222
HARTREY
AVE., EVANSTON,
IL.
60204
U.S.A.
I
DATA
MODELS 4-15, 420, 425,
AND
@
AREA
CODE312/328-9000 CABLE: SHUREMICRO
SHEET
430 "COMMANDO" SERIES
I
MODEL 415 MODEL 420 MODEL 425 MODEL 430
OMNI-DIRECTIONAL CONTROLLED MAGNETIC MICROPHONES
GENERAL
The Commando Series Microphones are designed for voice
reproduction and are ideal for tape recording, fixed or mobile
public address systems, amateur communications, and similar
uses. The microphones are pressure operated units using the
balanced armature controlled magnetic principle. They feature
high output, smooth response, extreme ruggedness and ability
to withstand severe moisture and temperature conditions.
Model 415 is a high-impedance microphone for connection
to amplifiers, mixers or tape recorders with high-impedance
microphone inputs.
The Models 420, 425 and 430 are dual-impedance micro-
phones with the option of low-impedance for connection to
microphone inputs rated at 25 to 200 ohms, or of high-impedance
for connection to high-impedance microphone inputs.
Model 415
can be used as a handheld unit or can be stand-
mounted with the furnished A25B swjvel adapter. The A25B has
standard %"-27 threads and is adjustable through 90" from
vertical through horizontal. The Model 415 has an attached 2.lm
(7 ft) single-conductor shielded cable.
Model 420
is designed specifically for applications requiring
a small wearable microphone. It is furnished with a detachable
lavalier cord and clip assembly and a small-diameter, extremely
flexible, attached 6.lm (20 ft) two-conductor shielded cable.
Model 420 allows the wearer full use of both hands used as
a lavalier microphone or can be used as a handheld micro-
phone removed from the lavalier assembly.
Model 425
has a %"-27 threaded base permitting easy goose-
neck mounting. It is furnished with a small-diameter attached
2.lm
(7
ft) two-conductor shielded cable. This microphone is
also available with an attached gooseneck in a 6 in. length as
Model 425-G6, in a 12 in. length as Model 425-G12, and in
an 18 in. length as Model 425-G18.
Model 430
is supplied with a detachable 4.6m (15 ft) two-
conductor shielded cable with an Amphenol MC2M connector
on the microphone end. It has a press-to-talk locking or non-
locking switch and can be used handheld or stand-mounted
in the furnished A25B swivel adapter.
ARCHITECTS' SPECIFICATIONS
The m~crophoneshall be Shure Model (415, 420, 425, 430)
or equivalent balanced armature controlled magnetic type mi-
crophone with a frequency response of 60 to 10,000 Hz. This
unit shall have an omnidirectional polar characteristic. The
microphone shall be dual impedance (except Model 415-high
impedance only) with a rated impedance of 150 ohms for
connection to microphone inputs rated at 25 to 200 ohms and
High for connection to high-impedance microphone inputs. The
microphone output shall be:
Low
........................................................................
-
54 dB
(0 dB
=
1 milliwatt with 10 microbars)
High
........................................................................
-
55 dB
(0 dB
=
1 volt per microbar)
Copyright
1967.
Shure Brothers
Inc.
27A116 (OA)
(OVER)
MODEL 415
-
The microphone shall be provided with a swivel
adapter adjustable through 90" from vertical to horizontal and
suitable for mounting on a stand having a =/e"-27 thread. The
microphone shall be provided with a 2.lm (7 ft) single-conductor
shielded cable. The overall dimensions shall be 173.0 mm
(6-13/16 in.) in length and 44.5 mm (1% in.) in diameter.
MODEL 420
-
The microphone shall be provided with a lavalier
cord and clip assembly for use as a wearable microphone.
The microphone shall be provided with a 6.lm (20 ft) two-
conductor shielded cable. The overall dimensions shall be
93.7 mm (3-11/16 in.) in length and 44.5 mm (1% in.) in diam-
eter.
MODEL 425
-
The microphone shall be provided with an
adapter having a Ye"-27 thread. The microphone shall be pro-
vided with a 2.lm (7 ft) two-conductor shielded cable. The
overall dimensions shall be 118 mm (4-21/32 in.) in length and
44.5 mm (1% in.) in diameter.
MODEL 430
-
The microphone shall be provided with an
On-Off switch and a swivel adapter adjustable through 90"
from vertical to horizontal and suitable for mounting on a
stand having a
5/8
"-27 thread. The microphone shall be provided
with a detachable 4.6m (15 ft) two-conductor shielded cable
with an Amphenol MC2M connector on the microphone end.
The overall dimensions shall be 177 mm (7 in.) in length and
44.5 mm (1% in.) in diameter.
IMPEDANCE SELECTION
The dual-impedance Models 420, 425, and 430 are shipped
connected for high-impedance operation.
To change Models 420 and 425 to low impedance:
1. Remove the three Phillips Head screws holding the bottom
cap or adapter to the microphone.
2. Gently pull down the cap or adapter.
3. Reach in with longnose pliers or tweezers and remove
the pin jack (WHITE lead) from the terminal marked "H".
(See Figure A,) Install this pin jack on terminal pin
marked
"L".
4. Reassemble bottom cap or adapter to microphone, making
sure that the cable strain relief is well seated in the
bottom cap and that the screws are tightened securely.
To change Model 430 to low impedance:
1. Remove the two Phillips Head screws located below the
nameplate and a third of the way around from the switch.
2. Loosen the screw between the switch and the nameplate
just enough to pull off the top part of the microphone.
This screw should remain attached to the switch bracket
inside the chrome base of the microphone.
3. Reach in with longnose pliers or tweezers and remove the
pin jack (RED lead) from the terminal marked
"H".
(See
Figure A,) Install this pin jack on terminal pin marked "L".
4. Reassemble the bottom chrome base to the upper part of
the microphone. Position switch bracket so that top part
of microphone slides easily into chrome base. Tighten
all screws securely.
