Siemens LMV 5 Series User manual

User manual
Siemens LMV 5x
M12914CA Rev.0 03/2008

3
SIEMENS LMV CONTROLLED BURNERS
Keys
1 Burner
2 Combustion head actuator
3 Gas butterfly valve actuator
4 Oil pressure governor actuator
5 Air damper actuator
6 Siemens LMV burner control
7 Personal Computer
8Gastrain
9Inverter
10 Siemens AZL User interface
The control system is made of the Siemens LMV central unit (6) that performs all the burner control functions and of the Siemens AZL
local programming unit (10) that interfaces the system with the user.
Main features:
zno mechanical linkages
zbuilt-in burner control box
zbuilt-in gas proving system
zmore flame checking devices available for several applications
zPID load controller
zup to six actuators can be controlled. Each of them is independent for the best burner setup
zbest air/fuel ratio. Repeatability and precision of set adjustments
zModbus communication
zmultilevel password
zsettings via PC
zadjustable prepurging time (according to the relevant Standards)
zcontinuous ventilation
zpost purging (adjustable time)
zproving system settable to on and off
zadjustable proving system time for all the valve volumes
zload controller settable to on and off
zthermal shock protection function settable to on and off (for cold starts)
zcontinuous operation and flame detection probe
Note: the picture above shows a complete control system.
12
3
5
4
6
7
8
9
10

4
USER SETTINGS
Go on adjusting the burner.
Users can set only the LMV parameters that can be accessed without password: (see “Adjusting the temperature set-point”).
The Siemens AZL User Interface allows programming the Siemens LMV control box and monitoring the system data.
The user interface is made of:
1. display: it showes menus and parameters
2. ESC key (previous level): it goes back to the prevoius level menu or exits the programming mode without changing data.
3. ENTER key (next level): it confirms the data changing and jumps to the next menu/parameter.
4. SELECT keys: they select a menu item and change the parameter values.
To know the actuator functions, proceed as follows:
1 remove the actuator covers
2 check the number of the LV green LED blinks for each actuator:
Blinks Actuator function
1 blink air damper actuator
2 blinks gas butterfly valve actuator
3 blinks oil pressure governor actuator
4 blinks auxiliary actuator
5 blinks auxiliary actuator
6 blinks auxiliary actuator
CAUTION: it is recommended not to adjust the actuators. Anyway, never press the actuator red button, otherwise the fun-
damental parameters, necessary for the burner operation, will be cancelled. The burner will therefore continuously lock out.
1
2
3
4
LV

5
Start-up procedure
1 Turn the burner on according to the following:
zual fuel burners: choose the requested fuel by means of the related control panel switch
zone fuel burners: turn the burner on by means of the burner main switch (placed on the burner control panel)
2 the LMV controller starts the system test cycle: the AZL display shows the System Test message; at the end of the test, it shows
the main page and the system stops (the safety chain is open) waiting for the startup enabling signal (standby - Program phase no.
12)
3 check the fan motor rotation;
4 (light/heavy oil burners) with the electrical panel open, prime the oil pump acting directly on the related CP contactor (see next pic-
ture): check the pump motor rotation and keep pressing for some seconds until the oil circuit is charged;
5 bleed the air from the Mpressure gauge port (see next picture) by loosing the cap without removing it, then release the contactor.
6 make the safety chain enabling the system to start up
7 the combustion cycle starts:
- Prepurging (program phase no.30)
- Driving to ignition position (program phase no.36)
- Ignition position (program phase no.38)
- Fuel (the fuel solenoid valves open)
- Flame (the flame lights up)
- Driving to low flame (the actuator drives to low flame).
NOTE: the C and A, on the .
Once the ignition cycle ends, the main page is shown:
Suntec T..
Main page
Setpoint 80°C
Act value
78°C
Fuel GAS
CP
M
VR

