Siemens SIRIUS 3RW30 User manual

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
Industrial Controls
Soft starters
SIRIUS 3RW30 / 3RW40
Manual
10/2018
NEB535199502000/RS
-AB/005
Introduction
1
Safety information
2
Product description
3
Product combinations
4
Functions
5
Messages and diagnosis
6
Application planning
7
Installation
8
Installation / mounting
9
Connecting
10
Operation
11
Configuration
12
Commissioning
13
Technical data
14
Dimension drawings
15
Typical circuit diagrams
16
Appendix
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
3ZX1012-0RW30-1AC1
Ⓟ
10/2018 Subject to change
Copyright © Siemens AG 2009.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 3
Table of contents
1 Introduction............................................................................................................................................. 9
1.1 Important notes .........................................................................................................................9
1.2 Additional documentation .......................................................................................................11
1.3 Siemens Industry Online Support ...........................................................................................13
1.4 Technical Assistance ..............................................................................................................15
1.5 Siemens Industry Online Support app ....................................................................................15
2 Safety information ................................................................................................................................. 17
2.1 ESD Guidelines.......................................................................................................................17
2.2 Reactive power compensation................................................................................................19
2.3 Electromagnetic compatibility (EMC) according to IEC 60947-4-1 ........................................19
2.4 Security information ................................................................................................................20
2.5 Recycling and disposal ...........................................................................................................21
2.6 Before commencing work: Isolating the equipment from the supply system and
ensuring that it cannot be reconnected...................................................................................21
2.7 Five safety rules for work in or on electrical systems .............................................................22
3 Product description ............................................................................................................................... 23
3.1 Fields of application ................................................................................................................23
3.2 Functional principle of the SIRIUS 3RW30 and 3RW40 soft starters.....................................24
3.2.1 Method of operation of a two-phase controlled soft starter ....................................................26
3.2.2 Starting current asymmetry.....................................................................................................28
3.2.3 Applications and use...............................................................................................................29
3.3 Comparison of device functions..............................................................................................30
3.4 Accessories.............................................................................................................................31
3.4.1 Accessories for 3RW30 soft starters ......................................................................................31
3.4.2 Accessories for 3RW40 soft starters ......................................................................................32
4 Product combinations............................................................................................................................ 33
4.1 SIRIUS modular system..........................................................................................................33
5 Functions .............................................................................................................................................. 35
5.1 Start modes.............................................................................................................................35
5.1.1 Voltage ramp...........................................................................................................................35
5.1.2 Current limiting and ramp-up detection (3RW40 only) ...........................................................38
5.2 Stop modes.............................................................................................................................40
5.2.1 Stop without load (3RW30 and 3RW40).................................................................................40
5.2.2 Soft stop (3RW40 only)...........................................................................................................41

