Preface
Introduction 1
Installing the Device 2
Communication Ports 3
Technical Specifications 4
Dimension Drawings 5
Certification 6

RUGGEDCOM RS900GPF
Installation Guide
ii
Copyright © 2018 Siemens Canada Ltd
All rights reserved. Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized
except where expressly permitted. Violations are liable for damages. All rights reserved, particularly for the purposes of patent application or
trademark registration.
This document contains proprietary information, which is protected by copyright. All rights are reserved. No part of this document may be
photocopied, reproduced or translated to another language without the prior written consent of Siemens Canada Ltd.
Disclaimer Of Liability
Siemens has verified the contents of this document against the hardware and/or software described. However, deviations between the product
and the documentation may exist.
Siemens shall not be liable for any errors or omissions contained herein or for consequential damages in connection with the furnishing,
performance, or use of this material.
The information given in this document is reviewed regularly and any necessary corrections will be included in subsequent editions. We
appreciate any suggested improvements. We reserve the right to make technical improvements without notice.
Registered Trademarks
RUGGEDCOM™ and ROS™ are trademarks of Siemens Canada Ltd.
Other designations in this manual might be trademarks whose use by third parties for their own purposes would infringe the rights of the
owner.
Third Party Copyrights
Siemens recognizes the following third party copyrights:
• Copyright © 2004 GoAhead Software, Inc. All Rights Reserved.
Security Information
Siemens provides products and solutions with industrial security functions that support the secure operation of plants, machines, equipment
and/or networks. They are important components in a holistic industrial security concept. With this in mind, Siemens' products and solutions
undergo continuous development. Siemens recommends strongly that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable preventive action (e.g. cell protection concept) and
integrate each component into a holistic, state-of-the-art industrial security concept. Third-party products that may be in use should also be
considered. For more information about industrial security, visit https://www.siemens.com/industrialsecurity.
To stay informed about product updates as they occur, sign up for a product-specific newsletter. For more information, visit https://
support.automation.siemens.com.
Warranty
Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance
during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all
warranties null and void. The warranties set forth in this article are exclusive and are in lieu of all other warranties, performance guarantees
and conditions whether written or oral, statutory, express or implied (including all warranties and conditions of merchantability and fitness for
a particular purpose, and all warranties and conditions arising from course of dealing or usage or trade). Correction of nonconformities in the
manner and for the period of time provided above shall constitute the Seller’s sole liability and the Customer’s exclusive remedy for defective
or nonconforming goods or services whether claims of the Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com/ruggedcom or contact a Siemens customer service representative.

RUGGEDCOM RS900GPF
Installation Guide
iii
Contacting Siemens
Address
Siemens Canada Ltd
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone
Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-mail
[email protected]
Web
https://www.siemens.com/ruggedcom

RUGGEDCOM RS900GPF
Installation Guide
iv

RUGGEDCOM RS900GPF
Installation Guide

Table of Contents
v
Table of Contents
Preface ............................................................................................................ vii
Alerts ................................................................................................................................................. vii
Related Documents ............................................................................................................................ viii
Accessing Documentation .................................................................................................................. viii
Training ............................................................................................................................................ viii
Customer Support .............................................................................................................................. viii
Chapter 1
Introduction ..................................................................................................... 1
1.1Feature Highlights ........................................................................................................................ 1
1.2Description ................................................................................................................................... 2
Chapter 2
Installing the Device ......................................................................................... 5
2.1General Procedure ........................................................................................................................ 6
2.2Required Tools and Materials ......................................................................................................... 6
2.3Cabling Recommendations ............................................................................................................ 6
2.4Mounting the Device .................................................................................................................... 7
2.4.1Mounting the Device on a DIN Rail ...................................................................................... 7
2.4.2Mounting the Device to a Panel .......................................................................................... 9
2.5Grounding the Device ................................................................................................................. 10
2.6Connecting the Failsafe Alarm Relay ............................................................................................. 11
2.7Connecting Power ....................................................................................................................... 12
2.8Connecting to the Device ............................................................................................................ 13
2.9Configuring the Device ................................................................................................................ 14
Chapter 3
Communication Ports ...................................................................................... 15
3.1Copper Ethernet Ports ................................................................................................................. 15
3.2PoE Ports .................................................................................................................................... 17
3.3Fiber Optic Ethernet Ports ........................................................................................................... 19
3.4SFP Transceivers ......................................................................................................................... 19
Chapter 4
Technical Specifications .................................................................................. 21
4.1Power Supply Specifications ........................................................................................................ 21


