Shuttle Spacewalker AV45GT User manual

AV45GT/AV45GTR
Pentium 4 Processor
Based DDR MAIN BOARD
User's Manual

Shuttle®SpacewalkerTM AV45GT/AV45GTR
Pentium 4 , 478-pin processor based DDR Mainboard
Manual Version 2.0
Copyright
Copyright©2002 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
VIA is a registered trademark of VIA Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M519

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
FIRST-TIMEDIYSYSTEMBUILDER ............................................................6
EXPERIENCEDDIY USER .........................................................................6
SYSTEMINTEGRATOR ...............................................................................6
1.2 ITEM CHECKLIST:.......................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................11
3.1 STEP BY STEP INSTALLATION................................................................ 11
Accessories of AV45GT/AV45GTR .......................................................11
STEP1 Installthe CPU...........................................................................12
STEP 2 Set Jumpers..............................................................................14
STEP3 InstallDDR SDRAM SystemMemory ........................................14
STEP4 Install Peripheralsin System Case.............................................15
STEP5 Mount theMainboard ontheComputer Chassis ........................16
STEP6 Connect FrontPanel Switches/LEDs/Speaker/USB ..................17
STEP 7 Connect IDE, IDE RAID(AV45GTR only), and Floppy Disk Drives ....18
STEP8Connect OtherInternal Peripherals ............................................19
STEP9 Connectthe Power Supply ........................................................19
STEP10 Install Add-onCards inExpansion Slots ..................................20
STEP11 ConnectExternalPeripherals toBack-Panel............................21
STEP 12 First Time System Boot Up......................................................22
STEP13 InstallDrivers & SoftwareComponents ....................................23
TABLE OF CONTENTS

- 2 -
3.2 JUMPER SETTINGS ..................................................................................24
JUMPERS& CONNECTORSGUIDE ....................................................25
Jumpers
Clear CMOS Setting (JP1) ....................................................................28
Onboard RAIDEnable/Disable Setting (JP2)(AV45GTRonly) ...............28
BIOSWrite Protection Setting(JP4) .......................................................29
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................30
USBPort 1/2 Connectors .......................................................................30
COM1/2Port Connectors .......................................................................30
ParallelPort Connector...........................................................................30
Line-Out(Front-Out)PortConnector .......................................................31
Line-In(Rear-Out)PortConnector...........................................................31
Mic-In PortConnector .............................................................................31
MIDI/GAMEPortConnector....................................................................31
Front-Panel Connectors
ATXPower On/OffSwitch Connector(Power ON)...................................32
SystemManagement InterfaceConnector (EPMI) ...................................32
Green LED/Power LED Connector (Green LED/Power LED) .................33
HDD LED Connector (HDD LED)...........................................................33
Power LED Connector (Power LED) ......................................................34
HardwareReset Connector(Reset) ........................................................34
SpeakerConnector (Speaker)................................................................34
ExtendedUSB Headers (JUSB1/3/4).....................................................35

- 3 -
Internal Peripherals Connectors
EnhancedIDE,IDE RAID(AV45GTR only),and FloppyConnector .........36
Other Connectors
ATXPower Supply Connector (J9,J10, J11, andA1)..............................37
CoolingFan Connectors forCPU (FAN1),System (FAN2),
Chipset(FAN3) ......................................................................................38
IRHeader (J12) ......................................................................................38
Wake-on LanConnector (WOL1)............................................................39
AudioCD-IN Connector(J7) (Black) /(J18) (White) ................................39
AudioAuxiliary-INConnector (J8)(White) ...............................................39
AudioBass/Center-Out Header(J14) .....................................................40
SPDIFExt/In/OutHeaders (J15/J16/J17)(optional) ................................40
3.3 SYSTEM MEMORY CONFIGURATION ......................................................41
1.INSTALL MEMORY.............................................................................41
2.UPGRADE MEMORY.........................................................................41
4 SOFTWARE UTILITY .......................................................................42
4.1 Mainboard CD Overview ..........................................................................42
4.2 Install Mainboard Software ......................................................................43
4.2.A InstallVIA4-IN-1Driver ......................................................................44
4.2.B InstallAudio Driver............................................................................45
InstallWINNTAudioDriver ...................................................................46
4.2.C InstallRAIDDriver andUtility (AV45GTRonly)...................................48
4.3 Install USB 2.0 Driver ...............................................................................49
4.4 View the User's Manual............................................................................50

