AXT400 Dual Channel Receiver

The AXT400 Dual Channel Receiver combines advanced analog and digital technology to deliver exceptional RF and audio performance. The receiver features ShowLink™

Remote Control for real-time transmitter adjustments, Frequency Diversity mode for seamless dual-frequency operation, and Interference Detection & Avoidance. It offers up

to 228 MHz of wideband tuning and supports Axient and UHF-R series transmitters. Connectivity options include transformer balanced audio outputs, AES3 digital audio out-

put, RF Cascade ports and dual Ethernet ports for networked control and monitoring via Shure Wireless Workbench®6 software.

Features

ShowLink™ Remote Control

The AXT400 offers comprehensive real-time remote control of a linked transmitter when used with the AXT610 ShowLink Access Point. Axient transmitters can be Linked to

each receiver channel using the Infrared Sync feature. The ShowLink Access Point maintains a 2.4 GHz wireless network communication with the transmitters and connects

to the receiver over Ethernet. All functions of the Linked transmitter including gain adjustments and synchronized frequency changes can be controlled from the front panel

menu of the AXT400 in real-time.

Interference Detection and Avoidance

During operation, the AXT400 receiver can detect the presence of an interfering analog or digital signal. When a potential interference source is detected, a warning mes-

sage is displayed along with options for changing frequency. When used with the AXT600 Spectrum Manager, the receiver can switch to a ‘backup’ frequency deployed by

the Spectrum Manager, either manually or automatically. The Spectrum Manager constantly monitors a compatible frequency list to ensure the best available frequencies are

used. With ShowLink™ Remote Control, the receiver and transmitter can execute a synchronized switch to a clear frequency, resolving the interference.

Frequency Diversity

Frequency Diversity provides seamless audio in environments where there is a risk of dropouts or interference by using transmission from a single audio source on two in-

dependent radio frequencies. In Frequency Diversity mode, the AXT400 Receiver continuously analyzes signal quality and uses both signals to provide optimized audio on a

single channel. In the case of RF interference on one frequency the receiver automatically uses the other frequency, delivering clean, uninterrupted audio.

Wideband Tuning

Up to 228 MHz tuning bandwidth accommodates multiple transmitter bands, providing flexibility and simplifying receiver inventories. A single receiver can cover the entire US

UHF TV band.

Networking

The AXT400 Receiver shares information with other system components via Ethernet, enabling advanced features such as remote control of transmitters and management

using WWB 6 software. The receiver has two RJ45 Ethernet ports capable of 10/100 Mbps network speeds. The Ethernet ports are power over Ethernet (PoE) enabled, which

can be used to supply power to a ShowLink Access Point. To verify the network is correctly configured, the list of network-ready devices can be identified using the Find All

utility in the front panel menu.

Groups and Channels

The receiver includes a wide selection of frequency Groups which allow easy access to compatible Channels for multiple receivers. Channel Scan finds an open frequency

within the current Group. Group Scan finds the open Channels in all Groups and allows easy programming of compatible frequencies to other AXT400 receivers over the

network.

RF Cascade Ports

The cascade ports share RF signal with up to 5 receivers within the same frequency band. RF cascade allows antenna signal to be conveniently distributed for up to 10 chan-

nels without using splitters or distribution amplifiers.

Compatible Transmitters

The receiver is compatible with the following Shure transmitters:

Included Components Mounting Instructions

This component is designed to fit into an audio rack.

WARNING: To prevent injury this apparatus must be securely at-

tached to the rack.

1-foot Coaxial Cascade Cable (2) 95N2035

IEC AC Power Cable (1) 95A9128

IEC AC Extension Cable (1) 95A9129

Shielded 3-foot Ethernet Cable (1) C803

Shielded 8-inch Ethernet Jumper Cable (1) C8006

Hardware Kit (1) 90XN1371

22-inch Coaxial Cable* (1) 95B9023

33-inch Coaxial Cable* (1) 95C9023

* with integrated bulkhead for front mounting antennas.

