SIMATIC NET
TeleControl
Configuration - DNP3
Configuration Manual
Configuration and diagnostics
11/2018
C79000
-G8976-C508-01
Preface
Functions and requirements
1
Communication mechanisms
2
Configuration
3
Diagnostics
4
OUC program blocks (CP)
A
SINEMA Remote Connect
(CP)
B
WBM of the TIM 1531 IRC
C
Bibliography
D

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C508-01
Ⓟ
11/2018 Subject to change
Copyright © Siemens AG 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 3
Preface
Validity of this manual
This manual is valid for all communications modules of the SIMATIC NET range listed below
which support the telecontrol protocol DNP3.
Note the structure of the documentation.
Supported modules
You can find the devices for which the configuration manual is valid in the section
Communications modules (Page 11).
Structure of the documentation
The documentation for the SIMATIC NET communications modules for Telecontrol consists
of the following manuals in each case:
●Manual or operating instructions
●One or more configuration manuals
The documentation for the modules specified above consists of the following manuals and
contents:
●
Manual / Operating instructions
Valid for the respective module or module group
–Application and functions
–Requirements (CPUs, configuration software, etc.)
–Hardware description
–Installation, wiring, commissioning, operation
–Diagnostics, maintenance
–Technical specifications, approvals, accessories
●
SINAUT ST7 system manual
–
Volume 1 - System and hardware
Valid for: TIM 3V-IE, TIM 3V-IE Advanced, TIM 4R-IE
Hardware description, installation, wiring, commissioning, operation, technical
specifications, approvals
–
Volume 2 - Configuration under STEP 7 V5
Valid for: TIM 3V-IE, TIM 3V-IE Advanced, TIM 4R-IE
–
Volume 3 - Configuration under STEP 7 Professional (TIA Portal)
Valid for all ST7-capable communications modules

Preface
Configuration - DNP3
4Configuration Manual, 11/2018, C79000-G8976-C508-01
●
Configuration manual DNP3
Configuration and diagnostics in STEP 7 Professional (TIA Portal)
Valid for all SIMATIC NET communications modules that support the DNP3 protocol.
●
Configuration manual IEC
Configuration and diagnostics in STEP 7 Professional (TIA Portal)
Valid for all SIMATIC NET communications modules that support the protocol IEC
60870-5-101/104.
You can find the Internet links for the manuals in the Bibliography (Page 187).
Abbreviations/device names
This manual often uses the following abbreviations/acronyms:
●
Module / device
Names for the respective communications modules
●
WBM
"WBM" is the acronym for the "Web Based Management", the pages of the TIM Web
server for configuration and diagnostics data.
New in this release
First issue
Current manual release on the Internet
You will also find the current version of this manual on the Internet pages of Siemens
Industry Online Support:
Link: (https://support.industry.siemens.com/cs/ww/en/ps/21764/man)
Required experience
Knowledge in the following areas is required for configuration and diagnostics of the devices:
●Setting up industrial networks with security functions
●Data transfer via WAN networks
●SIMATIC STEP 7 Professional
Cross references
In this manual there are often cross references to other sections.
To be able to return to the initial page after jumping to a cross reference, some PDF readers
support the command <Alt>+<left arrow>.

Preface
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 5
License conditions
Note
Open source software
The product contains open source software. Read the license conditions for open source
software carefully before using the product.
The manual for the relevant product provides information on finding the license conditions.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
Link: (http://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
Link: (http://www.siemens.com/industrialsecurity)
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary here:
●SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
●On the Internet under the following address:
Link: (http://support.automation.siemens.com/WW/view/en/50305045)

Preface
Configuration - DNP3
6Configuration Manual, 11/2018, C79000-G8976-C508-01

Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 7
Table of contents
Preface ................................................................................................................................................... 3
1 Functions and requirements.................................................................................................................. 11
1.1 Communications modules ......................................................................................................11
1.2 Configuration examples ..........................................................................................................12
1.3 Usable CPUs ..........................................................................................................................15
1.4 Software requirements............................................................................................................15
1.5 Performance data and configuration limits .............................................................................16
1.5.1 TIM 1531 IRC..........................................................................................................................16
1.5.2 TIM 4R-IE DNP3 / TIM 3V-IE DNP3 .......................................................................................17
1.5.3 CP 1243-8 IRC........................................................................................................................19
1.5.4 CP 1243-1...............................................................................................................................21
1.5.5 CP 1542SP-1 IRC...................................................................................................................22
1.6 PG routing...............................................................................................................................23
2 Communication mechanisms ................................................................................................................ 25
2.1 Addressing and network configuration....................................................................................25
2.2 Communications options ........................................................................................................26
2.3 Connection establishment ......................................................................................................27
2.4 Acknowledgment.....................................................................................................................28
3 Configuration ........................................................................................................................................ 29
3.1 Security recommendations .....................................................................................................29
3.2 Communication types .............................................................................................................32
3.3 Basic settings / Options ..........................................................................................................33
3.3.1 Basic settings..........................................................................................................................33
3.3.2 Options....................................................................................................................................35
3.4 Configuration of interfaces, networks and network nodes......................................................36
3.4.1 WAN settings of the interfaces ...............................................................................................36
3.4.2 Networking of the interfaces ...................................................................................................38
3.5 Ethernet interface....................................................................................................................40
3.5.1 Ethernet interface > address parameters ...............................................................................40
3.5.2 Advanced options ...................................................................................................................41
3.5.2.1 TCP connection monitoring ....................................................................................................41
3.5.2.2 Transmission settings .............................................................................................................42
3.5.3 Web server access .................................................................................................................42
3.5.3.1 CP ...........................................................................................................................................42
3.5.3.2 TIM 1531 IRC..........................................................................................................................42
3.6 Serial interface ........................................................................................................................43
3.6.1 Advanced options ...................................................................................................................43

Table of contents
Configuration - DNP3
8Configuration Manual, 11/2018, C79000-G8976-C508-01
3.6.1.1 Dedicated line ........................................................................................................................ 43
3.6.1.2 Dialup network ....................................................................................................................... 47
3.6.1.3 Transmission settings ............................................................................................................ 51
3.7 Configuring WAN networks.................................................................................................... 51
3.8 DNP3 parameters of the interfaces........................................................................................ 53
3.8.1 Transmission settings – DNP3............................................................................................... 53
3.8.2 Settings DNP3 master ........................................................................................................... 55
3.8.3 Settings DNP3 station............................................................................................................ 56
3.9 Web server............................................................................................................................. 59
3.10 Web diagnostics..................................................................................................................... 61
3.10.1 Web diagnostics of the TIM 1531 IRC ................................................................................... 61
3.11 DNS configuration.................................................................................................................. 61
3.12 Communication with the CPU................................................................................................ 62
3.13 Time-of-day synchronization.................................................................................................. 67
3.14 E-mail configuration ............................................................................................................... 72
3.15 Subscriber numbers............................................................................................................... 73
3.16 SNMP..................................................................................................................................... 74
3.17 Security (CP) and certificates ................................................................................................ 75
3.17.1 Parameters............................................................................................................................. 75
3.17.2 Security user .......................................................................................................................... 75
3.17.3 Log settings - Filtering of the system events ......................................................................... 76
3.17.4 VPN........................................................................................................................................ 76
3.17.4.1 VPN (Virtual Private Network)................................................................................................ 76
3.17.4.2 Creating a VPN tunnel for S7 communication between stations ........................................... 77
3.17.4.3 VPN communication with SOFTNET Security Client (engineering station)........................... 79
3.17.4.4 Establishment of VPN tunnel communication between the CP and SCALANCE M ............. 80
3.17.4.5 CP as passive subscriber of VPN connections...................................................................... 80
3.17.5 Certificate manager................................................................................................................ 81
3.17.6 Handling certificates............................................................................................................... 81
3.18 Protection (TIM 1531 IRC) ..................................................................................................... 83
3.18.1 Protection ............................................................................................................................... 83
3.18.2 Configuring access protection................................................................................................ 85
3.19 Telecontrol connections ......................................................................................................... 86
3.19.1 Telecontrol connections ......................................................................................................... 86
3.19.2 "Network data" editor ............................................................................................................. 87
3.19.3 Specifying connection paths .................................................................................................. 89
3.19.4 Connection table .................................................................................................................... 92
3.19.5 Parameters of the DNP3 connections ................................................................................... 97
3.19.5.1 General .................................................................................................................................. 97
3.19.5.2 TCP connection monitoring.................................................................................................... 98
3.19.5.3 DNP3 security options ........................................................................................................... 99
3.19.5.4 Transmission settings – DNP3............................................................................................. 102
3.19.5.5 Third-party device parameters ............................................................................................. 102
3.20 Configuring data points ........................................................................................................ 103
3.20.1 Data point configuration ....................................................................................................... 103

