Siemens RVD240 Operator's manual

Edition 3.0
Controller series D
CE1P2384en
27.05.2004
Siemens Building Technologies
HVAC Products
RVD240
District Heating and Domestic Hot Water Controller
Basic Documentation

2/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 27.05.2004
Siemens Building Technologies AG
HVAC Products
Gubelstrasse 22
CH 6301 Zug
Tel. [phone]
Fax [phone]
www.landisstaefa.com
© 1999 Siemens Building Technologies AG
Subject to change

3/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
Contents
1Summary ....................................................................................................... 13
1.1 Brief description and key features .................................................................13
1.2 Type summary............................................................................................... 13
1.3 Equipment combinations ............................................................................... 13
1.3.1 Suitable sensors ............................................................................................ 13
1.3.2 Suitable room units........................................................................................ 14
1.3.3 Suitable valve actuators ................................................................................ 14
1.3.4 Communication.............................................................................................. 14
1.3.5 Documentation .............................................................................................. 14
2Use ................................................................................................................ 15
2.1 Types of plant ................................................................................................ 15
2.2 Types of houses and buildings ...................................................................... 15
2.3 Types of heating systems.............................................................................. 15
2.4 Heating circuit functions ................................................................................ 15
2.5 D.h.w. functions ............................................................................................. 16
2.6 Auxiliary functions.......................................................................................... 16
3Fundamentals................................................................................................ 18
3.1 Key technical features ................................................................................... 18
3.1.1 Function blocks.............................................................................................. 18
3.1.2 Plant types..................................................................................................... 18
3.2 Operating modes ........................................................................................... 22
3.2.1 Heating circuit control .................................................................................... 22
3.2.2 D.h.w. heating................................................................................................ 23
3.2.3 Manual operation........................................................................................... 23
4Acquisition of measured values..................................................................... 24
4.1 General.......................................................................................................... 24
4.2 Flow temperature heating circuit ................................................................... 24
4.2.1 Types of sensors ...........................................................................................24
4.2.2 Handling faults............................................................................................... 24
4.3 Outside temperature (B9) .............................................................................. 24
4.3.1 Types of sensors ...........................................................................................24
4.3.2 Handling faults............................................................................................... 24
4.4 Room temperature (A6)................................................................................. 25
4.4.1 Types of sensors ...........................................................................................25
4.4.2 Handling faults............................................................................................... 25
4.4.3 Room model .................................................................................................. 25
4.5 D.h.w. temperature (B3) ................................................................................ 25
4.5.1 Measured variable ......................................................................................... 25

4/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
4.5.2 Types of sensors............................................................................................25
4.5.3 Handling faults ...............................................................................................26
4.6 D.h.w. storage tank temperature (B31)..........................................................26
4.6.1 Measured variable .........................................................................................26
4.6.2 Types of sensors............................................................................................26
4.6.3 Handling faults ...............................................................................................26
4.7 D.h.w. storage tank or return temperature (B32) ...........................................26
4.7.1 Measured variable .........................................................................................26
4.7.2 Types of sensors............................................................................................26
4.7.3 Handling faults ...............................................................................................27
4.8 Return temperature (B7, B71 and B72) .........................................................27
4.8.1 Measurement .................................................................................................27
4.8.2 Types of sensors............................................................................................27
4.8.3 Handling faults ...............................................................................................27
5Function block Space heating........................................................................28
5.1 Operating lines...............................................................................................28
5.2 Settings and displays .....................................................................................28
5.3 Heating program ............................................................................................29
6Function block Clock settings ........................................................................30
6.1 Operating lines...............................................................................................30
6.2 Entries............................................................................................................30
7Function block End-user d.h.w.......................................................................31
7.1 Operating lines...............................................................................................31
7.2 D.h.w. heating program..................................................................................31
7.3 Adjustment of setpoints..................................................................................31
8Function block Display of actual sensor values .............................................32
8.1 Operating lines...............................................................................................32
8.2 Displays .........................................................................................................32
9Function block Holiday settings .....................................................................33
9.1 Operating lines...............................................................................................33
9.2 Holiday program.............................................................................................33
10 Function block Indication of errors .................................................................34
10.1 Operating line.................................................................................................34
10.2 Indication of errors .........................................................................................34
11 Function block Plant configuration .................................................................35
11.1 Operating lines...............................................................................................35
11.2 Parameters to be set......................................................................................35
11.2.1 Plant type .......................................................................................................35
11.2.2 Input B71 / U1 ................................................................................................35

