Sharp DW-J27FA User manual

Device of this mark is a trademark of Sharp Corporation.
“Plasmacluster” and “Device of a cluster of grapes” are
trademarks of Sharp Corporation.
DW-J27FA
DW-J20FA AIR PURIFYING DEHUMIDIFIER
OPERATION MANUAL
空氣淨化抽濕機
使用說明書
ENGLISH
中文
* The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm3, which
is measured around the center of a room with the “high-
density plasmacluster 7000” applicable floor area (at 1.2
m height above the floor) when the product is placed close
to a wall at the LAUNDRY Operation “DEODORIZE mode
setting.
DW-J27FAJ20FAEN.indd1 2018/08/3115:36:35

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .........................................................2
PART NAMES..................................................................................................4
PREPARATION................................................................................................6
OPERATION
START/STOP ...............................................................................................6
DEHUMIDIFY OPERATION .........................................................................7
HUMIDITY SELECT.....................................................................................7
LAUNDRY OPERATION .............................................................................7
AIR PURIFY OPERATION ...........................................................................7
MOLD CONTROL OPERATION ..................................................................8
TIMER OPERATION ....................................................................................8
SWING LOUVER .........................................................................................9
INTERNAL DRY OPERATION .....................................................................9
CHILD LOCK................................................................................................9
SELECTING DISPLAY .................................................................................9
HOW TO CHANGE VARIOUS SETTING....................................................10
HOW TO DRAIN .............................................................................................11
CARE AND MAINTENANCE..........................................................................12
TROUBLESHOOTING....................................................................................15
SPECIFICATIONS...........................................................................................16
Thank you for purchasing this SHARP Air Purifying Dehumidifier.
Please read this manual carefully before using the product.
This manual should be kept in a safe place for handy reference.
ENGLISH
Dehumidify
In accordance with the principle of generating water droplets
when warm air with much moisture gets contact with cold
items, wet air is blown in a evaporator to remove moisture.
In the following cases, the compressor will stop and will not
dehumidify.
• When the room temperature is lower than 4°C or higher than 38°C.
• The 3 minutes when the Main Unit operated again in the following
to protect the Main Unit.
* Immediately after the power plug is inserted.
* Immediately after the Laundry Drying/
Dehumidifying operation is stopped.
• When the room temperature falls below 18°C, the compressor will
stop and “HIGH” air flow mode will operate for about 12 minutes once every 45 minutes to prevent
frost damage inside the Main Unit. (DEFROST mode / The DEFROST Indicator Light is turned on. )
Air Purify
The Air Purifying Dehumidifier draws in room air through the air intake, circulates it through a Pre-Filter, a Active
Carbon Deodorizing Filter and a HEPA Filter inside the Main Unit, and then discharges it through the air outlet.
The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that pass through the filter and also
helps absorb odors.The Active Carbon Deodorizing Filter gradually absorbs odors as they pass through the filter.
Some odors absorbed by the filters will break down over time, causing additional odors. Depending on
usage conditions, and especially if the Main Unit is used in environments significantly more severe than
a normal household, these odors may become noticeable sooner than expected. If these odors persist,
replace the filters.
①
④
②
③
Dry air
Damp air
Water Tank
Evaporator
Condenser
DW-J27FAJ20FAEN.indd2 2018/08/3115:37:19

EN-1
ENGLISH
A powerful Dehumidifier with a High Concentration of
Plasmacluster Ions, a high performance HEPA filter, and
a active carbon deodorizing filter for Room Air Purifying,
Laundry Deodorizing, Quick Drying, and Dehumidifying.
MOLD CONTROL OPERATION
It prevents the propagation of the mold by releasing Plasmacluster and dehumidified air into the room.
￥
LAUNDRY Drying
Wide angle louver swings to both top and bottom / left and right wards and provides wide-area air flow.
AIR PURIFYING
It collects toxic substances such as dust, pollen, airborne mold, unpleasant odor and purify the air through SHARP’s
triple filters (HEPA Filter, Active Carbon Deodorizing Filter and Pre-filter)
PM2.5 Monitor
It shows the approximate amount of PM2.5 by changing the color on the indicator and numbers on the monitor.
Large Tank 4.6L
It realizes continuous dehumidification.
g
￥
￥
12 3
Circulate Room Air
With High Air Volume Dehumidification Air Purification
Air Purify in
fewer than 50%
of humidity
Dehumidify in
more than 60%
DW-J27FAJ20FAEN.inddEN-1 2018/08/3115:37:20