- 4 -
5 BIOS SETUP.....................................................................................51
5.1 ENTER BIOS ..............................................................................................51
5.2 THE MAIN MENU .......................................................................................52
STANDARD CMOS FEATURES ................................................................54
ADVANCED BIOS FEATURES..................................................................57
ADVANCED CHIPSET FEATURES ...........................................................61
INTEGRATEDPERIPHERALS...................................................................65
POWERMANAGEMENT SETUP ..............................................................68
PNP/PCICONFIGURATION .......................................................................72
PC HEALTH STATUS.................................................................................74
FREQUENCY/VOLTAGECONTROL..........................................................75
LOAD FAIL-SAFE DEFAULTS...................................................................77
LOADOPTIMIZED DEFAULTS ..................................................................77
SET SUPERVISOR PASSWORD ..............................................................78
SET USER PASSWORD ...........................................................................78
SAVE & EXIT SETUP.................................................................................79
EXITWITHOUTSAVING.............................................................................79

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look ...................................................... Page 24
Drivers/Software Utilities >> How to Install ......................................... Page 42
BIOS Setup >> How to Configure ........................................................ Page 51
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we ha e designed the 3.1 Hardware Installation
section in a step-by-step fashion for all the first-time DIY system builders. Prior
to installation, we also suggest you to read the whole manual carefully to gain a
complete understanding of your new Shuttle AV45GT/AV45GTR mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AV45GT/AV45GTR mainboard.
You will find that installing your new Shuttle AV45GT/AV45GTR mainboard is
just easy. Bundled with an array of onboard functions, the highly-integrated
AV45GT/AV45GTR mainboard pro ides you with a total solution to build the
most stable and reliable system. Refer to sections 3.2 Jumper Settings and Chap-
ter 4 Drivers/So tware Utilities to find out how to get the best out of your new
mainboard. Chapter 5 BIOS Setup also contains the rele ant information on
how to tune up your system to achie e higher performance.
System Integrator
You ha e wisely chosen Shuttle AV45GT/AV45GTR to construct your system.
Shuttle AV45GT/AV45GTR incorporates all the state-of-the-art technology of
the P4X266A chipset from VIA. It integrates the most ad anced functions you
can find to date in a compact ATX board.
1INTRODUCTION
This manual adopted in AV45GT and AV45GTR mainboards at the same
time. The difference between AV45GT and AV45GTR is that AV45GTR
equips with onboard IDE RAID Controller. In the manual, if there are some
standards, characters, equipment or software only appeared or adopted by
AV45GTR; it will be mentioned (AV45GTR only)

- 7 -
1.2 Item Checklist:
Check all items with you AV45GT/AV45GTR mainboard to make sure
nothing is missing. The complete package should include:
One piece of Shuttle AV45GT/AV45GTR Mainboard
One piece of Audio Cable (Central/Bass Channel)
One piece of ATA 133/100/66/33 Ribbon Cable
One piece of Floppy Ribbon Cable
One piece of twin ports USB Cable (optional)
AV45GT/AV45GTR Users Manual
One piece of Bundled CD-ROM with containing:
Ø AV45GT/AV45GTR users manual sa ed in PDF format
Ø IDE RAID users manual sa ed in PDF format (AV45GTR only)
Ø VIA 4-IN-1 dri er
Ø Hardware Audio dri er
Ø IDE RAID dri er and Utility (AV45GTR only)
Ø USB 2.0 dri er
Ø Award Flashing Utility
KB1
USB1
JUSB1
JUSB3
JUSB4
1
1
1
1
1
1
J7
J18
J8
J12
1
1
1
1
Panasonic
CR20 32
3V
JAPAN1
IT8705F
0115-BXA
M3Q040
FAN1
FAN2
1
1
1
1
1
1
J5
Green
LED
Power
LED
HDD
LED
+
+- + -+ -
-
EPMI ResetSpeaker
Power
ON
Power
LED
DIM1
J11
DIM2
DIM3
1
1
1
1
1
1
FDD1
AUXPWR
J10
AJ1
J6
J9
A1
JP1
JP2
JP4
VT6202 0202CD TAIWAN23A50001700
WOL1
1
J14
JP3
AGP1
1
1
1
1
1
1
CMI8738/PCI-6ch-LX
HRTF3DAudioMCX58.02-0110
UGGDA
HighPoint
HTP372
0115A914ES
UA130820 0203 93718CF
UA130820 0203 93718CF
J17
J16
J15
VT8233A
0152CD TAIWAN
2IA3006141