• AXT100 Bodypack Transmitter

• AXT200 Frequency Diversity Handheld Transmitter

• UR1 Bodypack Transmitter

• UR1H Bodypack Transmitter

• UR1M Micro-Bodypack Transmitter

• UR2 Handheld Transmitter

navigate navigate control monitor power

clip

push

enter

exit

audioRF

sync

127

12 14

910

5 6

25 6

AXT400

A 470-698 MHz

Dual Wireless Receiver

A B

antenna

cascade

out

12.7V OUT

150 mA

B A

AXT400

236

11 13

12 14 12 14

11 13

Input 100-240 V ~ 50/60 Hz 0.8A max.

(5.8A max. outlet loaded)

Output 100-240~

5A max. 50/60 Hz UNSW.

analog outputs receiver 2

line

mic

lift

GND

AES3 output

word

clock

thru

Term 75Ω

analog outputs receiver 1

line

mic

lift

GND

Class 1 PoE

Front Panel

① Sync - Infrared (IR) Port

Infrared (IR) port. For sending parameter presets

(IR Preset) to a transmitter and linking the

transmitter and receiver to the same channel.

② Squelch LEDs

• Blue (On) = transmitter signal detected

• Off = no signal or signal squelched because of

poor reception or no tonekey

③ RF LEDs

Indicates the RF signal strength from the

transmitter.

• Amber (1-5) = -90 to -70 dBm in 5 dBm

increments

• Red = RF overload

④ Audio LEDs

Indicates the audio signal strength from the

transmitter.

• Green = signal present

• Yellow = normal peak

• Red = overload

To correct an overload, adjust the transmitter gain.

⑤ LCD display

Each channel has an LCD display for viewing

settings and parameters.

⑥ Menu navigation buttons

Use to select and navigate through parameter

menus.

⑦ Enter button

The Enter button flashes when an action or

parameter change is pending. Press Enter to save

the value.

⑧ Exit button

Cancels parameter changes or returns to a

previous menu screen.

⑨ Control wheel

• Push to select menu items for editing

• Turn to edit a parameter value

⑩ Monitor clip LED

Indicates audio overload when illuminated.

⑪ Monitor output LED

Indicates channel selection for monitoring.

⑫ Monitor volume knob

Adjusts monitor volume. Push to monitor channel

1 or channel 2.

⑬ Monitor jack

6.5 mm (1/4”) output jack for headphones.

⑭ Power switch

Power the unit on or off.

Rear Panel

① AC power primary switch

AC main power switch.

② AC power in

IEC connector 100 - 240 V AC.

③ AC power cascade

Use IEC extension cables to connect up to 5 rack

components to a single AC power source.

④ Network speed LED (amber)

• Off = 10 Mbps

• On = 100 Mbps

⑤ Ethernet ports: Class 1 PoE enabled (2)

Connect to an Ethernet network to enable remote

control and monitoring.

⑥ Network status LED (green)

• Off = no network link

• On = network link active

• Flashing = network link active, flash rate

corresponds to traffic volume

⑦ Word clock input

Connect to resolve the AXT400 AES3 digital

output to an external word clock source.

⑧ Word clock thru output

Passes word clock signal to additional

components.

⑨ Word clock termination switch

Set to thru when passing signal to additional

components. Set to 75Ω when thru connection is

not used.

⑩ AES3 digital audio output

24-bit digital audio output for channel 1 and

channel 2.

⑪ Line/Mic switch

Changes the output level 30 dB (XLR outputs

only).

⑫ Transformer balanced XLR audio output

For channel 1 and channel 2.

⑬ Ground lift switch

Lifts the ground from pin 1 of the XLR connector

and the sleeve of the ¼” jack.

⑭ Transformer balanced 1/4” output jack

For channel 1 and channel 2.

⑮ RF antenna input jacks

For antenna A and antenna B.

⑯ RF input status LED

Indicates the voltage status of the RF input.

• Green = DC voltage on

• Red flashing = fault condition

• Off = DC voltage off

⑰ RF cascade ports

Passes the RF signal from one receiver to the

next, allowing up to 5 receivers to share a single

pair of antennas.

⑱ Temperature activated fan

Ensures top performance in high temperature

environments. Clean fan screen as needed to

maintain airflow.