5/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
11.2.3 Circulating pump............................................................................................ 36
11.2.4 Input H5 ......................................................................................................... 36
11.2.5 Control of variable speed pump..................................................................... 36
12 Function block Space heating .......................................................................40
12.1 Operating lines .............................................................................................. 40
12.2 Compensating variables ................................................................................ 40
12.2.1 Outside temperature...................................................................................... 40
12.2.2 Room temperature......................................................................................... 41
12.3 Heating curve ................................................................................................ 42
12.4 Generation of setpoint ...................................................................................43
12.4.1 Display of setpoint ......................................................................................... 43
12.4.2 Setpoint of weather-compensated control ..................................................... 43
12.4.3 Setpoint of room-compensated control.......................................................... 44
12.4.4 Setpoint of weather-compensated control with room influence ..................... 44
12.5 Heating circuit control .................................................................................... 45
12.5.1 Weather-compensated control ...................................................................... 45
12.5.2 Room-compensated control .......................................................................... 45
12.5.3 Weather-compensated control with room influence ......................................45
12.6 Automatic ECO function ................................................................................ 46
12.6.1 Fundamentals................................................................................................ 46
12.6.2 Compensating variables and auxiliary variables ........................................... 46
12.6.3 Heating limit................................................................................................... 47
12.6.4 Mode of operation of ECO function 1 ............................................................ 47
12.6.5 Mode of operation of ECO function 2 ............................................................ 47
12.7 Pump overrun ................................................................................................ 47
12.8 Maximum limitation of the room temperature ................................................47
12.9 Optimization................................................................................................... 48
12.9.1 Definition and purpose................................................................................... 48
12.9.2 Fundamentals................................................................................................ 48
12.9.3 Process.......................................................................................................... 49
12.9.4 Room model temperature.............................................................................. 49
12.9.5 Optimum stop control .................................................................................... 50
12.9.6 Quick setback ................................................................................................ 50
12.9.7 Optimum start control ....................................................................................50
12.9.8 Maximum rate of flow temperature increase ................................................. 51
12.10 Frost protection for the building ..................................................................... 51
12.10.1 General.......................................................................................................... 51
12.10.2 Mode of operation with room sensor .............................................................51
12.10.3 Mode of operation without room sensor ........................................................51
12.11 Protective functions ....................................................................................... 52
12.11.1 Pump kick ...................................................................................................... 52
12.11.2 Valve kick ...................................................................................................... 52

6/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
12.11.3 Shutdown of pump .........................................................................................52
12.11.4 Pump and mixing valve overrun.....................................................................52
13 Function block Valve actuator of heat converter............................................54
13.1 Operating lines...............................................................................................54
13.2 Mode of operation ..........................................................................................54
13.3 Control process..............................................................................................54
13.4 Maximum limitation of the flow temperature ..................................................54
13.5 Minimum limitation of the flow temperature ...................................................54
13.6 External heat demand at input H5 .................................................................55
13.7 External heat demand at input U1 .................................................................55
14 Function block Valve actuator heating circuit ..................................................56
14.1 Operating lines...............................................................................................56
14.2 Mode of operation ..........................................................................................56
14.3 Control process..............................................................................................56
14.4 Maximum limitation of the flow temperature ..................................................56
14.5 Minimum limitation of the flow temperature ...................................................57
15 Function block D.h.w. heating........................................................................58
15.1 Operating lines...............................................................................................58
15.2 Release of d.h.w. heating ..............................................................................58
15.3 Control of the circulating pump ......................................................................59
15.4 Switching differential of d.h.w. control............................................................59
15.5 Legionella function .........................................................................................59
15.6 Priority of d.h.w. heating ................................................................................59
15.6.1 General ..........................................................................................................59
15.6.2 Absolute priority .............................................................................................60
15.6.3 Shifting priority ...............................................................................................60
15.6.4 No priority.......................................................................................................61
15.7 Pump overrun ................................................................................................61
15.7.1 General ..........................................................................................................61
15.7.2 Intermediate circuit pump...............................................................................61
15.7.3 Storage tank charging pump..........................................................................61
15.8 Frost protection for d.h.w. ..............................................................................62
15.9 Switching d.h.w. heating off ...........................................................................62
16 D.h.w. heating ................................................................................................63
16.1 D.h.w. heating with storage tanks ..................................................................63
16.1.1 General ..........................................................................................................63
16.1.2 Maximum charging time.................................................................................63
16.1.3 Manual storage tank heating..........................................................................63
16.1.4 Forced charging .............................................................................................63
16.1.5 Protection against discharging.......................................................................64
16.1.6 Protection against overtemperatures .............................................................64