Table of contents
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 9
3.20.2 Datapoint types .....................................................................................................................109
3.20.3 "General" tab.........................................................................................................................112
3.20.4 Rules for configuring the data point index: ...........................................................................113
3.20.5 Process image, type of transmission, event classes ............................................................113
3.20.6 Read cycle ............................................................................................................................115
3.20.7 "Trigger“ tab ..........................................................................................................................116
3.20.8 Threshold value trigger .........................................................................................................117
3.20.9 Analog value preprocessing .................................................................................................119
3.20.10 Command output ..................................................................................................................125
3.20.11 Partner stations.....................................................................................................................130
3.21 Configuring messages ..........................................................................................................130
3.21.1 Messages..............................................................................................................................130
3.21.2 Character set for messages..................................................................................................132
4 Diagnostics ......................................................................................................................................... 133
4.1 Diagnostics options...............................................................................................................133
4.2 Online security diagnostics via port 8448 (CP).....................................................................135
4.3 Online functions ....................................................................................................................135
4.4 SNMP....................................................................................................................................136
4.5 SINAUT special diagnostics .................................................................................................137
4.5.1 SINAUT-Spezial-Diagnose - Gültigkeit.................................................................................137
4.5.2 TIM diagnostics.....................................................................................................................138
4.5.2.1 TIM Diagnostics - functions ..................................................................................................138
4.5.2.2 TIM Diagnostics - Memory tab..............................................................................................139
4.5.2.3 TIM Diagnostics - Message buffer tab..................................................................................139
4.5.2.4 TIM Diagnostics - Communication tab..................................................................................141
4.5.2.5 TIM Diagnostics - Time Synchronization tab ........................................................................141
4.5.2.6 TIM Diagnostics - Time tab...................................................................................................141
4.5.2.7 TIM Diagnostics - Filesystem tab..........................................................................................142
4.5.2.8 TIM diagnostics - IP Parameters tab ....................................................................................142
4.5.2.9 TIM diagnostics - IP statistics tab .........................................................................................142
4.5.2.10 TIM diagnostics - MSC Communication tab .........................................................................143
4.5.3 TIM subscriber diagnostics ...................................................................................................145
4.5.3.1 TIM Subscriber Diagnostics - functions ................................................................................145
4.5.3.2 TIM Subscriber Diagnostics - Status tab ..............................................................................147
4.5.3.3 TIM Subscriber Diagnostics - Partner tab.............................................................................148
4.5.3.4 TIM Subscriber Diagnostics - Dialing extern tab ..................................................................149
4.5.3.5 TIM Subscriber Diagnostics - Polling intern..........................................................................150
4.5.4 TD7onTIM diagnostics..........................................................................................................151
4.5.4.1 TD7onTIM Diagnostics - functions........................................................................................151
4.6 Processing status of the messages (e-mail).........................................................................153
4.7 Maintenance .........................................................................................................................155
A OUC program blocks (CP) .................................................................................................................. 157
A.1 Validity ..................................................................................................................................157
A.2 Program blocks for OUC.......................................................................................................157
A.3 Changing the IP address during runtime ..............................................................................159