FDbp

FDhh

Screen Icons

Screen icons indicate the status of advanced features and provide details of receiver

settings.

Network

Indicates connectivity with other

devices on the network. IP

Address must be valid to enable

networked control.

ShowLink

Indicates ShowLink control active

between the receiver and the

Linked transmitter.

Lock

Indicates transmitter controls

locked.

Link Status

Displayed when the receiver

channel is Linked to a

transmitter.

Frequency Diversity Bodypack

Mode

Frequency Diversity configured

for use with bodypack

transmitters.

Frequency Diversity Handheld

Mode

Frequency Diversity configured

for use with handheld diversity

transmitters.

Asterisk

Appears next to the tuned

frequency if it is not included in

the compatible frequency list

(CFL) of the Spectrum Manager.

From:

References the source of the

currently tuned frequency. For

example, a Group and Channel

or the Device ID of a Spectrum

Manager currently controlling the

receiver.

OUT:

Displays the current level of

the audio output (0 to -30 dB or

Mute)

TV:

Displays the TV channel that

contains the tuned frequency.

Vocal 1

634.225 MHz

AXT200 5:15

Radio

Audio

Util

Gain Pw

+12 Nm

From: G: 8 Ch: 40

TV: 41 OUT: Mute

FDhh

10 12

Home Screen

The home menu displays a summary of receiver parameters and the top-level menu

choices. When a transmitter is received, its key settings are displayed.

① Audio channel name

The audio channel name is

shared by a receiver and a Linked

transmitter

② Frequency setting

The tuned frequency of the

receiver

③ Radio menu

Select to access Radio sub-menus

④ Audio menu

Select to access Audio sub-menus

⑤ Util menu

Select to access Utility sub-menus

⑥ Tx

Select to access Transmitter

sub-menus

⑦ Received Transmitter Data

Solid line: Receiving signal from a

Linked transmitter

Dashed line: Received signal is not

from a Linked transmitter

⑧ Transmitter Device ID

Displays the Device ID or model

number of the received transmitter

⑨ Transmitter Gain

Gain setting for received

transmitter

⑩ RF Power

Power level for received transmitter

⑪ Lock Status

Icon indicates transmitter controls

locked

⑫ Battery Life

Remaining runtime for the

transmitter battery is displayed

numerically, alternating with a

segmented battery icon.

ON OFF

DHCP

Shure

AXT620

Edit ID

Flash

Mute

[Device ID]

Gain: +10

Power: 10mW Lock: OFF

RF Output: On

Networking Receivers

The receiver uses an Ethernet connection to network with other components. For automatic network configuration, use a DHCP enabled Ethernet switch such as the Shure

AXT620 or an Ethernet router with DHCP service. Use multiple Ethernet switches to extend the network for larger installations.

Multiple device network example using the Shure AXT620

Ethernet switch

Automatic IP Addressing

1. If using a Shure AXT620 Ethernet switch, set the

DHCP switch to ON.

2. Set the IP mode to automatic for all devices (Util >

Network > Mode > Automatic)

Manual IP Addressing

1. Connect the Spectrum Manager and receivers to an

Ethernet switch.

2. Set the IP Mode to Manual for all devices:

• Menu: Util > Network

• Use the control wheel to set valid IP addresses

for all devices. Set the subnet mask for all

devices to the same value.

Troubleshooting

Use only one DHCP server per network

All devices must share the same subnet mask

All devices must have the same level of firmware

revision installed

Look for the network icons on the display of each

device:

• If the icon is not there, check the cable

connection and the LEDs on the network jack.

• If the LEDs are not on and the cable is plugged

in, replace the cable and recheck the LEDs and

network icon.

Use the Find All utility (Util > Network > Find All)

to view devices on the network:

• The Find All report lists all devices on the

network.

• Check the IP address for devices not shown in

the Find All report to ensure that they are on the

same subnet.

To check connectivity of WWB6 to the network:

1. Start WWB6 software and use Inventory view to see

devices connected to the network.

2. If not, find the IP address from one of the devices on

the network (such as an AXT400 receiver) and see if

you can ping it from the computer running WWB6.

