Siemens PC 677B User manual

SIMATIC Industrial PC SIMATIC Panel PC 677B
_
_____________
_
_____________
_
_____________
_
_____________
_
_____________
_
_____________
Safety
1
Delivery
2
Installation / panel-mounting
3
Connecting
4
Commissioning
5
Service and support
6
SIMATIC
Industrial PC
SIMATIC Panel PC 677B
Operating Instructions (Compact)
06/2008
A5E02217246-01

Safety Guidelines
Safety Guidelines
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The device/system may only be set up and used in conjunction with this documentation. Commissioning and
operation of a device/system may only be performed by qualified personnel. Within the context of the safety notes
in this documentation qualified persons are defined as persons who are authorized to commission, ground and
label devices, systems and circuits in accordance with established safety practices and standards.
Prescribed Usage
Note the following:
WARNING
This device may only be used for the applications described in the catalog or the technical description and only
in connection with devices or components from other manufacturers which have been approved or
recommended by Siemens. Correct, reliable operation of the product requires proper transport, storage,
positioning and assembly as well as careful operation and maintenance.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90327 NÜRNBERG
GERMANY
A5E02217246-01
Ⓟ 06/2008
Copyright © Siemens AG 2008.
Technical data subject to change
이기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이점을 주의하시기 바라며 가정 외의 지역에서 사용하는 것을 목적으로 합니다.

SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 3
Table of contents
1 Safety ........................................................................................................................................................ 5
2 Delivery...................................................................................................................................................... 7
2.1 Unpacking and checking the delivery ............................................................................................7
2.2 Device identification data...............................................................................................................8
2.3 Product Documentation .................................................................................................................8
3 Installation / panel-mounting...................................................................................................................... 9
3.1 Mounting depth of the device.........................................................................................................9
3.2 Permitted mounting positions.......................................................................................................10
3.3 Preparing the mounting cut-out....................................................................................................11
3.4 Securing the device with clamps..................................................................................................13
3.5 Securing with screws ...................................................................................................................14
4 Connecting .............................................................................................................................................. 17
4.1 Connection elements and operator controls ................................................................................18
4.2 Connecting the 120 V / 240 V AC power supply..........................................................................20
4.3 Connecting the (24 V) DC power supply .....................................................................................22
4.4 Connecting the Equipotential Bonding Circuit .............................................................................23
5 Commissioning ........................................................................................................................................ 25
5.1 Initial Startup ................................................................................................................................25
5.2 Setting up the language selection................................................................................................26
5.3 Setting the panel type ..................................................................................................................27
5.4 KeyTools (for key panel devices).................................................................................................28
5.5 On-screen keyboard (for touch panel device)..............................................................................29
6 Service and support................................................................................................................................. 31

SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 5
Safety 1
CAUTION
In order to avoid substantial damage and for your own safety, note the safety instructions in
this documentation and in the operating instructions.
WARNING
Function test while installing the device in machines or execute systems
Following the results of a risk analysis, additional protection equipment on the machine or
the system is necessary to avoid endangering persons. With this, especially the
programming, configuration and wiring of the inserted I/O modules have to be executed, in
accordance with the safety performance (SIL, PL or Cat.) identified by the necessary risk
analysis. The intended use of the device has to be ensured.
The proper use of the device has to be verified with a function test on the system. This test
can detect programming, configuration and wiring errors. The test results have to be
documented and, if necessary, entered into the relevant documents that verify safety.

Safety
SIMATIC Panel PC 677B
6 Operating Instructions (Compact), 06/2008, A5E02217246-01

SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 7
Delivery 2
2.1 Unpacking and checking the delivery
1. Please check the packaging material for transport damage upon delivery.
2. If any transport damage is present at the time of delivery, lodge a complaint at the
shipping company in charge. Have the shipper confirm the transport damage
immediately.
3. Unpack the device.
CAUTION
Do not lie the device on its back. This will avoid any damage to an optical drive which
may be present. Lie the front side on a soft surface to avoid damaging the front panel
USB port.
4. Keep the packaging material in case you have to transport the unit again.
NOTICE
The packaging protects the device during transport and storage. Therefore, never
dispose of the original packaging material!
5. Please keep the enclosed documentation in a safe place. You will need the
documentation when you start up the device for the first time.
6. Check the contents of the package for completeness and transportation damage. Check
for completeness using the enclosed scope of delivery list.
7. Should the contents of the package be incomplete or damaged, please inform the
responsible supply service immediately and fax us the enclosed form "SIMATIC IPC/PG
quality control report".
WARNING
Make sure that a damaged device is not installed nor put into operation.
8. Note the identification information (see chapter "Identification data of the device").

