ULX 
Shure ULX Wireless
ULX System Components
All systems include either a ULXS4 Standard Diversity Receiver or ULXP4 Professional Diversity Receiver.
Bodypack systems include a choice of lavalier, headworn, or instrument microphones.
Handheld systems include a choice of interchangeable microphone heads.

Shure Incorporated
5/31
Guitarsystemsincludea1/4”tomini4-pincable.
ULXP4 receivers include rack-mounting hardware.

Shure Incorporated
6/31
•
•
•
Antennas
Active Antennas
TheantennaconnectorsontheULXreceiverprovide12VDCforactivecircuitantennas.
Caution: Use only Shure antenna accessories to ensure the best operation. Do not use splitters, combiners, or antennas that provide a DC ground, as this can
cause the receiver to function improperly.
Antenna Combiners and Accessories
The supplied antennas can be connected directly to the BNC-type ANTENNA connectors. However, optional antenna mounting
accessories from Shure can improve reception and reduce rack clutter. Use the following guidelines:
Antennas and receivers must be from the same band.
Mount antennas more than 40 cm (16 inches) apart.
Use Shure UA825 or UA850 low-loss coaxial antenna cable (or any 50 ohm, low-loss cable such as RG-8U).
Visit www.shure.com for more information on wireless antenna accessories.
Coaxial Cables

Shure Incorporated
7/31
Front Mount Antenna Kit
1/2-Wave Antenna included with ULXP4 systems
Inline Antenna Amplifier
for long antenna cable runs
Antenna Rack Mount Kit

Shure Incorporated
8/31
Active Directional Antenna
for more focused reception
Distribution Amplifier
combines antennas and power supplies for multiple receivers
Rack Installation

Shure Incorporated
9/31
Rackmount Options
The following shows rackmounting options for one to four receivers and lists the required accessories.
Power

Shure Incorporated
10/31
•
•
•
Power switch
Power Connector
ConnectusingthesuppliedACadapterorcertified14–18Vdc(550mA)replacementsupply.
Batteries
Installation
Battery Life
Use only 9V alkaline or lithium batteries. Typical life for common types of 9V batteries are listed below. For detailed information
on battery performance, contact Shure Applications Engineering.
Recommended:
Lithium (16 hours)
Alkaline (8 hours)
Not recommended:
Carbon-Zinc (½ hour)