Table of contents
Configuration - DNP3
10 Configuration Manual, 11/2018, C79000-G8976-C508-01
B SINEMA Remote Connect (CP) ...........................................................................................................161
B.1 Validity.................................................................................................................................. 161
B.2 Connection to SINEMA RC.................................................................................................. 161
B.3 Telecontrol via SINEMA RC................................................................................................. 163
B.4 Security > VPN > SINEMA Remote Connect ...................................................................... 164
C WBM of the TIM 1531 IRC ...................................................................................................................167
C.1 Supported Web browsers .................................................................................................... 167
C.2 Establishing a connection to the WBM of the TIM ............................................................... 167
C.3 General functions of the WBM............................................................................................. 168
C.4 Start page............................................................................................................................. 169
C.5 System ................................................................................................................................. 171
C.5.1 Device info ........................................................................................................................... 171
C.5.2 SD card ................................................................................................................................ 171
C.5.3 System time ......................................................................................................................... 172
C.5.4 NTP ...................................................................................................................................... 172
C.5.5 Web server........................................................................................................................... 172
C.5.6 DNS configuration................................................................................................................ 173
C.6 Maintenance......................................................................................................................... 173
C.6.1 Firmware .............................................................................................................................. 173
C.6.2 Operating status................................................................................................................... 174
C.7 Diagnostics........................................................................................................................... 176
C.7.1 Events .................................................................................................................................. 176
C.7.2 Notifications.......................................................................................................................... 177
C.8 LAN ...................................................................................................................................... 178
C.8.1 Ethernet interface [Xn] ......................................................................................................... 178
C.9 Telecontrol ........................................................................................................................... 180
C.9.1 Partner information .............................................................................................................. 180
C.9.1.1 Connection overview............................................................................................................ 180
C.9.1.2 Send buffer........................................................................................................................... 183
C.9.2 Data points ........................................................................................................................... 185
C.10 Logging ................................................................................................................................ 186
D Bibliography.........................................................................................................................................187
Index ...................................................................................................................................................191

Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 11
Functions and requirements
1
1.1
Communications modules
Communications modules for the telecontrol protocol DNP3
The following SIMATIC NET communications modules can be used for the telecontrol
protocol DNP3.
You will find the TIM 4R-IE DNP3 with article number 6NH7803-4BA00-0AA0 twice in the
STEP 7 catalog, as built-in unit (S7-300 rack) and as stand-alone device.
Meaning of symbols in the table:
●X = Supported
●- = Not supported
Table 1- 1 Communications modules for DNP3
Module
Article number
Number of inter-
faces *
Station type
STEP 7
product
Required
firmware
IE
RS
Master
Node station
Station
TIM 1531 IRC
6GK7 543-1MX00-0XE0
3 1 X X X STEP 7
Professional
V2.0
TIM 4R-IE DNP3 /
TIM 4R-IE DNP3 Stand-alone
6NH7803-4BA00-0AA0
2 2 X X X STEP 7
Professional
V3.2
TIM 3V-IE DNP3
6NH7803-3BA00-0AA0
1 1 X X X STEP 7
Professional
V3.2
CP 1243-8 IRC
6GK7 243-8RX30-0XE0
1
- ***
-
-
X STEP 7
Basic
**
/
Professional
V3.1
CP 1243-1
6GK7 243-1BX30-0XE0
6AG1 243-1BX30-2AX0
1
-
-
-
X STEP 7
Basic
**
/
Professional
V3.1
CP 1542SP-1 IRC
6GK7 542-6VX00-0XE0
1
-
-
-
X STEP 7
Professional
V2.0
*
IE = Ethernet interfaces, RS = serial interfaces
**
STEP 7 Basic with connection of the CP to a third-party master. See note below.
*** The connection of a TS-Module to the CP 1243-8 IRC is not supported for DNP3.

Functions and requirements
1.2 Configuration examples
Configuration - DNP3
12 Configuration Manual, 11/2018, C79000-G8976-C508-01
Notes on the table
Notes on the columns:
●
Station type "Node station"
A node station is located in the plant hierarchy between the master station and other
lower-level stations. The module requires at least two interfaces.
In the configuration, the "network node type" of the interface connected to the master
station is configured as "Node station". See section Networking of the interfaces
(Page 38) for information on this.
●
STEP 7 product with S7-1200 CPs
S7-1200 CPs can be configured under STEP 7 Basic for connection to a third-party
master.
You need STEP 7 Professional project to connect the CPs to SIMATIC NET master or
node stations configured in STEP 7.
●
Firmware
The required firmware versions of the modules relate to the complete configuration
described in this manual. You can find the required STEP 7 version for this in the section
Software requirements (Page 15).
Modules with lower firmware versions can be configured in older STEP 7 versions with a
deviating scope of functions.
1.2
Configuration examples
Below, you will find several configuration examples with the communications modules that
can be used.
Communication via Ethernet / Internet, sending e-mails
In the sample configuration shown, S7 stations communicate with the master station via the
Ethernet interfaces of the different modules.
With their Ethernet interfaces, TIM modules enable connection to a redundant master
station.