- 8 -
AV45GT/AV45GTR mainboard is carefully designed for the demanding PC user who
wants high performance and maximum intelligent features in a compact package.
2.1 Specifications
CPU Support
Intel Pentium 4, 478-pin processors with 400/533 MHz FSB.
Chipset
Features VIA P4X266A N.B. and VIA VT8233A S.B..
CPU FSB Configuration
Soft-configuration FSB (The FSB speed is software configurable from 100MHz
to 160MHz by 1MHz step in the Frequency/Voltage Control of BIOS setup
program.)
On Board Multi-Channel Hardware Audio Controller
Support 5.1 speakers, C3DX positional audio in 6 CH speaker mode.
HRTF-3D positional audio, supporting Direct Sound 3D and A3D interface.
Legacy SBPRO compatible.
On Board IDE RAID Controller (AV45GTR only)
Support RAID 0, RAID 1, RAID 0+1 function.
On Board USB 2.0 Controller
High performance USB 2.0 host with integrated USB 2.0 transcei er, which
supports high-speed, full-speed and low-speed signaling.
Integrated two USB 1.1 - OHCI and one USB 2.0 - EHCI compliant host
controllers works with all USB 1.1 and USB 2.0 de ices
Versatile Memory Support
Three 184-pin DIMM slots to support up to 3GB of PC1600 or PC2100
compliant DDR SDRAM module.
PCI Expansion Slots
Pro ides fi e 32-bit PCI slots.
AGP Expansion Slots
Pro ides one 32-bit AGP slot which supports up to 1X/2X/4X AGP de ices.
2 FEATURES

- 9 -
8 USB Interface Onboard
Ø2 × USB connectors on back-panel.
ØOne sets of dual USB1.1 ports header and two sets of dual USB2.0 ports
header on mid-board.
I/O Interface
Pro ides a ariety of I/O interfaces:
Ø1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
format or for 5.25-inch FDD with 360K or 1.2MB format.
Ø1 × PS/2 mouse connector.
Ø1 × PS/2 Keyboard connector.
Ø2 × DB9 Serial connectors 16550 UART compatible.
Ø1 × Infrared communication port.
(Serial port COM2 can also be redirected to an external IrDA Adapter
for wireless connection.)
Ø1 × DB25 Parallel port supports Standard Parallel Port and Bi-directional
(SPP), Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)
data transmission schemes.
Ø1 × Line-Out (Front-Out) port.
Ø1 × Line-In port, shared with rear speaker output when multi-channel
audio is enabled.
Ø1 × Mic-In port.
Ø1 × MIDI/GAME port.
PCI Bus Master IDE Controller Onboard
Two Ultra DMA 133/100/66/33 Bus Master Dual-channel IDE ports pro ide
support to a maximum of four IDE de ices (one Master and one Sla e per chan-
nel). The IDE Bus implements data transfer speeds of up to 133/100/66/33 MB/
sec and also supports Enhanced PIO Modes.
80-pin Cable Backward Compatible Legacy ATAPI De ices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.
ATX Power Supply Connector
ATX power supply unit can connected to the onboard 20-pin Pentium 4
standard ATX power connectors, supporting Suspend and Soft-On/Off by
dual-function power button.
The Pentium 4 ATX power include three connectors.

- 10 -
Advanced Configuration and Power Interface
Features four power sa ing modes: S1 (Snoop), S3 (Suspend to RAM), S4
(Suspend to DISK), and S5 (Soft-Off). ACPI pro ides more efficient Energy
Sa ing Features controlled by your operating system that supports OS Direct
Power Management (OSPM) functionality.
System BIOS
Pro ides licensed Award BIOS V6.0 PG on Intel Firmware Hub 2Mb Flash
core and supports Green PC, Desktop Management Interface (DMI).
ATX Form Factor
System board conforms to ATX specification.
Board dimension: 305mm × 244mm.
Advanced Features
ØLow EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
ØDual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enters Soft-Off mode.
ØCPU Clock Setting - This item allows users to adjust CPU Host Clock in
BIOS.
ØCPU Multiplier Setting - This item allows users to adjust CPU Multiplier in
BIOS.
ØCPU Vcore Setting - This item allows users to select CPU Vcore in BIOS.
ØDDR/Chipset Voltage Setting - This item allows users to select DDR /
Chipset Voltage in BIOS.
Intelligent Features
ØVoltage Monitoring - Monitors arious oltages of key elements, such as
the CPU, and other critical system oltage le els to ensure stable current
passing through mainboard components.
ØFan Status Monitoring - To pre ent CPU from o erheating, the CPU fan is
monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
ØTemperature Monitoring - This item allows users to make sure whether the
CPU or system runs in a suitable temperature.

