
Part code PFIL-A148KKEZ(for KC-6500E)
• Active Carbon Filter : 1 unit
Part code PFIL-A139KKEZ(for KC-6400E)
• HEPA Filter : 1 unit
MIST Filter
REPLACING THE FILTERS
1. See page E-8,9 for directions on how to install the filters when replacing.
2. Fill in the usage start date of the filters on the Date Label.
Disposal of Filters
Please dispose of replaced filters according to the local disposal laws and regulations.
HEPA Filter materials:
• Filter: Polypropylene • Frame: Polyester
Active Carbon Filter Materials:
• Deodorizer: Activated charcoal • Net: Polypropylene 60%, Polyester 40%
Up to 1 year after opening
Guide for filter replacement timing.
• The Mist Filter life can be greatly reduced in poor environments.
Please exchange the Mist Filter, even if within 1 year after opening, if the following conditions
appear:
•Mineral deposits (white, black, or red masses) do not come off after cleaning or the Mist
Filter is still dirty.
•Severe damage or change of shape has resulted.
Replacement Filter
Part code PFIL-A135KKEZ(for KC-6500E)
• MIST Filter : 1 unit
Part code PFIL-A140KKEZ(for KC-6400E)
• MIST Filter : 1 unit
REPLACING THE FILTER
1. See page E-17 for directions on how to install the filters when replacing.
2. Fill in the usage start date of the filters on the Date Label.
Disposal of Filter
Please dispose of replaced filters according to the local disposal laws and regulations.
MIST Filter materials:
• Rayon , Polyester
Part code PFIL-A147KKEZ(for KC-6400E)
• Active Carbon Filter : 1 unit