Table of contents
SIRIUS 3RW30 / 3RW40
4Manual, 10/2018, NEB535199502000/RS-AB/005
5.3 Motor protection / intrinsic device protection (3RW40 only) .................................................. 42
5.3.1 Motor protection function ....................................................................................................... 42
5.3.2 Intrinsic device protection (3RW40 only) ............................................................................... 45
5.4 Functions of the RESET buttons............................................................................................ 47
5.4.1 SIRIUS 3RW402, 3RW403 and 3RW404 soft starters .......................................................... 47
5.4.1.1 Setting the RESET MODE ..................................................................................................... 47
5.4.1.2 Manual RESET ...................................................................................................................... 48
5.4.1.3 Remote RESET...................................................................................................................... 48
5.4.1.4 Auto RESET........................................................................................................................... 48
5.4.1.5 Acknowledging faults ............................................................................................................. 49
5.4.2 SIRIUS 3RW405 and 3RW407 soft starters .......................................................................... 49
5.4.2.1 Setting the RESET MODE ..................................................................................................... 49
5.4.2.2 Manual RESET ...................................................................................................................... 49
5.4.2.3 Auto RESET........................................................................................................................... 50
5.4.2.4 Acknowledging faults ............................................................................................................. 50
5.4.3 Other functions of the RESET button..................................................................................... 50
5.4.3.1 Motor protection trip test ........................................................................................................ 50
5.4.3.2 Reparameterizing the ON / RUN output contact.................................................................... 51
5.4.4 Reset options for fault acknowledgement.............................................................................. 51
5.5 Functions of the inputs........................................................................................................... 52
5.5.1 Start input (terminal 1) on 3RW30 and 3RW402 to 3RW404 ................................................ 52
5.5.2 Start input (terminal 3) on 3RW405 and 3RW407 ................................................................. 53
5.5.3 Thermistor input / connection on 3RW402 to 3RW404 ......................................................... 53
5.6 Functions of the outputs......................................................................................................... 54
5.6.1 3RW30: Output terminal 13 / 14 ON ...................................................................................... 54
5.6.2 3RW40: Output terminals 13 / 14 ON / RUN and 23 / 24 BYPASSED.................................. 54
5.6.3 3RW40: Group fault output at terminal 95 / 96 / 98 OVERLOAD / FAILURE........................ 56
6 Messages and diagnosis....................................................................................................................... 57
6.1 3RW30: LEDs ........................................................................................................................ 57
6.2 3RW30: Troubleshooting ....................................................................................................... 58
6.3 3RW402 / 3RW403 / 3RW404: LEDs .................................................................................... 59
6.4 3RW405 / 3RW407: LEDs ..................................................................................................... 61
6.5 3RW40: Troubleshooting ....................................................................................................... 63
7 Application planning.............................................................................................................................. 65
7.1 Application examples ............................................................................................................. 65
7.1.1 Roller conveyor application.................................................................................................... 65
7.1.2 Hydraulic pump application.................................................................................................... 66
8 Installation ............................................................................................................................................ 67
8.1 Installing the soft starter......................................................................................................... 67
8.1.1 Unpacking .............................................................................................................................. 67
8.1.2 Permissible mounting position ............................................................................................... 67
8.1.3 Mounting dimensions, clearances, and assembly type ......................................................... 68
8.1.4 Assembly type: Standalone assembly, side-by-side assembly, direct mounting .................. 69
8.1.5 Installation requirements........................................................................................................ 70

Table of contents
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 5
9 Installation / mounting ........................................................................................................................... 71
9.1 General information ................................................................................................................71
9.2 General feeder assembly (type of coordination 1)..................................................................72
9.3 Soft starter with line contactor (type of coordination 1) ..........................................................73
9.4 Soft starter assembly with type of coordination 2 ...................................................................74
9.5 Capacitors to improve the power factor ..................................................................................76
9.6 Maximum cable length ............................................................................................................76
10 Connecting ........................................................................................................................................... 77
10.1 Electrical connection ...............................................................................................................77
10.1.1 Control and auxiliary terminals ...............................................................................................77
10.1.2 Main circuit connection ...........................................................................................................77
11 Operation.............................................................................................................................................. 81
11.1 Operator controls, displays, and connections on the 3RW30.................................................81
11.2 Operator controls, displays, and connections on the 3RW40.................................................82
11.3 Effects on changing the potentiometer settings......................................................................84
12 Configuration ........................................................................................................................................ 85
12.1 Configuration in general..........................................................................................................85
12.1.1 Configuration procedure .........................................................................................................86
12.1.2 Selecting the optimum soft starter ..........................................................................................86
12.2 Startup class ...........................................................................................................................89
12.2.1 Application examples for normal starting (CLASS 10) with 3RW30 and 3RW40...................90
12.2.2 Application examples for heavy-duty starting (CLASS 20): 3RW40 only ...............................91
12.3 ON time and switching frequency ...........................................................................................92
12.4 Reducing the rated data .........................................................................................................93
12.5 Dimensioning of soft starters for motors with high starting current conditions .......................93
12.6 Installation altitude and ambient temperature.........................................................................94
12.7 Calculating the permissible switching frequency ....................................................................95
12.7.1 Table of permissible assembly combinations with switching frequency factors .....................95
12.7.2 Calculating the switching frequency (example) ......................................................................98
12.8 Configuration aids .................................................................................................................100
12.8.1 Selection of the soft starter using the Simulation Tool for Soft Starters ...............................100
12.9 Article number system for the 3RW30 ..................................................................................101
12.10 Article number system for the 3RW40..................................................................................102
13 Commissioning ................................................................................................................................... 103
13.1 Commissioning the 3RW30 ..................................................................................................103
13.1.1 Commissioning procedure ....................................................................................................103
13.1.2 Quick commissioning of the 3RW30 and optimization of the parameters ............................104
13.1.3 Setting the soft start function ................................................................................................105
13.1.4 Setting the starting voltage ...................................................................................................106
13.1.5 Setting the ramp time............................................................................................................106