- 11 -
Before removing or installing any of these devices including CPU, DIMMs, Add-On
Cards, Cables, lease make sure to un lug the onboard ower connector.
This section outlines how to install and configure your mainboard. Refer to the following
mainboard layout to help you to identify various jumpers, connectors, slots, and ports.
Then follow these steps designed to guide you through a quick and correct installation of
your system.
3.1 Step-by-Step Installation
3HARDWAREINSTALLATION
Accessories Of AV45GT/AV45GTR
KB1
USB1
DIMM1
DIMM2
DIMM3
JUSB1
JUSB3
JUSB4
USB 3 & 4
USB2.0 3 & 4
USB2.0 1 & 2
1
1
1
1
1
1
J7
J18
J8
J12
1
1
1
1
Panasonic
CR2032
3V
JAPAN1
IT8705F 0115-B XA M 3Q040
FAN3
FAN1
FAN2
1
1
1
1
1
1
J5
Green
LED Po wer
LED
HDD LED
+
+-
+
-+
-
-
EPMI ResetSpeaker
Po wer
ON
Po wer
LED
DIM1
J11
ATX PWR
DIM2
DIM3
ID E4 RA ID 2
ID E1
ID E2
ID E3 RA ID 1
1
1
1
1
1
1
FDD1
FDC
AU XPWR
J10
AJ 1
J6
J9
A1
ATX 12V
AGP
PCI1
PCI2
PCI3
PCI4
PCI5
JP1
JP2
JP4
V T 62 02
0 2 0 2 C D T A IW A N
23 A 5 00 01 70 0
WOL1
1
WOL
IR
P4X 2 66 A
0125CD TAIWAN
2JA0001424
J14
AGP1
1
1
1
1
1
C MI 8 73 8/P C I- 6 ch -LX HRTF3D Audio MCX58.02- 0110 UGG DA
AUX _IN
CD-IN
CD-IN
BASS
High Point HTP37 2 0115 A914ES
UA 130820
0203
93718C F
UA 130820
0203
93718C F
J17 J16
J15
VT8233A
0152CD TAIW AN
2IA3006141
Five PCI Slots
On Board Multi-Channel
Hardware Audio Controller
One AGP 1x/2x/ x Slot
SOCKET 78
FAN2
Two USB Connectors
Extended USB 1.1 Header -
JUSB1
Extended USB 2.0 Headers -
JUSB3/JUSB4
Extended USB 2.0
Controller
On Board RAID Enable/Disable Header -
JP 2
(AV45GTR only)
Parallel Connector
Serial Port
Connector (COM1)
Serial Port
Connector (COM2)
Line-Out/Line-In/Mic-In/
Game/MIDI Connectors
Onboard Audio
Connectors-
J7/J18/J8/J14
SPDIF Ext/In/Out Headers -
J15/J16/J17
(optional)
PS/2 Keyboard and
PS/2 Mouse Connectors
I/O Controller
Three 18 -pin DDR-SDRAM DIMM Sockets
FAN1
FAN3
ATX Power Connector
- J11
ATX -
J /A1
12V Power Connector
ATX AUX Power Connector -
J10
Front-Panel Connector - J5
IR -
J12
Header
Wake-on LAN -
WOL1
BIOS Write Protection -
JP 4
Clear CMOS - JP1
Programmable Flash
EEPROM
VIA VT8233A Chipset
On Board HighPoint 372 IDE RAID Controller
(AV45GTR only)
Floppy Connector
Two E-IDE Connectors
Two RAID Connectors
( only)
AV45GTR
VIA P X266A Chipset
DDR Clock Buffer
Main Clock Generator

- 12 -
Step 1
CPU Installation:
This mainboard supports Intel® Pentium® 4 Socket 478 series CPU. Please
follow the step as below to finish CPU installation.
Be careful of CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket le er and up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU
upper interface. Match Pin 1 and cut edge, then insert the CPU into the
socket. CPU pin 1 and cut edge
CPU socket lever up to
90 degree

- 13 -
3. Press down the CPU socket le er and finish CPU installation.
Note: If you do not match the CPU socket Pin 1 and CPU cut
edge well, it may damage the CPU.