7/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
16.1.7 Storage tank with electric immersion heater.................................................. 64
16.2 D.h.w. heating with stratification storage tank ............................................... 64
16.2.1 General.......................................................................................................... 64
16.2.2 D.h.w. heating................................................................................................ 65
16.2.3 Feeding the circulating water into the heat exchanger .................................. 65
16.3 Direct d.h.w. heating...................................................................................... 65
16.3.1 General.......................................................................................................... 65
16.3.2 D.h.w. heating................................................................................................ 65
16.3.3 Protection against cooling down.................................................................... 66
16.3.4 Siting the sensors .......................................................................................... 66
16.3.5 Flow switch .................................................................................................... 67
16.3.6 Compensation of heat losses through control ............................................... 67
16.3.7 Cold water sensor.......................................................................................... 68
17 Function block Extra legionella functions ...................................................... 69
17.1 Operating lines .............................................................................................. 69
17.1.1 Legionella function......................................................................................... 69
17.1.2 Setpoint ......................................................................................................... 69
17.1.3 Time............................................................................................................... 69
17.1.4 Dwelling time ................................................................................................. 69
17.1.5 Operation of circulating pump........................................................................ 70
17.1.6 Maximum limitation of the return temperature ............................................... 70
17.2 Mode of operation.......................................................................................... 70
18 Function block Valve actuator d.h.w.............................................................. 72
18.1 Operating lines .............................................................................................. 72
18.2 Mode of operation.......................................................................................... 72
18.3 Control process ............................................................................................. 72
18.4 Setpoint boost................................................................................................ 72
18.4.1 Charging boost .............................................................................................. 73
18.4.2 Flow temperature boost................................................................................. 73
18.5 Maximum setpoint of the d.h.w. temperature ................................................73
18.6 D.h.w. charging with two storage tank sensors ............................................. 73
18.7 Adjustable load limit....................................................................................... 73
18.7.1 Adjustment to the time of year....................................................................... 73
18.7.2 Load limit ....................................................................................................... 74
18.7.3 Child-proofing ................................................................................................ 74
19 Function block Assignment of d.h.w. ............................................................. 75
19.1 Operating line ................................................................................................ 75
19.2 Assignment of d.h.w. heating ........................................................................ 75
20 Function block LPB parameters .................................................................... 76
20.1 Operating lines .............................................................................................. 76
20.2 LPB parameters............................................................................................. 76