Functions and requirements
1.2 Configuration examples
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 13
Figure 1-1 Communication via Ethernet / Internet
E-mails
The modules can generate and send e-mails due to events. The following recipients are
possible:
●PCs with an Internet connection
●Cell phones
●SIMATIC stations with the appropriate program blocks
Inter-station communication
Direct inter-station communication between S7 stations with a TIM is possible via IP-based
networks.
Inter-station communication, in contrast, runs via a master station that forwards the frames to
the target subscriber.

Functions and requirements
1.2 Configuration examples
Configuration - DNP3
14 Configuration Manual, 11/2018, C79000-G8976-C508-01
Path redundancy using the serial interface
In the following example, the Ethernet interface and the serial interface are used with the
TIM 1531 IRC to set up redundant transmission paths.
●Ethernet interface for communication via Ethernet / Internet
●Serial interface for communication via a WAN network (dedicated line or dialup network)
Figure 1-2 Communication via redundant paths
Path redundancy is also possible over two Ethernet networks.

Functions and requirements
1.3 Usable CPUs
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 15
1.3
Usable CPUs
Compatible CPUs
The following can be configured as assigned CPUs of the communications modules:
●
TIM 1531 IRC
–S7-1500
All CPUs as of firmware version V2.1
–S7-300
All CPUs with PROFINET interface
–S7-400
All CPUs with PROFINET interface
●
CP 1243-1 / CP 1243-8 IRC
CPU with firmware version as of V4.2
●
CP 1542SP-1 IRC
CPUs as of firmware version V2.0:
–CPU 1510SP-1 PN
–CPU 1510SP F-1 PN
–CPU 1512SP-1 PN
–CPU 1512SP F-1 PN
You will find more detailed information on the CPUs and the BusAdapters in the manual
/5/ (Page 188).
1.4
Software requirements
Software for configuration and online functions
To configure the modules, the following configuration tool is required:
●STEP 7 Professional V15.1

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
16 Configuration Manual, 11/2018, C79000-G8976-C508-01
1.5
Performance data and configuration limits
1.5.1
TIM 1531 IRC
Connection resources
●
Telecontrol connections
The number of connections or communications partners is limited for the two interface
types and every individual interface.
Note that redundant connection paths of a connection between two partners require two
connection resources on each partner.
–Max. number of connections: 128
Distribution over 4 interfaces can take place in any way (max. 128 per interface).
●
E-mail
A connection to send e-mails can be established during runtime.
●
S7 connections
–Max. 4 connection resources for PG/OP connections (see below)
●
PG/OP connections
4 connection resources for connections to the engineering station or HMI devices
(included in the configuration limits of the S7 connections, see above)
●
PG routing
Max. 4 connections at the same time
●
Online functions
See PG/OP connections
●
HTTP/HTTPS
Max. 2 connections per Ethernet interface
Number of data points for the data point configuration
The maximum number of configurable data points is 3000.
Message memory: Send buffer / SD card
The TIM has a frame memory (send buffer) for the values of data points configured as an
event.
The send buffer has the following maximum size (number of events):
●250000
The size of the frame memory is divided equally among all configured communications
partners.

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 17
You will find details of how the send buffer works (storing and sending events) as well as the
options for transferring data in the section Process image, type of transmission, event
classes (Page 113).
For information on saving events on an optional SD card, see section Basic settings
(Page 33).
Messages: E-mail
Up to 10 messages which the TIM can send as e-mails can be configured in STEP 7.
●Number of characters per e-mail
Maximum number of characters that can be transferred per e-mail: 256 ASCII characters
including any value sent at the same time
1.5.2
TIM 4R-IE DNP3 / TIM 3V-IE DNP3
Number of DNP3 connections
You will find the connection resources in the form of the table after the following listing.
TIM configured as DNP3 master station / node station
●
TIM 4R-IE DNP3
Number in total: Max. 128,
of which:
–Pro Ethernet interface:
- Configured with master station function: Max. 64
- Configured with station function: Max. 16
–Pro RS-232 interface:
- Configured with master station function: Max. 32
- Configured with station function: Max. 16
●
TIM 3V-IE DNP3
Number in total: Max. 8,
of which:
–Via the Ethernet interface: Max. 8
–Via the RS-232 interface: Max. 8
TIM configured as DNP3 station
●
TIM 4R-IE DNP3
Number in total: Max. 32,
of which:
–Per Ethernet interface Max. 16
–Per RS-232 interface: Max. 16

