Shuttle Spacewalker AV40 User manual

AV40/AV40R
Pentium 4 Processor
Based MAIN BOARD
User's Manual

Shuttle®SpacewalkerTM AV40/AV40R
Pentium 4 , 478-pin processor based AGPset Mainboard
Manual Version 1.0
Copyright
Copyright©2001 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
VIA is a registered trademark of VIA Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M473

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
FIRST-TIMEDIYSYSTEMBUILDER ............................................................6
EXPERIENCEDDIY USER .........................................................................6
SYSTEMINTEGRATOR ...............................................................................6
1.2 ITEM CHECKLIST:.......................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................11
3.1 STEP BY STEP INSTALLATION................................................................ 11
Accessories of AV40/AV40R.................................................................11
STEP1 Installthe CPU...........................................................................12
STEP 2 Set Jumpers..............................................................................14
STEP3 InstallDDR SDRAM SystemMemory ........................................14
STEP4 Install Peripheralsin System Case.............................................15
STEP5 Mount theMainboard ontheComputer Chassis ........................16
STEP6 Connect FrontPanel Switches/LEDs/Speaker/USB ..................17
STEP7 Connect IDE, IDE RAID,andFloppy Disk Drives .......................19
STEP8Connect OtherInternal Peripherals ............................................20
STEP9 Connectthe Power Supply ........................................................21
STEP10 Install Add-onCards inExpansion Slots ..................................21
STEP11 ConnectExternalPeripherals toBack-Panel............................22
STEP 12 First Time System Boot Up......................................................24
STEP13 InstallDrivers & SoftwareComponents ....................................25
TABLE OF CONTENTS

- 2 -
3.2 JUMPER SETTINGS ..................................................................................26
JUMPERS& CONNECTORSGUIDE ....................................................27
Jumpers
Clear CMOS Setting (JP1) ....................................................................30
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................31
USB1/USB2Port Connectors.................................................................31
COM1/2Port Connectors .......................................................................31
ParallelPort Connector...........................................................................31
Line-Out PortConnector .........................................................................32
Line-InPortConnector............................................................................32
Mic-In PortConnector .............................................................................32
MIDI/GAMEPortConnector....................................................................32
Front-Panel Connectors
ATXPower On/OffSwitch Connector(Power ON)...................................33
SystemManagement InterfaceConnector (EPMI) ...................................33
GreenLED Connector (GreenLED) .......................................................34
HDD LED Connector (HDD LED)...........................................................34
Power LED Connector (Power LED) ......................................................34
HardwareResetConnector(RST) ..........................................................35
Speaker Connector (SPEAKER)............................................................35
ExtendedUSB Header (JUSB1/JUSB2).................................................36
Internal Peripherals Connectors
EnhancedIDE, IDERAID,and FloppyConnector ...................................37

- 3 -
Other Connectors
ATXPower Supply Connector(J9, J10, andJ11)....................................38
CoolingFan Connectors forCPU (FAN1),System (FAN2),
Chipset(FAN3) ......................................................................................39
IRHeader (J12) ......................................................................................39
Wake-on LanConnector (WOL1)............................................................40
AudioCD-IN Connector(J7) (Black) .......................................................40
AudioAuxiliary-INConnector (J8)(White) ...............................................40
AudioTAD-IN Connector(JP2) (Green) ..................................................41
3.3 SYSTEM MEMORY CONFIGURATION ......................................................42
1.INSTALL MEMORY.............................................................................42
2.UPGRADE MEMORY.........................................................................42
4 SOFTWARE UTILITY .......................................................................43
4.1 Mainboard CD Overview ..........................................................................43
4.2 Install Mainboard Software ......................................................................44
4.2.A InstallVIA4-IN-1Driver ......................................................................45
4.2.B InstallAudio Driver............................................................................46
4.2.C InstallIDE RAIDDriver (AV40Ronly).................................................47
4.3 View the User's Manual............................................................................48
5 BIOS SETUP.....................................................................................49
5.1 ENTER BIOS ..............................................................................................49
5.2 THE MAIN MENU .......................................................................................50
STANDARD CMOS FEATURES ................................................................52
ADVANCED BIOS FEATURES..................................................................56
ADVANCED CHIPSET FEATURES...........................................................59
INTEGRATED PERIPHERALS ...................................................................63

