Siemens MPA 1 Series User manual

Spectral Pyrometer ARDOMETER MPA 1x, 2x, 3x
7MC3030-..
Instruction Manual 06/17

s
Operating Manual MPA
ARDOMETER MPA
Ident.-Nr.: 105 3228
MPA1x_2x_3x_en.doc
Stand: 01.06.2017
830 hm / 810 het

s
Operating Manual MPA
Copyright prohibits duplication and transference of individual para-
graphs, drawings or pictures, even for educational purposes, without pri-
or consent of the author. This applies to duplications in any form, includ-
ing data storage, and every transference to paper, transparencies, films,
tapes, discs and other media.
Please note:
Unless otherwise stated in this instruction manual, technical alterations,
particularly those serving technical progress, may be made without no-
tice.
Warranty can only be assumed if the instrument has not been tampered
with and is returned intact to SIEMENS AG for repair and / or service.
Siemens AG
Digital Factory
Customer Services DF&PD
DF CS SD OP ITM
Telefon [phone]
Fax [phone]
Email: [e-mail]
Office/Testing Warehouse/Counter service
Breslauer Str. 5 Gundelfinger Str. 20
90766 Fürth 90451 Nürnberg
Germany Germany

s
Operating Manual MPA
Contents
1. Product Numbers ARDOMETER MPA ....................................... 1
2. Miscellaneous ............................................................................. 3
2.1 Information about this manual ............................................................ 3
2.2 Explanation of symbols ....................................................................... 3
2.3 Liability and Warranty ......................................................................... 3
2.4 Copyright ............................................................................................ 4
3. Safety .......................................................................................... 4
3.1 Intended use ....................................................................................... 4
3.2 User’s responsibility ............................................................................ 5
3.3 Safety requirements ........................................................................... 5
3.4 Electromagnetic Compatibility ............................................................ 5
4. General Description ................................................................... 5
4.1 Operating Controls and Display .......................................................... 7
5. Quick Reference Guide .............................................................. 8
5.1 MPA Connector Pin Assignment ........................................................ 8
5.2 Power Requirement 24 V DC ............................................................. 9
5.3 Current Outputs 0/4 - 20mA ............................................................... 9
5.4 Switching output ............................................................................... 10
6. Getting Started ......................................................................... 11
6.1 General installation tips .................................................................... 11
6.2 Pyrometer Alignment to Target ......................................................... 11
6.3 Setting parameters at the pyrometer (basic configuration) ............... 11
6.4 Setting Emissivity ............................................................................. 13
6.5 Output current range ........................................................................ 14
6.6 Simulated current signal for functional testing .................................. 14
7. How the pyrometer functions .................................................. 14
7.1 Internal signal processing ................................................................. 14
8. Configuration and Setup .......................................................... 15
8.1 Signal Conditioning ........................................................................... 15
8.2 I/O Configuration .............................................................................. 22
8.3 Digital inputs ..................................................................................... 27
8.4 General functions (configuration layer C011) ............................. 28
8.5 Simulate current signals for analogue output Ao1 and Ao2
(configuration layer: C100) ...................................................................... 28
9. Setting Parameters at the device ............................................ 28
9.1 Configuration layers .......................................................................... 28
10. CellaView software................................................................... 33
11. Installation of the USB driver .................................................. 34
12. How to operate the pyrometer with the CellaView software . 35
12.1 CellaView via USB point-to-point connection ................................... 35
12.2 CellaView via RS485 point-to-point connection ................................ 35
12.3 CellaView via RS485 bus connection ............................................... 37
12.4 Termination of RS485 bus ................................................................ 39
13. Operation of the pyrometer via terminal program ................. 39
13.1 Serial Data Transmission of Temperature Data ............................... 40
13.2 Terminal connection via USB ........................................................... 41
13.3 Terminal connection via RS485 ........................................................ 41