Table of contents
SIRIUS 3RW30 / 3RW40
6Manual, 10/2018, NEB535199502000/RS-AB/005
13.1.6 ON output............................................................................................................................. 108
13.2 Commissioning the 3RW40 ................................................................................................. 109
13.2.1 Commissioning procedure ................................................................................................... 109
13.2.2 Quick commissioning of the 3RW40 and optimization of the parameters ........................... 110
13.2.3 Setting the soft start function ............................................................................................... 111
13.2.4 Setting the starting voltage .................................................................................................. 112
13.2.5 Setting the ramp time........................................................................................................... 112
13.2.6 Current limiting in conjunction with a starting voltage ramp and ramp-up detection ........... 113
13.2.7 Setting the motor current ..................................................................................................... 114
13.2.8 Setting the current limiting value.......................................................................................... 114
13.2.9 Optimized setting ranges for current limiting ....................................................................... 116
13.2.10 Ramp-up detection............................................................................................................... 117
13.3 Setting the soft stop function................................................................................................ 118
13.3.1 Setting the ramp-down time ................................................................................................. 118
13.4 Setting the motor protection function ................................................................................... 119
13.4.1 Setting the electronic motor overload protection ................................................................. 119
13.4.2 Motor current settings .......................................................................................................... 120
13.4.3 Motor protection acc. to ATEX ............................................................................................. 120
13.5 Thermistor motor protection................................................................................................. 121
13.6 Motor protection trip test ...................................................................................................... 121
13.7 Functions of the outputs....................................................................................................... 122
13.7.1 Functions of the BYPASSED and ON / RUN outputs.......................................................... 122
13.7.2 Parameterizing the 3RW40 outputs..................................................................................... 123
13.7.3 Function of the FAILURE / OVERLOAD output................................................................... 125
14 Technical data .....................................................................................................................................127
14.1 Technical data in Siemens Industry Online Support............................................................ 127
14.2 3RW30 ................................................................................................................................. 128
14.2.1 Overview .............................................................................................................................. 128
14.2.2 3RW30..-.BB.. control electronics ........................................................................................ 129
14.2.3 3RW30..-.BB.. control times and parameters ...................................................................... 129
14.2.4 3RW30..-.BB.. power electronics......................................................................................... 130
14.2.5 3RW30 13, 14, 16, 17, 18-.BB.. power electronics.............................................................. 130
14.2.6 3RW30 26, 27, 28-.BB.. power electronics.......................................................................... 131
14.2.7 3RW30 36, 37, 38, 46, 47-.BB.. power electronics.............................................................. 131
14.2.8 3RW30 main conductor cross-sections ............................................................................... 132
14.2.9 3RW30 auxiliary conductor cross-sections.......................................................................... 133
14.2.10 Electromagnetic compatibility according to EN 60947-4-2 .................................................. 133
14.2.11 Recommended filters ........................................................................................................... 134
14.2.12 Types of coordination........................................................................................................... 134
14.2.13 Fuseless version .................................................................................................................. 135
14.2.14 Fused version (line protection only)..................................................................................... 136
14.2.15 Fused version with SITOR 3NE1 fuses ............................................................................... 137
14.2.16 Fused version with SITOR 3NE3/4/8 fuses ......................................................................... 138
14.3 3RW40 ................................................................................................................................. 140
14.3.1 Overview .............................................................................................................................. 140
14.3.2 3RW40 2., 3., 4. control electronics ..................................................................................... 141
14.3.3 3RW40 5., 7. control electronics.......................................................................................... 142

