Siemens SIMATIC ET 200SP HA User manual

SIMATIC
ET 200SP HA
Interface Module IM 155-6 PN HA
(6DL1155-6AU00-0PM0)
Manual
05/2017
A5E39262148-AA
Security information 1
Product overview 2
Wiring 3
Parameters 4
Maintenance 5
Displays and interrupts 6
Technical specifications 7
Diagnostic messages A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions. Qualified
personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in
this publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E39262148-AA
Ⓟ 05/2017 Subject to change
Copyright © Siemens AG 2017.
All rights reserved

Table of contents
1 Security information......................................................................................................................................5
2Product overview..........................................................................................................................................7
2.1 Properties.................................................................................................................................7
3Wiring.........................................................................................................................................................11
3.1 Pin assignment.......................................................................................................................11
3.2 Schematic circuit diagram......................................................................................................13
4 Parameters.................................................................................................................................................15
4.1 Parameter assignment...........................................................................................................15
5 Maintenance...............................................................................................................................................17
5.1 Exchanging the BusAdapter or interface of the distributed I/O..............................................17
6 Displays and interrupts...............................................................................................................................19
6.1 Status and error displays.......................................................................................................19
6.2 Interrupts................................................................................................................................23
7 Technical specifications..............................................................................................................................25
A Diagnostic messages.................................................................................................................................31
A.1 Diagnostics messages and maintenance events...................................................................31
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 3

Table of contents
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
4Manual, 05/2017, A5E39262148-AA

Security information 1
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines, and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines and
networks. Systems, machines and components should only be connected to the enterprise
network or the internet if and to the extent necessary and with appropriate security measures
(e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
http://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends to apply product updates as soon as available and to always
use the latest product versions. Use of product versions that are no longer supported, and
failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
http://www.siemens.com/industrialsecurity.
Validity of the documentation
This product manual describes the IM 155-6 PN HA interface module with the article number
6DL1155-6AU00-0PM0.
It supplements the system manual of the ET 200SP HA Distributed I/O System .
Functions that generally relate to the system are described in this manual.
The information in this product manual, system manual and function manual enables you to
commission the ET 200SP HA distributed I/O system.
Conventions
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product, or on the section of the documentation to which particular attention
should be paid.
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 5

Security information
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
6Manual, 05/2017, A5E39262148-AA

Product overview 2
2.1 Properties
View
①Module type and designation ⑧MAC address (specific address for this exact module)
②LED for operating state ⑨Function status and firmware version
③LED for diagnostics ⑩Article number
④LED for maintenance ⑪Connector for supply voltage
⑤2D matrix code ⑫Slot for PROFINET BusAdapter
⑥LED for master operation ⑬PROFINET BusAdapter
⑦LED for supply voltage ⑭Terminal block for interface module (figure: for redundant
interface modules)
Figure 2-1 View of IM 155‑6 PN HA
Properties
The IM 155‑6 PN HA, together with the carrier and BusAdapter, forms the interface of the
ET 200SP HA.
The interface is used for communication between the CPU and the connected ET 200SP HA
I/O modules via PROFINET IO.
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 7

The interface has the following technical properties:
● Supply voltage 1L+ 24 V DC (SELV/PELV).
The supply voltage is fed via the carrier module.
The connection plug is included in the scope of delivery of the interface module.
● PROFINET IO connection via BusAdapter (see following paragraph, "Accessories")
The interface supports the following functions:
● Firmware update
● I&M identification data
● Pulling and plugging modules in RUN
● Value status QI
● IO redundancy
● Time stamping
● Multi Hot Swap (pulling/plugging of multiple I/O modules during operation)
● Saving service data
● Recording the value status of I/O modules
● Reference temperature distribution
You can configure the interface with HW Config and integrate it into your system
Note
The IM 155‑6 PN HA cannot be pulled/plugged when the associated connector for the supply
voltage is plugged in.
PROFINET IO functions
The interface supports the following PROFINET IO functions:
● Integrated BusAdapter with 2 ports
● Supported Ethernet services: ping, arp, network diagnostics (SNMP)/MIB-2, LLDP-MIB and
MRP-MIB
● Port diagnostics
● Disabling of ports
● Minimum update time of 250 µs
● Device replacement without programming device (PG)
● Reset to factory settings via PROFINET IO
● System redundancy S2
● System redundancy R1
● Media redundancy (MRP)
● Support of submodules on suitable I/O modules
Product overview
2.1 Properties
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
8Manual, 05/2017, A5E39262148-AA