Table of Contents
RUGGEDCOM RS900GPF
Installation Guide
vi
4.2PoE Output Specifications ............................................................................................................ 21
4.3Failsafe Alarm Relay Specifications ............................................................................................... 22
4.4Copper Ethernet Port Specifications .............................................................................................. 22
4.5Fiber Optic Ethernet Port Specifications ........................................................................................ 22
4.6Operating Environment ............................................................................................................... 23
4.7Mechanical Specifications ............................................................................................................ 24
Chapter 5
Dimension Drawings ....................................................................................... 25
Chapter 6
Certification .................................................................................................... 29
6.1Approvals ................................................................................................................................... 29
6.1.1TÜV SÜD ......................................................................................................................... 29
6.1.2European Union (EU) ....................................................................................................... 30
6.1.3FCC ................................................................................................................................. 30
6.1.4FDA/CDRH ........................................................................................................................ 30
6.1.5ISED ................................................................................................................................ 31
6.1.6RoHS ............................................................................................................................... 31
6.1.7Other Approvals ............................................................................................................... 31
6.2EMC and Environmental Type Tests .............................................................................................. 31

RUGGEDCOM RS900GPF
Installation Guide

Preface
Alerts vii
Preface
This guide describes the RUGGEDCOM RS900GPF. It describes the major features of the device, installation,
commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible for the installation,
commissioning and maintenance of the device. It is also recommended for use by network and system planners,
system programmers, and line technicians.
CONTENTS
•“Alerts”
•“Related Documents”
•“Accessing Documentation”
•“Training”
•“Customer Support”
Alerts
The following types of alerts are used when necessary to highlight important information.
DANGER!
DANGER alerts describe imminently hazardous situations that, if not avoided, will result in death or
serious injury.
WARNING!
WARNING alerts describe hazardous situations that, if not avoided, may result in serious injury and/or
equipment damage.
CAUTION!
CAUTION alerts describe hazardous situations that, if not avoided, may result in equipment damage.
IMPORTANT!
IMPORTANT alerts provide important information that should be known before performing a procedure
or step, or using a feature.
NOTE
NOTE alerts provide additional information, such as facts, tips and details.


Preface
RUGGEDCOM RS900GPF
Installation Guide
viii Related Documents
Related Documents
Other documents that may be of interest include:
•RUGGEDCOM ROS User Guide for the RUGGEDCOM RS900GPF
Accessing Documentation
The latest user documentation for RUGGEDCOM RS900GPF is available online at
https://www.siemens.com/ruggedcom. To request or inquire about a user document, contact Siemens Customer
Support.
Training
Siemens offers a wide range of educational services ranging from in-house training of standard courses on
networking, Ethernet switches and routers, to on-site customized courses tailored to the customer's needs,
experience and application.
Siemens' Educational Services team thrives on providing our customers with the essential practical skills to make
sure users have the right knowledge and expertise to understand the various technologies associated with critical
communications network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain knowledge in the utility,
transportation and industrial markets, allows Siemens to provide training specific to the customer's application.
For more information about training services and course availability, visit https://www.siemens.com/ruggedcom or
contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general
information, contact Siemens Customer Support through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a Support Request (SR) or check
on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit http://
www.automation.siemens.com/mcms/aspa-db/en/automation-technology/Pages/default.aspx.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile
device and be able to:
• Access Siemens' extensive library of support documentation, including FAQs and manuals
• Submit SRs or check on the status of an existing SR

RUGGEDCOM RS900GPF
Installation Guide

Preface
Customer Support ix
• Contact a local Siemens representative from Sales, Technical Support, Training, etc.
• Ask questions or share knowledge with fellow Siemens customers and the support community