s
Operating Manual
MPA
14. User-defined calibration / scaling of the current output ....... 43
14.1 Calibration/scaling via CellaView ...................................................... 44
14.2 Calibration/scaling via terminal connection ....................................... 44
15. Theory of Non-Contact Temperature Measurements ............ 45
15.1 Advantages of Non-Contact Temperature Measurement ................. 45
15.2 Measurements at Black Bodies (Cavity Radiators) .......................... 45
15.3 Measurements of Real Radiators ..................................................... 46
15.4 Emissivity Coefficient Table MPA 10 ................................................ 47
15.5 Emissivity Coefficient Table MPA 20 – MPA 30 ............................... 48
16. Maintenance ............................................................................. 49
16.1 Cleaning the pyrometer lens ............................................................. 49
17. Technical Data MPA 10 ............................................................ 50
Field of View Diagrams for MPA 10 .............................................................. 51
18. Technical Data MPA 13 ............................................................ 52
18.1 Field of View Diagrams for MPA 13 .................................................. 53
19. Technical Data MPA 15 ............................................................ 54
19.1 Field of View Diagrams for PA 15 ..................................................... 55
20. Technical Data MPA 20 ............................................................ 56
20.1 Field of View Diagrams for MPA 20 .................................................. 57
21. Technical Data MPA 29 (150 … 800 °C) .................................. 59
21.1 Field of View Diagrams for MPA 29 .................................................. 60
22. Technical Data MPA 29 (180 … 1200 °C) ................................ 61
22.1 Field of View Diagrams for MPA 29 .................................................. 62
23. Technical Data MPA 29 (250 … 2000 °C) ................................ 64
23.1 Field of View Diagrams for MPA 29 .................................................. 65
24. Technical Data MPA 30 ............................................................ 67
24.1 Field of View Diagrams for MPA 30 .................................................. 68
25. Technical Data MPA 35 ............................................................ 70
25.1 Field of View Diagrams for MPA 35 .................................................. 71
26. Dimension Drawing .................................................................. 73
27. Optional Accessories ............................................................... 73
27.1 Cable VK 02/D .................................................................................. 74
27.2 Adapter cable MPA – MPZ ............................................................... 75
28. Glossary .................................................................................... 76
29. Shipping, Packaging and Disposal ......................................... 77
29.1 Inspecting your shipment .................................................................. 77
29.2 Packaging ......................................................................................... 77
29.3 Disposal of used apparatus .............................................................. 77
30. Copyright .................................................................................. 78
31. Default settings ........................................................................ 79
31.1 Temperature measurement via spectral channel 1 (configuration
layer: C001) ............................................................................................. 79
31.2 Configuration I/O (configuration layer: C010) ............................. 80
31.3 General Functions (configuration layer: C011) ........................... 81

s
Operating Manual
MPA
1
1. Product Numbers ARDOMETER MPA
Pyrometer Temperature range Product number
ARDOMETER MPA 10 AF1 MB: 0-1000 °C, D=50:1 (Standard lens) 7MC 3030-1AB10
ARDOMETER MPA 10 AF 2 MB: 0-1000 °C, D=48:1 (Close-up lens) 7MC 3030-1AC10
ARDOMETER MPA 13 AF 1 MB: 500-1600 °C, D=45:1 (Standard lens) 7MC 3030-1AB13
ARDOMETER MPA 15 AF 1 MB: 500-2500 °C, D=70:1 (Standard lens) 7MC 3030-1AB15
ARDOMETER MPA 15 AF 2 MB: 300-1300 °C, D=45:1 (Standard lens) 7MC 3030-1AC15
ARDOMETER MPA 20 AF 1 MB: 250-2000 °C, D=175:1 (Standard lens) 7MC 3030-1AB20
ARDOMETER MPA 20 AF 2 MB: 250-2000 °C, D=150:1 (Standard lens) 7MC 3030-1AC20
ARDOMETER MPA 20 AF 3 MB: 250-2000 °C, D=275:1 (Standard lens) 7MC 3030-1AD20
ARDOMETER MPA 20 AF 4 MB: 250-2000 °C, D=40:1 (Standard lens) 7MC 3030-1AE20
ARDOMETER MPA 20 AF 5 MB: 350-2500 °C, D=175:1 (Standard lens) 7MC 3030-1AF20
ARDOMETER MPA 20 AF 6 MB: 350-2500 °C, D=150:1 (Close-up lens) 7MC 3030-1AG20
ARDOMETER MPA 20 AF 7 MB: 350-2500 °C, D=275:1 (Telephoto lens) 7MC 3030-1AH20
ARDOMETER MPA 20 AF 8 MB: 350-2500 °C, D=40:1 (Wide-angle lens) 7MC 3030-1AJ20
ARDOMETER MPA 29 AF 1 MB: 250-2000 °C, D=210:1 (Standard lens) 7MC 3030-1AB29
ARDOMETER MPA 29 AF 2 MB: 250-2000 °C, D=200:1 (Close-up lens) 7MC 3030-1AC29
ARDOMETER MPA 29 AF 3 MB: 250-2000 °C, D=310:1 (Telephoto lens) 7MC 3030-1AD29
ARDOMETER MPA 29 AF 4 MB: 250-2000 °C, D=55:1 (Wide-angle lens) 7MC 3030-1AE29
ARDOMETER MPA 29 AF 10 MB: 150-800 °C, D=40:1 (Standard lens) 7MC 3030-1AB29
ARDOMETER MPA 29 AF 21 MB: 180-1200 °C, D=60:1 (Standard lens) 7MC 3030-1CB29
ARDOMETER MPA 29 AF 22 MB: 180-1200 °C, D=56:1 (Close-up lens) 7MC 3030-1CC29
ARDOMETER MPA 29 AF 23 MB: 180-1200 °C, D=210:1 (Telephoto lens) 7MC 3030-1CD29
ARDOMETER MPA 30 AF 1 MB: 500-2500 °C, D=210:1 (Standard lens) 7MC 3030-1AB30
ARDOMETER MPA 30 AF 2 MB: 500-2500 °C, D=200:1 (Close-up lens) 7MC 3030-1AC30
ARDOMETER MPA 30 AF 3 MB: 500-2500 °C, D=310:1 (Telephoto lens) 7MC 3030-1AD30
ARDOMETER MPA 30 AF 4 MB: 500-2500 °C, D=55:1 (Wide-angle lens) 7MC 3030-1AE30
ARDOMETER MPA 35 AF 1 MB: 600-3000 °C, D=210:1 (Standard lens) 7MC 3030-1AB35
ARDOMETER MPA 35 AF 2 MB: 600-3000 °C, D=200:1 (Close-up lens) 7MC 3030-1AC35