6
Set point: temperature set-point
Act value: actual temperature value
Load: load percentage (burner output)
Flame: percentage of flame detection current.
By pressing the ENTER key the display shows the second page:
Fuel: it shows (in degrees) the fuel actuator position.
Air: it shows (in degrees) the air actuator position.
Ax1..3: auxiliaries.
VSD: % value on the inverter maximum frequency
O2: oxygen percentage
Ld: load percentage (burner output).
Press the ENTER key to go back to the main page.
To access the main menu, from the main page, press the ESC key twice:
By pressing the ESC key once, the Operational Status (first item in the main menu) menu is directly shown:
the Operational Status menu provides the following items:
Normal operation: by selecting this item and pressing the ENTER key, the main page is shown; press ESC to go back to the main
menu.
Status/Reset: it shows system errors or faults occuring / it represents the lockout reset function.
Fault History: by selecting this item and pressing the ENTER key, the Lockout History will be shown about the last 21 faults occured.
Lockout History: by selecting this item and pressing the ENTER key, the Lockout History will be shown about the last 9 lockouts
occured, and the related date and hour.
Alarm act/deact: enable/disable the horn in case of alarm.
Main page
Setpoint 80°C
Act value
78°C
Load 24%
Second page
Fuel 0.0 Air 1.8
Ax1 VSD 0.0
Ax2 O2
Ax3 Ld 0.0
Operational status
Operation
Manual Operation
Params& Display
Main menu
Normal operation
Status/Reset
Fault History
Lockout History

7
Fault History
To visualise the Fault History, select it and press the ENTER key. The message will be as:
alternating by an error message as:
To see the other Fault History pages, press the arrow keys.
To exit the Fault History pages, press ESC.
Lockout History
To visualise the Lockout History, choose the related item and press ENTER. The message will be:
alternating by an error message as:
To see the other Lockout History pages, press the arrow keys.
To exit the Lockout History pages, press ESC.
Setting the temperature set-point value
To set the temperature set-point value, that is the generator operating temperature; proceed as follows.
From the main page, enter the main menu by pressing the ESC key twice:
by means of the arrow keys, select “Params&Display”, press ENTER: the system will ask you to enter the proper password
1 Class: 05Gas
Code BF Phase: 10
Diag.: 00 Lod: 0.0
Start No. 88
O2 control and
limiter automat
deactivated
1 10.08.07 13.47
C:71 D:00 F: 12
Start No: 88
Load 0.0 Gas
No flame at end
of safety time
Operational Status
Operation
Manual Operation
Params& Display

8
by means of the arrow keys, select “Access w-out pass” (access without password - user level), confirm by pressing ENTER.
The other levels require password reserved to the Technical Service, to the Manifacurer, etc.
The menu accessed without password is the following:
Choose “LoadController” and press ENTER: the following menu is shown:
Choose “ControllerParam” and press ENTER: the following menu is displayed:
Choose “SetPointW1” and press ENTER:
Curr: it shows the current set-point; use the arrows keys to change it.
NOTE: the available range depends on the probe used; the measure unit of the detected data and its relevant limits are set by “Service”
level parameters.
Once the new set-point is set, confirm by pressing ENTER, otherwise exit without changings by pressing ESC.
Press ESC to exit the set-point programming mode.
Once the temperature set-point W1 is imposed, set the Switch-on (SDon) and the Switch-off (SDoff) point of the 2-position controller:
To set these values, select the item SD_ModOn (SDOn), by scrolling down the “Load controller” menu with the arrow keys and press
ENTER:
Access w-out PW
Access Serv
Access OEM
Access LS
BurnerControl
RatioControl
O2Contr./Guard.
LoadController
ControllerParam
Configuration
Adaption
SW Version
ContrlParamList
MinActuatorStep
SW_FilterTmeCon
SetPointW1
SetpointW1
Curr: 90°
New: 90°
Setpoint Actual value
SDoff
W
SDon

9
the display will show:
The deafult value for this parameter is1% that is, the burner will light again at a temperature 1% lower than the set-point.
Change value, if needed, by means of the arrow keys; press ENTER to confirm and the press ESC to exit. Press only ESC to exit
without changing.
Now choose SD_ModOff always scrolling down theLoad Controller menu, by menas of the arrow keys, and press ENTER.
the display will show:
The deafult value for this parameter is10% that is, the burner will turn off at a temperature 1% higher than the set-point.
Change value, if needed, by means of the arrow keys; press ENTER to confirm and the press ESC to exit. Press only ESC to exit
without changing.
Press the ESC key until the following menu is shown:
scroll this menu down until the tiem “AZL” is reached
confirm by pressing ENTER:
SetPointW1
SetPointW2
SD_ModOn
SD_ModOff
SD_ModOn
Curr: 1.0%
New: 1.0%
SetPointW1
SetPointW2
SD_ModOn
SD_ModOff
SD_ModOff
Curr: 10.0%
New: 10.0%
BurnerControl
RatioControl
O2Contr./Guard.
LoadController
LoadController
AZL
Actuators
VSD Module

