SINUMERIK
SINUMERIK 828D
PPU
Manual
Valid for:
SINUMERIK 828D
PPU 24x.2 BASIC T
PPU 24x.2 BASIC M
PPU 26x.2
PPU 28x.2
03/2013
6FC5397-2DP40-3BA1
Preface
Safety notes
1
System description
2
Application planning
3
Installing
4
Rules for permitted
topologies
5
Interface description
6
Connectable components
7
Technical data
8
Appendix
A

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
Order number: 6FC5397-2DP40-3BA1
Ⓟ 01/2013 Technical data subject to change
Copyright © Siemens AG 2009 - 2013.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 3
Preface
SINUMERIK documentation
The SINUMERIK documentation is organized into the following categories:
● General documentation
● User documentation
● Manufacturer/service documentation
Additional information
You can find information on the following topics under the link
(www.siemens.com/motioncontrol/docu):
● Ordering documentation / current documentation overview
● Additional links to download documents
● Using documentation online (finding and searching in manuals/information)
Please send any questions about the technical documentation (e.g. suggestions for
improvement, corrections) to the following address:
(mailto:[e-mail])
My Documentation Manager (MDM)
Under the following link you will find information to individually compile OEM-specific
machine documentation based on the Siemens content: MDM (www.siemens.com/mdm)
Training
For information about the range of training courses, refer to:
● SITRAIN (www.siemens.com/sitrain) - training courses from Siemens for automation
products, systems and solutions
● SinuTrain (www.siemens.com/sinutrain) - training software for SINUMERIK
FAQs
You can find Frequently Asked Questions in the Service&Support pages under Product
Support (www.siemens.com/automation/service&support).

Preface
PPU
4 Manual, 03/2013, 6FC5397-2DP40-3BA1
SINUMERIK
You can find information on SINUMERIK under the following link:
(www.siemens.com/sinumerik)
Target group
This documentation is intended for manufacturers of machine tools, particularly:
● Project engineers, electricians and installers
● Maintenance and service personnel
Benefits
The information in this manual facilitates installation and connection of the
SINUMERIK 828D numerical control.
Standard version
This documentation only describes the functionality of the standard version. Extensions or
changes made by the machine manufacturer are documented by the machine manufacturer.
Other functions not described in this documentation might be executable in the control.
However, no claim can be made regarding the availability of these functions when the
equipment is first supplied or in the event of servicing.
Further, for the sake of simplicity, this documentation does not contain all detailed
information about all types of the product and cannot cover every conceivable case of
installation, operation or maintenance.
Technical support
Country-specific telephone numbers for technical support are provided in the Internet under
"Contact" (www.siemens.com/automation/service&support).
EC Declaration of Conformity
The EC declaration of conformity for the EMC directive can be found in the Internet
(www.siemens.com/automation/service&support).
Enter as search term the number 15257461 or contact your local Siemens office.

PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 5
Table of contents
Preface ...................................................................................................................................................... 3
1 Safety notes............................................................................................................................................... 9
1.1 Danger notices...............................................................................................................................9
1.2 ESD notices .................................................................................................................................11
2 System description .................................................................................................................................. 13
2.1 Controller features .......................................................................................................................13
2.2 System versions, BASIC T and BASIC M....................................................................................16
2.3 System versions horizontal and vertical ......................................................................................18
2.4 Operator controls and display elements ......................................................................................20
2.5 Type plate ....................................................................................................................................22
2.6 System overview..........................................................................................................................24
2.7 Connectable components ............................................................................................................26
2.8 Ordering data ...............................................................................................................................27
2.9 CompactFlash Cards ...................................................................................................................29
2.9.1 CompactFlash card system .........................................................................................................29
2.9.2 Inserting the system CompactFlash Card....................................................................................30
2.9.3 CompactFlash card for user data.................................................................................................33
3 Application planning................................................................................................................................. 35
3.1 Secondary electrical conditions ...................................................................................................35
3.1.1 Protective Separation as per EN 61800-5-1 ................................................................................35
3.1.2 Grounding concept.......................................................................................................................35
3.1.3 RI suppression measures ............................................................................................................37
3.2 Climatic and mechanical environmental conditions.....................................................................39
3.2.1 Ambient conditions.......................................................................................................................39
3.2.2 Transport and Storage Conditions...............................................................................................40
3.2.3 Operating Conditions ...................................................................................................................41
3.3 Recycling and disposal ................................................................................................................43
4 Installing .................................................................................................................................................. 45
4.1 Mounting positions .......................................................................................................................46
4.2 Dimension drawings.....................................................................................................................52
5 Rules for permitted topologies ................................................................................................................. 55
5.1 Topology rules for S120 Combi ...................................................................................................55
5.2 Topology rules for S120 Booksize ...............................................................................................57
5.3 Topology rules for Safety Integrated functions ............................................................................61

