SI Sensation Series User manual

Thank you for purchasing a Screen Innovations projection screen.
Before use, please read instructions carefully. After installation, store instructions for future reference.
U.S.Screen Corp.
2105 Denton Drive
Austin, TX 78758
P [phone]
F [phone]
www.screeninnovations.com
Installation Guide for
Sensation Series Fixed Frame Screen

16
4:3
16:9
80" 92" 100" 106"
24 26 28 30
22 24 28 28
Description
Accessories
Side frame
Horizontal frame
Screen fabric
Remark：Two extra Fixing lugs for each screen
Format Size(inch)
Qty(pcs)
Fixing lug
Top bracket
Horizontal frame (2pcs)
Side frame (2 )pcs
Horizontal tensioning bar (2 )pcs
Side tensioning bar (2 )pcs
Fixing lug (Ref. list 1)
5x60 mm Tapping screw (8pcs)
Corner bracket (4 )pcs
5x10mm Corner screw (16 )pcs
Instruction manual 1( pc)
Top bracket(1pc)
Fixing lug list 1
Qty(pcs)
Ignoring the safety warnings may
lead to injuries and/or damaging
the product.
Fixtures should be installed in a secure
place to avoid accidents or the screen
falling.
Please contact your local dealer for
repairs or maintenance. Please contact
our company if you have any further
questions. Avoid taking apart the
fixtures yourself. Loose parts may
cause the screen to fall.
Warnings
Do not take apart and replace with unknown parts. If there are any problems, please contact your local dealer.
Product specifications are subject to change.
When installing, make sure it is facing forward. The back of the screen will be labeled with a sticker.
Please read the following as any damage to the screen surface will affect the quality of the picture:
1.The frame is made with lightweight aluminum. Please handle with care.
2.Avoid contact or touching the screen surface as it may cause scratches or tears.
3.Do not write or draw on the surface.
4.Clean the screen with a soft cloth and lukewarm water. Do not use any detergent or cleaning products.
5.Use a cotton cloth to carefully wipe off the dust on the frame to prevent any damages
6.If it is not in use for a long period of time, cover the screen to shut out dust and dirt.
To prevent unnecessary damage, the operating and maintenance of the screen should be done by adults.
Installation Help Line [phone]
110"
30
30
120"
32
30
133”
34
34

2
5
1. Locate Horizontal frames and Side frames on tidy flat surface. (Figure 1)
2. Slide Fixing lugs into grooves on reverse side of frames and align with arrows. (Figure 2-3)
Figure 1
3. Connect Horizontal frame and Side frame with Corner bracket, adjust the Corner bracket to match screw
holes on frame and Corner backet, then fix with the Corner bracket screws. Same way to other 3 Corner
brackets installtion. (Figure 4-7)
Cor ner
7. Uplift the assembled screen to make sure Up groove meet with Top bracket, and the frames are matched
on brackets ideally. (Figure 19-20)
Up groove
Bottom groove
Take out all the parts from the packaging and follow the accessories guideline to ensure you have all parts,
then install the screen as below.
Installation
Side frame
Horizontal frame
Figure 2 Figure 3
Fixing lug
Side frame
Horizontal frame
Figure 4 Figure 5
Figure 6 Figure 7
Figure 19 Figure 20

34
5. Double align Fixing lugs with arrows. Using the Tensioning bar, pull fabric eyelets over Fixing lugs by your
hands clockwise (Tips: arrange Horizontal tensioning bars first then Side tensioning bars). (Figure 11-15)
6. The Top brackets' length is at half of Horizontal frames'. And there is 5 groups of holes on bracket with 10cm
distance, each group has 3 holes at 5 8 & 6 from left to right. Bracket is suggested to mount at the
middle point of frame with only 30% fluctuation if needed. (Figure 16)
Up bracket
10CM
4. Unfold screen fabric and insert 4 Tensioning bars seperately into 4 different fabric grooves, be careful not
to poke the fabric. (Figure 8-10)
Figure 8
Figure 10
Figure 9
5mm Tensioning
bar
Figure 11
Figure 12
Figure 13
Figure 14
Figure 15
Here below are the mounting details:
a) Wood wall mounting: to fix the bracket onto the wall using 2 provided Wooden screws 5 x 60. (Figure 17)
b) Concrete wall mounting: to use an electric drill to drill 2 holes and hammer the provided tapping anchors
into each hole, then fix the brackets onto the wall by fastening the tapping screws to the tapping anchors.
(Figure 18)
Figure 17 Figure 18
Figure 19