EN-2
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions
when using electrical appliances, including
the following:
WARNING – Always observe the following
to reduce the risk of electrical shock, fire, or
injury:
• Read all instructions before using the Main
Unit.
• Use only a 220-240 volt outlet.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety. Children
should be supervised to ensure they do
not play with the appliance.
• If the power cord is damaged, it must be
replaced by the manufacturer, its service
agent, a Sharp authorized Service
Center or similarly qualified persons in
order to avoid a hazard.
• Be sure to remove the power plug when
draining the water, before performing
maintenance, when removing and
attaching and replacing the filter and
when not using for a long time. Failure
to do so can cause a short circuit
resulting in electrical shock or fire.
• Do not use the Main Unit if the power cord
or plug is damaged or if the connection to
the wall outlet is loose.
• Periodically remove dust from the plug.
• Do not insert fingers or foreign objects into
the air intake or air outlet.
• When removing the power plug, always
hold the plug and never pull on the cord.
Failure to do so can cause a short circuit
resulting in electrical shock or fire.
• When removing the Main Unit, do not
damage the power cord with the casters.
Failure to do so can cause electric shock,
heat generation, or fire.
• Be careful not to damage the power cord,
it may cause electric shock, excess heat or
fires.
• Do not remove the plug when your hands
are wet.
• Do not place the Main Unit near gas
appliances or fireplaces.
• Only a Sharp Authorized Service
Center should service this air purifying
dehumidifier. Contact the nearest Service
Center for any problems, adjustments, or
repairs.
• Do not operate the Main Unit in rooms
where aerosol insecticides are present. Do
not operate the Main Unit in rooms where
there is oily residue, incense, sparks from
lit cigarettes, or chemical fumes in the air.
Do not operate the Main Unit in places
where it may get wet, such as a bathroom.
• Be cautious when cleaning the Main Unit.
Strong corrosive cleansers can damage the
exterior.
• When carrying the Main Unit, first remove
the Water Tank, and then hold the Main
Unit by the handles on both sides.
• Do not drink the water in the Water Tank.
• Do not expose the Main Unit to water.
Doing so can cause a short circuit or
electrical shock.
• Clean the Water Tank regularly. When the
Main Unit is not in use, dispose of the water
in the Water Tank. Leaving water in the
Water Tank can cause mold, bacteria, and
bad odors. In rare cases, such bacteria can
be a health hazard.
• Check for bent hose/falling height when
you want to drain continuous, and place the
hose where it will securely drain.
• Keep the temperature around the hose
above freezing point when using the hose.
Inner water may leak in the room and
dampen the furniture or may cause electric
shock/leakage, fire.
NOTE - What to do if the Main Unit interferes
with radio or TV reception.
If the Air Purifying Dehumidifier interferes with
radio or television reception, try one or more
of the following measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the Main
Unit and the radio or TV.
• Connect the equipment into an outlet on a
circuit different from that of the radio or TV
receiver.
• Consult the dealer or a qualified radio or
TV technician.
DW-J27FAJ20FAEN.inddEN-2 2018/08/3115:37:21