Delivery
2.2 Device identification data
SIMATIC Panel PC 677B
8 Operating Instructions (Compact), 06/2008, A5E02217246-01
2.2 Device identification data
Enter the identification data of the device into the table.
SVP number (on the type plate)
Order No.
Package with Windows 2000 / XP Professional:
"Microsoft Windows Product Key" from "Certificate of
Authenticity" (COA)
The label is attached to the device.
Ethernet address:
BIOS Setup (F2 key) under
"Main > Hardware Options > Ethernet Address"
2.3 Product Documentation
The detailed operating instructions for Panel PC 677B can be downloaded as a PDF file on
the Internet under the following address:
http://www.siemens.com/automation/service&support, article ID 25737077

SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 9
Installation / panel-mounting 3
3.1 Mounting depth of the device
7
Panel PC with operator control units Depth D
Key panel with 12" TFT 105 mm
Key panel with 15" TFT 124 mm
Touch panel with 12" TFT 123 mm
Touch panel with 15" TFT 121 mm
Touch panel with 17" TFT 130 mm
Touch panel with 19" TFT 130 mm
Note
Additional mounting depth with optical drive
The installation depth increases by 21 mm when an optical drive is installed in the device.

Installation / panel-mounting
3.2 Permitted mounting positions
SIMATIC Panel PC 677B
10 Operating Instructions (Compact), 06/2008, A5E02217246-01
3.2 Permitted mounting positions
Approval
Only certain mounting positions are approved for the device.
$%
Figure 3-1 Mounting position
Table 3-1 Permissible deviations from the vertical mounting position
Temperature Angle A Angle B
to 45°C 20° 20°
Note
When mounting the device at an angle, note the following.
•Do not subject the device to mechanical stress.
•Operation of a DVD drive is not permitted.

Installation / panel-mounting
3.3 Preparing the mounting cut-out
SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 11
3.3 Preparing the mounting cut-out
The following illustration shows the dimensions for the mounting cut-out.
PP


/
/ /
/ 6 6 /
/ 6 6 /
/
/
/
/
$
6
/
/
66
/ $
 
 
Figure 3-2 Drill holes for the screws and pressure points for the clamp screws
(1) Drill hole for screw attachment (4) Clamp
(2) Pressure points for clamp (5) RZ 120 in the seal area
(3) Setscrews (6) Seal area
Note
Mounting dimensions can be read from the dimension overview or they can be transferred to
the cabinet from the mounting template supplied.

Installation / panel-mounting
3.3 Preparing the mounting cut-out
SIMATIC Panel PC 677B
12 Operating Instructions (Compact), 06/2008, A5E02217246-01
Table 3-2 Dimensions for the mounting cut-out in mm
Control
unit
L1 L2 L3 1) L4
1) L5 L6 2) L7 2) L8 2) L9 2) A1 A2 S1 S2
S3
S4
S53) S6
3)
S73)
Tolerance ±1 +1 ±0,2 ±0,2 ±0,5 ±0,5 ±0,5 ±0,5 +1 ±1 ±1 ±1 ±1 ±1 ±1
Key
panel
12" TFT
15" TFT
450
450
290
321
465
465
235
279
112
112
—
186
—
135
—
25
—
165
16
16
10
17
78
51
78
51
56
56
—
—
Touch
panel
12" TFT
15" TFT
17" TFT
19" TFT
368
450
450
450
290
290
380
380
—
465
465
465
—
235
235
235
112
112
112
112
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
16
16
16
16
10
10
10
10
19
81
46
46
35
81
46
46
56
56
—
—
—
—
33
33
1) M6 thread or drill holes with a diameter of 7 mm
2) Cut-outs for the shafts of the insert strips are only necessary for 15" key panels.
3) Two clamps necessary for vertically securing clamps for 17" and 19" touch panels only.
Preparing the mounting cut-out
Steps for preparing the mounting cut-out
1 Select a location suitable for mounting, taking into account the mounting position.
2 On the basis of the dimensions, check whether the required screw and pressure points on the
rear and the seal area are easily accessible after the completion of the mounting cut-out.
Otherwise the mounting cut-out is useless.
3 Complete the mounting cut-out in accordance with the dimensions.

