P/N 315-033240-13
INTRODUCTION The Model NIC-C from Siemens Industry, Inc., is a card
that provides HNET/XNET and CAN network communi-
cation within and between enclosures.The HNET/XNET
network can be wired either Class-B/Style 4 or Class-X/
Style 7. For HNET one NIC-C is required in each enclo-
sure. Each NIC-C (HNET or XNET) occupies one HNET
address. See Table 1 for restrictions on the location of
equipment on the HNET and XNET.
When configured for XNET, the NIC-C provides commu-
nication between FireFinder XLS/Desigo Fire Safety
Modular/Cerberus PRO Modular systems, as well as the
NCC or Desigo CC in an XNET network. MXL systems
may also reside on the same XNET. All events occurring
in the FireFinder XLS/Desigo Fire Safety Modular/
Cerberus PRO Modular will be displayed at the NCC or
Desigo CC. Additionally, these events may be acknowl-
edged and the system can be reset via the NCC or
Desigo CC. Events initiated by FireFinder XLS/Desigo
Fire Safety Modular/Cerberus PRO Modular members
can cause output state changes (inter-panel logic) in
other FireFinder XLS/Desigo Fire Safety Modular/
Cerberus PRO Modular panels. Inter-panel logic be-
tween FireFinder XLS/Desigo Fire Safety Modular/
Cerberus PRO Modular and MXL is not available. One
NIC-C configured for XNET is required in each FireFinder
XLS/Desigo Fire Safety Modular/Cerberus PRO Modular
system connected to XNET. This NIC-C must reside in
the same enclosure as the PMI/PMI-2/PMI-3 (XLS),
FCM2041-U2 (Desigo Fire Safety Modular), FCM2041-
U3 (Cerberus PRO Modular).
Additionally, the NCC-GL is supported where display and
control of an individual XLS/Desigo Fire Safety Modular/
Cerberus PRO Modular system is required.The NCC-GL
must be connected to the XNET network.The
connection to HNET is not supported.
The CAN network is also supported by NIC-C. It can be isolated within a given
enclosure or extended external to the enclosure. External CAN networks require
either an RNI, OCM-16 or SIM-16 in the remote enclosure. The CAN address of the
NIC-C does not need to be set.
A single NIC-C provides either HNET or XNET. The CAN interface is available regard-
less of the HNET/XNET selection.
Figure 1
NIC-C Network Interface Card
Network Interface Card
Installation Instructions
Model NIC-C

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-132
The NIC-C supervises each network to insure proper operation. Any faults that are
detected by the NIC-C are reported to the PMI/PMI-2/PMI-3 (XLS), FCM2041-U2
(Desigo Fire Safety Modular), FCM2041-U3 (Cerberus PRO Modular) for annunciation.
In addition, the NIC-C has diagnostic LEDs that indicate which faults have been
found. Individual LEDs are included for HNET/XNET Loop A and Loop B faults, as well
as an LED for complete failure of the HNET or XNET network or the CAN network.
The NIC-C can also be configured to perform ground fault detection on both net-
works.
Features The NIC-C isolates short circuit faults to each individual segment of the HNET/XNET
network. If a short occurs, only the segment of wire between the two NIC-Cs is
affected. In a Class-B/Style 4 system the network will be divided into two sections.
Communication in each of the sections will continue. For a Class-X/Style 7 network,
the fault will be detected and the network will continue to operate as a single
network. An HNET/XNET network monitoring jack is included for connection of
diagnostic tools. This jack is located on the front bezel.
The NIC-C supports the LCM-8/SCM-8/FCM-6/OCM-16/SIM-16 CAN modules. LEDs
are visible through the front bezel to indicate the NIC-C configuration. All switch
selectable options are displayed here.This allows for easy confirmation of the NIC-C
configuration settings.
The NIC-C is compatible with the XNET Bridge. Refer to the XNET Bridge installation
instructions, P/N 315-050017, for more details.
TENHTENX
4elytS/B-ssalC7elytS/X-ssalC4elytS/B-ssalC7elytS/X-ssalC
,)SLX(3-IMP/2-IMP/IMP
eriFogiseD(2U-1402MC
F
,)raludoMytefaS
surebreC(3U-1402MCF
)TENH()raludoMORP
YY * *
3-IMP/2-IMP/IMPlabolG
2U-1402MCF,)SLX(
ytefaSeriFo
giseD(
3U-1402MCF,)raludoM
)raludoMORPsurebreC(
)TENX(
**Y **N
MER-DSS/C-DSS/DSS
LTNI-C-DSS/LTNI-DSS YN* *
MPRYN**
dewollA
toN=N,dewollA=Y
.krowtensihtnodewollatoN*
.seYesiwrehto,4XOBMER/2XOBMERanidellatsninehW**
Class-B/Style 4 = ULC DCLB
Class-X/Style 7 = ULC DCLC
In Canada, ULC S524 requires that all interconnecting data communications links for
networks be wired DCLC (style 7) except for dedicated network communication to
annunciators.
Table 1
Module Placement AtThe End Of a HNET Or XNET Network
OPERATION Network supervision is accomplished through passive monitoring of the network
signals. No additional bandwidth is required. Each NIC-C continuously monitors all
networks for activity and reports any problems to the PMI/PMI-2/PMI-3 (XLS),
FCM2041-U2 (Desigo Fire Safety Modular), FCM2041-U3 (Cerberus PRO Modular). In
some cases, a reset at the PMI/PMI-2/PMI-3 (XLS), FCM2041-U2 (Desigo Fire Safety
Modular), FCM2041-U3 (Cerberus PRO Modular) is required to clear network troubles.