Preface
RUGGEDCOM RS900GPF
Installation Guide
x Customer Support

RUGGEDCOM RS900GPF
Installation Guide
Chapter 1
Introduction
Feature Highlights 1
Introduction
The RUGGEDCOM RS900GPF is an industrially hardened, fully managed Ethernet switch providing dual fiber
optical Gigabit Ethernet ports and eight Fast Ethernet copper ports, each capable of supplying high power 802.3at
compliant Power over Ethernet (PoE).
Designed to operate reliably in harsh industrial environments, the RUGGEDCOM RS900GPF provides a high level
of immunity to electromagnetic interference and heavy electrical surges typical of environments found in electric
utility substations, factory floors or in curb side traffic control cabinets. An operating temperature range of -40 to
85 °C (-40 to 185 °F) coupled with optional conformal coating and a powder coated aluminum enclosure allows
the RUGGEDCOM RS900GPF to be placed in almost any location.
The embedded RUGGEDCOM ROS (Rugged Operating System) provides advanced networking features such as
Enhanced Rapid Spanning Tree (eRSTP), Port Rate Limiting and a full array of intelligent functionality for high
network availability and manageability.
CONTENTS
•Section1.1, “Feature Highlights”
•Section1.2, “Description”
Section1.1
Feature Highlights
Ethernet Ports
• Up to 2 x 100/1000Base-X fiber optic ports or 2 x 10/100/1000Base-TX copper ports
• 8 x 10/100Base-TX RJ45 802.3af/802.3at compliant PoE ports
• Data and power over a single Ethernet cable
• Auto-sensing ports provide power only to PoE end devices
• Compatible with RUGGEDCOM WIN CPE and Pico base stations
• Industry standard fiber optic connectors: LC, SC, ST and SFP pluggable optics
• Bi-directional simplex fiber support
• Long haul optics allow Gigabit distances up to 70 km (43.5 mi)
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• -40 to 85°C (-40 to 185 °F) operating temperature (no fans)
• [Optional] Conformal coated printed circuit boards
Power Supply
• Single 54 VDC, 255 W (or greater) external power supply can deliver 30 W x 8 port per IEEE 802.3at

Chapter 1
Introduction
RUGGEDCOM RS900GPF
Installation Guide
2 Description
• Second power supply input for a redundant 54 V power supply
• Complies with IEEE 802.3af, 15 W x 8 output when using 48 VDC power supplies
Section1.2
Description
The RUGGEDCOM RS900GPF features various ports, controls and indicator LEDs on the front panel for connecting,
configuring and troubleshooting the device.
3
1
4
5
6
2
7
Figure1:RUGGEDCOM RS900GPF
1.Fiber Optic or SFP (Small Form-Factor Pluggable) Ethernet Ports 2.Copper PoE Ethernet Ports 3.POWER LED 4.RS-232 Console Port
(DB9) 5.ALARM LED 6.Failsafe Alarm Relay 7.Redundant Power Supply Terminal Blocks
Communication Ports Receive and transmit network traffic, as well as provide remote Web access to the
RUGGEDCOM ROS operating system. For more information, refer to:
•Section2.8, “Connecting to the Device”
•Chapter3, Communication Ports
RS-232 Console Port The serial console port is for interfacing directly with the device and accessing initial
management functions. For information about connecting to the device via the serial
console port, refer to Section2.8, “Connecting to the Device”.
POWER LED Illuminates when power is being supplied to the device.
Color Description
Green Device is receiving power
Off No power
ALARM LED Illuminates when an alarm condition exists.
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm condition occurs. For more
information, refer to:

RUGGEDCOM RS900GPF
Installation Guide
Chapter 1
Introduction
Description 3
•Section2.6, “Connecting the Failsafe Alarm Relay”
•Section4.3, “Failsafe Alarm Relay Specifications”
Power Supply Terminal Block A pluggable terminal block. For more information, refer to:
•Section2.7, “Connecting Power”
•Section4.1, “Power Supply Specifications”

Chapter 1
Introduction
RUGGEDCOM RS900GPF
Installation Guide
4 Description

RUGGEDCOM RS900GPF
Installation Guide
Chapter 2
Installing the Device
5
Installing the Device
This section describes how to install the device, including mounting the device, connecting power, and
connecting the device to the network.
DANGER!
Electrocution hazard – risk of serious personal injury and/or damage to equipment. Before performing
any maintenance tasks, make sure all power to the device has been disconnected and wait
approximately two minutes for any remaining energy to dissipate.
WARNING!
Burn hazard – risk of serious personal injury. Avoid contact with the surface of the unit. The metal
surface may be hot due to the high allowable ambient temperature per specification.
WARNING!
Radiation hazard – risk of serious personal injury. This product contains a laser system and is classified
as a CLASS 1 LASER PRODUCT. Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation exposure.
IMPORTANT!
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void.
Changes or modifications not expressly approved by RuggedCom Inc. could invalidate specifications,
test results, and agency approvals, and void the user's authority to operate the equipment.
IMPORTANT!
This product should be installed in a restricted access location where access can only be gained by
authorized personnel who have been informed of the restrictions and any precautions that must be
taken. Access must only be possible through the use of a tool, lock and key, or other means of security,
and controlled by the authority responsible for the location.
NOTE
This product contains a Lithium battery that is not replaceable by the operator or by service personnel.
CONTENTS
•Section2.1, “General Procedure”
•Section2.2, “Required Tools and Materials”
•Section2.3, “Cabling Recommendations”
•Section2.4, “Mounting the Device”
•Section2.5, “Grounding the Device”