EN-3
ENGLISH
CAUTIONS CONCERNING
OPERATION
• Do not block the air intake or air outlet.
• Do not place the Main Unit near or on
hot objects, such as stoves or heaters, or
where it may come into contact with steam.
• Always operate the Main Unit in an upright
position.
• When moving the Main Unit, use the
handles on both sides. Do not move the
Main Unit when it is in operation.
• If the Main Unit is on easily damaged
flooring, an uneven surface, or thick-piled
carpet, lift it up when moving.
• When moving the Main Unit by its casters,
move it slowly and in a horizontal direction.
• Turn the Main Unit off and remove the
Water Tank before moving, take care not to
catch your fingers.
• Do not operate the Main Unit without the
filters and the Water Tank properly installed.
• Do not wash and reuse the HEPA filter and
the Active Carbon Deodorizing Filter. Doing
so will not improve filter performance and
can also cause electric shock or operating
malfunctions.
• Clean the exterior with a soft cloth only.
Do not use volatile fluids or detergents.
The Main Unit surface may be damaged
or cracked with Benzene paint thinner or
polishing powder. In addition, the sensors
may malfunction as a result.
• Keep the Main Unit away from water.
• Be sure to wipe off any excess water on the
outside of the Water Tank.
• Do not shake the Water Tank with holding
the carrying handle.
• Avoid spilling water when removing or
cleaning the Water Tank.
• Do not remove the Float.
• Do not use the detergents for maintenance
of the Water Tank and Tank Cover. If cause
deformation, tarnishing, cracking (water
leakage).
• Do not scrub the Back Panel hard during its
maintenance.
INSTALLATION GUIDELINES
• Avoid locations where the sensors are
exposed to direct wind. Doing so can cause
the Main Unit to malfunction.
• Avoid locations where furniture, fabrics, or
other objects can come in contact with the
Main Unit and interfere with the intake and
outtake of air.
• Avoid locations where the Main Unit
is exposed to condensation or drastic
changes in temperature. Appropriate room
temperature is between 4 - 38°C.
• Place the Main Unit on a level and stable
surface with sufficient air circulation. When
placed on heavy carpet, the Main Unit may
vibrate slightly. Place the Main Unit on a
level surface to avoid water leakage from
the Water Tank.
• Avoid locations that generate grease or
oily smoke. Doing so can cause the Main
Unit exterior to crack and the sensors to
malfunction.
• The dust collecting ability of the Main Unit
is effective even when the Main Unit is as
close to 3 cm from the wall,the surrounding
walls and floor may get dirty. Please place
the Main Unit at a distance from the wall.
The wall directly behind the air outlet may
become dirty over time. When using the
Main Unit for an extended period of time
at the same location, periodically clean the
walls adjacent to it.
FILTER GUIDELINES
• Follow the instructions in this manual for
proper filter care and maintenance.
DW-J27FAJ20FAEN.inddEN-3 2018/08/3115:37:21

EN-4
MAIN UNIT
PART NAMES
1
3
4
5
6
7
15
16
17
20
21
22
24
23
18
19
1Operation Panel 13 Water Level Window
2Air Outlet 14 Tank Knob
3Vertical Louver 15 HEPA Filter
4Horizontal Louver 16 Active Carbon Deodorizing Filter
5Main Unit 17 Back Panel (Pre-Filter)
6Handle (2 Locations) 18 Air Inlet
7Front Display 19 Odor Sensor
8Water Tank 20 Temperature/Humidity Sensor
9Drain Outlet 21 Dust Sensitive Sensor, Sensor Filter
10 Float 22 Drainage Hole, Rubber Cap
11 Tank Handle 23 Caster (4 Locations)
12 Tank Cover 24 Power Cord, Plug
2
8
9
10
11
12
13
14
(FRONT)
(BACK)
DW-J27FAJ20FAEN.inddEN-4 2018/08/3115:37:21

EN-5
ENGLISH
OPERATION PANEL
FRONT DISPLAY
1Power ON/OFF Button 8H.SWING Button, Indicator Light
2MOLD CONTROL Button, Indicator Light 9ON/OFF TIMER Button
3AIR PURIFY Button, Indicator Light 10 FILTER RESET Indicator Light
4LAUNDRY Button, Indicator Light 11 INTERNAL DRY Indicator Light
5DEHUMIDIFY Button, Indicator Light 12 Child-Lock Indicator Light
6HUMIDITY SELECT Button 13 Light Sensor
7V.SWING Button, Indicator Light
1
Humidity / Temperature / PM2.5 Monitor
Indicates the approximate humidity level or
temperature or PM2.5 level in the room.
Timer Monitor
Indicates setting time or remaining time of ON/
OFF timer.
HUMIDITY SELECT Monitor
Indicates setting humidity of HUMIDITY
SELECT mode.
6Odor Indicator Light
Indicates the Odor Sensor detects odors.
OFF Orange Red
Clean Impure
7
Dust Indicator Light
Indicates the Dust(sensitive) Sensor detects
usual dust.
OFF Orange Red
Clean Impure
8
PM2.5 Indicator Light
Indicates the Dust(sensitive) Sensor detects
microscopic dust.
OFF Orange Red
Clean Impure
9DEFROST Indicator Light
Indicates the Main Unit operates the
DEFROST mode.
10
Cleanliness Monitor
Indicates the air purity of the room in 3 levels
with color changes.
Blue Yellow Red
Clean Impure
When mold control mode
It will indicate with Purple.
2Plasmacluster Ion Indicator Light (Blue)
3OFF Timer Indicator Light
4ON Timer Indicator Light
5Tank FULL Indicator Light (Red)
Blinking when the Water Tank is Full.
16910 23457
13 12 11
8
12345678
910
Humidity 20% to 90% is displayed.
Temperature 0oC to
5 0oC is displayed.
PM2.5 Density 10μg/m3to
499 μg/m3is displayed.
20%
or less
90%
or more
50oC
or more
500μg/m3
or more
-1oC
or less
9μg/m3
or less
Press the button with " " to start.
DW-J27FAJ20FAEN.inddEN-5 2018/08/3115:37:24