3. From a WINDOWS/MAC command prompt, type

“ping IPADDRESS” of the device (e.g. “ping

192.168.1.100”).

4. If the ping returns success (no packet loss), then the

computer can see the device on the network. If the

ping returns failure (100% packet loss), then check

the IP address of the computer to ensure it’s on the

same subnet as the device.

5. If the pings are successful and the devices still

do not show up in the WWB6 inventory, check to

ensure all firewalls are either disabled or allow the

WWB network traffic to pass to the application.

Check that firewall settings are not blocking network

access.

Adding ShowLink for Remote Control

Adding a ShowLink Access Point enables remote control of a linked Axient transmitter from the front panel of the receiver.

Connecting a ShowLink Access Point

1. Connect the Access Point to the Ethernet port of

the receiver to establish a network connection and

supply power.

2. Position the access point within range of the

transmitter.

3. Check the transmitter and receiver menus for the

ShowLink icon, indicating that remote control is

possible.

Remote Control of Transmitters

When a linked transmitter is within range of a ShowLink

Access Point, the transmitter adjustment menu is

enabled.

1. From the home screen, select Tx > Adjust

2. Press the control wheel to highlight a parameter for

adjustment.

3. Turn the control wheel to change a parameter value.

ShowLink Test

To check the ShowLink network and connectivity,

you can use the ShowLink test mode in the AXT400

receiver:

1. Connect the AXT610 Access Point to the network.

2. Link a transmitter to the receiver by doing an IR

sync.

3. You should see the ShowLink icon on the receiver

display next to the transmitter information.

4. From the receiver menu: Util > More >

ShowLink Test.

5. Use the control wheel to highlight a transmitter to

test, and then press Start.

6. The ShowLink test will run and display a signal

strength indication.

7. If the ShowLink signal strength is low, check the an-

tenna connection on the AXT610 and the transmitter.

Frequency Diversity

Frequency Diversity uses two independent radio frequencies sent from an AXT200 handheld transmitter or from two AXT100 bodypack transmitters connected with a “Y”

cable to deliver a single uninterrupted audio channel. To optimize performance, Frequency Diversity mode must match the transmitter type.

To set Frequency Diversity mode:

1. Menu: Options > Diversity

2. Turn the control wheel to select FD-Bodypack for AXT100 bodypack transmitters or to select FD-Handheld for AXT200 handheld transmitters.

Note: For smaller systems, connect the receivers

to one another using the Ethernet ports on the

back panel. The devices fall back to compatible

addresses if the IP mode is set to automatic and

there is no DHCP server.

navigate navigate control monitor power

clip

push

enter

exit

audioRF

sync

AXT400

A470-698 MHz

DualWireless Receiver

A B

New Freq

Scan

Options

Squelch

G:01 Ch:01

470.350 MHz TV: 14

Band: G1

: AXT600

Frequency

Server

Setting up an Audio Channel

Linking a Transmitter using IR Sync

The IR Sync function forms a link between a transmit-

ter and the receiver and automatically sets the trans-

mitter frequency.

1. Menu: Tx

2. Align the transmitter with the IR port on the front

panel. The red IR sync LED on the receiver IR port

will illluminate to indicate correct alignment. Press

Sync.

3. The display indicates if the IR sync is successful.

Check transmitter alignment and select Retry if a

failure occurs. The receiver passes an audio signal

if successful.

Setting the Frequency Band

Set to the Receiver to the same frequency band as the

transmitter.

1. From the home menu screen, select Radio.

2. Press the control wheel to highlight Band.

3. Turn the control wheel to set the receiver band to

match the transmitter band.

4. Press the ENTER button to save.

4. Linking a transmitter creates a persistent control re-

lationship with the receiver channel, enabling remote

control and synchronized frequency changes when

ShowLink is active.

• Up to 2 transmitters can be linked, which

allows alternate transmitters to be added to the

channel and remotely controlled.

• Turn the control wheel to select the transmitter

in slot 1 or slot 2 before pressing Sync.

5. When a transmitter is successfully linked, a confir-

mation is displayed and the link status icon appears

to the left of the channel name on the receiver home

menu. Link status is not maintained with UHF-R

series transmitters.