Chapter 2
Installing the Device
RUGGEDCOM RS900GPF
Installation Guide
6 General Procedure
•Section2.6, “Connecting the Failsafe Alarm Relay”
•Section2.7, “Connecting Power”
•Section2.8, “Connecting to the Device”
•Section2.9, “Configuring the Device”
Section2.1
General Procedure
The general procedure for installing the device is as follows:
1. Review the relevant certification information for any regulatory requirements. For more information, refer to
Section6.1, “Approvals”.
2. Mount the device.
3. Connect the failsafe alarm relay.
4. Connect power to the device and ground the device to safety Earth.
5. Connect the device to the network.
6. Configure the device.
Section2.2
Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RS900GPF:
Tools/Materials Purpose
DC power cord (16 AWG) For connecting power to the device.
CAT-5 Ethernet cables For connecting the device to the network.
#2 Phillips Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
4 x M3.5 (#6-32) screws For mounting the device to a panel.
Section2.3
Cabling Recommendations
Siemens does not recommend the use of copper cabling of any length for critical, real-time substation automation
applications. All copper Ethernet ports on RUGGEDCOM products include transient suppression circuitry to protect
against damage from electrical transients and conform with IEC 61850-3 and IEEE 1613 Class 1 standards. This
means that during a transient electrical event, communications errors or interruptions may occur, but recovery is
automatic.
Siemens also does not recommend using copper Ethernet ports to interface with devices in the field across
distances that could produce high levels of ground potential rise (i.e. greater than 2500 V), during line-to-ground
fault conditions.

RUGGEDCOM RS900GPF
Installation Guide
Chapter 2
Installing the Device
Mounting the Device 7
Section2.4
Mounting the Device
The RUGGEDCOM RS900GPF is designed for maximum mounting and display flexibility. It can be equipped with
connectors that allow it to be installed in a 35 mm (1.4 in) DIN rail or directly on a panel.
IMPORTANT!
Heat generated by the device is channeled outwards from the enclosure. As such, it is recommended
that 2.5 cm (1 in) of space be maintained on all open sides of the device to allow for some
convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a reduction of ambient
temperature and improve the long-term reliability of all equipment mounted in the rack space.
NOTE
For detailed dimensions of the device with either DIN rail or panel hardware installed, refer to
Chapter5, Dimension Drawings.
CONTENTS
•Section2.4.1, “Mounting the Device on a DIN Rail”
•Section2.4.2, “Mounting the Device to a Panel”
Section2.4.1
Mounting the Device on a DIN Rail
For DIN rail installations, the RUGGEDCOM RS900GPF can be equipped with a DIN rail bracket that allows the
device to be slid onto a standard 35 mm (1.4 in) DIN rail.
To mount the device to a DIN rail, do the following:
1. Secure the DIN rail bracket to the back of the device chassis.

Chapter 2
Installing the Device
RUGGEDCOM RS900GPF
Installation Guide
8 Mounting the Device on a DIN Rail
2
1
Figure2:DIN Rail Bracket Assembly
1.DIN Rail Bracket 2.Screw
2. Align the slot in the bracket with the DIN rail.
1
1
2
Figure3:DIN Rail Mounting
1.DIN Rail 2.DIN Rail Bracket
3. Pull the release on the bracket down and slide the device onto the DIN rail. Let go of the release to lock the
device in position.

RUGGEDCOM RS900GPF
Installation Guide
Chapter 2
Installing the Device
Mounting the Device to a Panel 9
Section2.4.2
Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RS900GPF can be equipped with panel adapters that allow the device to
be attached to a panel in multiple orientations.
3
2
1
Figure4:Panel Mount Options
1.Rear Mount Orientation 2.Front Mount Orientation 3.Side Mount Orientation
1. Secure the adapters to the device in the desired orientation.
2. Place the device against (side or rear mount orientation) or insert it into (front mount orientation) the panel
and align the adapters with the mounting holes.

Chapter 2
Installing the Device
RUGGEDCOM RS900GPF
Installation Guide
10 Grounding the Device
2
1
2
1
Figure5:Panel Mounting (Rear Mount Orientation Shown)
1.Panel Adapter 2.Screw
3. Install #6 screws (not supplied) to secure the adapters to the panel.
Section2.5
Grounding the Device
The RUGGEDCOM RS900GPF chassis features a threaded hole for connecting the device to ground (Earth). It is
recommended to terminate the ground connection with an M3 ring or spade lug, and then torque to 1.7 N·m (15
lbf-in).