EN-6
OPERATION
FILTER INSTALLATION
START / STOP
PREPARATION
♪♪〜
START STOP
AUTO OFF Function
The operation will stop automatically after 12
hours in case the Main Unit has been forgotten
to be turned off.
When you want to run the Main Unit for more
than 12 hours continuously or drain water
continuously, turn off the Auto Off function.
(page 10)
The operation is not stopped while operating with
"Air purification operation" and "Deodorization
operation".
1. Remove the Back Panel.
Back Panel
2. Remove the plastic bag from the
each filter.
HEPA Filter Active Carbon Deodorizing Filter
3. Install the filters in the correct order as
shown.
HEPA Filter
Active Carbon Deodorizing Filter
Tag
4. Install the Back Panel.
Click
DW-J27FAJ20FAEN.inddEN-6 2018/08/3115:37:26

EN-7
ENGLISH
AUTO :
The humidity and the fan speed are automatically
controlled by the "temperature and humidity
sensor".
SELECT :
You can select your favorite humidity. (See below)
When you press the DEFUMIDIFY button to set
SELECT mode, target humidity level can be
changed to cycle among 60%, 70%, 80%, 40% and
50%RH in seguence.
* HUMIDITY SELECT can be works only when in
SELECT mode.
OPERATION
DEHUMIDIFY OPERATION
HUMIDITY SELECT
♪
♪
♪
♪♪
Temperature 4-26oC 26-38oC
Humidity 60% 55%
♪♪ ♪ ♪
♪♪
AUTO :
When you want to dry with less power
consumption, the Main Unit will repeat the
Dehumidifying operation and the Air Flow mode
to dry the laundry.
DEODORIZE :
When you want to deodorize your laundry, the
Main Unit operates at "HIGH" fan speed.
Make sure the air blowing out from air outlet is
directed to your laundry.
It operates automatically the Plasmacluster Ion
“ON”.
AUTO :
The fan speed is automatically changed according
to amount of impurities in the air.
SLEEP :
The Main Unit will operate very quietly, and the
fan speed is automatically changed depending on
amount of impurities in the air.
The light of Front Monitor gets off automatically.
LAUNDRY OPERATION
AIR PURIFY OPERATION
♪
♪
♪
♪♪
♪
♪
♪
♪♪
DW-J27FAJ20FAEN.inddEN-7 2018/08/3115:37:30

EN-8
OPERATION TIMER OPERATION
The Main Unit automatically starts once the
selected time passes.
The Main Unit automatically stops once the
selected time comes.
ON TIMER
OFF TIMER
(with the Main Unit OFF)
(with the Main Unit ON)
Front Display
Front Display
……
♪ ♪ ♪ ♪ ♪♪
1hour 2hour 3hour 12hour Cancel
……
♪ ♪ ♪ ♪ ♪♪
1hour 2hour 3hour 12hour Cancel
MOLD CONTROL OPERATION
【for about 80 minutes】
(Cleanliness Monitor: blinking with Purple)
※Operating time depends on the room environment,
usage conditions, and location of the Main Unit.
NOTE
• When the air in the room is purified and the humidity
becomes low, the main unit operates with “Low” air
flow. (
Cleanliness Monitor : lighting in Blue)
• If the humidity becomes high again, it will switch to
the above operation under the condition of “in a high
humidity”.
In a low humidity
In a high humidity
It operates in “HIGH” mode of dehumidification
until the humidity of the room decreases to
the level which the mold less likely appears.
Once the humidity in room becomes low, the
model switches the operation with maximum
airflow.
This mode is used to suppress the mold through
strong air flow with Plasmacluster Ion.
When turned ON, it firstly starts ventilation for 10
minutes with maximum air flow, and then repeats
following operation.
(Cleanliness monitor shows actual operating mode.
Purple: high air volume, Blue: low air volume.)
It operates automatically the Plasmacluster Ion
“ON”.
After 8 seconds, the beep sounds.
After 8 seconds, the beep sounds.
DW-J27FAJ20FAEN.inddEN-8 2018/08/3115:37:34