6. Transmitters can be unlinked from the channel,

clearing the link relationship.

• From the home screen menu, select Tx

• Turn the control wheel to select the device ID of

the transmitter to be unlinked

• Press the Unlink menu option or link another

transmitter to overwrite the selected link slot

Dual Digital Signal Processors (DSP) in the receiver analyze the RF signal for signs of interference that can degrade the audio signal. When interference is present, the

receiver screen turns red and displays one of the following warning messages:

Interference Alert

Displayed on the home screen when low-level interference is detected. Interference at this level may not be audible or may only cause a slight disruption to the audio signal.

All receiver controls can still be accessed, and If the interference is not audible, a frequency change may not be necessary.

If Interference Avoidance is set to Auto mode, a frequency change will not occur unless the strength of the interference increases to trigger an Interference

Detected message.

Interference Detected

Displayed when high-level interference likely to disrupt the audio signal is detected. The menu screen displays on-screen options for changing to a clear frequency or if

Interference Avoidance mode is set to Auto, the channel will automatically switch to a clear frequency deployed by the Spectrum Manager.

If the Interference clears without being addressed or if a frequency change is made by the Spectrum Manager, the LCD screen will return to its normal color. The detection

message indicating time elapsed since the interference occurred will remain on the screen for up to 60 minutes or until dismissed.

Interference Detection

Normal

• Generates a message in response to low levels

of interference well below the audibility threshold

• Provides more time to react to messages

• Interference Detection is suppressed when

received signal strength is below the Exclusion

threshold

More Sensitive

• Generates a message in response to moderate

levels of interference below the audibility

threshold

• Provides more time to react to messages

• Interference Detection can trigger at low received

signal levels, regardless of the Exclusion

threshold setting

Less Sensitive

• Detects interference at a level just below the

audibility threshold

• Fewer detection messages

• Less time to react to messages

• Interference Detection is suppressed when

received signal strength is below the Exclusion

threshold

Detection Sensitivity

The sensitivity setting allow you to vary the timing of warning messages to match the RF conditions and the need to avoid interference.

Specifications–AXT400 Receiver

System Gain

In an audio system containing both AXT400 and UR4 receivers, the overall system audio gain at the XLR (line) output varies depending on the receiver model and the type of

transmitter.

The table below offers a comparison of the output gain at the XLR output for AXT400 and UR4 receivers for each transmitter model. Use the information in the table to achieve

consistent gain levels when using systems comprised of both Axient series and UR series components.

System gain from transmitter input to receiver XLR output (line) when transmitter gain = 0 dB

Transmitter AXT100 Bodypack AXT200 Handheld UR1 Bodypack UR1M Bodypack UR2 Handheld

gain = 0 dB gain = 0 dB gain = 0 dB gain = 0 dB gain = 0 dB

sens = 0 dB sens = 0 dB

Receiver AXT400 +10 dB gain +15 dB gain +15 dB gain +15 dB gain +15 dB gain

gain setting = 0 dB UR4 N/A N/A +18 dB gain +18 dB gain +18 dB gain

Firmware Updates

Firmware is embedded software in each component that controls functionality. Periodically, new versions of firmware are developed to incorporate additional features and

enhancements. To take advantage of design improvements, new versions of the firmware can be uploaded and installed using the Firmware Update Manager tool available in

WWB6 software. Firmware is available for download from http://www.shure.com/wwb.

RF Carrier Frequency Range 470–952 MHz

Note: varies by region

Working Range Under typical conditions: 150 m (500 ft)

Line of Sight, outdoors for a single system: 500 m (1600 ft)

Note: Actual range depends on RF signal absorption, reflection and interference.

Audio Frequency Response 40 – 18 kHz (+1, -3 dB)

Note: Dependent on microphone type

RF Tuning Step Size 25 kHz

Modulation

45 kHz max. deviation FM, Audio Reference Companding with pre- and de-emphasis

Dynamic Range XLR Output: >118 dB, A-weighted

AES3 Output: >130 dB, A-weighted

Image Rejection >120 dB, typical

RF Sensitivity -110 dBm for 12 dB SINAD, typical

Spurious Rejection >110 dB, typical

Ultimate Quieting >110 dB, A-Weighted

Squelch Quieting >115 dB, A-Weighted

Latency <1 ms

Total Harmonic Distortion

45 kHz max. deviation <0.3%, A-weighted, typical

System Audio Polarity Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces

positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 1/4-

inch output.

