Shuttle FB61 User manual

FB61
Pentium4/Celeron,478-pinProcessor
Based MAIN BOARD

Shuttle®FB61
Pentium 4/Celeron , 478-pin Processor Based Mainboard
Manual Version 1.1
Copyright
Copyright©2003 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Shuttle is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other product names used in this manual are ascribed to their respective
owners and acknowledged.
M849

Statement of Shuttle Mainboard via the EMI Test
Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/
CISPR22/AS/NZS3548ClassB,EN55024(1998/AS/NZS),EN4252.1(1994),EN61000,ANSI
C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-
trated as follows:
(A)Voltage:AC110V/60HZ &AC230V/50HZ
(B) Tested Product Information:
Product Name: PC Mainboard
Status: Sample
ModelName:FB61
S/N:
CPU:
External Frequency: 100 MHz
Intel P4 1.8/2.0/2.2/2.4/2.5GHz
External Frequency: 133 MHz
IntelP42.26/2.4/2.53/2.66/2.80/3.06GHz
External Frequency: 200 MHz
Intel P4 Northwood 2.4/2.6/2.80/3.0 GHz
Keyboard Port: one port with 6 pins
Mouse Port: one port with 6 pins
USB 2.0 Port: four ports with 4 pins respectively
Parallel Port: one port with 9 pins
LAN Port: one port with 8 pins
1394 Port: one port with 6 pins
VGA Port: one port with 15 pins
Line-Out & Line-In & Mic-In Ports: one port for each
DDR Memory: 256 MB *2
All CPUs have completely been tested, and values offered by the worst EMI combination of
CPU external frequency are listed as follows:
(C) Remedy for the Tested Product & Its EMI Interference:
Remedy:N/A
EMIInterference:
Crystal:32.768KHz(X1)/14.318MHz(X2)/25 MHz(X4)/24.576(X6)
Clock Generator: U5
Test Mode External Frequency CPU Power Supply Case
Open/Closed
1133MHz Pentium4
3.06GHz ENP-2320 Closed
2133MHz Pentium4
3.06GHz ENP-2320 Open
3100MHz Pentium4
2.4GHz ENP-2320 Closed
4100MHz Pentium4
2.4GHz ENP-2320 Open

(D) Supported Host Peripherals:
(E) Notices for Assembling Computers:
1. Cases should be made of iron or other metal that has good electric conductivity.
2. Cylinders in a case should be made of metal, and as having a mainboard mounted
in a case, make sure screws are all utilized and fastened on a mainboard.
3. An I/O shielding should be contacted with I/O metallic parts of a mainboard.
4. Cables should appropriately be arranged and fixed in a case. Follow instructions:
Ø Leave IDE cables not crossed upon CPU and SDRAM;
Ø Leave power cables minimum in length, and not crossed upon a mainboard;
Ø Leave CPU fan cables minimum in length, and not near CPU;
Ø Leave cables on panels and other spare cables tied in a computer case.
5. Make sure an EMI shielding attached to a case has properly been installed.
6. Make sure a 5.25" or 3.5" FDD and screws are fastened to an EMI shielding.
7. Make sure a case is closely in contact with EMI connected points.
8. Make sure there is no cleft in a case which is not deformed.
9. Make sure a PCI orAGP door is bound to a case.
10. Make sure cables of other devices (fans or some others) are fixed in a case.
Host Peripheral Product Name Model Name S/N FCC ID
#1 Case KF45A N/A
#2 Power Supply (300W) ENP-0730 (ATX12V) 1000002885
#3 IBM HDD (30.7GB) 91024UB YKFY7981 3892I168
#4 MITSUMI FDD D353M
#5 SONY VCD Player CDU4811 3892A291
#6 AGP Card Winfast Geforce 2 MX 3892C520
#7 Power Cable Detachable and Shielded