EN-9
ENGLISH
CHILD LOCK
SELECTING DISPLAY
SWING LOUVER INTERNAL DRY OPERATION
When you set the Internal Dry operation, the Main
Unit automatically operate the Air Flow mode it for
approximate 90 minutes after stopping.
The operation of the operation panel will be locked.
more 3 sec.
more 3 sec.
more 3 sec.
more 3 sec.
VERTICAL SWING
DRY, DEODORIZE AIR PURIFY, DEHUMIDIFY
WIDE
UP
DOWN
♪
♪
♪
♪♪
♪
♪
♪
♪♪
DRY, DEODORIZE AIR PURIFY, DEHUMIDIFY
ROUND
WIDE
SPOT
♪♪〜
ON CANCELLATION
♪ ♪
♪♪
Humidity Temperature PM2.5
CANCEL(OFF)
CANCEL(OFF)
HORIZONTAL SWING
After 8 seconds, the beep sounds.
(with the Main Unit ON)
(with the Main Unit ON)
DW-J27FAJ20FAEN.inddEN-9 2018/08/3115:37:38

EN-10
OPERATION
HOW TO CHANGE VARIOUS SETTING
Type of setting
Function Setting
Auto Restart
If the Main Unit is
unplugged or if there is a
power failure, the Main Unit
will resume operation with
the previous settings after
power is restored.
Cancellation
ON (default)
Sound Indicator Setting
You can turn off the beeping
sound when the Main Unit
stops perating as follows.
When the Main Unit stops
operating as the following
situation, you can turn off
the beeping sound.
Cancellation
ON(default)
Light Control
You can select the
brightness of the Front
Display.
Turn off
When set to “Turn off”, the
“Darker” light illuminates for 8
seconds after operation starts
and then the light turns off.
The FULL Light flashes darker
only when the Water Tank is full.
Darker
Auto (default)
Light automatically switches
based on room brightness.
Room Front Display
bright brighter
dark darker
* When "SLEEP" mode operate;
Room is bright : light is darker
Room is dark : light is OFF
PLASMACLUSTER ION
ON/OFF
OFF
ON (default)
Auto Off
The operation will stop
automatically after 12 hours in
case the Main Unit has been
forgotten to be turned off.
Cancellation
ON (default)
Adjusting Sensor Sensitivity (F6-F8)
Light Sensor Low
Dust(sensitive)
Sensor Standard (default)
Odor Sensor High
* Light Sensor : Default is "Middle".
Dust(sensitive) and Odor Sensor : Default is "High".
You can change the functions in the table "Type of setting".
1. Turn off the Main Unit power.
2.
more 3 sec.
♪
3. Select "Function number".
Forward Reverse
or
････
Set ♪
4. Select "Setting number".
Forward Reverse
or
Set ♪
5. Press Power ON/OFF Button to
finish the setting mode.
♪〜
Turn off
♪
♪
♪
♪
DW-J27FAJ20FAEN.inddEN-10 2018/08/3115:37:52

EN-11
ENGLISH
1. Remove the Plug.
2. Remove the Water Tank and the
Rubber Cap.
Rubber Cap
3. Set the hose in the Back Hole.
Back Hole
Commercial hose :
inner diameter 15mm
(outer diameter up to
21mm)
4. Insert the hose firmly to bottom in the
Drain Hole.
HoseDrain OutletDrain Stopper
Back Hole
5. Install the Water Tank.
When you want to drain continuous
HOW TO DRAIN
How to pipe the hose
♪♪･･･
When the Water Tank
is Full, the TANK FULL
Indicator Light is blinking.
Always have the tip slanted.
Do not bend.
Under cold weather,
do not put the hose
into the water.
1. Remove the Water Tank.
Tank knob
Water Tank
2. Dispose the water of the Water Tank.
▶
Drain Outlet
3. Install the Water Tank.
Drain Outlet
NOTE
• Clean the Water Tank about once a week. If you
do not clean the Water Tank, it can cause mold,
bacteria, and bad odors.
DW-J27FAJ20FAEN.inddEN-11 2018/08/3115:38:01