Table of contents
PPU
6 Manual, 03/2013, 6FC5397-2DP40-3BA1
5.4 Topology example without Safety Integrated functions .............................................................. 62
5.5 Topology example with Safety Integrated functions ................................................................... 65
6 Interface description ................................................................................................................................ 69
6.1 Interface overview ....................................................................................................................... 69
6.2 Power supply connection ............................................................................................................ 72
6.2.1 Requirements for the power supply ............................................................................................ 72
6.2.2 Connecting the power supply...................................................................................................... 74
6.3 Ethernet....................................................................................................................................... 75
6.4 PLC I/O Interface based on PROFINET ..................................................................................... 77
6.4.1 Addressing the I/O modules........................................................................................................ 80
6.5 Digital inputs/outputs................................................................................................................... 81
6.5.1 Terminal connection diagram...................................................................................................... 85
6.5.2 Example: Connecting an inductive proximity switch (BEROs).................................................... 86
6.5.3 Technical data............................................................................................................................. 87
6.6 DRIVE-CLiQ................................................................................................................................ 89
6.6.1 DRIVE-CLiQ interface................................................................................................................. 89
6.6.2 SINAMICS components .............................................................................................................. 91
6.7 Handwheel .................................................................................................................................. 92
6.8 USB............................................................................................................................................. 94
6.9 RS 232 serial interface................................................................................................................ 95
7 Connectable components ........................................................................................................................ 97
7.1 MCP 483C PN............................................................................................................................. 97
7.1.1 Operator controls and display elements ..................................................................................... 98
7.1.2 Mounting.................................................................................................................................... 101
7.1.3 Connecting ................................................................................................................................ 103
7.1.3.1 Connection ................................................................................................................................ 103
7.1.3.2 Description ................................................................................................................................ 104
7.1.4 Parameterization ....................................................................................................................... 108
7.1.5 Technical data........................................................................................................................... 110
7.1.6 Spare parts and accessories .................................................................................................... 111
7.2 MCP 310C PN........................................................................................................................... 115
7.2.1 Operator controls and display elements ...................................................................................116
7.2.2 Mounting.................................................................................................................................... 119
7.2.3 Connecting ................................................................................................................................ 121
7.2.3.1 Description ................................................................................................................................ 122
7.2.4 Parameterization ....................................................................................................................... 126
7.2.5 Technical data........................................................................................................................... 128
7.2.6 Spare parts and accessories .................................................................................................... 129
7.3 Mini handheld unit..................................................................................................................... 133
7.3.1 Description ................................................................................................................................ 133
7.3.2 Mounting.................................................................................................................................... 135
7.3.3 Connecting ................................................................................................................................ 138
7.3.4 Parameterization ....................................................................................................................... 140
7.3.5 Technical data........................................................................................................................... 142
7.3.6 Spare parts and accessories .................................................................................................... 143