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-133
Controls and Indicators The front panel of the NIC-C contains one reset switch, fifteen LEDs, one network
port and three HNET address switches as shown in Figure 1.
A reset switch is located on the top of the front panel. Pushing the reset switch re-
initializes the NIC-C operation.
The LEDs follow the reset switch and their functions are defined as follows:
POWER (Green) Normally ON. When illuminated, indi-
cates that power for the NIC-C is applied
to the card.
CARD FAIL (Yellow) Normally OFF. When illuminated, indicates
that the card microprocessor has failed.
CAN FAIL (Yellow) Normally OFF. When illuminated, indi-
cates that all CAN modules connected to
the NIC-C are not communicating.
HNET FAIL (Yellow) Normally OFF. When illuminated, indi-
cates that the HNET communication
with the NIC-C has terminated and the
card goes into degrade mode.
XNET FAIL (Yellow) Normally OFF. When illuminated, indi-
cates that the XNET communication with
the NIC-C has terminated.
GND FAULT (Yellow) Normally OFF. When illuminated, indi-
cates that the NIC-C has detected either
a negative or positive ground fault on its
network.
LOOP A FAIL (Yellow) Normally OFF. When illuminated, indi-
cates that the NIC-C has detected a
trouble on Loop A (open circuit or short
circuit).
LOOP B FAIL (Yellow) Normally OFF. When illuminated, indi-
cates that the NIC-C has detected a
trouble on Loop B (open circuit or short
circuit).
ACTIVE NETWORKS: CAN (Green) Normally OFF. When illuminated, indi-
cates that the CAN network is enabled.
ACTIVE NETWORKS: HNET (Green) When illuminated, indicates that the
HNET network is enabled.
ACTIVE NETWORKS: XNET (Green) When illuminated, indicates that the
XNET network is enabled.
CLASS-X/STYLE 7 (Green) When illuminated, indicates that the
HNET/XNET is configured as Class-X/Style
7 (see Pre-Installation - S3 on page 4).