EN-12
NOTE How to clean and remove a heavy dirt.
Back Panel
1.Add a small amount of neutral
detergent to water and soak for
about 10 minutes.
CAUTION
Do not give excessive pressure to
the back panel when scrubbing it.
2.Rinse off the neutral detergent with
clean water.
3.Completely dry the filter in a well-
ventilated area.
Sensor Filter
1.Remove the Back Panel.
2.Remove the sensor filter.
3.If the sensor filter is very dirty, wash
it with water and dry it thoroughly.
WATER TANK (About once a week) BACK PANEL / SENSOR
(About once every 2 weeks)
MAIN UNIT (About once a month)
CARE AND MAINTENANCE
Remove the dust
gently with a
cleaning tool such
as a vacuum cleaner.
Wipe with a dry, soft cloth.
Do not wash with water.
1. Remove the Tank Cover, and dispose
of the water.
▶
Tank Cover
2. Wash the inside of the Water Tank.
NOTE
• If the dirt is heavy, please dissolve neutral
detergent in lukewarm water and wash.
3. Dry the tank with a soft cloth.
Check the float.
4. Install the Tank Cover.
Sensor Filter
DW-J27FAJ20FAEN.inddEN-12 2018/08/3115:38:07

EN-13
ENGLISH
HEPA FILTER / Active
Carbon Deodorizing Filter
(About once a month)
LIFE OF FILTERS
Filter life varies depending on the room environment,
usage conditions, and location of the Main Unit.
Lifespan of HEPA filter and Active Carbon
Deodorizing Filter and replacement suggestions are
based on purifying a room in which 5 cigarettes are
smoked per day and the Main Unit's dust collection
and deodorizing performance has declined to half
the level of a new filter.
We recommend replacing the filter more frequently if
the Main Unit is used in conditions significantly more
severe (PM2.5 etc.,) than a normal household.
•HEPA Filter
About 10 years after opening
•Active Carbon Deodorizing Filter
About 10 years after opening
Replacement Filter Model
Consult your dealer when purchasing a replacement
filter.
HEPA Filter(1 unit)
FZ-J20HFE
Active Carbon Deodorizing Filter(1 unit)
FZ-J20DFE
Disposing of filters
Dispose of used filters according to local laws and
regulations.
HEPA Filter material:
• Polypropylene
• Polyethylene
Active Carbon Deodorizing Filter material:
• Polypropylene
• Polyethylene
• Activated carbon
FILTER REPLACEMENT
The FILTER RESET Indicator light will turn on after
approximately 720 hours operating. (30 days × 24 hours
=720 hours)
This is a reminder to perform the maintenance described
below. After performing maintenance, reset the FILTER
RESET Indicator.
FILTER INDICATOR
RESET
more 3 sec.
♪
Remove the dust on the HEPA Filter and
Active Carbon Deodorizing Filter.
CAUTION
Do not wash the filters. Do not expose to sunlight.
(Otherwise these filters may lose efficacy.)
HEPA FILTER Clean only the tagged
surface. Do not clean up the
opposite surface. The filter is
fragile, so be careful not to
give too much pressure.
Active Carbon Deodorizing Filter
Both surfaces can be
cleaned.
The filter may be broken if
being too much pressure is
applied on it, so please
handle it with care.
Some odors absorbed by the filters will break down over time,
causing additional odors. Depending on usage conditions,
and especially if the Main Unit is used in environments
significantly more severe than a normal household, these
odors may become noticeable sooner than expected.
Replace the filter in those cases or if dust is unable to be
removed after maintenance.
Tag
DW-J27FAJ20FAEN.inddEN-13 2018/08/3115:38:12

EN-14
When storing for a long period (not in use)
CARE AND MAINTENANCE
1. Operate the INTERNAL DRY
OPERATION.
①Start operation.
②Select the Internal
Dry Operation.
③Stop Operation.
*Start the Internal Dry Operation, and
stop automatically after approximate 90
minutes.
2. Dispose tank water and care the Main
Unit.
3. Store in a dry place away from direct
sunlight.
Plastic bag
♪
more 3 sec.
♪〜
DW-J27FAJ20FAEN.inddEN-14 2018/08/3115:38:17