8/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
20.2.1 Addressing the devices..................................................................................76
20.2.2 Source of time of day .....................................................................................76
20.2.3 Bus power supply...........................................................................................77
20.2.4 Outside temperature source ..........................................................................77
21 Locking signals ..............................................................................................78
21.1 Fundamentals ................................................................................................78
21.2 Critical locking signals....................................................................................78
21.3 Uncritical locking signals................................................................................78
21.3.1 General ..........................................................................................................78
21.3.2 Controller-internal uncritical locking signals...................................................79
21.3.3 Uncritical locking signals from the data bus...................................................79
22 Function block Device functions ....................................................................80
22.1 Operating lines...............................................................................................80
22.2 Actuator pulse lock.........................................................................................80
22.3 Frost protection for the plant ..........................................................................80
22.3.1 Principle .........................................................................................................80
22.3.2 Mode of operation with outside sensor ..........................................................80
22.3.3 Mode of operation without outside sensor .....................................................81
22.3.4 Frost protection for the heating circuit flow ....................................................81
22.4 Flow alarm .....................................................................................................81
22.4.1 Heating circuit and d.h.w. circuit with storage tanks ......................................81
22.4.2 Direct d.h.w. heating via heat exchanger.......................................................82
22.5 Winter- / summertime changeover.................................................................83
23 Function block M-bus parameter ...................................................................84
23.1 Operating lines...............................................................................................84
23.2 General ..........................................................................................................84
23.3 Addressing and identification .........................................................................84
23.4 Baud rate .......................................................................................................84
23.5 Load management .........................................................................................84
23.5.1 Load management of d.h.w. ..........................................................................84
23.5.2 Load management of the heating system......................................................84
23.5.3 Resetting the load control signals ..................................................................85
23.5.4 Use on the LPB..............................................................................................85
23.5.5 Resolution of M-bus signals...........................................................................85
24 Function block PPS parameter ......................................................................86
24.1 Operating lines...............................................................................................86
24.2 Suitable devices.............................................................................................86
24.3 Impacts of a room unit on the heating circuits ...............................................86
25 Function block Test and display.....................................................................87
25.1 Operating lines...............................................................................................87

9/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
25.2 Sensor test .................................................................................................... 87
25.3 Setpoint test................................................................................................... 87
25.4 Relay test....................................................................................................... 88
25.5 Display of the pump speed ............................................................................ 88
25.6 Display of the digital inputs............................................................................ 88
25.7 Limitations ..................................................................................................... 89
25.8 Software version............................................................................................ 90
26 Function block DRT and maximum limitation of the return temperature ....... 91
26.1 Operating lines .............................................................................................. 91
26.2 Maximum limitation of the primary return temperature .................................. 91
26.2.1 General.......................................................................................................... 91
26.2.2 Maximum limitation in heating mode ............................................................. 92
26.2.3 Maximum limitation in d.h.w. mode ............................................................... 92
26.3 Maximum limitation of the secondary return temperature ............................. 93
26.4 Maximum limitation of the temperature differential (DRT function) ...............94
26.4.1 Mode of operation.......................................................................................... 94
26.4.2 Purpose ......................................................................................................... 94
26.5 Integral action time of the limitation functions................................................ 94
27 Function block Various functions................................................................... 95
27.1 Operating lines .............................................................................................. 95
27.2 Limitation function at contact H5 ...................................................................95
27.3 Suppression of hydraulic creep ..................................................................... 96
27.3.1 Mode of operation.......................................................................................... 96
27.3.2 Mode of operation.......................................................................................... 96
27.4 Raising the reduced room temperature setpoint ........................................... 96
28 Function block Operation locking functions ................................................... 98
28.1 Operating lines .............................................................................................. 98
28.2 Locking settings on the software side............................................................ 98
28.3 Locking of setting level "Locking functions" on the hardware side ................ 98
29 Combination with PPS devices...................................................................... 99
29.1 General.......................................................................................................... 99
29.2 Combination with room unit QAW50... ..........................................................99
29.2.1 General.......................................................................................................... 99
29.2.2 Overriding the operating mode ...................................................................... 99
29.2.3 Knob for room temperature readjustments.................................................. 100
29.2.4 Controller with operation lock ...................................................................... 100
29.3 Combination with room unit QAW70 ...........................................................100
29.3.1 General........................................................................................................ 100
29.3.2 Overriding the operating mode .................................................................... 101
29.3.3 Knob for readjusting the room temperature................................................. 101
29.3.4 Impact of the individual QAW70 operating lines on the RVD240 ................ 101