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-134
CLASS-B/STYLE 4 (Green) When illuminated, indicates that the
HNET/XNET is configured as Class-B/Style
4 (see Pre-Installation - S3 on page 4).
ENABLED (Green) When illuminated, indicates that ground
fault detection is enabled (see Pre-
Installation - on page 4).
DISABLED (Green) When illuminated, indicates that ground
fault detection is disabled (see Pre-
Installation - on page 4).
Three rotary dial switches at the bottom of the front panel are used to set the HNET
network address of the NIC-C.
PRE-INSTALLATION The following components must be set prior to inserting the card into the CC-5 (refer
to Figure 2):
S1, Ground Fault Detection Control: Press the lever down to enable ground fault
detection. Move the lever to the up position to disable ground fault detection. (Refer
to Figure 2.)
It is recommended to enable ground fault detection on ONLY one NIC-C in the system.
(One for HNET and if used, one for XNET.) If multiple NIC-Cs have ground fault detection
enabled, multiple troubles will be reported to the PMI/PMI-2/PMI-3 (XLS), FCM2041-U2
(Desigo Fire Safety Modular), FCM2041-U3 (Cerberus PRO Modular) when a ground
fault is present. In all cases at least one NIC-C must have ground fault detection
enabled.
S3, NIC-C Options:
Position 1: Network Selection -
Set this switch to the ON
position for HNET. Set to the OFF
position for XNET.
Position 2: Network Style -
Set to ON for Class-B/Style 4.
Set to OFF for Class-X/Style 7.
Position 3: CAN Network enable-
Set to ON if CAN network is
used. Set to OFF if CAN network
is not used
Position 4: Future Use -
Set to OFF.
S4, Reset Switch: Momentarily Closed
switch that when pressed will initiate a hard
reset to the NIC-C (similar to a cold boot).
NCC-2F-HNET-VNT Jumper Settings:
When Class-B/Style 4 wiring is used for an
NCC-2F-HNET-VNT application, remove
jumper P2 except on the NIC-C that is
connected to the NCC-2F card. When Class-
X/Style 7 wiring is used for an NCC-2F-HNET-
VNT application, remove jumpers P2 and P4
except on the NIC-C that is connected to the NCC-2F card.
Figure 2
NIC-C
Switch
Location
96 PIN DIN
PLUG CONNECTOR
S5, S6, S7
S3
S1
S4
On
14
3
2
RESET
SWITCH
NETWORK
ADDRESS
NETWORK
PORT
P5 P3
P4 P2

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-135
S5, S6, S7, Network Address Switches: Set the three-digit HNET network address
for the NIC-C using the three rotary dial address switches located near the bottom of
the front panel. (Refer to Figure 1 for the location of the switches.) The address for
the NIC-C must be the same as the address selected for it in the Zeus Programming
Tool. To set the address, turn the pointers on each of the three dials to the numbers
for the selected address. For example, if the address is 123, set the pointer for the
HUNDREDS dial to “1”, set the pointer for the TENS dial to “2”, and set the pointer for
the ONES dial to “3”. The range of allowable addresses is from 001 to 251 (leading
zeros must be used).
WIRING
Remove all system power before installation, first battery then AC. (To power up,
connect the AC first, then the battery.)
All HNET/XNET field wiring to the NIC-C is connected to the terminal blocks of the
CC-5 card cage slot in which it is installed.
The CAN bus is connected internally to the CC-5 backplane. For CAN modules
located on the inner door inside the same enclosure as the NIC-C connect to P3 on
the CC-5 using cable CCL. For CAN modules located outside the enclosure connect
to TB1 on the PSC-12. See Figures 11, 12 and 13.
Internal Repeaters The NIC-C provides an electrical repeater for each HNET/XNET pair.The diagram in
Figure 3 shows the wiring for each pair. Be sure to connect the pairs following the
proper polarity. Do not cross the A and B pairs. Removing the NIC-C from the CC-5 will
break the network. Removing power from the NIC-C does not break the network.
To Connect the HNET or XNET
1. Loosen the screw of the terminal by turning it counterclockwise.
2. Insert the wire into the side of the terminal block.
3. Tighten the screw of the terminal block by turning it clockwise.
The NIC-C supports Class-B/Style 4 (DCLB) and Class-X/Style 7 (DCLC) HNET/XNET wiring.
Check the Zeus configuration for the proper network Style (refer to Figures 4 and 5).
The screw terminals can accommodate one 12 -18 AWG or two 16-18 AWG.
15
A– A–
26
A+ A+
37
48
B– B–
B+ B+
TERMINAL BLOCK
ON THE CC-5/CC-2
APAIR
REPEATER
BPAIR
REPEATER
Figure 3
NIC-C Internal Repeaters
HNET