Table of contents
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 7
14.3.4 3RW40 2., 3., 4. control electronics......................................................................................142
14.3.5 3RW40 5., 7. control electronics...........................................................................................143
14.3.6 3RW40 protection functions..................................................................................................143
14.3.7 3RW40 control times and parameters ..................................................................................144
14.3.8 3RW40 2. to 7. power electronics.........................................................................................145
14.3.9 3RW40 24, 26, 27, 28 power electronics..............................................................................146
14.3.10 3RW40 36, 37, 38, 46, 47 power electronics........................................................................147
14.3.11 3RW40 55, 56, 73, 74, 75, 76 power electronics..................................................................148
14.3.12 3RW40 2., 3., 4. main conductor cross-sections ..................................................................149
14.3.13 3RW40 5., 7. main conductor cross-sections .......................................................................150
14.3.14 3RW40 .. auxiliary conductor cross-sections........................................................................151
14.3.15 Electromagnetic compatibility according to EN 60947-4-2...................................................151
14.3.16 Recommended filters ............................................................................................................152
14.3.17 Types of coordination............................................................................................................152
14.3.18 Fuseless version ...................................................................................................................153
14.3.19 Fused version (line protection only)......................................................................................154
14.3.20 Fused version with SITOR 3NE1 fuses ................................................................................155
14.3.21 Fused version with SITOR 3NE3/4/8 fuses ..........................................................................156
14.3.22 Motor protection tripping characteristics for 3RW40 (with symmetry) ..................................157
14.3.23 Motor protection tripping characteristics for 3RW40 (with asymmetry) ................................158
15 Dimension drawings............................................................................................................................ 159
15.1 CAx data ...............................................................................................................................159
16 Typical circuit diagrams....................................................................................................................... 161
16.1 Typical circuit for the optional thermistor motor protection evaluation .................................161
16.2 Control by pushbutton...........................................................................................................162
16.2.1 Control of the 3RW30 by pushbutton....................................................................................162
16.2.2 Control of the 3RW40 by pushbutton....................................................................................163
16.3 Control by switch...................................................................................................................165
16.3.1 Control of the 3RW30 by switch ...........................................................................................165
16.3.2 Control of the 3RW40 by switch ...........................................................................................166
16.4 Control in automatic mode....................................................................................................168
16.4.1 Control of the 3RW30 in automatic mode.............................................................................168
16.4.2 Control of the 3RW40 in automatic mode.............................................................................169
16.5 Control by PLC......................................................................................................................171
16.5.1 Control of the 3RW30 with 24 V DC by PLC ........................................................................171
16.5.2 Control of the 3RW40 by PLC ..............................................................................................172
16.6 Control with an optional main / line contactor .......................................................................174
16.6.1 Control of the 3RW30 with a main contactor ........................................................................174
16.6.2 Control of the 3RW40 with a main contactor ........................................................................175
16.7 Reversing circuit ...................................................................................................................177
16.7.1 3RW30 reversing circuit........................................................................................................177
16.7.2 3RW40 reversing circuit........................................................................................................178
16.8 Control of a magnetic parking brake.....................................................................................180
16.8.1 3RW30 motor with magnetic parking brake..........................................................................180
16.8.2 3RW402 - 3RW404, control of a motor with a magnetic parking brake ...............................181
16.8.3 3RW405 - 3RW407, control of a motor with a magnetic parking brake ...............................182