s
Operating Manual
MPA
2
Pyrometer Temperarute range Product number
ARDOMETER MPA 35 AF 3 MB: 600-3000 °C, D=310:1 (Telephoto lens) 7MC 3030-1AD35
ARDOMETER MPA 35 AF 4 MB: 600-3000 °C, D=55:1 (Wide-angle lens) 7MC 3030-1AE35

s
Operating Manual
MPA
3
2. Miscellaneous
2.1 Information about this manual
The Operating Manual shall enable the user to properly install the
pyrometer and those accessories which are necessary.
Before starting installation, be sure to read and understand this entire
manual, in particular the chapter on safety! The instructions contained in
this manual, especially those concerning safety, as well as site-specific
regulations governing UV radiation must be complied with at all times!
2.2 Explanation of symbols
Important safety-related references in this manual are marked with a
symbol.
CAUTION!
This symbol indicates important information which, if neglected, might
result in pyrometer damage, malfunction or breakdown.

NOTE !
This symbol points out guidelines which should be heeded for efficient
and trouble-free operation.
2.3 Liability and Warranty
All information compiled in this manual is in accordance with applicable
regulations. The statements made are based on state-of-the-art technol-
ogy and reflect our extensive knowledge and many years of experience.

NOTE !
Always carefully read this Operating Manual before beginning any
work on or with the instrument, especially prior to installation and
initial setup! The Manufacturer shall not be held liable for any
damages or malfunctions arising from a disregard of the warnings
and instructions contained herein.
This Operating Manual must be retained for future use. Please ensure
that all persons who wish to operate the instrument have access to this
manual.

s
Operating Manual
MPA
4
2.4 Copyright
This Operating Manual should be treated as confidential. It is solely in-
tended for use by persons involved with the instrument. This manual
may not be made available to a third party without prior Manufacturer’s
consent. Please contact the Manufacturer if the need should arise.

NOTE !
The data, texts, charts, drawings, images or other representations
contained in this manual are copyright-protected and furthermore,
subject to intellectual property rights. Violators will be prosecuted.
Unauthorised use and copyright infringement will be subject to
penalty by law.
Reproductions of any kind, in whole or in part, as well as the exploitation
or disclosure of this manual’s content without the explicit written approval
of the Manufacturer are expressly prohibited by law. Violations shall be
subject to compensation claims by the Manufacturer. The right to claim
additional indemnities remains reserved.
3. Safety
This chapter outlines all important safety aspects to be considered for
optimum employee protection and to ensure safe and reliable opera-
tions.
3.1 Intended use
The pyrometer is solely intended for non-contact measurement of tem-
peratures as described in this manual. Any other use is not intended.
Operational safety can only be ensured when the instrument is used for
its intended purpose.
CAUTION !
It is prohibited to use the pyrometer for any other purpose
beyond what is specified in this manual. Using the instru-
ment in any other manner will be considered as improper.
The Manufacturer/Authorised Agent shall not be held liable for any dam-
ages or loss resulting from such unintended or improper use; in this case
the risk is solely borne by the user.