- 4 -
POWERMANAGEMENT SETUP ..............................................................67
PNP/PCICONFIGURATION .......................................................................71
PC HEALTH STATUS.................................................................................73
FREQUENCY/VOLTAGECONTROL..........................................................74
LOAD FAIL-SAFE DEFAULTS...................................................................76
LOADOPTIMIZED DEFAULTS ..................................................................76
SET SUPERVISOR PASSWORD ..............................................................77
SET USER PASSWORD ...........................................................................77
SAVE & EXIT SETUP.................................................................................79
EXITWITHOUTSAVING.............................................................................79

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look ...................................................... Page 26
Drivers/Software Utilities >> How to Install ......................................... Page 43
BIOS Setup >> How to Configure ........................................................ Page 49
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we ha e designed the 3.1 Hardware Installation
section in a step-by-step fashion for all the first-time DIY system builders. Prior
to installation, we also suggest you to read the whole manual carefully to gain a
complete understanding of your new Shuttle AV40/AV40R mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AV40/AV40R mainboard. You
will find that installing your new Shuttle AV40/AV40R mainboard is just easy.
Bundled with an array of onboard functions, the highly-integrated AV40/AV40R
mainboard pro ides you with a total solution to build the most stable and reli-
able system. Refer to sections 3.2 Jumper Settings and Chapter 4 Drivers/
Software tilities to find out how to get the best out of your new mainboard.
Chapter 5 BIOS Setup also contains the rele ant information on how to tune
up your system to achie e higher performance.
System Integrator
You ha e wisely chosen Shuttle AV40/AV40R to construct your system.
Shuttle AV40/AV40R incorporates all the state-of-the-art technology of the
P4X266 chipset from Intel. It integrates the most ad anced functions you can
find to date in a compact ATX board.
1INTRODUCTION
This manual adopted in AV40 and AV40R mainboards at the same time.
The difference between AV40 and AV40R is that AV40R equips with
onboard IDE RAID Controller. In the manual, if there are some standards,
characters, equipment or software only appeared or adopted by AV40R; it
will be mentioned (AV40R only)

- 7 -
1.2 Item Checklist:
Check all items with you AV40/AV40R mainboard to make sure nothing is
missing. The complete package should include:
One piece of Shuttle AV40/AV40R Mainboard
One piece of ATA 100/66/33 Ribbon Cable
One piece of Floppy Ribbon Cable
One piece of twin ports USB Cable (optional)
AV40/AV40R Users Manual
One piece of Bundled CD-ROM with containing:
Ø AV40/AV40R users manual sa ed in PDF format
Ø IDE RAID users manual sa ed in PDF format (AV40R only)
Ø VIA 4-IN-1 dri er
Ø VIA Audio dri er
Ø IDE RAID dri er (AV40R only)
Ø Award Flashing Utility
UJ01C-ES 01132 950202AF
PROMISE
PDC20265R
2000-0051
c
KB1
USB1
14.3C93
14.3C93
JUSB1
JUSB2
1
1
1
J7
J8
J12
JP2
1
1
1
1
Panasonic
CR2032
3V
JAPAN1
IT8705F
0115-BXA
M3Q040
FAN1
FAN2
1
1
1
J5
Green
LED
HDD
LED
+
+ + - -
-
EPMI RSTSPEAKER
Power
ON
Power
LED
ID E 4
DIM1
J11
DIM2
DIM3
ID E 3
1
1
1
1
1
1
FDD1
AUXPWR
J10
AJ1
J6
J9
TAD_IO
IN TERQUIP
66.666C3
C9AB
JP1
WOL1
1

- 8 -
AV40/AV40R mainboard is carefully designed for the demanding PC user who wants
high performance and maximum intelligent features in a compact package.
2.1 Specifications
CPU Support
Intel Pentium 4, 478-pin processors with 100 MHz FSB.
Chipset
Features VIA P4X266 N.B. and VIA VT8233 S.B..
Jumperless CPU Configuration
Soft-configuration FSB (The FSB speed is software configurable from 100MHz
to 132MHz by 1MHz step in the Frequency/Voltage Control of BIOS setup
program.)
AC'97 Link for Audio and Telephony CODEC
AC'97 2.1 compliant
Spread independent PCI functions for Audio and Modem
On Board IDE RAID Controller (AV40R only)
Support RAID 0, RAID 1 function.
Versatile Memory Support
Three 184-pin DIMM slots to support up to 1.5GB of PC1600 or PC2100
compliant DDR SDRAM module.
PCI Expansion Slots
Pro ides fi e 32-bit PCI slots.
AGP Expansion Slots
Pro ides one 32-bit AGP slot which supports up to 4X AGP de ices.
6 USB Interface Onboard
Ø2 × USB connectors on back-panel and two sets of dual USB ports headers
on mid-board.
2 FEATURES