Table of contents
SIRIUS 3RW30 / 3RW40
8Manual, 10/2018, NEB535199502000/RS-AB/005
16.9 EMERGENCY STOP ........................................................................................................... 183
16.9.1 3RW30 EMERGENCY STOP and 3TK2823 safety relay.................................................... 183
16.9.2 3RW402 - 3RW404 EMERGENCY STOP and 3TK2823 safety relay ................................ 185
16.9.3 3RW405 - 3RW407 EMERGENCY STOP and 3TK2823 safety relay ................................ 187
16.10 3RW and contactor for emergency starting ......................................................................... 189
16.10.1 3RW30 and contactor for emergency starting ..................................................................... 189
16.10.2 3RW40 and contactor for emergency starting ..................................................................... 190
16.11 Dahlander / multispeed motor.............................................................................................. 192
16.11.1 3RW30 and Dahlander motor starting ................................................................................. 192
16.11.2 3RW402 - 3RW404 and Dahlander motor starting .............................................................. 194
16.11.3 3RW405 - 3RW407 and Dahlander motor starting .............................................................. 195
A Appendix .............................................................................................................................................197
A.1 Configuration data................................................................................................................ 197
A.2 Table of parameters used .................................................................................................... 199
Index ...................................................................................................................................................201

SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 9
Introduction
1
1.1
Important notes
Purpose of this manual
This manual contains fundamental information and practical tips for using SIRIUS soft
starters. The SIRIUS 3RW30 and 3RW40 soft starters are electronic motor control devices
that facilitate optimal starting and stopping three-phase induction motors.
The manual describes all of the functions of the SIRIUS 3RW30 and 3RW40 soft starters.
Target group
This manual is intended for any user involved in
●Commissioning
●Servicing and maintenance
●Planning and configuring systems
Basic knowledge required
A general knowledge of the field of electrical engineering is required to understand this
manual.
Scope of validity
The manual is valid for the SIRIUS 3RW30 and 3RW40 soft starters. It describes the
components that are valid at the time of publication. SIEMENS reserves the right to include a
Product Information for each new component, and for each component of a later version.
Standards and approvals
The SIRIUS 3RW30 and 3RW40 soft starters are based on the IEC/EN 60947-4-2 standard.
Disclaimer of liability
It is the responsibility of the manufacturer to ensure that a system or machine is functioning
properly as a whole. SIEMENS AG, its regional offices, and associated companies
(hereinafter referred to as "SIEMENS") cannot guarantee all the properties of a whole plant
system or machine that has not been designed by SIEMENS.
Similarly, SIEMENS can assume no liability for recommendations that appear or are implied
in the following description. No new guarantee, warranty, or liability claims beyond the scope
of the SIEMENS general terms of supply are to be derived or inferred from the following
description.

Introduction
1.1 Important notes
SIRIUS 3RW30 / 3RW40
10 Manual, 10/2018, NEB535199502000/RS-AB/005
Orientation aids
The manual contains various features supporting quick access to specific information:
●At the beginning of the manual you will find a table of contents.
●A comprehensive index at the end of the manual allows quick access to information on
specific subjects.
Selection data and ordering data
You can find additional information about soft starters on the Internet in the Industry Mall.
Here, you have access to
●Catalogs/brochures (http://www.siemens.com/industrial-controls/catalogs)
●Online configuration (http://www.siemens.com/sirius/configurators)

Introduction
1.2 Additional documentation
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 11
1.2
Additional documentation
Manuals/operating instructions
At this point, you will find further manuals and operating instructions that may be of interest
to you for your automation system. They are available to download from the Internet free of
charge. You can create your own individual system documentation in mySupport.
Manuals
●Manual - SIRIUS 3RW44 Soft Starter
(https://support.industry.siemens.com/cs/document/21772518)
●Manual PROFINET communication module for SIRIUS 3RW44 soft starter
(https://support.industry.siemens.com/cs/document/85225796)
Operating instructions
●SIRIUS 3RW301/302/303/304 soft starters
(https://support.industry.siemens.com/cs/document/26378636)
●Semiconductor motor controllers
(https://support.industry.siemens.com/cs/document/9835687)
●SIRIUS semiconductor motor controllers
(https://support.industry.siemens.com/cs/document/6015580)
●SIRIUS 3RW405/407 soft starters
(https://support.industry.siemens.com/cs/document/19501475)
●SIRIUS 3RW40 soft starters - Safety and commissioning instructions for hazardous areas
(https://support.industry.siemens.com/cs/document/22809303)
●SIRIUS 3RW442/443/444/445/446 soft starters
(https://support.industry.siemens.com/cs/document/21189750)
Note
The operating instructions are included in the s
cope of supply.
Interesting links
●FAQs on 3RW soft starters (https://support.industry.siemens.com/cs/ww/de/ps/16212/faq)
●Downloads relating to 3RW soft starters
(https://support.industry.siemens.com/cs/ww/de/ps/16212/dl)
●Manuals in Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/de/ps/man)
●Product support for STEP 7 (TIA Portal)
(https://support.industry.siemens.com/cs/ww/de/ps/14672)