s
Operating Manual
MPA
5
3.2 User’s responsibility
The pyrometer may only be used when it is in perfect working condition.
3.3 Safety requirements
The instrument works with an operating voltage of 24 VDC. The voltage re-
quired for operation must be supplied by a separate power supply. This
power supply unit must conform to directive DIN IEC 61010.
3.4 Electromagnetic Compatibility
The devices comply with the essential safety requirements of the Elec-
tromagnetic Compatibility Directive 2014/30/EU (EMC Act).
When connecting a power supply unit, make sure that is also conforms
to these standards. Radio interference may arise if the pyrometer is in-
terconnected with such peripheral devices which have not been properly
interference-suppressed. This may necessitate additional interference
suppression measures.
4. General Description
The ARDOMETER MPA Series provides efficient, microprocessor-
controlled pyrometers for non-contact temperature measurements
The field of applications for ARDOMETER MPA 1x includes temperature
detection of materials such as synthetic materials, rubber, textiles, pa-
per, coated sheet steel, wood or varnish within a range from 0 °C to
1000 °C.
The ARDOMETER MPA 13 is specially designed to detect the tempera-
ture of objects in flame-heated furnaces. Because MPA 13 works at a
narrow spectral range of 3.9 μm, water vapour and CO2 in the detector’s
field of view will not influence the measurement, even at greater target
distances. The spectral sensitivity of this model enables highly accurate
and reliable measurements through flames and combustion gases. This
pyrometer can also tackle other atmospheric challenges such as reduc-
ing the effect of background radiation within.
The ARDOMETER MPA 15 was specially developed for temperature
measurements of glass. Glass is transparent in the visible spectral range
and in the near infrared range. Its emissivity depends on the wavelength,
the type and the thickness of the glass. In the range of 4.5 - 8 µm glass
has an emissivity of almost 100%. Above 5 µm, atmospheric influences,
such as humidity or water vapour, affect the measurement. The MPA 15
is provided with a blocking filter with a spectral sensitivity of 4.6 - 4.9 µm.

s
Operating Manual
MPA
6
thus measuring the temperature from the near surface area of the glass.
Changes in thickness, different types of glass, or varying moisture con-
tents in the atmosphere do not affect the measurement reading owing to
the wavelength used.
The ARDOMETER MPA 29 was designed with a special band-stop filter
and sensor which ignore interfering IR radiation from sources such as
daylight or laser beams. ARDOMETER MPA 29 features a response
spectrum which is far less sensitive to incidental light reflections from
nearby hot objects than most commonly available pyrometers which are
responsive at short wavelengths.
The spectral pyrometers ARDOMETER MPA 2x and MPA 3x are used
for temperature measurements from 250 °C to 2000 °C or 500 °C to
3000 °C, respectively. Their applications cover large segments of the
iron and steel producing industry and the metal, glass, ceramics and
chemical industries.
To indicate the exact measurement spot the ARDOMETER MPA has a
through-the-lens sighting and focusable lens. Through-the-lens sighting
with target marker facilitates easy alignment to the target.
The instruments have rugged housings which make them ideal for use in
hostile industrial environments. ARDOMETER MPA pyrometers are
splash water proof according to IP65 (DIN 40050)
ARDOMETER MPA 1x features dynamic signal filtering known as a
“smoothing function”. This provides a steady signal and allows the py-
rometer to respond quickly when the temperature of the targeted surface
fluctuates erratically.
The adjustable emissivity factor makes it easy to adapt the pyrometer to
the specific radiation characteristics of the particular material measured.
All pyrometers of the ARDOMETER MPA series have two analogue cur-
rent outputs, each is switchable from 0 - 20 mA to 4 - 20 mA.
The output currents are linear to the measured temperature. The re-
quired temperature range can be set at the pyrometer.
When ambient temperatures are higher than the admissible working
temperature, the output current is > 20.5 mA.
ARDOMETER MPA also features an analogue voltage input which can
be used as an alternative to current output 2. The emissivity factor or a

