Shure 527B User manual

Model 527B User Guide
Dynamic Communications Microphone
©2013 Shure Incorporated
27C2083 (Rev. 7)
Printed in U.S.A.
GENERAL
The 527B microphone is an extremely reliable handheld
dynamic microphone with an extended low- and
high-frequency response particularly suited to ham radio
use, mobile FM transmission, and top-quality paging
systems. The microphone has a clear, crisp, and natural
voice response. It features small size, light weight, and
modular construction.
The modular construction of the 527B permits ease of field
serviceability. The design of the cartridge, switch, and cable
makes them easily replaceable. The microphone is wired to
prevent lead breakage or crimping.
The unit fits naturally and comfortably in the hand and is not
affected by heat or humidity. The exclusive ARMO-DUR®
case is immune to oil, grease, fumes, salt spray, sun, rust,
and corrosion and is outstanding in its ability to withstand
mechanical shocks and vibrations. The “Million-Cycle”
leaf-type switch is designed to withstand severe operating
conditions and constant usage.
INTERNAL CONNECTIONS
FIGURE 1
Features
• Extended low- and high-frequency response
• Highly intelligible voice response
• Unparalleled ruggedness and reliability
• Moving coil (dynamic) element
• ARMO-DUR case
• “Million-Cycle” leaf-type switch controlling microphone and
external relay or switching circuits
• Modular construction for easy field service
• “Lifetime” hang-up button and mounting bracket
• Long-life neoprene-jacketed coil cord
APPLICATIONS
The 527B microphone is highly recommended for all types
of mobile communications, ham radios, industrial and
commercial paging systems, and outdoor public address
systems. The 527B is a low-impedance microphone and is
recommended where long cable lengths are required.
INSTALLATION
A quick release mounting bracket for permanent installation
is supplied with each microphone. The bracket has
mounting holes with clearance for No. 6 or No. 8 screws
(see Figure 4).
CONNECTIONS
The internal switch connections of the 527B are shown in
Figure 1. The 527B has a four-conductor, coiled cord cable
and a double-pole, single-throw, leaf-type switch to control
the microphone circuit and an external relay or switching
circuit. The WHITE and GREEN leads are the audio
conductors for balanced-line connection to the microphone
circuit; the shield is connected to the microphone circuit
ground (see Table 1).
CABLE-TO-CONNECTOR WIRING
TABLE 1
BLACK
RED
GREEN
WHITE
BLACK
BUTTON MOVEMENT
+
CARTRIDGE SWITCH CABLE
INPUT TYPE
WIRE
COLOR
FUNCTION XLR
CONNECTOR
1/4 IN.
PHONE PLUG
WHITE AUDIO + PIN 2 TIP
BALANCED GREEN AUDIO - PIN 3 RING
SHIELD CHASSIS GROUND PIN 1 SLEEVE

The 527B is wired for balanced-line operation and is
recommended for use where long cable lengths are
required, or areas where strong noise fields may exist. The
527B microphone can be fed directly into a standard
low-impedance amplifier, or a Shure A95 Series Line
Matching Transformer can be used for coupling the 527B to
the input of a high-impedance amplifier. A two-conductor
shielded cable can be used for extending only the
microphone circuit. If both the microphone circuit and the
remote circuit are to be extended, a four-conductor cable,
having two shielded conductors for the microphone, should
be used.
OPERATION
The 527B will operate satisfactorily under all ordinary
conditions of humidity, heat, and cold. Dropping the
microphone or other severe mechanical shocks should be
avoided.
SPECIFICATIONS
Type
Dynamic
Frequency Response
300 to 5,000 Hz (see Figure 2)
TYPICAL FREQUENCY RESPONSE
FIGURE 2
Sensitivity (at 1,000 Hz)
Open Circuit Voltage* ...................... -53 dBV/Pa (2.2
mV)
*1 Pascal=94 dB SPL
Impedance
Microphone impedance rating is 150 Ω(200 Ωactual) for
connection to microphone inputs rated at 19 to 300 Ω
Switch
Double-pole, single-throw, leaf-type
Cable
Attached, 1.8 m (6 ft), 4-conductor (2 shielded),
neoprene-jacketed
Dimensions (See Figure 3)
OVERALL DIMENSIONS
FIGURE 3
MOUNTING BRACKET
FIGURE 4
Net Weight
337 g (11.9 oz)
Packaged Weight
533 g (18.8 oz)
Certification
Meets European Union EMC Emissions and Immunity
Requirements (EN 50081-1: 1992, EN 50082-1: 1992).
FURNISHED ACCESSORY
Mounting Bracket (3 in kit).............................................. RK6MB
REPLACEMENT PARTS
Cartridge.............................................................................R131
Switch............................................................................ RK319S
Cable ................................................................................. C29C
0
+10
9876543298765
FREQUENCY IN HERTZ
20000100001000
432
100
–10
5020
RELATIVE RESPONSE IN dB
3.688 in.
[9.37 cm]
1.765 in.
[4.48 cm]
.375 in.
[.95 cm]
.750 in.
[1.91 cm]
.093 in.
[.24 cm]
.062 in.
[.16 cm]
.032 in.
[.08 cm]
2.625 in.
[6.67 cm]