10
Times: it sets the “Summer (SUM) Time / Winter (WIN) Time” operation and the continent (EU - Europe; US - United States)
choose the Summertime/Wintertime mode desired and cofirm by pressing ENTER; press ESC to exit.
Set the time zone (Time EU/US) in the same way.
Languages: it allows setting the current language
choose the desired language and cofirm by pressing ENTER; press ESC to exit.
DateFormat: it allows setting the date format as DD-MM-YY (day-month-year) or MM-DD-YY (month-day-year)
choose the desired format and cofirm by pressing ENTER; press ESC to exit.
PhysicalUnits: it allows setting the measuring units for temperature and pressure
Temperature units: °C or °F
Pressure units: bar or psi.
choose the desired unit and cofirm by pressing ENTER; press ESC to exit.
System lockout
If the system locks out, the following message will appear:
call the Technical Service and tell the message data.
Times
Languages
DateFormat
PhysicalUnits
Sum/Winter Time
Time EU/US
Languages
Curr: Italiano
New: English
DateFormat
Curr: DD-MM-YY
New: MM-DD-YY
UnitTemperature
UnitPressure
1 Class: 05Gas
Code BF Phase: 10
Diag.: 00 Lod: 0.0
Start No. 88

11
Cold start thermal shock (CSTP)
If there is a steam boiler that must start up cold in the plant, the fireman will heat the boiler keeping the burner at the lowest output to
prevent thermal shocks.
The LMV control box provides the CSTP (Cold Start Thermal Schock) function that is already set by the Technical service (access by
reserved password).
if this function is enabled, when the burner starts upthe “Thermal shock protection activated” message will be shown.
If this function is not enabled, after startup, the burner will rapidly increase the load according to the requested value and, if necessary,
to the maximum output.
Manual mode
To by-pass the thermal protection or not to let the buner operate in high flame stage after ignition, the manuale mode is provided.
To choose the manual mode (Manual Operation), use the SELECT arrow keys
Items to be set are the fllowing:
SetLoad: to set the required load percentage
set the required percentage and confirm by pressing ENTER; press ESC to exit.
choose “Autom/Manual/Off
three modes are provided:
Automatic: automatic operation
Burner on: manual operation
Burner off: burner in stand-by
If the BurnerOn mode is choosen,the burner does not follow the modulator and probe settings, but operates at the set load.
Caution: if BurnerOff mode is selected, the burner stays in stand-by
Caution: in the BurnerOn mode, the safety thresholds are set by the Technical Service.
Operational Status
Operation
Manual Operation
Params& Display
SetLoad
Autom/Manual/Off
SetLoad
Curr: 0.0%
New: 20.0%
SetLoad
Autom/Manual/Off
Autom/Manual/Off
Att: Automatic
Nuov: Burner On

12
SPARE PARTS
Desription Code
SIEMENS LMV51.100 - 110V BURNER CONTROL 2020460
SIEMENS LMV51.100 - 230V BURNER CONTROL 2020456
SIEMENS LMV51.200 - 110V BURNER CONTROL 2020463
SIEMENS LMV51.200 - 230V BURNER CONTROL 2020457
SIEMENS LMV52.200 - 110V BURNER CONTROL 2020461
SIEMENS LMV52.200 - 230V BURNER CONTROL 2020459
SIEMENS PLL52.110 O2 PCB FOR LMV52 2022111
AZL52.00 USER INTERFACE 2022112
AZL52.09 USER INTERFACE 2022121
AGG5.220 - 220V POWER SUPPLY 2022103
AGG5.210 - 110V POWER SUPPLY 2022113
SIEMENS SQM45 ACTUATOR 2480070
SIEMENS SQM48 ACTUATOR 2480071
SIEMENS QRI2A2 IR PROBE (FRONTAL ILLUMINATION) 2510028
SIEMENS QRI2B2 IR PROBE (LATERAL ILLUMINATION) 2510027
SIEMENS AGG5.310 SPEED SENSOR 2512108
SIEMENS QGO OXYGEN PROBE 2570304

C.I.B. UNIGAS S.p.A.
Via L.Galvani, 9 - 35011 Campodarsego (PD) - ITALY
Tel. [phone] - Fax [phone]
web site: www.cibunigas.it - e-mail: [email protected]