EN-15
ENGLISH
ERROR DISPLAY
TROUBLESHOOTING
Before contact for service, check the following points to make sure that the problem is not a Main Unit malfunction.
If error occurs repeatedly, contact the Sharp Service
Center.
The room becomes hot.
• The Main Unit generates heat during LAUNDRY DRY
operation and DEHUMIDIFY operation and the room
temperature will rise. Warm air will be come out from
the air outlet, but this is normal and does not indicate
a problem with the Main Unit.
The Main Unit does not dehumidify.
• The performance of dehumidification level varies with
the size, structure, temperature and humidity level of
the room. When room temperature or humidity level
is low, the performance will become low in general.
• Check whether the Back Panel is clean.
• Check whether the air outlet or air inlet is not
blocked.
Sounds
• The Main Unit may make clicking or ticking sounds
when it is generating ions.
• The Main Unit may seem rather loud for the first 2 to
3 minutes when the Main Unit is turned on. This is the
sound of the compressor starting-up and is perfectly
normal.
• A soft, swishing noise can be heard immediately after
the Main Unit is turned on or off, and also during
operation. This is the sound of the refrigerant flowing
inside the Main Unit.
The sound is too loud.
• The Main Unit will sound loudly for the first few seconds
upon power-on when the room temperature is low.
• Check whether the Main Unit is placed on a stable
and level floor.
• Check whether the Back Panel is not clogged.
Odor and smoke persists.
Air discharged from the Main Unit has an
odor.
• Check whether the filters are extremely dirty.
• Clean or replace the filters.
The Cleanliness Monitor light is not
blue even when the air is clean.
• Dirty or clogged dust(sensitive) sensor openings
interfere with sensor operation. Gently clean the
sensor filter or the back panel.
• When the Main Unit is operating MOLD CONTROL
operation, the light indicates the operation mode of
the MOLD CONTROL operation.
The Main Unit does not operate when
cigarette smoke is in the air.
• Make sure the Main Unit is installed in a location in
which the sensors can detect cigarette smoke.
• Check whether the dust(sensitive) sensor openings
are blocked or clogged. If they are blocked or
clogged, clean the sensor filter or the back panel.
The FILTER RESET Indicator Light is on.
• Whenever after performing maintenance or replacing
the filters, connect the power cord to an outlet and
then press the ON/OFF Timer Button. (page 13)
There is a discrepancy between the
Main Unit’s Humidity Monitor and
another hygrometer in the room.
• There is a difference in the humidity level within the
same room.
• The sensor have different measurement parameters.
• If the monitor indicates temperature or PM2.5 level,
switch the display by pressing the DISPLAY SELECT
button. (page 9)
The Main Unit PM2.5 monitor does
not match weather report or other
local PM2.5 data.
• Ambient / Indoor air condition or home environment
vary in each place. This may cause the discrepancy
of each reported number. Please take note PM2.5
monitor shows reference numbers.
The water leaks.
• Check whether the main unit is placed horizontally.
• When draining continuous, check whether the hose is
inserted all the way seated.
• If the Water Tank is full, drain
the water.
• If the Water Tank is not
properly placed, place the
Water Tank correctly.
• The Main Unit is operating
with the DEFROST mode.
• Laundry DRY (Auto)
operation has completed, and
the operation has stopped.
• The operation has stopped
with the Auto Off function.
 

• Unplug the Main Unit, wait
one minute, and then plug
the Main Unit in again.
DW-J27FAJ20FAEN.inddEN-15 2018/08/3115:38:21