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-136
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
DO NOT USE DO NOT USE
ONE SLOT OF CC-5
FIRST NIC-C
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
DO NOT USE
PAIR A
SUPERVISED
POWER LIMITED
ONE SLOT OF CC-5
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
DO NOT USE
ONE SLOT OF CC-5
LAST NIC-C
Figure 4
NIC-C Class-B/Style 4 (ULC DCLB) Network Wiring
NOTES:
1. No EOLR required.
2. 18 AWG min., 12 AWG max.
3. 2000 feet (33.8 ohms) max.
per pair between CC-5s/CC-2s.
Unshielded twisted pair
.25μF max. line to line
Shielded twisted pair
.15μF max. line to line
.2μF max. line to shield
4. Terminate shields at one end
only.
5. Power limited to NFPA 70
per NEC 760.
6 CC-5 terminals 9 - 14 are not
connected and can be used
to tie shields together.
7. Positive or negative ground
fault detected at <10K ohms
on pins 1 - 4.
Figure 5
NIC-C Class-X/Style 7 (ULC DCLC) Network Wiring
NOTES:
1. No EOLR required.
2. 18 AWG min., 12 AWG max.
3. 2000 (33.8 ohms) feet max.
per pair between CC-5s/CC-2s.
Unshielded twisted pair
.25μF max. line to line
Shielded twisted pair
.15μF max. line to line
.2μF max. line to shield
4. Terminate shields at one end
only.
5. Power limited to NFPA 70
per NEC 760.
6. CC-5 terminals 9 - 14 are not
connected and can be used
to tie shields together.
7. Positive or negative ground
fault detected at <10K ohms
on pins 1 - 8.
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
DO NOT USE DO NOT USE DO NOT USEDO NOT USE
ONE SLOT OF CC-5
FIRST NIC-C
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
PAIR A
SUPERVISED
POWER LIMITED
PAIR B
SUPERVISED
POWER LIMITED
ONE SLOT OF CC-5
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
DO NOT USE
ONE SLOT OF CC-5
LAST NIC-C

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-137
Figure 6 NCC-2F-HNET-VNT Class-B/Style 4 Wiring
PSC-12
RESET POWER MODULE FAIL H - NET FAIL GND FAULT 24V 12 FAIL 24V 4A FAIL CAN FAIL
TB3
+ -
P4
TB1
P5
TB2
+
+
_
_
H
N
GND
P9 P12
TB4
BATTERY
OFF
O—
ON
ONES TENS HUNDREDS
HNET
(ONE SLOT
OF
CC-5/CC-2)
LAST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
FIRST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
NCC-2F
2
34
*
1
PAIR A SUPERVISED POWER LIMITED
* EOLR 120 OHMS,
1/2W, 5% P/N 140-820350
* EOLR 120 OHMS, 1/2W, 5%
P/N 140-820350
5
TB1
60-PIN RIBBON CABLE FROM PSC-12
CC-2 CC-2 CC-2
60-PIN
RIBBON
CABLE
I I
C
60-PIN
RIBBON
CABLE I
I
C
*
DO NOT USE
DO NOT USE
DO NOT USE
DO NOT
USE
SEE NOTE 6 DO NOT
USE
SEE NOTE 6 DO NOT
USE
SEE NOTE 6
DO NOT USE DO NOT USE DO NOT USE
*
NOTES: 1. EOLR required. 2. 18 AWG min., 12 AWG max. 3. 2000 feet (33.8 ohms) max. per pair between CC-5s/CC-2s.
Unshielded twisted pair .25μF max. line to line Shielded twisted pair .15μF max. line to line .2μF max. line to shield
4. Terminate shields at one end only. 5. Power limited to NFPA 70 per NEC 760. 6 CC-5/CC-2 terminals 9 - 14 are not connected and can be used to tie shields
together.
7. Positive or negative ground fault detected at <10K ohms on pins 1 - 4.
8. Remove jumper P2 from all NIC-Cs in this wiring configuration except on the
NIC-C that is connected to the NCC-2F card.

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-138
Figure 7 NCC-2F-HNET-VNT Class-X/Style 7 Wiring
PSC-12
RESET POWER MODULE FAIL H - NET FAIL GND FAULT 24V 12 FAIL 24V 4A FAIL CAN FAIL
TB3
+ -
P4
TB1
P5
TB2
+
+
_
_
H
N
GND
P9 P12
TB4
BATTERY
OFF
O—
ON
ONES TENS HUNDREDS
HNET
(ONE SLOT
OF
CC-5/CC-2)
LAST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
FIRST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
NCC-2F
2
34
*
1
PAIR A SUPERVISED POWER LIMITED
* EOLR 120 OHMS, 1/2W, 5%
P/N 140-820350
5
TB1
60-PIN RIBBON CABLE FROM PSC-12
CC-2 CC-2 CC-2
60-PIN
RIBBON
CABLE I
I
C
60-PIN
RIBBON
CABLE I
I
C
*
PAIR B
SUPERVISED
POWER LIMITED
* EOLR 120 OHMS, 1/2W, 5%
P/N 140-820350
*
*
DO NOT
USE
DO NOT
USE
DO NOT
USE
SEE NOTE 6
DO NOT
USE
DO NOT
USE
DO NOT
USE
SEE NOTE 6
DO NOT
USE
SEE NOTE 6
DO NOT USE
DO NOT USE
DO NOT USE
NOTES: 1. EOLR required. 2. 18 AWG min., 12 AWG max. 3. 2000 feet (33.8 ohms) max. per pair between
CC-5s/CC-2s. Unshielded twisted pair .25μF max. line to line Shielded twisted pair .15μF max. line to line .2μF max. line to shield
4. Terminate shields at one end only. 5. Power limited to NFPA 70 per NEC 760. 6. CC-5/CC-2 terminals 9 - 14 are not connected and
can be used to tie shields together.
7. Positive or negative ground fault detected at
<10K ohms on pins 1 - 8.
8. Remove jumpers P2 and P4 from all NIC-Cs in
this wiring configuration except on the NIC-C that is connected to the NCC-2F card.