Accessories
The following accessories must be ordered separately:
BusAdapter
● BusAdapter BA 2×RJ45 (6DL1-6AR00-0AA0) - adapter for Ethernet cable with RJ45
connector
● BusAdapter BA 2×FC (6DL1-6AP00-0AA0) - adapter for direct connection of the Fast
Connect bus cable
● BusAdapter BA 2×LC (6DL1-6AG00-0AA0) - adapter for glass fiber optic cable with
IE FC FO connector
Carrier modules
● Carriers for the IM 155‑6 PN HA are available in the following variants:
– Carrier for one IM 155‑6 PN HA
– Carrier for two IM 155‑6 PN HA for redundant configuration
The carriers connect the IM 155‑6 PN HA to the backplane bus. They enable data exchange
with the I/O modules.
Server module and power bus cover
● The server module and power bus cover are included in the product package of the carrier
module and are available separately as accessories.
● The server module and power bus cover terminate the configuration of the ET 200SP HA.
● Place the server module and the power bus cover at the end of the configuration.
The power bus cover serves to protect the power bus contacts.
Marking options
● Labeling strips
● Reference identification label
Product overview
2.1 Properties
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 9

Product overview
2.1 Properties
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
10 Manual, 05/2017, A5E39262148-AA

Wiring 3
3.1 Pin assignment
24 V DC supply voltage
The following table shows the signal names and the descriptions of the pin assignment for a
24 V DC supply voltage.
Table 3-1 Pin assignment 24 V DC supply voltage
View Signal name1Description
Plug IM connection
//00
1L+ 24 V DC
2L+ 24 V DC (for looping through)2
1M Ground
2M Ground (for looping through)2
11L+ and 2L+ as well as 1M and 2M are bridged internally.
2Maximum 10 A permitted.
Each interface module has its own 24 V connection.
PROFINET IO with BusAdapter BA 2×RJ45
The following table shows the signal name and designation of the pin assignment of the
BusAdapter BA 2×RJ45.
Table 3-2 Pin assignment of PROFINET IO with BusAdapter BA 2×RJ45
View Signal name Description
6KLHOGLQJ3RUW3RUW6KLHOGLQJ
1 TD Transmit data +
2 TD_N Transmit data –
3 RD Receive data +
4 GND Ground
5 GND Ground
6 RD_N Receive data –
7 GND Ground
8 GND Ground
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 11

PROFINET IO with BusAdapter BA 2×FC
The following table shows the signal name and designation of the pin assignment of the
BusAdapter BA 2×FC.
Table 3-3 Pin assignment of PROFINET IO with BusAdapter BA 2×FC
View Signal name Description
6KLHOGLQJ3RUW3RUW
1 TD Transmit data +
2 TD_N Transmit data –
3 RD Receive data +
4 RD_N Receive data -
PROFINET IO with BusAdapter BA 2×LC
The following table shows the signal name and designation of the pin assignment of the
BusAdapter BA 2×LC.
Table 3-4 Pin assignment of PROFINET IO with BusAdapter BA 2×LC
View Signal
name
Description
3RUW3RUW
①Receiver / Receive data
②Sender / Transmit data
Wiring
3.1 Pin assignment
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
12 Manual, 05/2017, A5E39262148-AA

3.2 Schematic circuit diagram
Schematic circuit diagram
The following figure shows the block diagram of the IM 155‑6 PN HA interface module.
/;'&903:507(5513535;/./.$&7
①Switch L+ Supply voltage (24 V DC)
②Backplane bus connection and electronics M Ground
③Backplane bus LK 1,2 Link TX/RX LED
④Internal voltage distribution ACT ACT LED
X80 Supply voltage infeed (24 V DC) RN RUN LED (green)
X5 BusAdapter ER ERROR LED (red)
P1 R PROFINET interface X1 Port 1 MT MAINTENANCE LED (yellow)
P2 R PROFINET interface X1 Port 2 PWR Power LED (green)
Figure 3-1 Block diagram for the IM 155-6 PN HA interface module
Wiring
3.2 Schematic circuit diagram
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 13

Wiring
3.2 Schematic circuit diagram
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
14 Manual, 05/2017, A5E39262148-AA