EN-16
SPECIFICATIONS
Model DW-J27FA DW-J20FA
Power Supply 220V-240V/50Hz
Dehumidifying Capacity ※130°C/80%RH 27 L/day 20 L/day
26.7°C/60%RH 16 L/day 12.5 L/day
Power Consumption ※230°C/80%RH 420 W 340 W
26.7°C/60%RH 345 W 260 W
Standby Power ※30.9 W 0.9 W
Recommended Room Size for Dehumidifying ※433-67 m226-52 m2
Water Tank Capacity Approx. 4.6 L
Cord Length Approx. 2 m
Dimensions 359 mm(W) × 303 mm(D) ×
665 mm(H)
359 mm(W) × 301 mm(D) ×
665 mm(H)
Weight 17.8 kg 16.7 kg
Model DW-J27FA DW-J20FA
Recommended Room Size for Air Purifying ※432 m228 m2
Recommended Room Size for High density
Plasmacluster ion ※533 m223 m2
Fan Speed Adjustment LOW HIGH LOW HIGH
Fan Speed 90 m3/h 306 m3/h 90 m3/h 258 m3/h
Rated Power 7.3 W 67 W 7.3 W 50 W
Noise Level 29 dB 53 dB 29 dB 51 dB
Dehumidifying Specifications
Air Purifying Specifications
※1 The amount of humidity that a dehumidifier removes from the air in a day when room temperature and relative humidity are
kept at 30°C/80%RH and 26.7°C/60%RH respectively.
※2 The consumption value when fan speed reaches the highest.
※3 When the Main Unit’s power plug is inserted in a wall outlet it consumes the standby power in order to operate electrical
circuits.
※4 Based on standards of JEMA.
※5 Recommended Room Size for High density Plasmacluster ion in which approximately 7000 ions per cubic centimeter can
be measured in the center of the room when the Main Unit is placed next to a wall, is running at LAUNDRY Operation
"DEODORIZE" mode settings, and is at a height of approximately 1.2 meters from the floor.
DW-J27FAJ20FAEN.inddEN-16 2018/08/3115:38:26

ENGLISH
MEMO
DW-J27FAJ20FAEN.inddEN-17 2018/08/3115:38:27

安全注意事項.................................................................................................. 2頁
各部分名稱...................................................................................................... 4頁
使用前............................................................................................................. 6頁
操作方法
運行開始 /停止............................................................................................
7頁
除濕模式...................................................................................................... 7頁
濕度設定...................................................................................................... 7頁
乾衣除濕模式 .............................................................................................. 7頁
空氣淨化模式 .............................................................................................. 7頁
抑菌防霉模式 .............................................................................................. 8頁
定時開 /關機 ............................................................................................... 8頁
搖擺送風...................................................................................................... 9頁
內部除濕模式 .............................................................................................. 9頁
兒童安全鎖.................................................................................................. 9頁
濕度 /溫度 / PM 2.5 濃度偵測指示燈顯示切換............................................ 9頁
各種功能的變更設定................................................................................... 10 頁
排水方法 ........................................................................................................ 11 頁
保養與清潔..................................................................................................... 12 頁
故障時的檢查事項.......................................................................................... 15 頁
規格 ............................................................................................................... 16 頁
目錄
感謝您購買 SHARP 空氣淨化抽濕機。
在使用本產品之前，請先詳細閱讀本使用說明書。
在閱讀後，請妥善保存本使用說明書，以便於日後有需要時查閱。
除濕
根據高濕度的溫暖空氣接觸冰冷物品時會產生水滴的原理，
將潮濕空氣吸入蒸發器中，去除水分。
在下列情況中，壓縮機將會停止，且不會除濕。
• 室溫低於 4°C 或高於 38°C。
• 在下列情況中，主機會再次運行 3 分鐘，以保護主機。
* 插上電源插頭後立即運行。
* 在乾衣除濕／除濕模式停止後立即進行。
• 當室溫低於 18°C 時，壓縮機可能會停止，進行除霜模式，且每
45 分鐘，會運行約 12 分鐘「強」風量模式，以避免主機內部
受到結霜的傷害（除霜模式／除霜指示燈亮起）。
空氣淨化
空氣淨化抽濕機是經由吸氣口吸入室內空氣，然後空氣會通過主機內的前置過濾網、活性碳除臭過濾網和HEPA
集塵過濾網，從吹出口排出。
當空氣通過時，HEPA 集塵過濾網能去除高達 99.97% 之0.3 微米的大小灰塵粒子，同時能協助吸收異味。當異
味成分通過活性碳除臭過濾網時，會被逐步吸收。
過濾網吸收的一些異味會隨時間分解，而產生其他異味。根據使用狀況，特別是在氣味比普通家庭氣味強烈的環境
中使用主機時，這些異味可能會比預期更強烈。如果這些異味持續存在，請更換過濾網。
①
④
②
③
乾空氣
潮濕空氣
儲水箱
蒸發器
冷凝器
中文
DW-J27FAJ20FACN.indd2 2018/08/3115:39:17