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-139
NOTES:
1. No EOLR required for NIC-C.
2. The screw terminals can accommodate one
12-24AWG or two 16-24AWG.
3. From the NCC-2F to NIM-1R, NIM-1W or
NCC-2F:
80 Ohms max. per pair.
Unshielded twisted pair - .5μF line to line
Shielded twisted pair - .3μF line to line, .4μF
line to shield
4. From the NCC-2F to NIC-C:
2000 feet (33.8 ohms) max. per pair between
CC-5s/CC-2s.
Figure 8
Connecting To An XNET
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7 DO NOT USE
D
O
N
O
T
US
E
DO NOT USE DO NOT USE
ONE SLOT OF CC-5
NIC-C
12345
PAIR A
SUPERVISED
POWER LIMITED
PAIR B
(OMIT FOR STYLE 4)
SUPERVISED
POWER LIMITED
LOCATED INSIDE NCC/
DESIGO CC/VNT
NOTE:
IF THE NCC/DESIGO CC/VNT
IS LOCATED AT THE END OF THE
XNET NETWORK, INSTALL EOLR
P/N 140-820350 ACROSS
TERMINALS 1 & 2 AND 3 & 4.
NCC-2F MOM-4
TB3 OR TB4
NIM-1R / NIM-1W
1234
TO ADDITIONAL
NIM-1Rs, NIM-1Ws,
NCC-2Fs OR NIC-C
s
(MUST BE IN SAME ENCLOSURE AS THE PMI/
PMI-2/PMI-3 [XLS], FCM2041-U2 [DESIGO FIRE
SAFETY MODULAR], FCM2041-U3 [CERBERUS
PRO MODULAR])
TB2
NIM-1M
NIM-1W
MOM-2
1 2 3 4
TB4
TB6
A PAIR
*
*
MOM2-XMP
+
-
B PAI
R
B PAIR
(OMIT FOR
CLASS-B/
STYLE 4
(ULC DCLB))
TO
PSC-12
TB3
TO
COMPANION
NIM-1M
24V
24V RET
DO NOT USE DO NOT USE
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
NIC-C
A PAIR
EOLR P/N 140-099066
(SUPPLIED WITH NIM-1W)
*
Figure 9
Wiring The NIC-C To An XNET Bridge
NOTES:
1. Refer to NIM-1W Installation Instructions,
P/N 315-099106 for NIM-1W setup and
NIM-1M setup and wiring instructions.
2. No EOLR required at the NIC-C.
3. All wiring power limited to NFPA 70 per
NEC 760.
4. Class-B/Style 4 Bridge shown. For Class-X/
Style 7, a second NIM-1W/NIM-1M is
required.
5. The NIC-C and the NIM-1W /NIM-1M must
be in the same enclosure.
6. Positive or negative ground fault detected
at <10K ohms on pins 1 - 8.
Unshielded twisted pair
.25μF max. line to line
Shielded twisted pair
.15μF max. line to line
.2μF max. line to shield
5. Use twisted pair or twisted shielded pair.
6. Terminate shields at one end only.
7. Power limited to NFPA 70 per NEC 760.
8. CC-5 terminals 9 - 14 are not connected and
can be used to tie shields together.
9. Positive or negative ground fault detected at
<10K ohms on pins 3-4, 7-8 of the NIC-C.
10. Each pair independently supervised.
11. Maximum voltage 8V P-P.
12. Maximum current 75mA during message
transmission.