Introduction
1.2 Additional documentation
SIRIUS 3RW30 / 3RW40
12 Manual, 10/2018, NEB535199502000/RS-AB/005
●Further information on PROFINET
(https://www.siemens.com/global/de/home/produkte/automatisierung/industrielle-
kommunikation/profinet.html)
●SIMATIC Modbus/TCP - The easy way to interface SIMATIC controllers to multi-vendor
systems (http://w3.siemens.com/mcms/human-machine-interface/de/kundenspezifische-
produkte/kundenspezifische-
software/Seiten/default.aspx?tabcardname=simatic%20modbus/tcp)
●Premium Efficiency - Efficiency class IE3
(http://w3.siemens.com/mcms/topics/de/applikationsberatung/ie3ready/seiten/default.asp
x)

Introduction
1.3 Siemens Industry Online Support
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 13
1.3
Siemens Industry Online Support
Information and service
At Siemens Industry Online Support you can obtain up-to-date information from our global
support database quickly and simply. To accompany our products and systems, we offer a
wealth of information and services that provide support in every phase of the lifecycle of your
machine or plant – from planning and implementation and commissioning, right through to
maintenance and modernization:
●Product support
●Application examples
●Services
●Forum
●mySupport
Link:
Siemens Industry Online Support (https://support.industry.siemens.com/cs/de/en)
Product support
Here you will find all the information and comprehensive know-how for your product:
●
FAQs
Our replies to frequently asked questions.
●
Manuals/operating instructions
Read online or download, available as PDF or individually configurable.
●
Certificates
Clearly sorted according to approving authority, type and country.
●
Characteristics
For support in planning and configuring your system.
●
Product announcements
The latest information and news concerning our products.
●
Downloads
Here you will find updates, service packs, HSPs and much more for your product.
●
Application examples
Function blocks, background and system descriptions, performance statements,
demonstration systems, and application examples, clearly explained and represented.
●
Technical data
Technical product data for support in planning and implementing your project.
Link:
Product support (https://support.industry.siemens.com/cs/ww/en/ps)

Introduction
1.3 Siemens Industry Online Support
SIRIUS 3RW30 / 3RW40
14 Manual, 10/2018, NEB535199502000/RS-AB/005
mySupport
With "mySupport", your personal work area, you get the very best out of your Industry Online
Support experience. Everything enables you to find the right information - every time.
The following functions are now available:
●
Personal Messages
Your personal mailbox for exchanging information and managing your contacts
●
Requests
Use our online form for specific solution suggestions, or send your technical inquiry
directly to a specialist in Technical Support
●
Notifications
Make sure you always have the latest information - individually tailored to your needs
●
Filter
Simple management and re-use of your filter settings from Product Support and the
Technical Forum
●
Favorites / Tagging
Create your own knowledge database by assigning "Favorites" and "Tags" to documents
– simply and efficiently
●
Entries last viewed
Clear presentation of your last viewed entries
●
Documentation
Configure your individual documentation from different manuals – quickly and without
complications
●
Personal data
Change personal data and contact information here
●
CAx data
Simple access to thousands of items of CAx data such as 3D models, 2D dimension
drawings, EPLAN macros, and much more

