  9. Siemens FDB181 Series User manual

Siemens FDB181 Series User manual

Building Technologies
Fire safety and security products
FDB181 Detector Base
Product Manual
Overview
The FDB181detector bases is a universal base. It’s fixed on fire detection site and used
for installations of FD181 series detectors:
−FDO181 smoke detector
−FDT181 heat detector
Characteristics
– Universal bases,applicable to both surface install and conceal install
– Large opening in the detector base for easy cable insertion
– Adopt environmental friendly material
Installation
The installation of a base should strictly follow the engineering design drawings. The
bases should be evenly distributed.
Procedure of installation:
1.Insert the cables through the base and connect them to the terminals.
2.Fix the base to the ceiling with screws.
Note:
The detector should be installed after the construction has been finished.
In order to ensure the reliability of the connection between the base and the detector,
please do not use U-type terminals.
Twisted-pairs with the wiring requirement of 1.0~1.5mm2 are recommended.
Beijing Siemens Cerberus Electronics Limited
No.1,Fengzhidonglu, Xibeiwang, HaiDian District,
Beijing, 100094, China
Tel: +10 6476 8806
Fax: +10 6476 8899
© Data and design subject to change without notice.
Doc No.
A6V10326265_d_en_--
Manual FD18
Edition
07.2012
100858266
Dimensions
In:mm
95.6
R2.15 0.50±
74.0 0.1±20.1
Electric connection
51a
6 1b
To next base
Terminal resistor
is not necessary
To controller
FDB181 Base
PP
S
S
Technical data
Connecting terminals
1.0 ... 1.5 mm
2
Operating temperature
Storage temperature
Humidity
Protection category EGB4208-93
According to data of detectors
Color
White
,
RAL 9010
Details for ordering
Type
Material No.
Part No.
Designation
Weight
FDB181
S54320-F1-A1
100856213
Detector base
0.027 kg

This manual suits for next models

2