Parameters 4
4.1 Parameter assignment
Configuring
You configure the ET 200SP HA on a CPU 410 as of FW V8.2.
Parameters
The parameter assignment specifies the properties of the IO device.
Additional information
You can find information on basic procedures and available settings in the following
documentation:
● STEP 7 online help
● Function manual
SIMATIC; ET 200SP HA; ET 200SP HA - High-precision Time Stamping
● When PCS 7 as of V9.0 is used:
– Configuration manual PCS 7 Process Control System; Engineering System V9.0
– Function manual SIMATIC; Process Control System PCS 7; High-precision Time
Stamping with ET 200SP HA
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 15

Parameters
4.1 Parameter assignment
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
16 Manual, 05/2017, A5E39262148-AA

Maintenance 5
5.1 Exchanging the BusAdapter or interface of the distributed I/O
The device name of the distributed I/O device is saved at the following locations when
transferring the device name to the distributed I/O:
● In the BusAdapter
● In the interface of the distributed I/O device (e.g. interface module or I/O device itself)
Note
Replacing a BusAdapter (removing/inserting)
Removing/inserting the BusAdapter under voltage is prohibited.
Device replacement without transfer of topological configuration
The following scenarios are the result of saving the device name on the BusAdapter and in
the interface when exchanging the two components:
Interface non-program‐
med
(without device name)
Interface with device name
BusAdapter non-programmed
(without device name)
No device names When the supply voltage is switched on,
the device name is copied from the inter‐
face to the BusAdapter.
BusAdapter with device name When the supply voltage is switched on, the device name is copied
from the BusAdapter to the interface.
Note
Restoring the factory settings
Not possible for ET 200SP HA:
The reset to factory settings deletes the device name in the interface and in the BusAdapter.
Avoiding deleting of the device name in the BusAdapter:
Proceed as follows:
1. Pull the BusAdapter from the distributed I/O device.
2. Restore the factory settings of the distributed I/O device.
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 17

Maintenance
5.1 Exchanging the BusAdapter or interface of the distributed I/O
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
18 Manual, 05/2017, A5E39262148-AA

Displays and interrupts 6
6.1 Status and error displays
LED displays
The status and error displays of the IM 155-6 PN HA are shown in the figure below.
SIEMENS

①RN LED (green)
②ER LED (red)
③MT LED (yellow)
④ACT LED (green)
⑤PWR LED (green)
On BusAdapter:
⑥LED LK1 (green)
⑦LED LK2 (green)
Figure 6-1 LED displays on the interface module and BusAdapter
Meaning of the LED displays
The following tables provide the meaning of the status, error and maintenance displays. You
can find remedies for diagnostic messages in the section Diagnostics messages and
maintenance events (Page 31)
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
Manual, 05/2017, A5E39262148-AA 19

RN LED
Table 6-1 Status and error displays of the RN LED
RN LED Meaning Remedy
Off
No supply voltage or insufficient supply voltage at the
interface module.
Check the supply voltage or switch it on at the inter‐
face module.
Check the backplane bus for short-circuit
Flashes
Interface module is deactivated. Activate the interface module with the configuration
software or the user program.
Interface module is not configured. Configure the interface module with the configuration
software.
ET 200SP HA starts up. ---
ET 200SP HA parameters are assigned
On
ET 200SP HA is exchanging data with the IO Control‐
ler.
---
ER LED
Table 6-2 Error displays of the ER LED
ER LED Meaning Remedy
Flashes
Group fault and group fault for channels Evaluate the diagnostics and eliminate the error.
Configured settings do not match the actual configu‐
ration of the ET 200SP HA.
Check the configuration of the ET 200SP HA for miss‐
ing modules, defective modules or the presence of
non-configured modules.
Impermissible configuration states You can find information about the hardware configu‐
ration of the ET 200SP HA in the system manual
ET 200SP HA Distributed I/O System ; System Plan‐
ning, Hardware Configuration.
Parameter assignment error in the I/O module Evaluate the display of the module information in HW-
Konfig and eliminate the error in the corresponding I/
O module.
Note
Configuration errors are only checked when the station starts up and not during a CiR or H-
CiR process.
Displays and interrupts
6.1 Status and error displays
Interface Module IM 155-6 PN HA (6DL1155-6AU00-0PM0)
20 Manual, 05/2017, A5E39262148-AA