s
Operating Manual
MPA
7
correction for reflected ambient temperature can be controlled using this
voltage input.
Two serial interfaces (USB and RS485) are available. They enable the
user to change all operating parameters such as emissivity setting, tem-
perature range, smoothing function or output current range during run-
ning operations.
ARDOMETER MPA allows for continuous temperature data output in a
user-configured cycle time.
4.1 Operating Controls and Display
The rear panel of the ARDOMETER MPA has a 4-digit display and 3
push-buttons. The display shows the current temperature or, during con-
figuration using the push-buttons, the display will show the correspond-
ing parameter.
Whenever the display shows a parameter, the F1 Parameter LED (yel-
low) will light up. The function of the F2 Status LED (green) is user-
configurable. In its initial state when supplied to the customer the F2
LED indicates current status for the switch able output Do1 as ready for
operation.
Pyrometer rear panel
Display
Parameter LED Status LED
Parameter
select/change
USB connection
Mode key

s
Operating Manual
MPA
8
5. Quick Reference Guide
5.1 MPA Connector Pin Assignment
CAUTION!
The pyrometer housing is connected to the signal ground via a
0.1  F/50V capacitor. Isolate any unused wires in order to avoid
the display of erroneous data.

s
Operating Manual
MPA
9
5.2 Power Requirement 24 V DC
The instrument works with an operating voltage of 24 V DC. The voltage
required for operation must be supplied by a separate power supply.
This power supply unit must conform to directive DIN IEC 61010.
The current consumption is  135 mA. ARDOMETER MPA is equipped
with inverse polarity protection. The output currents and voltages share
one ground connection via pin 8 of the connector.
A self-test is performed when the instrument is switched on. The display
will briefly indicate the software version and after that the emissivity set-
ting. When the self-test is completed the pyrometer is ready for opera-
tion and the display will show the current temperature reading.

NOTE !
In order to achieve a high degree of measurement accuracy and
repeatability it is important to allow the pyrometer time to warm
up. Turn the power supply on about 10 minutes, with camera 20
min before starting. We recommend that you protect the feed line
to the pyrometer against short circuit by using a 250 mA micro-
fuse.
5.3 Current Outputs 0/4 - 20mA
ARDOMETER MPA features two current outputs. Both of these outputs
are active current sources which supply linear output current. The user
can select between two scales: either 0 - 20 mA or 4 - 20 mA. Maximum
load is 500 .
The two current outputs are factory preset to 4 - 20 mA !

s
Operating Manual
MPA
10
For all pyrometers of the MPA Series the current outputs are short-
circuit-proof and share one ground connection via pin 8 of the connector.
Each current output can be individually scaled and can be set either at
the display or via interface.
When only one current output is required, Output 1 should be selected
(Pin 4)
5.4 Switching output
All pyrometers of the PA Series feature two switching outputs which can
be configured as digital outputs or digital inputs. The open collector out-
puts allow for a voltage of +24 V DC. For signal processing a pull-down
resistor can be applied to the ground connection of the supply voltage.
The maximum current of each open collector output is 30 mA.
See Chapter 8 for more information on configuration.
red
VK 02/I
Digital input 1
blue
brown
Digital input 2
Ground
PLC
+24 V
GND
51 KΩ
Imax = 30 mA
24 V DC
PA
brown
red
white
+ 24 V
bulb
relay

s
Operating Manual
MPA
11
6. Getting Started
6.1 General installation tips
Install the pyrometer in a location where it will not be unnecessarily ex-
posed to smoke, ambient heat or water vapour.
A false reading (too low) will be displayed when the pyrometer lens is
dirty. Therefore always ensure that the lens is clean.
The pyrometer’s optical path must remain unobstructed. Any interfer-
ence or obstacle may lead to measurement errors.
6.2 Pyrometer Alignment to Target
For accurate temperature measurement, it is essential that the py-
rometer is correctly aimed and focused on the target object. Make
sure that the optical path is not obscured because this would most
likely impair accuracy.
When aiming the pyrometer with through-the-lens sighting to a target,
both the targeted object and the target marker (distinctly marked circled
spot in the viewfinder) must appear in sharp focus simultaneously. The
measured object must completely fill the target circle in the viewfinder.
Instruments with a measuring range of > 2000 °C are equipped with a
polarization filter to control brightness and protect the user’s eye.
If the actual target spot is the same size as the minimum spot size re-
quired by the distance-to-target ratio, or only marginally larger, then we
recommend that you check the maximum output current to verify proper
focussing.
6.3 Setting parameters at the pyrometer (basic configuration)
Use the buttons ▲▼ and the „MODE" button on the rear panel to ac-
cess and configure parameters. With these buttons you can view and
adjust all settings required for operating the pyrometer. (See Chap. 4.1).