10/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Contents 27.05.2004
29.3.5 Controller with operation lock.......................................................................102
29.3.6 Entry of holiday periods ...............................................................................102
29.4 Room temperature sensor QAA10...............................................................102
30 Manual operation .........................................................................................103
31 Handling.......................................................................................................104
31.1 Operation .....................................................................................................104
31.1.1 General ........................................................................................................104
31.1.2 Analog operating elements ..........................................................................105
31.1.3 Digital operating elements ...........................................................................105
31.1.4 Controller in "nonoperated state" .................................................................106
31.1.5 Safety concept .............................................................................................106
31.1.6 Setting levels and access rights...................................................................106
31.2 Commissioning ............................................................................................107
31.2.1 Installation instructions.................................................................................107
31.2.2 Operating lines.............................................................................................107
31.3 Installation....................................................................................................107
31.3.1 Mounting location.........................................................................................107
31.3.2 Mounting choices .........................................................................................107
31.3.3 Electrical installation ....................................................................................108
32 Engineering..................................................................................................109
32.1 Connection terminals ...................................................................................109
32.2 Relays ..........................................................................................................110
32.3 PWM output .................................................................................................110
32.4 Lightning protection in M-bus plants ............................................................110
32.5 Connection diagrams ...................................................................................111
32.5.1 Low-voltage side ..........................................................................................111
32.5.2 Mains voltage side .......................................................................................111
33 Mechanical design .......................................................................................112
33.1 Basic design.................................................................................................112
33.2 Dimensions ..................................................................................................112
34 Technical data..............................................................................................113

11/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Glossary 27.05.2004
Glossary
In this Basic Documentation, the following key terms are used:
Term Explanation
Heat converter Heat exchanger that, on the primary side, is con-
nected to the district heat network and that, on the
secondary side, delivers the hot water to a com-
mon flow. The flow then supplies the hot water to
several consumers that are controlled by zone
controllers, etc.
Heat exchanger Heat exchanger that delivers the heat directly to
the consumers (e.g. space heating, d.h.w. heat-
ing, etc.).
Term Explanation
Storage tank charging pump Pump that supplies tap water via the heat ex-
changer into the storage tank where it is made
available as d.h.w.
Intermediate circuit pump Pump that supplies water as a heat carrier. The
water transfers its heat via a coil or storage tank
to the d.h.w. without getting in direct contact with
it.
Term Explanation
Coil type storage tank
2383S33
Instantaneous d.h.w. heating (via
heat exchanger)
2383S34
Stratification storage tank
2383S35
Storage tanks Common term used for coil type and stratification
storage tanks.
Heat source, heat
generation
Pumps
D.h.w. heating

12/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products Glossary 27.05.2004

13/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 1 Summary 27.05.2004
1 Summary
1.1 Brief description and key features
• The RVD240 is a multifunctional heating controller for controlling the flow tempera-
ture of 2 heating circuits and for controlling d.h.w. heating
• The controller’s field of use covers exclusively plants with district heat connections. It
has been designed specifically for small to medium-size residential and non-
residential buildings with 2 heating circuits
• The RVD240 has 4 heating circuit types and 11 d.h.w. plant types preprogrammed.
By combining the different plants, it is possible to configure 14 plant types. The con-
figuration activates all functions and settings required for the respective type of plant
• In terms of control, the RVD240 is designed as a flow temperature controller. Control
can be effected in one of 5 different ways:
− Only weather-compensated control of the heating circuit flow temperatures
− Weather- and room-compensated control of the heating circuit flow temperatures
− Only room-compensated control of the heating circuit flow temperatures
− Demand-dependent control of the common heating circuit flow temperature
• In terms of d.h.w. control, the RVD240 is designed for the following types of applica-
tions:
− D.h.w. heating with coil type storage tanks
− D.h.w. heating with stratification storage tanks
− Direct d.h.w. heating via heat exchanger
− Common or separate heat exchangers for the heating circuit and d.h.w. heating
− Two-stage separation of the d.h.w. from district heating
• The RVD240 is suited for the control of 2-port and 3-port valves and pumps, includ-
ing variable speed pumps
• For the direct adjustment of the nominal room temperature setpoint, there is a setting
knob available. All the other parameters are set digitally based on the operating line
principle
• Key design features: Operating voltage AC 230 V, CE conformity, overall dimensions
to DIN 43700 (96 × 144 mm)
1.2 Type summary
The RVD240 is a compact controller and requires no accessories such as inserts, plug-
in modules, etc. The controller is supplied complete with base.
1.3 Equipment combinations
1.3.1 Suitable sensors
• For the flow temperatures:
Suitable are all types of temperature sensors that use a sensing element LG-
Ni 1000. The following types are presently available:
− Strap-on temperature sensor QAD22
− Immersion temperature sensors QAE2...
For the control of the d.h.w. flow temperature (B3), it is also possible to use commer-
cially available sensors with Pt 500 sensing elements
• For the return temperatures:
The following types of temperature sensors are presently available:
− Strap-on temperature sensor QAD22
− Immersion temperature sensors QAE2...

