Siemens optiPoint 300 basic Instruction Manual


Information and
Communications
optiPoint 300 basic
IP Telephone
Operation and Andministration Manual

Copyright © Siemens AG, 2000
All rights reserved.
HiNet is a trademark of Siemens Aktiengesellschaft.
All other brand and product names may be trademarks of their respective holders.
Siemens AG provides this documentation without any warranty of any kind, either implied or expressed, including, but
not limited to, the implied warranties of merchantability or fitness for a particular purpose.

Contents
Safety
8
For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Protection of the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Location of the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product information
9
About these operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Echo effect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes and symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Symbols in the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Layout of the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Standard package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Display and controls
15
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Symbol keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programmable keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Control keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation
18
Preparing the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Integrating the telephone into the communication environment . . . . . 19
Loading the application software . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

HiPath system with DHCP server . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
HiPath system without DHCP server . . . . . . . . . . . . . . . . . . . . . . . . 21
Label quick-dial keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Operation 23
Basic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Dialling with handset picked up . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Dialling with handset in cradle (on-hook dialling) . . . . . . . . . . . . . . 25
Incoming call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Incoming call while in idle mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Second incoming call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Placing a second call (consultation) . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Place a second call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Changing between callers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
End consultation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Terminating a connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Your caller hangs up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Changing the settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Turning on the speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Adjusting speakerphone volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using the mute control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Turning on the speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Enable call-waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Display elapsed call duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Display your telephone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Adjusting handset volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Adjusting ringer volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Adjusting display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Advanced dialling features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Redial feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Quick-dial feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Programming the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Programming the quick-dial keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Editing the redial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Adjusting date/time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Customising the ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Incoming call while in programming mode . . . . . . . . . . . . . . . . . . . . 42
Configuration and administration 43
Service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Changing to service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Incoming call while in service mode . . . . . . . . . . . . . . . . . . . . . . . . . 46
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Country setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
DTMF dialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Daylight Savings Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Key click . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Firmware version (read only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Application version (read only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
IP assignment by DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
GK discovery IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
HiPath . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Telephone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Subnet mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Gatekeeper’s IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Download server’s IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
SNTP server IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Time zone offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Terminal NIC MAC (read only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
HiPath PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Administration from a web server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Display test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Keyboard test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Audio loop test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
RAM test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
ROM test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
PING test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
MIB2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Terminal reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Telephone restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Restore factory default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Telephone not available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
The web pages 64
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Browser compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
User error handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Overall structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Frameset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Home page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
HiPath administrator login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Local administrator login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Administrator settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
IP address and routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Gatekeeper information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Speech parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Time & date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
File transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
FTP username & password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
SNMP information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Download application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Save (upload) configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Restore (download) configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Restart terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Change administrator password . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Annex
80

Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Country settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Factory default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Local functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Index
87

Safety
8
Safety
For your safety
The IP telephone optiPoint 300 basic complies with the European
standard EN 60 950 which deals with the safety of information
technology appliances including electronic office equipment.This
device has been designed with safety in mind, thus protecting
both individuals and objects.
There is always the danger of small objects being swallowed by
young children.In the case of the optiPoint 300 basic, this applies
in particular to the connecting cord clip.
Please make sure that such items are not accessible to children.
●
Use only the enclosed power supply and the special LAN ca-
ble.
●
Never open the power supply enclosure.
Protection of the telephone
●
The telephone must not be used in bathrooms, etc.as it is not
splashproof.
●
Before connecting or disconnecting the LAN cable or the
headset cord, pull the power plug out of the plug receptacle
first.
Location of the telephone
● The telephone should be operated in a controlled environment
with an ambient temperature between 5˚C and 40˚C (41˚F and
104˚F).
●
Do not install the telephone in a room where large quantities
of dust accumulate; this can considerably reduce the service
life of the telephone.
●
Do not expose the telephone to direct sunlight or any other
sourceof heat,as thisis liabletodamage the electronic equip-
ment and the plastic casing.
●
Do not operate the telephone in damp environments such as
bathrooms.

Product information
9
Product information
About these operating instructions
These operating instructions will help you get to know the opti-
Point 300 basic and to use its functions.The instructions contain
important information for safe and proper operation of the opti-
Point 300 basic.Follow them carefully to avoid improper operation
and get the most out of your multi-function telephone in a network
environment.
These operating instructions must be read and followed by every
person installing, operating or programming the optiPoint 300
basic.
These operating instructions are laid out in a user-oriented man-
ner, which means that you are led through the operation of the
optiPoint 300 basic step by step – starting from the description of
simple basic functions, continuing through the setting of all oper-
ating parameters, and ending with the special functions and ad-
ministrative tasks at the end of the manual.The separate quick ref-
erence guide brings together basic information on the most
commonly used functions.
Intended use
The optiPoint 300 basic telephone is a desktop unit designed for
voicetransmissionandforconnectiontoaLAN.Itcanbeoperated
also as a stand-alone unit. Any other use is regarded as not pre-
scribed.
Product identification
The identification details of your telephone are given on the name-
plate containing the exact product desgination and serial number
onthe bottom of the base unit.Pleasehavetheseready whenever
you call our service department because of trouble with or defects
on the unit itself.
Foryourownprotection, pleasereadthesectiondealing
with safety.Follow the safety instructions carefully in or-
der to avoid endangering yourself or other persons and
to prevent damage to the unit.