Table of contents
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 7
7.4 Electronic handwheel.................................................................................................................144
7.4.1 Description .................................................................................................................................144
7.4.2 Mounting ....................................................................................................................................146
7.4.3 Connection.................................................................................................................................147
7.4.4 Technical specifications .............................................................................................................148
7.4.5 Spare parts and accessories .....................................................................................................149
7.5 PP 72/48D PN............................................................................................................................150
7.5.1 Description .................................................................................................................................150
7.5.2 Mounting ....................................................................................................................................153
7.5.3 Connecting.................................................................................................................................155
7.5.3.1 X1 power supply ........................................................................................................................156
7.5.3.2 X2 PROFINET............................................................................................................................157
7.5.3.3 X111, X222 and X333 pin assignment ......................................................................................159
7.5.3.4 Specification of the digital inputs................................................................................................162
7.5.3.5 Specification of the digital outputs .............................................................................................163
7.5.4 Parameter assignment...............................................................................................................165
7.5.4.1 Input / output images .................................................................................................................165
7.5.4.2 Diagnostics via input image .......................................................................................................167
7.5.5 Technical data............................................................................................................................169
7.6 PP 72/48D 2/2A PN ...................................................................................................................170
7.6.1 Description .................................................................................................................................170
7.6.2 Assembling.................................................................................................................................173
7.6.3 Connection.................................................................................................................................175
7.6.3.1 X1 power supply ........................................................................................................................176
7.6.3.2 X2 PROFINET............................................................................................................................179
7.6.3.3 X111, X222 and X333 pin assignment ......................................................................................181
7.6.3.4 Specification of the digital inputs................................................................................................184
7.6.3.5 Specification of the digital outputs .............................................................................................185
7.6.3.6 Analog X3 inputs/outputs ...........................................................................................................186
7.6.4 Assigning parameters ................................................................................................................191
7.6.4.1 Input / output images .................................................................................................................191
7.6.4.2 Diagnostics via input image .......................................................................................................193
7.6.4.3 Assigning parameters to the analog inputs / outputs.................................................................195
7.6.4.4 Analog value representation ......................................................................................................197
7.6.4.5 Examples ...................................................................................................................................200
7.6.5 Technical data............................................................................................................................202
7.7 NX10.3 .......................................................................................................................................203
7.7.1 Description .................................................................................................................................203
7.7.2 Mounting ....................................................................................................................................206
7.7.3 Connecting.................................................................................................................................208
7.7.4 Technical data............................................................................................................................212
7.8 PN/PN coupler ...........................................................................................................................213
7.8.1 Principle of operation .................................................................................................................213
7.8.2 Configuration..............................................................................................................................214
7.9 GSM modem..............................................................................................................................216
7.10 Terminal strip converter .............................................................................................................219
8 Technical data ....................................................................................................................................... 221

Table of contents
PPU
8 Manual, 03/2013, 6FC5397-2DP40-3BA1
A Appendix................................................................................................................................................ 223
A.1 Information about third-party software used ............................................................................. 223
A.2 Abbreviations ............................................................................................................................ 225
A.3 Documentation overview SINUMERIK 828D............................................................................ 227
Index...................................................................................................................................................... 229

PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 9
Safety notes 1
1.1 Danger notices
The following notices are intended firstly for your personal safety and secondly to prevent
damage occurring to the product described or any connected devices and machines. Non-
observance of the warnings can result in severe personal injury or property damage.
DANGER
Qualified personnel
Only appropriately qualified personnel may commission/start-up SINUMERIK equipment.
The personnel must take into account the information provided in the technical customer
documentation for the product, and be familiar with and observe the specified danger and
warning notices.
When electrical equipment and motors are operated, the electrical circuits automatically
conduct a dangerous voltage.
When the system is operating, dangerous axis movements may occur throughout the entire
work area.
A potential fire hazard exists due to the energy being transferred in the equipment and the
work materials used.
All work on the electrical system must be performed after the system has been switched off
and disconnected from the power supply.
DANGER
Supply voltage
External power supply units for supplying components of the drive control must have safety
isolation from circuits with dangerous voltages (DVC A according to EN 61800-5-1;
SELV/PELV). In addition only power units with control circuits that have safety isolation
from circuits with dangerous voltages may be connected.