- 1 -
TABLE OF CONTENTS
WHAT'S IN THE MANUAL.................................................................... 5
Quick Reference............................................................................................... 5
About This Manual ........................................................................................... 5
1 INTRODUCTION................................................................................ 6
1.1 TO DIFFERENT USERS ............................................................................. 6
FIRST-TIMEDIYSYSTEMBUILDER............................................................ 6
EXPERIENCEDDIY USER ........................................................................ 6
SYSTEMINTEGRATOR............................................................................... 6
1.2 ITEM CHECKLIST....................................................................................... 7
2 FEATURES ........................................................................................ 8
2.1 SPECIFICATIONS ....................................................................................... 8
3 HARDWARE INSTALLATION.......................................................... 11
3.1 STEP BY STEP INSTALLATION................................................................11
Accessories of FB61.............................................................................11
STEP1 CPUInstallation........................................................................ 12
STEP 2 Set Jumpers............................................................................. 13
STEP3 InstallDDRSDRAM SystemMemory........................................ 13
STEP 4InstallInternal PeripheralsinSystem Case ................................ 14
STEP5 Mountthe Mainboard onthe ComputerChassis........................ 15
STEP6 Connect FrontPanelSwitches/LEDs/USB/1394a/MIC/Line-in/Line-
out ......................................................................................................... 16
STEP 7 Connect IDE, Floppy, and SerialATA Disk Drives ..................... 18
STEP8Connect OtherInternalPeripherals............................................ 19
STEP9 ConnectthePower Supply........................................................ 21
STEP10 InstallAdd-on Cards in ExpansionSlots .................................. 21
STEP11 ConnectExternalPeripherals toBack-Panel........................... 22
STEP 12 First Time System Boot Up ..................................................... 23

- 2 -
STEP13 InstallDrivers& SoftwareComponents ................................... 24
3.2 JUMPER SETTINGS ................................................................................. 25
JUMPERS& CONNECTORSGUIDE.................................................... 26
Jumpers
Clear CMOS Setting (JP1) ................................................................... 29
Back-Panel Connectors
COM1Port Connector ........................................................................... 30
VGAPortConnector .............................................................................. 30
IEEE1394a PortConnectors................................................................. 30
USB0/1Port Connectors ....................................................................... 30
10/100base-T LANPort Connector....................................................... 30
USB2/3Port Connectors ....................................................................... 30
PS/2Keyboard &PS/2 MouseConnectors............................................ 31
Bass/Center-OutPortConnector ........................................................... 31
Rear-OutPortConnector ...................................................................... .31
Front-OutPortConnector....................................................................... 31
Front-Panel Connectors
ATXPower On/Off SwitchHeader(PWON)............................................ 32
HDD LED Header (HLED).................................................................... 32
Green LED / Power LED Header (GLED/PLED) .................................. 33
HardwareReset Header (RST)............................................................. 33
FrontPanelConnector (JP16) ............................................................... 34
Internal Peripherals Connectors
EnhancedIDE,FloppyATAConnectors ................................................. 35
SerialATAConnectors........................................................................... 35
Other Connectors
ATXPower SupplyConnector (ATX1 andATX2).................................... 36
CPUand SystemFanConnector(FAN1/2/3) ......................................... 37

- 3 -
AudioCD_IN Connector(JP11)(Black) ................................................. 37
WirelessKeyboard andMouse Headers (JP6) ..................................... 37
ParallelPort Header(JP8)..................................................................... 38
IRHeader(JP7)..................................................................................... 38
SPDIF-Out/InHeader(JP3) ................................................................... 39
ExtendUSB Header(USB4).................................................................. 39
3.3 SYSTEM MEMORY CONFIGURATION ..................................................... 40
INSTALLMEMORY................................................................................ 40
UPGRADEMEMORY............................................................................ 40
4 SOFTWARE UTILITY ......................................................................41
4.1 Mainboard CD Overview ......................................................................... 41
4.2 Install Mainboard Software ..................................................................... 42
4.2.A Install Intel Chipset Driver.................................................................... 43
4.2.B Install VGA Driver .................................................................................. 44
4.2.C Install Realtek Audio Driver .................................................................. 45
4.2.D Install Realtek LAN Driver..................................................................... 46
4.2.E Install USB2.0 Driver ............................................................................ 47
4.3 View the User's Manual........................................................................... 48
5 BIOS SETUP ................................................................................... 49
5.1 ENTER BIOS ............................................................................................. 49
5.2 THE MAIN MENU ...................................................................................... 50
STANDARD CMOS FEATURES ............................................................... 52
ADVANCED BIOS FEATURES................................................................. 55
ADVANCED CHIPSET FEATURES .......................................................... 59
INTEGRATEDPERIPHERALS .................................................................. 62
POWERMANAGEMENT SETUP.............................................................. 69
PNP/PCICONFIGURATIONS .................................................................... 73

- 4 -
PCHEALTH STATUS................................................................................ 75
FREQUENCY/VOLTAGECONTROL ......................................................... 77
LOAD FAIL-SAFE DEFAULTS .................................................................. 79
LOADOPTIMIZEDDEFAULTS ................................................................. 79
SET PASSWORD ..................................................................................... 80
SAVE & EXIT SETUP................................................................................ 81
EXITWITHOUTSAVING ............................................................................ 81