Product information
10
Echo effect
In some cases, while using the telephone you may hear an echo,
which can be quite strong.This is not due to any design defect or
other fault with your IP telephone, but caused by the other client.
For example, if the echo occurs during a teleconference, it may be
that the loudspeakers and microphones need to be repositioned.
Service
In the case of any trouble or defects on the unit itself, please dial
the service number of your country.
The Siemens service department can only help you
with trouble or defects on the unit itself.
Should you have any questions regarding the opera-
tion,yourspecialist retailer ornetwork administrator will
gladly help you with the right answers.
For any questions regarding the telephone connection,
please contact your network provider.

Product information
11
Notes and symbols
Safety
Information that is important for preventing injury or damages is
markedspecially, as theyareimportant instructionsforcorrectuse
of the unit.
Symbols in the manual
The operating steps of actions are shown as follows:
●
Lift the handset.
●
Dial the required number.
●
...
Whereseveraldifferentoptionsor possibilities are described, they
are shown like this:
– Option A
– Option B
– ...
This symbol indicates a hazard. Failure to follow the in-
structions given may result in injury or in damage to the
unit.
Key information important for the proper use of the unit
is marked with this symbol.

Product information
12
Product description
Overview
The IP telephone optiPoint 300 basic is a modern multi-function
telephone set. It is designed to be connected to a data network,
and it is not directly connected with an ISDN system or to the
PSTN.
You can use the optiPoint 300 basic in the same way as you would
use a normal telephone – the only difference being that you’re
making it via a data network.The telephone is equipped with an
Ethernet interface so that when using the TCP/IP protocol, you
can make the telephone calls both via your own intranet and via
the worldwide internet. Its conformity to international standards
such as H.323 makes it possible to use this telephone for video
conferences via a LAN.The optiPoint 300 basic supports other
standard protocols, optimizing data and voice transmission and
simplifying the associated network administration task.It is for ex-
ample possible to download updates of equipment software or ex-
tended features to the optiPoint 300 basic via an FTP server.
The optiPoint 300 basic is provided with a one-line display and
specialfunctionkeysenablingauser-friendlyoperation.Thanksto
its advanced features, it can be customised to meet most user re-
quirements.
Features
– numerical display
– time and date display
– speakerphone
– re-dial feature
– on-hook dialling
– programmable quick-dial keys
– selected dialling destination numbers storable to dialling keys
– caller identification
– consultation, alternating, waiting
– password protection for administrator tasks
– variable ringer melody, volume and sequence
– wall fastening device (optional)

Product information
13
Layout of the telephone
1 handset
2 key block with 3 function keys
3 one-line numerical display
4 key block (fourteen quick-dial keys and two
special function keys)
5 key block with 4 function keys
6 dialling keypad
7 function key
8 two control keys

Product information
14
Standard package
The complete optiPoint 300 basic IP telephone package consists
of the following items:
– IP phone optiPoint 300 basic
– Handset
– Handset cord
– LAN cable
– Power supply unit
– Installation and Startup manual (not shown)
– Quick Reference Guide (not shown)
– CD ROM with the Operation and Administration Manual
(not shown)
– Set of overlays for programmable quick-dial keys (not shown)

Display and controls
15
Display and controls
Display
The optiPoint 300 basic is provided with the following display:
Theupperareaofthe displaycontainsanumberofsymbolswhich
indicate the currently used function of the phone.The optiPoint
300 basic uses nine symbols out of the total of twelve available.
In idle mode the optiPoint 300 basic displays the current date on
the left side of the bottom line and the time of day on the right side.
Pictograph Explanation
Programming mode active
DTMF outband is active
Handset mute is on
Not used
Initialising data is being input
Not used
Call-waiting is enabled
In consultation or alternate mode
Elapsed call duration is being displayed
Caller identification not available
Enter PIN
Not used
12—01—00 10—36P
12—01—00 2—36P

Display and controls
16
Symbol keys
The symbol keys on the telephone are used to control the indivi-
dual operating steps or functions.
Symbol Explanation
q
Turns mute on and off
R
– Put caller on hold to consult with someone else or
– Switch from one caller to another
– Redial previous number
– While in programming mode:edit last number
dialled
h
– Cancel current function, discard any changes.
– End consultation
– While calling: turn elapsed call duration display on
or off
– While in programming mode:set date and time
<
– Line editor mode:
- short press deletes the last character
- long press deletes the whole line
– Mask editor mode: position insert point (cursor)
?
– Dial the displayed number when handset is lifted
– While in programming mode or service mode:
confirm action
j
– While calling: switch loudspeaker on or off
– While in programming mode:change ringer setting
+
– While calling: increase loudspeaker volume
– While in idle mode: increase display contrast
-
– While calling: decrease loudspeaker volume
– While in idle mode: decrease display contrast