Safety notes
1.1 Danger notices
PPU
10 Manual, 03/2013, 6FC5397-2DP40-3BA1
DANGER
Commissioning and operation of the devices
Proper transportation, expert storage, installation and mounting, as well as careful
operation and maintenance are essential for this SINUMERIK device to operate correctly
and reliably.
The details in the catalogs and proposals also apply to the design of special equipment
versions.
In addition to the danger and warning information provided in the technical customer
documentation, the applicable national, local, and system-specific regulations and
requirements must be taken into account.
Only class DVC A protective extra-low voltages (PELVs) may be connected to connections
and terminals up to 60 V DC in accordance with EN 61800-5-1.
Should it be necessary to test or take measurements on live equipment, then the
specifications and procedural instructions defined in Accident Prevention Regulation BGV
A2 must be adhered to, in particular § 8 "Permissible deviations when working on live
components". Suitable electric tools should be used.
DANGER
Carrying out of repairs
Repairs to devices that we have supplied may only be carried out by Siemens Customer
Service or by repair centers authorized by Siemens.
When replacing parts or components, only use those parts that are included in the spare
parts list.
EMERGENCY STOP/EMERGENCY OFF devices according to EN 60204-1 (VDE 0113
Part 1) must remain active in all modes of the automation equipment. Resetting the
EMERGENCY STOP/EMERGENCY OFF device must not cause an uncontrolled or
undefined restart.
Anywhere in the automation equipment where faults might cause physical injury or major
material damage, in other words, where faults could be dangerous, additional external
precautions must be taken, or facilities must be provided, that guarantee or enforce a safe
operational state, even when there is a fault (e.g. using an independent limit value switch,
mechanical locking mechanisms, EMERGENCY STOP/EMERGENCY OFF devices).

Safety notes
1.2 ESD notices
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 11
1.2 ESD notices
NOTICE
Handling ESD modules:
The modules contain electrostatically sensitive devices. Discharge yourself of electrostatic
energy before touching the components. The easiest way to do this is to touch a
conductive, grounded object immediately beforehand (for example, bare metal parts of
control cabinet or the protective ground contact of a socket outlet).
When handling electrostatically sensitive devices, make sure that operator, workplace
and packing material are properly grounded.
Generally, electronic modules must not be touched unless work has to be carried out on
them. When handling PC boards make absolutely sure that you do not touch component
pins or printed conductors.
Touch components only if:
– you are constantly grounded via an ESD arm band,
– ESD shoes or ESD shoe grounding strips if there is an ESD floor.
Boards/modules must only be placed on conductive surfaces (table with ESD surface,
conductive ESD foam, ESD packaging, ESD transport container).
Keep modules away from visual display units, monitors or TV sets (minimum distance
from screen 10 cm).
Do not bring ESD-sensitive modules into contact with chargeable and highly-insulating
materials, such as plastic, insulating table tops or clothing made of synthetic materials.
Measurements on modules are allowed only if:
– The measuring instrument is properly earthed (e.g., protective conductor) or
– Before measuring with a floating measuring instrument, the probe is briefly
discharged (e.g., touch the bare metal parts of the control housing).

Safety notes
1.2 ESD notices
PPU
12 Manual, 03/2013, 6FC5397-2DP40-3BA1

PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 13
System description 2
2.1 Controller features
Features
The SINUMERIK 828D is a tailor-made CNC solution for milling and turning machines in the
medium performance range.
SINUMERIK 828D is a panel-based CNC (panel processing unit). A CNC, PLC, operator
panel and axis control for six drives (standard) are combined in one unit. This design
provides a high degree of robustness by eliminating the need for hardware interfaces
between the CNC electronics board and the operator panel. In order to guarantee that
operation is as low-maintenance as possible, there are no wearing parts such as fans or
back-up batteries.
● CNC operator panel with tailor-made system software versions for turning and milling
technologies. PPU 28x and PPU 26x as well as PPU 24x in the versions: BASIC T and
BASIC M.
● Two operator panel versions for horizontal and vertical operator panel housings.
● Integrated full QWERTY CNC keyboard with mechanical short-stroke keys.
This enables the user to enter text for part-program names or tool identifiers and plain-
text language commands directly, without using the keys of the second input level (shift
key). The keys have IP65 degree of protection.
● USB, CompactFlash card and Ethernet interface on the operator panel front.
● Additional Ethernet interface on the rear of the CNC for permanent factory network.
● PLC I/O Interface based on PROFINET for the connection of PLC I/O devices and a
machine control panel.
● PP 72/48D PN and PP 72/48D 2/2A PN as PLC I/O module.
● Two connectable handwheels.
● Optional GSM modem connection possible.
● Up to six axes/spindles for milling applications and up to eight axes/spindles for turning
applications.
● One machining channel/mode group.
● Integrated PLC based on the SIMATIC S7-200 command set with Ladder Steps
programming
● Standardized 3/8" threads are embedded in the upper edges of the operator panel. These
threads can be used for attaching commercially available additional components such as
holders for diagrams or similar.