- 5 -
WHAT'S IN THE MANUAL
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look.......................................................Page 26
Drivers/Software Utilities >> How to Install .........................................Page 41
BIOS Setup >> How to Configure.........................................................Page 49
About This Manual
For First-Time DIY System Builder.........................................................Page 6
For Experienced DIY User ......................................................................Page 6
For System Integrator .............................................................................Page 6

- 6 -
1INTRODUCTION
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as diffi-
cult as you may think. To make your first computer DIY experience successful,
right from the start, we have designed the 3.1 Hardware Installation section
in a step-by-step fashion for all the first-time DIY system builders. Prior to
installation, we also suggest you to read the whole manual carefully to gain a
complete understanding of your new Shuttle FB61 mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle FB61 mainboard. You will find
that installing your new Shuttle FB61 mainboard is just easy. Bundled with an
array of onboard functions, the highly-integrated FB61 mainboard provides you
with a total solution to build the most stable and reliable system. Refer to sec-
tions 3.2 Jumper Settings and Chapter 4 Drivers/Software Utilities to
find out how to get the best out of your new mainboard. Chapter 5 BIOS
Setup also contains the relevant information on how to tune up your system to
achieve higher performance.
System Integrator
You have wisely chosen Shuttle FB61 to construct your system. Shuttle FB61
incorporates all the state-of-the-art technology of the Intel82865G+82801EB
chipset from Intel. It integrates the most advanced functions you can find to
date in a compact Small Form Factor ATX board.

- 7 -
1.2 Item Checklist
Check all items with your FB61 mainboard to make sure nothing is missing.
The complete package should include:
-One piece of Shuttle FB61 Mainboard
-One piece of ATA100/66 /33 Ribbon Cable
-One piece of Floppy Ribbon Cable
-One piece of twin ports USB Cable (optional)
-One piece of Serial ATA Cable
-FB61 User's Manual
-One piece of Bundled CD-ROM with containing:
ØFB61 user's manual saved in PDF format
ØIntel Chipset driver
ØInstall VGA driver
ØInstall Realtek Audio driver
ØInstall Realtek LAN driver
ØInstall USB2.0 driver
ØAward Flashing Utility
C
A
R
6
1
D
-
5
6
0
0
3
0
2
9
8
5
2
6
0
7
C
F
I
C
S
SST
49LF004A 33-4C-NH 0206053-B
USB4
JP13
JP1
SPDIF
JP3
JP6
JP11
PCI1
AGP
FAN1
1
1
1
1
1
1
1
1
1
JP8
IDE1
FDD
IDE2
ATX1
ATX2
DIMM1
FAN2
JP7
IR
DIMM2
-
VT6306
0244CDTAIWAN 12G0352000
cAmMega87-96 MFNW83
R
t
9
2
4
1
C
S
4
E
H
1
C
F3040018
QE41ES
INTEL01
Intel
SECRET FW2801EB
PHILIPPINES
RTL8100B 2B051S1 245ETAIWAN
1
FAN3
1
1
MFL8J.01
CMI9739A
UYD1HG
0245
1
JP16
JP5
1
SERIAL
ATA
V
S
O

- 8 -
2 FEATURES
FB61 mainboard is carefully designed for the demanding PC user who wants high perfor-
mance and maximum intelligent features in a compact package.
2.1 Specifications
-CPU Support
Intel Pentium 4/Celeron, 478-pin supports Northwood processors with 400/
533/800MHz FSB.
Willamette not support.
-Chipset
Features Intel 865G N.B. and ICH5 S.B..
Onboard Lan
Realtek 8100B, support 10Mbps and 100Mbps operation.
Onboard 1394a
VIA VT6307, support 400Mb/s, 200Mb/s, or100Mb/s data transfer rate.
-Jumperless CPU Configuration
Soft-configuration FSB (The FSB speed is software configurable from 100MHz
to 255MHz in the Frequency/Voltage Control of BIOS setup program.)
-On Board 5.1 Channel AC97 Audio
Compliant with AC'97 2.2 specifications.
5.1 channel slot selectable DAC Output for multi-channel applications.
-Versatile Memory Support
Features the dual-channel mode of 128 bit data transfer rate.
Two 184-pin DIMM slots to support up to 2GB of PC2100, PC2700 or
PC3200 compliant DDR SDRAM module.
-AGP Expansion Slot
Provides one 32-bit AGP slot which support 4X/8X AGP device.
-PCI Expansion Slots
Provides one 32-bit PCI slot.
-8 USB 2.0/1.1 Complaint Interface Onboard
Ø4 x USB 2.0 connectors on back-panel and two sets of dual USB port
headers on mid-board.