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-1310
To Connect the Internal CAN Bus
1. Install the CCL cable into P3 of the CC-5 in the upper left corner of the
enclosure.
2. Install the other end of the CCL cable into the first CAN module on the
inner door.
3. Observe the location of the CAN termination devices. Install one CAN
terminator P/N 110-134215 in the last CAN module on the inner door. Install
the 120 Ohm CAN termination resistor P/N 140-820150 into TB1 10 and 11
on the PSC-12.
4. The NIC-C may be installed into any open slot of a CC-5.
To Connect the External CAN Bus
1. Loosen the screw of the terminal by turning it counterclockwise.
2. Insert the wire into the side of the terminal block
3. Tighten the screw of the terminal block by turning it clockwise.
4. Observe the location of the CAN termination devices. Install one CAN
terminator P/N 110-134215 in the last CAN module on the inner door. If no
CAN modules are installed on the inner door inset the CAN terminator into
P3 of the CC-5 where the NIC-C is installed.
5. Install the second CAN terminator in the last CAN module in the remote
enclosure.
6. The NIC-C may be installed into any open slot of a CC-5.
Figure 10
CAN Wiring - Single Enclosure

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-1311
Figure 11
CAN Wiring - Single Remote Enclosure
24 V
TB1
LVM
1 2
9
10
P1
1
4
3
64
13
6
P3
P4
59
6
5
4
3
2
1
60
TB2
RNI
TB3 TB4 TB5
TB6
2
1
1
2
P2
PSC-12
RESET
POWER
MO DULE FAIL
H - NET FAIL
GNDFAULT
24V12 FAIL
24V4A FAIL
CAN FAIL
TB3
CAN + CAN -
P4
TB1
P5
BATTERY AC
TB2
1
++
__
2
HNGND
P9
P12
TB4
REFER TO
SINGLE ENCLOSURE
WIRING DIAGRAM
FIG. 6
SHIELD
CONNECTION
POINTS
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5 6
7
8
9
0
1
2
3
4
5 6
7
8
9
0
FCM-6
LCM-8
OR
SCM-8
LCM-8
OR
SCM-8
P1
P2
10 1112
CAN TERMINATOR
P/N 110-134215
INCLUDED IN CAN TERMINATOR KIT
(SHIPPED WITH THE NIC-C)
*
*
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
OCM-16
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
TB2
TB1
P2 P3
TB3
TB4
SIM-16
CLASS-B/
STYLE 4
(ULC DCLB)
NOTES:
1. 18 AWG min., 12 AWG max.
2. 15 ohms max. for CAN
network.
3. Use twisted pair or twisted
shielded pair.
4. Power limited to NFPA 70
per NEC 760.
5. All field wiring supervised.
Figure 12
CAN Wiring - Multiple Remote Enclosures
24 V
24 V
TB1TB1
LVMLVM
11 22
99 10
10
P1P1
CAN OUTCAN OUT
11
4
4
33
66 44
11 33
66
P3
P3
P4
P4
CAN INCAN IN
59
59
6
6
5
5
4
4
3
3
2
2
1
1
60
60
TB2TB2
RNI
RNI
TB3TB3 TB4TB4 TB5TB5
TB6TB6
22
1
1
11
2
2
P2P2
PSC-12
RESET
POWER
MODULE FAIL
H - NET FAIL
GND FAULT
24V 12 FA IL
24V 4A FAIL
CAN FAIL
TB3
CAN +
CAN –
CAN -
CAN +
P4
TB1
P5
BATTERY AC
TB2
1
++
__
2
HNGND
P9
P12
TB4
10 11 12
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
OCM-16
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
TB2
TB1
P2 P3
TB3
TB4
SIM-16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
OCM-16
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
TB2
TB1
P2 P3
TB3
TB4
SIM-16
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5 6
7
8
9
0
1
2
3
4
5 6
7
8
9
0
FCM-6
LCM-8
OR
SCM-8
LCM-8
OR
SCM-8
P1
P2
CAN TERMINATOR
P/N 110-134215
INCLUDED IN CAN TERMINATOR KIT
(SHIPPED WITH THE NIC-C)
*
*
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
FCM-6
LCM-8
OR
SCM-8
LCM-8
OR
SCM-8
P1
P2
S
HIELD
CONNECTION
POINTS
SHIELD
CONNECTION
POINTS
REFER TO
SINGLE ENCLOSURE
WIRING DIAGRAM
FIG. 6
CLASS-B/
STYLE 4
(ULC DCLB)
NOTES:
1. 18 AWG min., 12 AWG max.
2. 15 ohms max. for CAN
network.
3. Use twisted pair or twisted
shielded pair.
4. Power limited to NFPA 70
per NEC 760.
5. All field wiring supervised.