System description
2.1 Controller features
PPU
14 Manual, 03/2013, 6FC5397-2DP40-3BA1
Controller versions
The SINUMERIK 828D is available in different versions (horizontal or vertical; turning or
milling) as well as with different performance levels.
For the PPU 24x.2 a distinction is made between the turning and milling versions. When
booting, the preconfigured technology-specific system software automatically scales itself as
a result of the hardware that is found. As a consequence, e.g. a PPU 24x.2 BASIC T cannot
be used for milling.
The SINUMERIK 828D is available in the following versions:
● PPU 240.2 BASIC T (vertical operator panel)
● PPU 240.2 BASIC M (vertical operator panel)
● PPU 241.2 BASIC T (horizontal operator panel)
● PPU 241.2 BASIC M (horizontal operator panel)
● PPU 260.2 (vertical operator panel)
● PPU 261.2 (horizontal operator panel)
● PPU 280.2 (vertical operator panel)
● PPU 281.2 (horizontal operator panel)
Performance
The following table shows the difference between the different versions based on
characteristic technical data/features:
Function PPU 240.2 / 241.2 PPU 260.2 / 261.2 PPU 280.2 / 281.2
BASIC T BASIC M Turning Milling Turning Milling
Non-volatile memory (NVRAM):
For OEM data
For user data
512 KB
1 MB
512 KB
1 MB
512 KB
3 MB
512 KB
3 MB
512 KB
5 MB
512 KB
5 MB
Number of DRIVE-CLiQ interfaces 3 3 3 3 3 3
Number of axes/spindles 3 4 3 4 3 4
Maximum number of axes/spindles 5 5 6 6 6 / 8 * 6
Maximum number of axes with drive-
based Safety Integrated
5 5 6 6 6 / 8 * 6
Axis expansion with NX10.3 -- -- -- 1 1 1
Maximum number of I/O modules
(digital/analog)
3 3 4 4 5 5
IPO cycle for maximum configuration 9 ms 9 ms 6 ms 6 ms 6 ms 3 ms
Minimum block change time ~9 ms ~9 ms ~6 ms ~6 ms ~6 ms ~3 ms
Position-control cycle 3 ms 3 ms 3 ms 3 ms 1.5 ms 3 ms
PLC cycle time 9 ms 9 ms 6 ms 6 ms 6 ms 3 ms

System description
2.1 Controller features
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 15
Function PPU 240.2 / 241.2 PPU 260.2 / 261.2 PPU 280.2 / 281.2
Reaction time to process interrupts
(terminal to terminal)
7.5 ms 7.5 ms 7.5 ms 7.5 ms 7.5 ms 7.5 ms
Speed/current controller cycle 125 μs 125 μs 125 μs 125 μs 125 μs 125 μs
Reduced speed/current controller cycle
(see note)
-- -- -- 62.5 μs -- 62.5 μs
Note
With the help of a NX10.3, the following extensions can be connected:
The maximum number of axes can be increased to eight, six of which can be connected
to the PPU and two to the NX10.3.
A high-speed spindle (e.g. 24,000 rpm with four pole pairs) can be connected to the
NX10.3 (62.5 μs) and five axes to the PPU (125 μs).
For the reduced speed/current controller cycle, in accordance with Topology Rules
(Page 65), the following apply:
Max. number of axes = 5 for mixed operation 4 x 125 μs and 1 x 62.5 μs
Max. number of axes = 6 with NX10.3

System description
2.2 System versions, BASIC T and BASIC M
PPU
16 Manual, 03/2013, 6FC5397-2DP40-3BA1
2.2 System versions, BASIC T and BASIC M
Front panel of the SINUMERIK 828D BASIC T with interfaces