- 9 -
-I/O Interface
Provides a variety of I/O interfaces:
Ø1 x Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
format or for 5.25-inch FDD with 360K or 1.2MB format.
Ø1 x DB9 Serial connectors 16550 UART compatible.
Ø1 x VGA connector.
Ø4 x USB2.0 ports.
Ø1 x IEEE1394a connectors.
Ø1 x RJ45 LAN connector.
Ø1 x PS/2 mouse connector.
Ø1 x PS/2 Keyboard connector.
Ø1 x Front-Out port.
Ø1 x Rear-Out port.
Ø1 x Bass/Center-Out port.
-PCI Bus Master IDE Controller Onboard
Two Ultra DMA 100/66/33 Bus Master Dual-channel IDE ports provide sup-
port to a maximum of four IDE devices (one Master and one Slave per channel).
The IDE Bus implements data transfer speeds of up to 100/66/33 MB/sec and
also supports Enhanced PIO Modes.
80-pin Cable Backward Compatible Legacy ATAPI Devices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.
-ATX Power Supply Connector
ATX power supply unit can connect to the onboard 20-pin Pentium 4 stan-
dard ATX power connectors, supporting Suspend and Soft-On/Off by dual-
function power button.
The Pentium 4 ATX power include other 4-pin +12V ATX power connector.
-Advanced Configuration and Power Interface
Features four power saving modes: S1 (Snoop), S3 (Suspend to RAM), S4
(Suspend to DISK), and S5 (Soft-Off). ACPI provides more efficient Energy
Saving Features controlled by your operating system that supports OS
Direct Power Management (OSPM) functionality.

- 10 -
-System BIOS
Provides licensed Award BIOS V6.0 PG on 4Mb Flash core and supports
Green PC, Desktop Management Interface (DMI).
-Form Factor
System board conforms to Small from factor ATX specification.
Board dimension: 254mm x 185mm.
-Advanced Features
ØLow EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
ØDual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the
power button for less than 4 seconds places the system into Suspend
mode. When the power button is pressed for longer than 4 seconds, the
system enters Soft-Off mode.
ØModem Ring Power-On - The system can be powered on automatically
by the activation of modem ringing.
-Intelligent Features
ØVoltage Monitoring - Monitors various voltages of key elements, such
as the CPU, and other critical system voltage levels to ensure stable
current passing through mainboard components.
ØFan Status Monitoring -To prevent CPU from overheating, the CPU fan
is monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
ØTemperature Monitoring -This item allows users to make sure whether
the CPU or system runs in a suitable temperature.
ØCPU Fan AutoGuardian -This SMART Bios enabled 3 phase Variable
Fan Speed and CPU temperature Control feature.

- 11 -
3HARDWAREINSTALLATION
Before removing or installing any of these devices including CPU, DIMMs,
Add-On Cards, Cables, please make sure to unplug the onboard power
connector.
This section outlines how to install and configure your mainboard. Refer to the following
mainboard layout to help you to identify various jumpers, connectors, slots, and ports.
Then follow these steps designed to guide you through a quick and correct installation of
your system.
3.1 Step-by-Step Installation
Accessories Of FB61
C
A
R
6
1
D
-
5
6
0
0
3
0
2
9
8
5
2
6
0
7
C
F
I
C
S
S
S
T
4
9
L
F
0
0
4
A
3
3
-
4
C
-
N
H
0
2
0
6
0
5
3
-
B
USB4
JP13
JP1
SPDIF
JP3
JP6
JP11
PCI1
AGP
FAN1
1
1
1
1
1
1
1
1
1
JP8
IDE1
FDD
IDE2
ATX1
ATX2
DIMM1
FAN2
JP7
IR
DIMM2
-
VT6307
0244CD TAIWAN 12G0352000
cAmMega 87-9
6
MFNW83
R
t
9
2
4
1
C
S
4
E
H
1
C
F
3
0
4
0
0
1
8
Q
E
4
1
E
S
I
N
T
E
L
0
1
I
n
t
e
l
S
E
C
R
E
T
F
W
2
8
0
1
E
B
P
H
I
L
I
P
P
I
N
E
S
RTL8100B 2B051S1 245ETAIWAN
1
FAN3
1
1
MFL8J.01
CMI9739A
UYD1HG
0245
1
JP16
JP5
1
PS/2 Keyboard/Mouse Connectors
COM1 & VGA Connectors
LAN & USB1.1/2.0 Connectors
1394 & USB1.1/2.0 Connectors
IRHeader-
JP7
One PCI Slot
OneAGPSlots
Front Panel Connector
- JP16
Clear CMOS- JP1
Front-Panel Connector
- JP13
Extended USB 2.0
Headers - USB4
Two184-pinDDR-SDRAMDIMM Sockets
Two IDE Connectors - IDE1/IDE2
One FloppyConnector
ATX Power Connector- ATX1
FAN2
SOCKET 478
FAN3
Center/Bass/Rear-Out/Front-OutHeader
SPDIF IN/OUT Connector- JP3
ATX+12VPowerConnector-
ATX2
Intel 82801EB Chipset
Intel 82865G Chipset
SerialATA Connectors
- SATA1/ATA1
EXT. Print Port- JP8
CD-IN Connector- JP11
FA N1
Wireless KB/MS Connector - JP6
I
T
E
8
7
1
2
F