14/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 1 Summary 27.05.2004
For the control of the primary return temperatures (B7, B71, B72), it is also possible to
use commercially available sensors with Pt 500 sensing elements.
• For the outside temperature:
− Outside sensor QAC22 (sensing element LG-Ni 1000)
− Outside sensor QAC32 (sensing element NTC 575)
• For the room temperature:
PPS-compatible sensors must be used. The following units are available:
− Room temperature sensor QAA10
• For the storage tank temperature:
− Cable temperature sensor QAP21.3
− Immersion temperature sensors QAE2...
1.3.2 Suitable room units
• Room units QAW50...
• Room unit QAW70
1.3.3 Suitable valve actuators
All actuators from Siemens with the following features can be used:
• Electric or electrohydraulic actuators with a running time of 10...900 seconds
• 3-position control
• Operating voltage AC 24 V...AC 230 V
1.3.4 Communication
Communication with other devices, controllers, etc., is possible:
• Via LPB, e.g. assignment of d.h.w., reception of radio signal, master / slave assign-
ments for the time switch, reception of outside temperature signal
• Via M-bus, e.g. reading setpoints and actual values, or output control for space heat-
ing
1.3.5 Documentation
Type of documentation Classification number
Data Sheet RVD240 N2384
Operating Instructions RVD240 B2384
Installation Instructions RVD240 G2384
Data Sheet QAW50... N1635
Data Sheet QAW70 N1637
Installation Instructions QAW70 G1637
Data Sheet QAA10 N1725
Data Sheet "LPB Basic System Data" N2030
Data Sheet "LPB Basic Engineering Data" N2032
Basic Documentation M-Bus P5361

15/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 2 Use 27.05.2004
2 Use
2.1 Types of plant
Basically, the RVD240 is suited for the control of all types of heating plants in houses or
buildings
• that are connected to a district heat network
• that use 2 heating circuits
• in which the flow temperature of the heating circuits is controlled either weather- or
room-compensated
• in which the control of d.h.w. heating can be integrated as an option
2.2 Types of houses and buildings
Basically, the RVD240 is suited for use in all types of houses and buildings in which the
heating is controlled either weather- or room-compensated. It has been designed espe-
cially for:
• Single-family homes
• Multifamily houses
• Small to medium-size non-residential buildings
2.3 Types of heating systems
The RVD240 is suited for use with all standard heating systems, such as:
• Radiators
• Convectors
• Underfloor heating systems
• Ceiling heating systems
• Radiant panels
2.4 Heating circuit functions
The RVD240 is used if 1 or several of the following heating circuit functions is / are
required:
• Weather- or room-compensated or weather- and room-compensated flow tempera-
ture control
• Separate flow temperature control of both heating circuits
• Flow temperature control through a modulating seat or slipper valve
• Common or separate heat exchangers for the heating circuits and for d.h.w. heating
• Optimum heating up and setback of the room temperature by learning the switch-on
and switch-off time
• Quick setback with and without room temperature sensor
• ECO function: Demand-dependent switching of the heating system as a function of
the outside temperature
• 7-day program for the heating periods with a maximum of 3 heating periods per day
and varying on times
• Frost protection for the plant and the house or building
• Yearly clock
• Holiday programs
• Independent time programs for space heating and d.h.w.
• Separate time programs for each heating circuit