Gain Adjustment Range 0 to -30 dB (in 1 dB steps), plus Mute setting

Dimensions 44 mm x 483 mm x 366 mm (1.7 in. x 19.0 in. x 14.4 in.), H x W x D

Weight 5.5 kg (12.0 lbs)

Housing Steel; Extruded aluminum

Power Requirements 100 to 240 V AC, 50-60 Hz

Current Drain 1.1 A RMS (referenced at 120 V AC)

Operating Temperature Range -18°C (0°F) to 63°C (145°F)

Storage Temperature Range -29°C (-20°F) to 74°C (165°F)

1/4”

XLR

line

mic

Relay Mute

Relay

Mute

GND

Lift

GND Lift

AES3 Output

Word Clock

Clock

Conditioning

thru

75ΩTermination

Cascade Output

Connector Type BNC

Configuration Unbalanced, filtered to receiver band

Impedance 50Ω

Analog Audio Output

RF Input

Connector Type BNC

Configuration Unbalanced, active

Impedance 50Ω

Bias Voltage 12 V DC, 150 mA (300 mA maximum)

Configuration Monitor: Unbalanced mono, 1/4 in. (will drive stereo

phones)

6.35 mm

(1/4”): Transformer Coupled Balanced

XLR: Transformer Coupled Balanced

Impedance Monitor: 50Ω

6.35 mm

(1/4”): <50Ω

XLR: <150Ω

Maximum Signal

Level

45 kHz max.

deviation

Monitor: 1W@63Ω

6.35 mm

(1/4”): 9 dBu

XLR: +18 dBu

Mic/Line Switch 30 dB

Pin Assignments Monitor: Tip: audio +

Ring: audio +

Sleeve: ground

6.35 mm

(1/4”): Tip: audio +

Ring: audio -

Sleeve: ground

XLR: 1: ground

2: audio +

3: audio -

Phantom Power

Protection

Monitor: No

6.35 mm

(1/4”): Yes

XLR: Yes

Digital Audio Output

Configuration AES3 Type 1, XLR connector: Channel 1: Left

Channel 2: Right

Word Clock Input Level: 3 Vpp

Frequency: 48/96 kHz

Impedance 75Ω

Pin Assignments 1: ground

2: audio +

3: audio -

Phantom Power

Protection Yes

Networking

Power Over Ethernet

(PoE) 50 V DC, Class 1

Network Interface Dual Port Ethernet 10/100 Mbps

Network Addressing

Capability DHCP or Manual IP address

Certifications

Meets essential requirements of the following European Directives:

• R&TTE Directive 99/5/EC

• WEEE Directive 2002/96/EC, as amended by 2008/34/EC

• RoHS Directive 2002/95/EC, as amended by 2008/35/EC

Note: Please follow your regional recycling scheme for electronic waste

• Conforms to European Regulation (EC) No. 1275/2008, as amended.

Meets requirements of the following standards: EN 300 422 Parts 1 and 2, EN 301 489 Parts 1 and 9, EN60065.

Approved under the Declaration of Conformity (DoC) provision of FCC Part 15.

Certified in Canada by IC to RSS-123.

IC: 616A-AXT400

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Note: EMC conformance testing is based on the use of supplied and recommended cable types. The use of other cable types may degrade EMC performance.

Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

The CE Declaration of Conformity can be obtained from Shure Incorporated or any of its European representatives. For contact information please visit www.shure.com

The CE Declaration of Conformity can be obtained from: www.shure.com/europe/compliance

Authorized European representative:

Shure Europe GmbH

Headquarters Europe, Middle East & Africa

Department: EMEA Approval

Jakob-Dieffenbacher-Str. 12

75031 Eppingen, Germany

Phone: 49-7262-92 49 0

Fax: 49-7262-92 49 11 4

Email: [email protected]

Information to the user

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a par-

ticular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