Display and controls
17
Programmable keys
The optiPoint 300 basic is equipped with fourteen programmable
quick-dial keys for frequently called numbers. In addition, there
are two special function keys: :
If you press one of these keys, the preprogrammed function is car-
ried out.
Control keys
The two control keys
-
and
+
are located above the
j
key.De-
pending on the operating mode, you can vary the following set-
tings:
CW key Controls the call waiting function
Service key Controls the service and programming modes
Operating mode
--
--
key
++
++
key
Idle mode Reduce the display
contrast Increase the display contrast
Receiving a call Reducethevolume
of the ringer tone Increase the volume of the ringer tone
Using the handset
to telephone Reducethevolume of the handset
loudspeaker
Increase the volume
of the handset
loudspeaker

Installation
18
Installation
This chapter tells you how to connect the components of the opti-
Point 300 basic telephone to one another prior to use.
Connecting the telephone to a LAN and configuring it for proper
operation are tasks of the network administrator.They are de-
scribed in the chapter entitled "Configuration and administration".
Administrators who wish to install and configure IP phone telepho-
ny devices via a web interface will find detailed informations in the
chapter entitled "The web pages".
Preparing the telephone
To connect the telephone components, proceed as follows.
●
Latch the Western plug of the handset cord in the handset
receptacle ("short" end).
●
Latch the other end of the cord in the receptacle (3) on the
bottom of the telephone ("long" end).
●
Feed the cord through the guide channel in the base unit.
● Latch the LAN cord with the eight-pin Western plug (RJ 45) in
the receptacle (2) on the bottom of the telephone, and con-
nect with LAN.
● Feed the LAN cord through the guide channel in the base unit.
The two cable ends of the handset cord are equipped
with identical four-pinWestern plugs (RJ 11).

Installation
19
●
Latch the four-pin (red)Western plug (RJ 11) of the power
supply unit cord in the receptacle (1) on the bottom of the tele-
phone.
●
Feed the power supply unit cord through the guide channel in
the base unit.
Integrating the telephone into the communication environment
Like all terminal equipment connected to a LAN, the optiPoint 300
basic must have an IP address assigned.The procedure for set-
ting up the network environment for the telephone is described be-
low. Note that the optiPoint 300 basic can operate with a HiPath
5500/ 5300, but this is not mandatory.
If you have any questions concerning the LAN environment or the
terminology used, contact your network administrator.
Loading the application software
When the optiPoint 300 basic telephone is connected to power, it
automatically boots up, i.e.loads and executes the application
software.During the boot phase you will see three dashes scroll-
ing across the display, from left to right:
If the boot phase cannot be completed successfully (because of
missing or defective application software), you will see:
In such a case, please ask your network administrator or call the
service.
After the boot phase, the telephone checks whether it is config-
ured to automatically load basic settings from a DHCP server.If it
is,thebootprocesscontinuesasdescribedin“HiPathsystemwith
DHCP server” on page 20. If it is not set to load settings from a
DHCP server, the boot process continues as described in “HiPath
system without DHCP server” on page 21.
The Western plugs of all cable connections must
audibly snap into place.
– – –
b00t FA1LEd

Installation
20
HiPath system with DHCP server
TheoptiPoint 300 basictelephonecomeswithfactorysettingsthat
enable it to get an IP address automatically from the DHCP serv-
er, once it is connected to a LAN.
When the settings cannot be successfully downloaded from a
DHCP server, the error message “No IP” is displayed. Press the
Service key and switch the telephone to manual IP assignment as
described in “IP assignment by DHCP”onpage 50.Then continue
as described in “HiPath system without DHCP server”on page 21.
When the settings have been received correctly, you will be asked
to make some additional settings, as shown here:
Press the
?
key (all other keys will be disabled).
You will hear a beep confirming successful completion. For five
seconds, the display will show:
After that, the telephone goes into idle mode.
You may break off initialisation at any time by pressing the
h
key.
Any settings previously entered will be cancelled, and you will be
returned to the point at which you were asked to enter the admini-
strator's PIN.
If an SNTP server is located within the HiPath environment, the te-
lephone unit will automatically get the correct date and time from
it.Otherwise, you must manually enter this information, as descri-
bed in the chapter entitled "Configuration and administration".
– – – – – – – – – – – – – – –
Whilethephonesearches
for a server, “DHCP” and
three scrolling dahes are
displayed.
– – – – – – – – – – – – – – –
symbols for programming
and for initialisation will
flash, as will the dash line
– – – – – –
Enter the administrator's
PIN
? Confirm your input
P2 _
Enter the telephone num-
ber to be used
?
Confirm the telephone
number and exit the menu
P PA55Ed
Initialisation successful
12 – 03 – 00 12 – 34
Idle mode