Installation / panel-mounting
3.4 Securing the device with clamps
SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 13
3.4 Securing the device with clamps
Requirement
Accessories Display
12" 15" 17" 19"
6 x 6 x 8 x 8 x Clamp
The clamps are provided with the control unit.
Tool 2.5 mm hexagonal spanner
Procedure
Figure 3-3 Clamp assembly
1. Disconnect the device from the power supply.
2. Working from the front, insert the device into the 19" rack on the swivel arm or in the
mounting cut-out.
3. Fasten the control unit from the rear using the clamps.
4. Tighten the setscrews to a torque of 0.4 - 0.5 Nm.
IP65 degree of protection
The plant builder is responsible for the correct installation of the device.
The degree of protection IP65 is only guaranteed for the front of the device if the ring seal is
properly applied with the correct size of cutout, the unit has been clamped in place, and the
instructions below are observed.
NOTICE
Control cabinet installation: Material strength at the mounting cut-out
Ensure that the material strength at the mounting cut-out is a minimum of 2 mm and a
maximum of 6 mm. Please follow the specifications for the dimensions in the "Preparing the
mounting cut-out" section.
The degrees of protection are only guaranteed when the following is observed:
•The surface plane deviation of the mounting cut-out in relation to the external
dimensions of the control unit amounts to ≤ 0.5 mm when the control unit is mounted.

Installation / panel-mounting
3.5 Securing with screws
SIMATIC Panel PC 677B
14 Operating Instructions (Compact), 06/2008, A5E02217246-01
3.5 Securing with screws
Note
Securing with screws is not possible with the 12" touch panel variant. To secure the 17" and
19" touch panel with screws, backing plates with order number 6AV7672-8KE00-0AA0 are
required on the front.
Drill holes in the control unit
Steps for drilling holes
1 Drill holes (Ø approx. 2.5 mm) from the rear in the four recesses of the control unit
2 Drill these holes with a diameter of Ø 5.5 mm for M5 and a Ø 6.5 mm for M6.
3 Deburr the holes from the front of the control unit
NOTICE
Risk of damage
Ensure that no metal cuttings enter the device when the holes are drilled. Cover the device
with film or when drilling, use removal by suction.

Installation / panel-mounting
3.5 Securing with screws
SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 15
Drill holes in the mounting unit
1. Drill the holes at the prepared mounting cut-out according to the information for L3 and
L4. (see Chapter "Mounting cut-out" )
2. Working from the front, insert the device into the 19" rack on the swivel arm or in the
mounting cut-out of the control cabinet.
3. Secure the control unit by inserting suitable screws and nuts
IP54 degree of protection
The IP54 degree of protection is guaranteed for mounting together with the ring seal.
CAUTION
Observe the panel seal when mounting
Ensure you do not damage the panel seal when mounting the device.
NOTICE
Control cabinet installation: Material strength at the mounting cut-out
Ensure that the material strength at the mounting cut-out is a minimum of 2 mm and a
maximum of 6 mm. Please follow the specifications for the dimensions in the "Preparing the
mounting cut-out" section.
The degrees of protection are only guaranteed when the following is observed:
•The surface plane deviation of the mounting cut-out in relation to the external
dimensions of the control unit amounts to ≤ 0.5 mm when the control unit is mounted.