16/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 2 Use 27.05.2004
• Maximum rate of flow temperature increase
• Minimum and maximum limitation of the flow temperature
• Maximum limitation of the room temperature
• Flow alarm
• Heat demand signal can be received
• Differential temperature limitation (DRT function)
• Maximum limitation of the primary return temperature, can be adjusted with 4 vari-
ables
• Limitation of power or volumetric flow by pulses
• Suppression of hydraulic creep in the primary circuit
• Weather-compensated raising of the reduced room temperature setpoint
• Remote operation via room unit
2.5 D.h.w. functions
The RVD240 is used if one or several of the following d.h.w. functions is / are required:
• Common or separate heat exchangers for the heating circuit and for d.h.w. heating
• D.h.w. heating with a coil type storage tank, with charging pump
• Direct d.h.w. heating via heat exchanger
• D.h.w. heating with coil type or stratification storage tanks, with or without mixing
valve in the intermediate circuit
• Continuous d.h.w. heating with mixing valve
• Flow switch with an adjustable load limit, child-proofing and adaptation to the season
• Own time program for the release of d.h.w.
• Optional assignment of the circulating pump to the heating circuit or the d.h.w. circuit
time program
• Protection against cooling down with d.h.w. heating via heat exchanger
• Legionella protection
• Forced d.h.w. charging
• frost protection for d.h.w.
• Selectable priority for d.h.w. heating : Absolute, shifting or parallel
• Manual d.h.w. charging outside the time program
• Maximum limitation of the d.h.w. return temperature
• Flow alarm
2.6 Auxiliary functions
The RVD240 is used if one or several of the following functions is / are required:
• Pump kick, periodic pump run
• Demand-dependent control of the common flow
• Pump overrun
• Valve kick, periodic activation of all actuators on the secondary side
• PWM output, control of a variable speed pump
• Display of parameters, actual values, operating states and fault status signals
• Alarm input
• Analog input DC 0...10 V (display, external heat demand)
• Digital input (heat meter, external heat demand, etc.)
• Flow switch (including child-proofing and adaptation to the season)
• Communication via M-bus
• Communication via LPB (Local Process Bus)
• Service functions
• Pulse lock for actuators
• Sensor test

17/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 2 Use 27.05.2004
• Relay test
• Display of setpoint
• Display of all active limitations
• Locking of settings
• Connection of sensors for display only

18/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 3 Fundamentals 27.05.2004
3 Fundamentals
3.1 Key technical features
The RVD240 offers 2 key technical features:
• The controller has 14 different plant types preprogrammed.
Subsection 3.1.2 shows the relevant plant diagrams.
• The settings are assigned to different setting levels each of which contains a number
of function blocks with the relevant settings
3.1.1 Function blocks
Setting levels Function block
Space heating
Clock setting
End-user d.h.w. heating
Display of actual sensor values
Holiday settings
End-user
Indication of errors
Plant configuration
Space heating
Actuator heat exchanger
Actuator heating circuit
D.h.w. heating
D.h.w. actuator
Assignment of d.h.w.
Extra legionella functions
LPB parameter
Control functions
M-bus parameter
PPS parameter
Heating engi-
neer
Test and display
DRT and limitation of the return temperature
Various functions
Locking func-
tions
Locking functions
For each function block, the required settings are available in the form of operating
lines. On the following pages, a description of the individual functions per block and
line is given.
3.1.2 Plant types
The RVD240 has 14 plant types preprogrammed; the functions required for each type
of plant are ready assigned. When commissioning the installation, the relevant plant
type must be selected.
Each plant type is comprised of 2 heating circuits and 1 d.h.w. circuit. When making
use of all possible or practical combinations, the above mentioned total of 14 plant
types are available.
With the number of preprogrammed plant types available, practically all types of heat-
ing plants with district heat connection and own d.h.w. heating can be handled and
controlled.
Elements shown in broken lines (sensors B7 and B71, circulating pump and flow
switch) are optional components.
Note on the plant
diagrams