Introduction
1.4 Technical Assistance
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 15
1.4
Technical Assistance
Using the support request form in Online Support you can send your query directly to our
Technical Assistance. After describing your query in a few guided steps, you will immediately
be provided with possible suggestions for solving the problem.
Technical Assistance:
Telephone: [phone] (8:00 a.m. - 5:00 p.m. CET) Fax: +49 (0)
911-895-5907
E-mail (mailto:[e-mail])
Internet (http://www.siemens.com/sirius/technical-assistance)
1.5
Siemens Industry Online Support app
Siemens Industry Online Support app
You can use the Siemens Industry Online Support app to access all the device-specific
information available on the Siemens Industry Online Support portal for a particular article
number, including operating instructions, manuals, datasheets, FAQs etc.
The Siemens Industry Online Support app is available for iOS, Android or Windows Phone
devices. You can download the app from the following links:
Link for Android
Link for iOS
Link for Windows Phone

Introduction
1.5 Siemens Industry Online Support app
SIRIUS 3RW30 / 3RW40
16 Manual, 10/2018, NEB535199502000/RS-AB/005

SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 17
Safety information
2
2.1
ESD Guidelines
ESD
All electronic devices are equipped with large-scale integrated ICs or components. Due to
their design, these electronic elements are highly sensitive to overvoltage, and thus to any
electrostatic discharge.
The acronym ESD has become the established designation for such electrostatic sensitive
components/devices. This is also the international abbreviation for such devices.
ESD devices are identified by the following symbol:
NOTICE
Electrostatic discharge
ESD devices can be destroyed by voltages well below the threshold of human perception.
These static voltages develop when you touch a component or electrical connection of a
device without having drained the static charges present on your body. The damage
caused to a device by overvoltage is usually not immediately evident and is only noticed
after an extended period of operation.
Electrostatic charging
Anyone who is not connected to the electrical potential of their surroundings can be
electrostatically charged.
The diagram below shows the maximum electrostatic voltage which may build up on a
person coming into contact with the materials specified in the diagram. These values
correspond to IEC 801-2 specifications.

Safety information
2.1 ESD Guidelines
SIRIUS 3RW30 / 3RW40
18 Manual, 10/2018, NEB535199502000/RS-AB/005
Basic protective measures against electrostatic discharge
●Make sure the grounding is good:
When handling electrostatic sensitive devices, ensure that your body, the workplace and
packaging are grounded. In this way, you can avoid becoming electrostatically charged.
●Avoid direct contact:
As a general rule, only touch electrostatic sensitive devices when this is unavoidable (e.g.
during maintenance work). Handle the devices without touching any chip pins or PCB
traces. In this way, the discharged energy cannot reach or damage sensitive devices.
Discharge your body before taking any necessary measurements on a device. Do so by
touching grounded metallic parts. Use only grounded measuring instruments.

Safety information
2.2 Reactive power compensation
SIRIUS 3RW30 / 3RW40
Manual, 10/2018, NEB535199502000/RS-AB/005 19
2.2
Reactive power compensation
Capacitors for improving the power factor (reactive power compensation)
Capacitors may not be connected to the output terminals of the 3RW52 soft starter.
Connecting capacitors to the output terminals will damage the 3RW52 soft starter.
Active filters, e.g. for reactive power compensation, must not be operated parallel to the
motor control device.
If capacitors are to be used to correct the power factor (actively or passively), they must be
connected on the line side of the device. They must not actively control the power factor
during the starting and coasting down phases. If a contactor disconnector or main contactor
are used together with the electronic 3RW52 soft starter, the capacitors must be
disconnected from the 3RW52 soft starter when the contactor is open.
2.3
Electromagnetic compatibility (EMC) according to IEC 60947-4-1
This product is designed for Environment A. It may produce radio interference in domestic
environments, in which case the user may be required to take adequate mitigation
measures.

Safety information
2.4 Security information
SIRIUS 3RW30 / 3RW40
20 Manual, 10/2018, NEB535199502000/RS-AB/005
2.4
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines, and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines
and networks. Systems, machines and components should only be connected to the
enterprise network or the internet if and to the extent necessary and with appropriate security
measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. You can find more information about industrial security by visiting:
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends you apply product updates as soon as available and
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/industrialsecurity.