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
18 Configuration Manual, 11/2018, C79000-G8976-C508-01
●
TIM 3V-IE DNP3
Number in total: Max. 8,
of which:
–Via the Ethernet interface: Max. 8
–Via the RS-232 interface: Max. 8
Note
Double the connection resources with direct communication between stations (only via
Ethernet or dial-up network)
Note that when there is direct communication between two stations, 2 connection
resources
are occupied per station: One for the master station connection, one for the station
connection.
Table 1- 2 Overview of the connection resources
TIM type
Subscriber type /
interface configura-
tion
Max. number of
connections per
TIM in total
Interface
Network type
Max. number of
connections per
interface
TIM 4R-IE DNP3 Master station 128
*
Ethernet 1
TCP
64
Ethernet 2
TCP
64
RS232 no. 1
Dedicated line
32
Dialup network
32
RS232 no. 2
Dedicated line
32
Dialup network
32
Station 32
Ethernet 1
TCP
16
Ethernet 2
TCP
16
RS232 no. 1
Dedicated line
16
Dialup network
16
RS232 no. 2
Dedicated line
16
Dialup network
16
TIM 3V-IE DNP3 Master station /
node station
8
Ethernet
TCP
8
RS232 Dedicated line 8
Dialup network
8
Station 8 Ethernet TCP 8
RS232
Dedicated line
8
Dialup network
8
*
The total number of 128 also applies to the TIM 4R IE DNP3 as a node station. The maximum number per interface is
obtained from the information in the "Master station" or "Station" rows.
Number of communications objects per TIM
The maximum number of communications objects for DNP3 communication per TIM is 100.

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01 19
Size of the message memory for events
●TIM 3V-IE DNP3: 64 000 events
●TIM 4R-IE DNP3: 200 000 events
Number of S7 connections via Ethernet
In addition to the DNP3 connections, the number of possible S7 connections via the Ethernet
interface is as follows:
●
TIM 4R-IE DNP3
Number in total: Max. 5,
of which:
–2 configurable S7 connections
–2 PG connections
–1 OP connection
●
TIM 3V-IE DNP3
Number in total: Max. 3,
of which:
–2 PG connections
–1 OP connection
No S7 connections can be established via the serial interface.
Number of MODBUS slaves per station
The maximum number of MODBUS slaves that can be connected to the serial interface of a
TIM depends on the configured interface standard:
●RS-232: Maximum of 1 MODBUS slave
●RS-485: Maximum of 8 MODBUS slaves
1.5.3
CP 1243-8 IRC
Number of CMs/CPs per station
In each S7-1200 station, up to three CMs/CPs can be plugged in and configured, of which a
maximum of one CP 1243-8 IRC.

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
20 Configuration Manual, 11/2018, C79000-G8976-C508-01
Connection resources
●
Telecontrol connections
The CP can establish connections to up to 4 communications partners.
The partners can be linked redundantly.
●
TCP connections
The CP can establish connections to up to 4 communications partners (S7 stations).
●
Online functions
1 connection resource is reserved for online functions.
●
S7 connections
8 connection resources for S7 connections (BSEND/BRCV)
●
S7 routing
Max. 4 connections at the same time
●
PG/OP connections
–2 connection resources for PG connections
–1 connection resource for OP connections
Number of data points for the data point configuration
The maximum number of configurable data points is 200.
Frame memory (send buffer)
The CP has a frame memory (send buffer) for the values of data points configured as an
event.
The send buffer has a maximum size of 64000 events. The size of the frame memory is
divided equally among all configured communications partners. It can be set in STEP 7, refer
to the section Communication with the CPU (Page 62).
You will find details of how the send buffer works (storing and sending events) as well as the
options for transferring data in the section Process image, type of transmission, event
classes (Page 113).
Messages: E-mail
Up to 10 messages to be sent as e-mails can be configured in STEP 7.
●Maximum number of characters that can be transferred per e-mail: 256 ASCII characters
including any value sent at the same time
IPsec tunnel (VPN)
Up to 8 IPsec terminals can be established for secure communication with other security
modules.