Installation / panel-mounting
3.5 Securing with screws
SIMATIC Panel PC 677B
16 Operating Instructions (Compact), 06/2008, A5E02217246-01

SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 17
Connecting 4

Connecting
4.1 Connection elements and operator controls
SIMATIC Panel PC 677B
18 Operating Instructions (Compact), 06/2008, A5E02217246-01
4.1 Connection elements and operator controls
Connection and Operator Control Components of the Computer Unit
Locations of connection and operator control components
Pos Name Description
(1) PCI (e) 2 slots for PCI expansion
module
(2) DVI/VGA DVI/VGA socket for
CRT or LCD monitor with DVI
interface or
VGA monitor via
DVI/VGA adapter
(3) Compact Flash Slot for Compact Flash card
(4) COM 1 Serial interface (RS232)
9-pin D-sub connector
(5) USB 4 USB 2.0 interfaces
(2 interfaces can be
simultaneously used as high
current (500 mA) outputs)
(6) Ethernet 2 RJ45 connections for
10/100 Mbps
(7) PROFIBUS DP/MPI MPI interface (RS485,
electrically isolated),
9-pin D-sub plug
(8) On / Off switch -









(9) 100 - 240 V AC
or 24 V DC
Connection for AC or DC power
supply (depending on the
product variant, the figure
shows the AC power plug)
The relevant angle is included
with the device for interlocking
the connector.

(10) PROFINET CP 1616 onboard interface,
three RJ45 sockets (optional
product version)

Connecting
4.1 Connection elements and operator controls
SIMATIC Panel PC 677B
Operating Instructions (Compact), 06/2008, A5E02217246-01 19
NOTICE
On / Off switch
The On / Off switch does not disconnect the device from the mains. When the switch is in
the 0 position, the device is still connected to the auxiliary voltage.
Connection components of the control unit
USB connection control unit
Pos Name Description

(1) USB 1 connection
USB 2.0 high current /
500 mA
under sealed cover
(not available with every
product variant).
NOTICE
Ensuring degree of protection P65
When the sealed cover over the USB interface is removed in order to connect a USB
component, the IP65 degree of protection for the device is no longer guaranteed.
Note
Use of USB devices
•Wait at least ten seconds between removal and reconnection of USB devices. This also
applies to control units with touch screen panels, especially for touch operation.
•When using standard USB peripherals, bear in mind that their EMC immunity level is
frequently designed for office applications only. These devices may be used for
commissioning and servicing. However, only industry-standard devices are allowed for
industrial operation.
•Peripherals are developed and marketed by individual vendors. The respective
manufacturers offer support for the peripherals. Moreover, the terms of liability of the
individual vendors or suppliers apply here.

Connecting
4.2 Connecting the 120 V / 240 V AC power supply
SIMATIC Panel PC 677B
20 Operating Instructions (Compact), 06/2008, A5E02217246-01
4.2 Connecting the 120 V / 240 V AC power supply
Note before connecting the device
Note
The varying voltage power supply module is designed for operation on 120 / 240 V AC
networks. The setting of the voltage range takes place automatically.
WARNING
Do not connect or disconnect power and data cables during thunderstorms.
WARNING
The device is designed for operation on grounded power supply networks (TN networks to
VDE 0100, Part 300, or IEC 60364-3).
Operation on ungrounded or impedance-grounded power networks (IT networks) is
prohibited.
WARNING
The permitted nominal voltage of the device must conform with local mains voltage.
CAUTION
The mains connector must be disconnected to fully isolate the device from the mains.
Ensure easy access to this area.
A master mains disconnect switch must be installed if the device is mounted in a switch
cabinet.
Always ensure free and easy access to the power inlet on the device or that the safety
power outlet of the building installation is freely accessible and located close to the device.
Note
The power supply contains an active PFC (Power Factor Correction) circuit to conform to the
EMC guidelines.
Uninterruptible AC power systems (UPS) must supply a sinusoidal output voltage in the
normal and buffered mode when used with SIMATIC PCs with an active PFC.
UPS characteristics are described and classified in the standards EN 50091-3 and IEC
62040-3. Devices with sinusoidal output voltage in the normal and buffered mode are
identified with the classification "VFI-SS-...." or "VI-SS-....".