- 14 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings ha e been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as any of the
following cases:
1. Clear CMOS
2. BIOS Write Protection
3. Enable/Disable IDE RAID
For first-time DIY system builders, we recommend that you do not change the
default jumper settings if you are not totally familiar with the mainboard
configuration procedures. The factory-set default settings are tuned for opti-
mum system performance. For the ad anced users who wish to customize
their system, section 3.2 Jumper Settings will pro ide detailed information on
how to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert DDR SDRAM memory module(s) in any one or two
or three DIMM banks. Note that DDR SDRAM modules are directional and
will not go in the DIMM banks if they are not properly oriented. After the
module is fully inserted into the DIMM bank, lift the clips of both sides of the
DIMM bank to lock the module in place.

- 15 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral de ices into the
computer housing, including but not limited to the hard disk dri e (IDE/
HDD), floppy disk dri e (FDD), CD-ROM dri e, and ATX power supply unit.
This will greatly facilitate in making the connections to the mainboard de-
scribed below.
To install IDE & FDD dri es, follow this procedure:
1. Set the required jumpers on each de ice according to the instructions
pro ided by the manufacturer. (IDE de ices, HDD, and CD-ROM, ha e to
set jumpers to Master or Sla e mode depending on whether you install
more than one de ice of each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral de ices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
the de ice as well.
3. Connect an a ailable power cable from your system power supply unit
to the back-panel of each peripheral de ice. Note that the power cable is
directional and cannot fit in if not properly positioned.

- 16 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose
correct mounting holes, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of the chassis and the mainboard. The studs are used to fix the
mainboard and to keep a certain distance between the system chassis
and the mainboard, in order to a oid any electrical shorts between the
board and the metal frame of the chassis. (If your computer case is
already equipped with mounting studs, you will need to tighten screws to
attach the mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachment points to install mounting studs and then fix the
mainboard. If there arent enough matching holes, then make sure to
install at least 4 mounting studs to ensure proper attachment of the
mainboard.

- 17 -
Step 6
Connect Front Panel Switches/LEDs/Speaker/USB
You can find there are se eral different cables already existing in the system
case and originating from the computers front-panel de ices (HDD LED,
Power LED, Reset Switch, PC Speaker, or USB de ices etc.) These cables
ser e to connect the front-panel switches, LEDs, and USB connectors to the
mainboards front-panel connectors group (J5 and JUSB1/3/4), as shown
below.
1. ATX Soft Power On/Off (Power ON)
2. System Management Interface Button (EPMI)
3. Green-LED/Power-LED (Green LED/Power LED)
4. HDD-LED (HDD LED)
5. Power LED (Power LED)
6. Hardware Reset Switch Button (Reset)
7. PC Speaker (Speaker)
8. Extended USB Headers
Green
LED Power
LED
HDD LED
+
+
+
+
-
-
--
-
EPMI ResetSpeaker
Power
ON
Power
LED
1
1
3
5
4
2
7
6
J5
Green
LED Power
LED
HDD LED
+
+
-
+
-
+
-
-
EPMI ResetSpeaker
Power
ON
Power
LED
1
1
JUSB1
JUSB3
JUSB4
USB 3 & 4
USB2.0
3 & 4
USB2.0 1 & 2
1
1
1
KEY GND +5V DATA+ DATA- KEY GND +5V DATA+ DATA-
NC
GND
+5V
DATA+
DATA-
NC
GND
+5V
DATA+
DATA-
11
USB1.1 port3 USB2.0 port1/3
USB1.1 port4 USB2.0 port2/4
8

- 18 -
Step 7
Connect IDE, IDE RAID (AV45GTR only), and Floppy Disk Drives
1. IDE cable connector
2. IDE RAID cable connector (AV45GTR only)
3. Floppy cable connector
IDE1IDE2
1
1
IDE4 RAID2
IDE3 RAID1
1
1
1
FDD1
FDC