19/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 3 Fundamentals 27.05.2004
Type ref. Diagram Legend
Y1 B7 B71
B1
Q1
B9 A6
Y7 B72 B3
B12
Q2
A6
2384 S01
A6 Room units
B1 Flow sensor heating circuit 1
B12 Flow sensor heating circuit 2
B3 Secondary return sensor heating circuit 2
B7 Primary return sensor heating circuit 1*
B71 Secondary return sensor heating circuit 1
B72 Primary return sensor heating circuit 2*
B9 Outside sensor
Q1 Pump heating circuit 1
Q2 Pump heating circuit 2
Y1 2-port valve primary return heating circuit 2
Y7 2-port valve primary return heating circuit 2
Y1 B7
B1
Q1
B9 A6
Y7 B72
B12
Q2
A6
B31
Q3
B71
2384 S02
Y5
B32
A6 Room units
B1 Flow sensor heating circuit 1
B12 Flow sensor heating circuit 2
B31 Storage tank sensor 1
B32 Storage tank sensor 2
B7 Primary return sensor heating circuit 1*
B71 Return sensor d.h.w. circuit
B72 Primary return sensor heating circuit 2*
B9 Outside sensor
Q1 Pump heating circuit 1
Q2 Pump heating circuit 2
Q3 Circulating pump (optional)
Y1 2-port valve primary return heating circuit 2
Y5 2-port valve d.h.w. primary return
Y7 2-port valve primary return heating circuit 2
B12
Y7
Y5
B72 Q2
A6
2384S03
B3
H5
B71
Q3
Y1 B7
B1
Q1
B9 A6
B32
A6 Room units
B1 Flow sensor heating circuit 1
B12 Flow sensor heating circuit 2
B3 D.h.w. flow sensor
B32 Return sensor d.h.w.
B7 Primary return sensor heating circuit 1*
B71 Primary return sensor d.h.w. circuit
B72 Primary return sensor heating circuit 2*
B9 Outside sensor
H5 Flow switch (optional)
Q1 Pump heating circuit 1
Q2 Pump heating circuit 2
Q3 Circulating pump (optional)
Y1 2-port valve primary return heating circuit 2
Y5 2-port valve d.h.w. primary return
Y7 2-port valve primary return heating circuit 2
Y1 B7
B1
Q1
B9 A6
Y7 B72
B12
Q2
A6
B71
Y5
B3
B32
Q3
Q
B31
b)
a)
2384S04
A6 Room units
B1 Flow sensor heating circuit 1
B12 Flow sensor heating circuit 2
B3 D.h.w. flow sensor
B31 Storage tank sensor 1
B32 Storage tank sensor 2
B7 Primary return sensor heating circuit 1*
B71 Primary return sensor d.h.w. circuit
B72 Primary return sensor heating circuit 2*
B9 Outside sensor
Q Circulating pump (controlled externally, optional)
Q1 Pump heating circuit 1
Q2 Pump heating circuit 2
Q3 Storage tank charging pump
Y1 2-port valve primary return heating circuit 2
Y5 2-port valve d.h.w. primary return
Y7 2-port valve primary return heating circuit 2
* Suppression of hydraulic creep

20/126
Siemens Building Technologies Basic documentation RVD240 CE1P2384en
HVAC Products 3 Fundamentals 27.05.2004
Y1 B7
B1
Q1
B9 A6
Y7 B72
B12
Q2
A6
B31
B71
2384S05 Y5
B32
B3
Q3
Q
A6 Room units
B1 Flow sensor heating circuit 1
B12 Flow sensor heating circuit 2
B3 D.h.w. flow sensor
B31 Storage tank sensor 1
B32 Storage tank sensor 2
B7 Primary return sensor heating circuit 1*