- 12 -
Step 1
CPU Installation:
This mainboard supports Intel Pentium 4/Celeron Socket 478 series CPU.
Please follow the steps as follows to finish CPU installation.
Note the CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket lever to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU
upper interface. Match Pin 1 and cut edge, and insert the CPU into the
socket.
3. Press down the CPU socket lever and finish CPU installation.
4. Intel Pentium 4/Celeron processors require a set of heatsink and fan to cool
down the processor. You need to purchase a heatsink and fan if they are not
bundled with your CPU. Required is that install the set and plug its cable
in the CPU fan power connector. Note that there are kinds of CPU fan
connectors. Normally, if your mainboard supports a hardware monitoring
function, a 3-pin fan power connector can have your system detect the
CPU fan's speed. A CPU fan with a 2-pin or 4-pin fan power connector
does not support the detection of the CPU fan's speed, and must directly
be connected to the system's power supply unit.
CPU socket lever up to
90-degree angle
CPU Pin 1 and cut edge
Note: The CPU might be
damaged if you do not match
the CPU socket Pin 1 and cut
edge well.

- 13 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings have been set
for the common usage standard of this mainboard. Therefore, you do not
need to reset the jumpers unless you require special adjustments as any of
the following cases:
1. Clear CMOS
For first-time DIY system builders, we recommend that you do not change
the default jumper settings if you are not totally familiar with the mainboard
configuration procedures. The factory-set default settings are tuned for
optimum system performance. For the advanced users who wish to
customize their system, section 3.2 Jumper Settings will provide detailed
information on how to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert DDR SDRAM memory module(s) in DIMM slot(s).
Note that DDR SDRAM modules are directional and will not go in the DIMM
slots unless properly oriented. After the module is fully inserted into the
DIMM slots, lift the clips of both sides of the DIMM slot to lock the module in
place.
DDR SDRAM

- 14 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral devices into
the computer housing, including but not limited to the hard disk drive (IDE/
HDD), floppy disk drive (FDD), CD-ROM drive, and ATX power supply unit.
This will greatly facilitate in making the connections to the mainboard de-
scribed below.
To install IDE & FDD drives, follow this procedure:
1. Set the required jumpers on each device according to the instructions
provided by the manufacturer. (IDE devices, HDD, and CD-ROM, have to
set jumpers to Master or Slave mode depending on whether you install
more than one device of each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral devices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
the device as well.
3. Connect an available power cable from your system power supply unit
to the back-panel of each peripheral device. Note that the power cable is
directional and cannot fit in if not properly positioned.

- 15 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose
correct mounting holes, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of the chassis and the mainboard. The studs are used to fix
the mainboard and to keep a certain distance between the system's
chassis and the mainboard, in order to avoid any electrical shorts
between the board and the metal frame of the chassis. (If your computer
case is already equipped with mounting studs, you will need to tighten
screws to attach the mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachment points to install mounting studs and then fix the
mainboard. If there aren't enough matching holes, then make sure
to install at least 4 mounting studs to ensure proper attachment of
the mainboard.

- 16 -
Step 6
Connect Front Panel Switches/LEDs
You can find there are several different cables already existing in the system
case and originatinting from the computer's front-panel devices (HDD LED,
Power LED,or Reset Switch devices etc.) These cables serve to connect the
front-panel switches and LEDs connectors to the mainboard's front-panel
connectors group, as shown below.
1. ATX Soft Power On/Off (PWON)
2. HDD-LED (HLED)
3. Green-LED and Power-LED (GLED/PLED)
4. Hardware Reset Switch Button (RST)
1
JP13
Front Panel
P
W
O
N
G
L
E
D
/
P
L
E
D
R
S
T
H
L
E
D
-
+
-
+
-
+
1
Front Panel-JP13
-
+
-+
+-
RST
HLED
GLED
PLED
PWON
1
3
4
2