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-1312
Figure 13
CAN Wiring - Remote Enclosure Without An RNI
+24 V
CAN +
CAN –
SHIELD
SHIELD (OPTIONAL)
24V RETURN
PSC-12
RESET
POWER
MODULE FAIL
H - NE T FAIL
GND FAULT
24V 12 FAIL
24V 4A FAIL
CAN FAIL
TB3
CAN + –
+_
P4
TB1
P5
BATTERY AC
TB2
1
++
__
2
HNGND
P9
P12
TB4
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
FCM-6
LCM-8
OR
SCM-8
LCM-8
OR
SCM-8
P1
P2
10 11 12
CAN TERMINATOR
P/N 110-134215
INCLUDED IN CAN TERMINATOR KIT
(SHIPPED WITH THE NIC-C)
*
*
1 2 3 4 5 6 7 81 2 3 4 5 6 7 81 2 3 4 5 6 7 8
9 10 11 12 13 14 15 169 10 11 12 13 14 15 169 10 11 12 13 14 15 16
17 18 19 20 21 22 23 2417 18 19 20 21 22 23 2417 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
S1
1
5
3
7
2
6
4
8
S2
1
5
3
7
2
6
4
8
OCM-16OCM-16OCM-16
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
TB2
TB1
P2 P3
TB3
TB4
SIM-16
REFER TO
SINGLE
ENCLOSURE
WIRING
DIAGRAM
FIG. 6
CLASS-B/
STYLE 4
(ULC DCLB)
NOTES:
1. 18 AWG min., 12 AWG max.
2. 15 ohms max. for CAN
network.
3. Use twisted pair or twisted
shielded pair.
4. Power limited to NFPA 70
per NEC 760.
5. All field wiring supervised.
The screw terminals can accommodate one 12 -18 AWG or two 16-18 AWG.
INSTALLATION The NIC-C plugs perpendicularly into one slot in the CC-5 card-cage via two 96-pin
DIN connectors and can occupy any slot in the card cage. (Refer to Figure 14.)
Insert the NIC-C card into the card guides rightside up (lettering on the
front panel is legible)
Slide the card in until the card edge connectors contact the recep-
tacles on the motherboard.
Verify that the DIN connectors of the card and the card-cage aligned
properly.The card can only plug in one direction to the card cage, if it
does not align, DO NOT FORCE the card.
Place thumbs on the front panel adjacent to the captive screws and
gently apply even pressure on the card until the connectors seat in the
receptacles on the motherboard. Secure with the captive screws.
Figure 14
Installing The NIC-C
rewoPtupnI rewoPtuptuO
tnerruCenalPkcaBV42Am021 TENX/TENHhcaE
riaPkrowteNNACdnA
.xamkaepotkaepV8
tnerruCV42l
animreTwercS0 )noissimsnartgsmgnirud(.xamAm57
tnerruCenalPkcaBV2.60
tnerruCybdnatSV42Am021
ELECTRICAL RATINGS

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-1313
Cyber security disclaimer
Siemens products and solutions provide security functions to ensure the secure operation of building comfort, fire
safety, security management and physical security systems. The security functions on these products and solutions
are important components of a comprehensive security concept.
It is, however, necessary to implement and maintain a comprehensive, state-of-the-art security concept that is
customized to individual security needs. Such a security concept may result in additional site-specific preventive
action to ensure that the building comfort, fire safety, security management or physical security system for your site
are operated in a secure manner.These measures may include, but are not limited to, separating networks, physically
protecting system components, user awareness programs, defense in depth, etc.
For additional information on building technology security and our offerings, contact your Siemens sales or project
department. We strongly recommend customers to follow our security advisories, which provide information on the
latest security threats, patches and other mitigation measures.
http://www.siemens.com/cert/en/cert-security-advisories.htm

Siemens Industry, Inc.
Building Technologies Division
Florham Park, NJ
Siemens Canada, Ltd.
1577 North Service Road East
Oakville, Ontario
L6H 0H6 Canada
P/N 315-033240-13Siemens AG
I BT DE FS SYS
D-81379 München
For CE applications in Cerberus E100 systems refer to
Installation Instruction A24205-A334-B844 (English) or A24205-A334-A844 (German).
Document ID A6V10239113