- 9 -
I/O Interface
Pro ides a ariety of I/O interfaces:
Ø1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
format or for 5.25-inch FDD with 360K or 1.2MB format.
Ø1 × PS/2 mouse connector.
Ø1 × PS/2 Keyboard connector.
Ø2 × DB9 Serial connectors 16550 UART compatible.
Ø1 × Infrared communication port.
(Serial port COM2 can also be redirected to an external IrDA Adapter
for wireless connection.)
Ø1 × DB25 Parallel port supports Standard Parallel Port and Bi-directional
(SPP), Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)
data transmission schemes.
Ø1 × Line-Out port.
Ø1 × Line-In port.
Ø1 × Mic-In port.
Ø1 × MIDI/GAME port.
PCI Bus Master IDE Controller Onboard
Two Ultra DMA 100/66/33 Bus Master Dual-channel IDE ports pro ide sup-
port to a maximum of four IDE de ices (one Master and one Sla e per channel).
The IDE Bus implements data transfer speeds of up to 100/66/33 MB/sec and
also supports Enhanced PIO Modes.
80-pin Cable Backward Compatible Legacy ATAPI De ices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.
ATX Power Supply Connector
ATX power supply unit can connected to the onboard 20-pin Pentium 4
standard ATX power connectors, supporting Suspend and Soft-On/Off by
dual-function power button.
The Pentium 4 ATX power include three connectors.
Advanced Configuration and Power Interface
Features four power sa ing modes: S1 (Snoop), S3 (Suspend to RAM), and S5
(Soft-Off). ACPI pro ides more efficient Energy Sa ing Features controlled by
your operating system that supports OS Direct Power Management (OSPM)
functionality.

- 10 -
System BIOS
Pro ides licensed Award BIOS V6.0 PG on Intel Firmware Hub 2Mb Flash
core and supports Green PC, Desktop Management Interface (DMI).
ATX Form Factor
System board conforms to ATX specification.
Board dimension: 305mm × 244mm.
Advanced Features
ØLow EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
ØDual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enters Soft-Off mode.
ØCP Clock Setting - This item allows users to adjust CPU Host Clock in
BIOS.
ØCP Multiplier Setting - This item allows users to adjust CPU Multiplier in
BIOS.
ØCP Vcore Setting - This item allows users to select CPU Vcore in BIOS.
ØDDR Voltage Setting - This item allows users to select DDR Voltage in
BIOS.
ØChipset Voltage Setting - This item allows users to select Chipset Voltage
in BIOS.
Intelligent Features
ØVoltage Monitoring - Monitors arious oltages of key elements, such as
the CPU, and other critical system oltage le els to ensure stable current
passing through mainboard components.
ØFan Status Monitoring - To pre ent CPU from o erheating, the CPU fan is
monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
ØTemperature Monitoring - This item allows users to make sure whether the
CPU or system runs in a suitable temperature.

- 11 -
Before removing or installing any of these devices including CP , DIMMs, Add-On
Cards, Cables, please make sure to unplug the onboard power connector.
This section outlines how to install and configure your mainboard. Refer to the following
mainboard layout to help you to identify arious jumpers, connectors, slots, and ports.
Then follow these steps designed to guide you through a quick and correct installation of
your system.
3.1 Step-by-Step Installation
3HARDWAREINSTALLATION
Accessories Of AV40/AV40R
UJ01C -ES
01132
950202AF
PRO MI SE
P DC2026 5R
2000-0 051c
KB1
USB1
14.3C93
14.3C93
DIMM1 DIMM2 DIMM3
JUSB1
JUSB2
USB 5&6
USB 3&4
1
1
1
J7
J8
J12
JP2