s
Operating Manual
MPA
12
Menu structure:
1. Press the MODE button while in normal operating mode to switch
to "configuration layer" mode.
2. Use ▲▼ to select the configuration layer for the parameter you
wish to set.
3. Press MODE to confirm. Press ▲▼ to select the particular pa-
rameter.
4. Press MODE to confirm. Press ▲▼ to adjust the parameter val-
ue.
5. Press MODE again to end. Press ▲▼ to select END/SAVE.
6. Now use MODE to either apply the changes you have made to
the settings [SAVE] or to close without saving these changes
[END]. After that, the display panel will resume showing the tem-
perature reading.
Parameter configuration
layer
Explanation
EPS.1 C001 Emissivity spectral channel 1
(see chapter 0).
AO1._ C010
Lower limit of temperature span
analogue output Ao1 (see chapter
6.5).
AO1.~ C010
Upper limit of temperature span
analogue output Ao1
(see chapter 6.5).
AO1.4 C010
Hardware configuration of the ana-
logue output 0-20 mA, 4-20 mA
(see chapter 6.5).
AO1.T C100 Temperature measurement simula-
tion to verify signal transmission
(see chapter 6.6).
Normal
operating mode
(temperature)
Select
config. layer
C000-
C999
Select
parameter
EPS
Adjust
parameter
99.9
MODE
MODE MODE
▲▼
▲▼
▲▼

s
Operating Manual
MPA
13

Note:
Key lock may have been activated at the terminal. When selecting
the configuration layer you will be prompted to enter an access
code with P000. To obtain full access to parameter settings,
enter P100 otherwise you will only be able to view parameters
but not change them.
6.4 Setting Emissivity
A pyrometer measures temperature by detecting the radiant energy emit-
ted from an object’s surface in the form of electromagnetic waves. The
temperature reading not only depends on the intensity of the object’s
thermal radiation (how hot the object is), but also on the material’s par-
ticular surface characteristics and thus its specific ability to emit thermal
energy. This is called emissivity. To obtain an accurate temperature
reading, it is imperative that the pyrometer be adjusted for this emissivity
prior to measurement.
Set the emissivity correction at configuration layer C001 See the
Emissivity Coefficient Table in Chapter 15.4 to select the proper emissiv-
ity factor for your application. We recommend that you first perform a
comparison temperature measurement with another device to determine
the correct emissivity factor for the task.

NOTE !
During normal operating mode, the emissivity ratio can be set at
the pyrometer using the ▲▼ buttons. When simultaneously
pressing the MODE key, the display shows the current measuring
temperature while the emissivity coefficient continues to be ad-
justed in the background. This is an easy way to determine the
emissivity when the object temperature is known. The modified
values are directly adopted.
CAUTION!
Once you have configured the emissivity parameter, the py-
rometer will maintain this specific setting. The pyrometer will
always operate with this value unless you change the setting.

s
Operating Manual
MPA
14
6.5 Output current range
For the pyrometer’s two analogue current outputs, select the current loop
scale – (0 - 20 or 4 – 20 mA)—which matches that of the downstream
signal processing equipment (PLC, display device, controller, etc.). At
the pyrometer and at the controller, set the upper and lower limits of the
temperature range and the current loop output signal. Access this setting
using configuration layer C010.
6.6 Simulated current signal for functional testing
After initial installation, you should perform a function test to verify that
temperature data is correctly transmitted to the controller. To do so, use
the push-buttons on the pyrometer rear panel to simulate a temperature
reading, which is applied as an output current signal scaled to the se-
lected current range. The appropriate parameter can be accessed via
configuration layer C100.
If the pyrometer is set up correctly, the downstream controller should in-
dicate the values you have entered (only within the scaled range). If
there is a discrepancy, please check the current range scale or the cable
connection.
When you have completed the function test, exit by pressing "ESC" and
return to normal operating mode.
7. How the pyrometer functions
7.1 Internal signal processing
Sensor Calculate temp.
of target object
Segmented
linearisation
Fil-
ter
peak value Tempera-
ture reading
/ Display
Ao1
Ao2
Do2
Do1
Emissivity
Transmitance
Correction for extraneous radiation
User-defined
Table
Averaging interval
Mode Filtering time
Filter
Source Scale
Cycle time
PreMax