 








 








① ⑩ Protective cover for user interfaces
② Menu back key
③ Alphabetic key group
④ Control key group
⑤ Hotkey group
⑥ Cursor key group

System description
2.2 System versions, BASIC T and BASIC M
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 17
⑦ Numerical block
⑧ Menu forward key
⑨ 3/8" threads for additional components
⑪ X127 Ethernet (service socket)
⑫ Status LED: RDY, NC, CF
⑬ X125 USB interface
⑭ Slot for CompactFlash card with user data
Figure 2-1 System versions
Rear of the PPU 24x.2












① ② X122, X132 Digital inputs/outputs, drive
③ ④ X242, X252 Digital inputs/outputs for NCK; controller of the analog spindle
(X252)
⑤ X143 Handwheels
⑥ M, T2, T1, T0 Measuring sockets
⑦ X1 Power supply
⑧ X135 USB interface: For service purposes only
⑨ X130 Ethernet LAN
⑩ PN PLC I/O Interface
⑪ SYNC, FAULT Status LEDs
⑫ X100, X101, X102 DRIVE-CLiQ interfaces
⑬ X140 Serial interface RS232
Figure 2-2 Interfaces at the rear

System description
2.3 System versions horizontal and vertical
PPU
18 Manual, 03/2013, 6FC5397-2DP40-3BA1
2.3 System versions horizontal and vertical
Front of the PPU versions 26x.2 and 28x.2




 








 








① Protective cover for user interfaces
② Menu back key
③ Alphabetic key group
④ Control key group
⑤ Hotkey group
⑥ Cursor key group
⑦ Numerical block

System description
2.3 System versions horizontal and vertical
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1 19
⑧ Menu forward key
⑨ 3/8" threads for additional components
⑩ Protective cover for user interfaces
⑪ X127 Ethernet (service socket)
⑫ Status LED: RDY, NC, CF
⑬ X125 USB interface
⑭ Slot for CompactFlash card with user data
Figure 2-3 System versions
Rear of the PPU 26x.2 and 28x.2












① ② X122, X132 Digital inputs/outputs, drive
③ ④ X242, X252 Digital inputs/outputs for NCK; controller of the analog spindle
(X252)
⑤ X143 Handwheels
⑥ M, T2, T1, T0 Measuring sockets
⑦ X1 Power supply
⑧ X135 USB interface: For service purposes only
⑨ X130 Ethernet LAN
⑩ PN 1, PN 2 PLC I/O Interface
⑪ SYNC, FAULT Status LEDs
⑫ X100, X101, X102 DRIVE-CLiQ interfaces
⑬ X140 Serial interface RS232
Figure 2-4 Interfaces on the rear side of the PPU

System description
2.4 Operator controls and display elements
PPU
20 Manual, 03/2013, 6FC5397-2DP40-3BA1
2.4 Operator controls and display elements
TFT color display
The TFT color display has a diagonal size of 10.4" (PPU 26x.2/28x.2) or 8.4" (PPU 24x.2).
The resolution is 800 x 600 pixels. The softkeys are arranged in an 8 + 8 layout; this makes
the CNC easy to operate using only a very small number of menu levels.
Note
Pixel error acc. to DIN EN ISO 13406-2 Class II.
Keyboard
Several keys and key pads are installed on the operator panel front:
● The alphabetic key group contains the letters A ... Z and the space character for entering
text.
● The numeric key group contains the digits 0 - 9, arithmetic/special characters and the
decimal point for entering numeric characters and operators.
● The cursor key group is used to navigate on the screen.
● The control key group includes special functions.
● The area changeover displays the operating areas.
● The menu forward key allows the horizontal softkey bar to be extended in the same
menu.
● The softkeys call up functions that are available on screen via a menu bar.
● The machine area key switches directly into the "Machine" operating area.
● The menu back key returns to the superordinate menu, one window is closed.
The keys used on the operator panel front along with the corresponding function keys on the
PC keyboard are shown in the following overview:
Key Function corresponds to PC
key function
Key Function corresponds to PC
key function
Esc End
F11 Backspace
F12 Tabulator