Panasonic
CR2032
3V
JAPAN1
IT8705F 0115-BXA M3Q040
FAN3
FAN1
FAN2
1
1
1
J5
Green
LED
HDD LED
+
+
+
-
-
-
EPMI RSTSPEAKER
Power
ON
Power
LED
IDE4
DIM1
J11
ATX PWR
DIM2 DIM3
IDE3
RAID2
ID E 1ID E 2
RAID1
1
1
1
11
1
FDD1
FDC
AUXPW R J10
AJ1
J6
J9
ATX12V
CD-IN
AUX-IN
TAD_IO
IN T ER Q UIP
66.666C 3
C9AB
AG P1
PCI1
PCI2
PCI3
PCI4
PCI5
JP1
WOL1 1
WOL
P4X266
0125CD TAIWAN
2JA0001424
Five PCI Slots
Onboard Audio CODEC
One AGP 4x Slot
SOCKET 478
FAN
Two USB Connectors
Extended USB 1.1 Headers - JU SB1/2
Parallel Connector
Serial Port
Connector (COM1)
Serial Port
Connector (COM )
Line-Out/Line-In/Mic-In/
Game/MIDI Connectors
Onboard Audio
Connectors- J7/J8/JP2
PS/ Keyboard and
PS/ Mouse Connectors
I/O Controller
Three DIMM Slots
FAN1
FAN3
ATX Power Connector
ATX 1 V Power Connector
ATX AUX Power Connector
Buzzer
Front-Panel Connector - J5
IR Connector - J12
Wake-on LAN - WOL1
Clear CMOS - JP1
Clock Generator
Programmable Flash
EEPROM (FWH)
VIA VT8 33 Chipset
On Board Promise 0 65R IDE RAID Controller (AV40R only)
Floppy Connector
Two E-IDE Connectors
Two RAID Connectors (AV40R only)
VIA P4X 66 Chipset

- 12 -
Step 1
CPU Installation:
This mainboard supports Intel® Pentium® 4 Socket 478 series CPU. Please
follow the step as below to finish CPU installation.
Be careful of CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket le el and up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU
upper interface. Match Pin 1 and cut edge, then insert the CPU into the
socket. CPU pin 1 and cut edge
CPU socket level up to
90 degree

- 13 -
3. Press down the CPU socket le el and finish CPU installation.
Note: If you do not match the CPU socket Pin 1 and CPU cut
edge well, it may damage the CPU.

- 14 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings ha e been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as any of the
following cases:
1. Clear CMOS
For first-time DIY system builders, we recommend that you do not change the
default jumper settings if you are not totally familiar with the mainboard
configuration procedures. The factory-set default settings are tuned for opti-
mum system performance. For the ad anced users who wish to customize
their system, section 3.2 Jumper Settings will pro ide detailed information on
how to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert SDRAM memory module(s) in any one or two or
three DIMM banks. Note that SDRAM modules are directional and will not
go in the DIMM banks if they are not properly oriented. After the module is
fully inserted into the DIMM bank, lift the clips of both sides of the DIMM
bank to lock the module in place.

- 15 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral de ices into the
computer housing, including but not limited to the hard disk dri e (IDE/
HDD), floppy disk dri e (FDD), CD-ROM dri e, and ATX power supply unit.
This will greatly facilitate in making the connections to the mainboard de-
scribed below.
To install IDE & FDD dri es, follow this procedure:
1. Set the required jumpers on each de ice according to the instructions
pro ided by the manufacturer. (IDE de ices, HDD, and CD-ROM, ha e to
set jumpers to Master or Sla e mode depending on whether you install
more than one de ice of each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral de ices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
the de ice as well.
3. Connect an a ailable power cable from your system power supply unit
to the back-panel of each peripheral de ice. Note that the power cable is
directional and cannot fit in if not properly positioned.

- 16 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose
correct mounting holes, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of the chassis and the mainboard. The studs are used to fix the
mainboard and to keep a certain distance between the system chassis
and the mainboard, in order to a oid any electrical shorts between the
board and the metal frame of the chassis. (If your computer case is
already equipped with mounting studs, you will need to tighten screws to
attach the mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachment points to install mounting studs and then fix the
mainboard. If there arent enough matching holes, then make sure to
install at least 4 mounting studs to ensure proper attachment of the
mainboard.

- 17 -
Step 6
Connect Front Panel Switches/LEDs/Speaker/USB
You can find there are se eral different cables already existing in the system
case and originating from the computers front-panel de ices (HDD LED,
Power LED, Reset Switch, PC Speaker, or USB de ices etc.) These cables
ser e to connect the front-panel switches, LEDs, and USB connectors to the
mainboards front-panel connectors group (J5 and JUSB1/2), as shown below.
1. Hardware Reset Switch Button (RST)
2. HDD-LED (HDD LED)
JUSB1
JUSB2
USB 5 & 6
USB 3 & 4
1
1
J5
Green
LED
HDD LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1

- 18 -
3. Green-LED (Green LED)
4. System Management Interface Button
(EPMI)
5. ATX Soft Power On/Off (Power ON)
6. Power LED (Power LED)
7. PC Speaker (SPEAKER)
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
J5
Green
LED
HDD
LED
+
++--
-
EPMI RSTSPEAKER
Power
ON
Power
LED
1
