Siemens 7KG6106 User manual

1
Operating Instructions
Operating Instructions
Transducer with auxiliary power
for alternating voltage or alternating current (RMS)
with expanded start range
with expanded end range
with non-linear characteristic curve
7KG6106 and 7KG6113
Compact device for DIN rail mounting
Operating Instructions
A5E38679986B / RS-AB
Operating
Instructions
SIMEAS-T
s

SIMEAS-T - Transducer with auxiliary power
2
Safety instructions
These operating instructions contain the information required for the proper usage of
the products described therein. They are addressed to technically qualified personnel,
who are specially trained or have otherwise obtained the relevant know-how in
instrumentation and control engineering (in the following referred to as automation
engineering). The knowledge and technically correct implementation of the safety
instructions and warnings contained in this manual are required for safe installation
and commissioning, as well as for safety during operation and maintenance of the
described product. Only qualified personnel as stipulated overleaf have the
specialized knowledge to interpret the general safety warnings and instructions of
this documentation in every specific case and to implement them in practice.
These operating instructions are an integral part of the scope of delivery. For reasons
of clarity, they do not include all details about all model of the product described, and
also cannot take into account every conceivable type of installation, operation and
maintenance. If you would like further information or if particular problems arise
which are not covered in sufficient detail in the documentation, please request the
necessary information from your local Siemens office or contact the addresses on the
back cover of the operating instructions directly.
Furthermore, it should be noted that this product documentation is neither part of a
previous or existing agreement, commitment, or legal relationship nor does it modify
such a relationship in any way. All Siemens obligations derive from the respective
sales contract, which also contains the complete and exclusive warranty agreement.
This warranty agreement is neither extended nor restricted by any statements in this
manual.
WARNING!
When electrical devices are operated, certain parts necessarily conduct dangerous
voltages. If the safety warnings are not heeded, severe injury or damage can occur.
Only appropriately qualified persons are permitted to work on this equipment.
Appropriate transport, storage, mounting, and installation, as well as careful
operation and service, are essential for the error-free, safe and reliable operation of
this equipment.
This must be observed during installation (section 10 Mounting and operation)
and use of the devices.

SIMEAS-T - Transducer with auxiliary power
3
QUALIFIED PERSONNEL
Unqualified intervention in the device/system or failure to heed the safety warnings
in this manual can lead to serious injury or material damage. Therefore, only suitably
qualified personnel are permitted to service this device/system. Qualified personnel
in the sense of the safety-related notices in these operating instructions or on the
product itself are persons who
•are either familiar with the safety concepts of automation engineering as
configuration personnel
•or have been trained to handle automation engineering equipment as
operating personnel and are familiar with the content of these operating
instructions
•or are trained to repair such automation equipment as commissioning and
service personnel
or are authorized to commission, ground and label electric circuits and
devices/systems according to the standards of safety engineering.
NOTICE!
Always use the correct version of the transducer for your application. Ensure that the
operating data of your system corresponds to the values on the rating plate.
WARNING!
If you do not use the device in the manner described herein, the device protection
may be impaired.

SIMEAS-T - Transducer with auxiliary power
4

SIMEAS-T - Transducer with auxiliary power
5
Safety instructions ......................................................................................................................... 2
Operating Instructions ..................................................................................................................... 7
1 Area of application .................................................................................................................... 7
2 Characteristic curves.................................................................................................................. 7
3 Performance characteristics ....................................................................................................... 8
4 Operating principle.................................................................................................................... 9
5 Overview circuit diagram ........................................................................................................... 9
6 Technical specifications ........................................................................................................... 10
7 Rating plate symbols................................................................................................................ 12
8 Description.............................................................................................................................. 13
9 Ordering data .......................................................................................................................... 14
10 Mounting and operation......................................................................................................... 16
10.1 Installation ....................................................................................................................... 17
10.2 Connection....................................................................................................................... 17
10.3 Installation material.......................................................................................................... 18
11 Commissioning ...................................................................................................................... 18
12 Maintenance .......................................................................................................................... 18
13 Calibrating and testing ........................................................................................................... 19
Siemens Aktiengesellschaft © SIEMENS AG 2006, 2011, 2014, 2015. 2016 All Rights Reserved
Subject to change without prior notice A5E38679986B / RS-AB

SIMEAS-T - Transducer with auxiliary power
6

SIMEAS-T - Transducer with auxiliary power
7
Operating Instructions
1 Area of application
Transducers are used to convert different measured signals from high-voltage and
low-voltage systems into proportional output variables. Areas of application are, for
example
Power supply and distribution for areas in which measured signals must be sent over
a large
distance. The active SIMEAS transducers convert the alternating input voltage or the
alternating input current from the high-current power network (45 to 65Hz) into a
load-independent direct output current or a load-independent direct output voltage.
Up to the maximum permissible load, multiple devices – such as recorders, displays,
remote control systems, computers and controllers – can be connected and operated
directly or via long-distance lines at the output. Input and output with auxiliary power
supply are electrically isolated from each other.
The SIMEAS transducers must be installed in a closed system, such as a control
cabinet.
2 Characteristic curves
Alternating current and voltage

SIMEAS-T - Transducer with auxiliary power
8
3 Performance characteristics
• High measuring precision
• Powerful output signal circuits
• High system safety and reliability
• CE mark
• High immunity to EMC interference
• Compliance with relevant national and international standards
• Electrical isolation at a high test voltage
• High quality, long service life
• Low price
• Short delivery times, standard types from stock
• Extremely small dimensions

SIMEAS-T - Transducer with auxiliary power
9
4 Operating principle
The transformer (1) transfers the input signal IE or UE to the effective value
Direct voltage converter (2) which drives the output amplifier (4) via the expansion
circuit (3). Fed by the auxiliary source (6), the output amplifier provides load-
independent current IA or load-independent voltage UAproportional to the input
value IE or UA . The protective circuit (5) protects the output against no-load and
transient overvoltage.
5 Overview circuit diagram
1
Transformer
2
RMS direct voltage converter
3
Expansion circuit
4
Output amplifier
5
Protective circuit
6
Auxiliary power

SIMEAS-T - Transducer with auxiliary power
10
6 Technical specifications
General input transducer
Only for connecting to alternating voltage systems!
Maximum voltage to earth
500 V ~
Power consumption of the measuring circuit
approx. 0.06 VA
Permissible modulation range
1.2 I
EN
or 1.2 U
EN
Rated frequency fEN
50 Hz, 60 Hz
Frequency range fE
45 Hz to 65 Hz
Curve form
Sine, square, triangle, phase control
Crest factor
i/Ieff ≤ 2, but I ≤ 2.1 IEN
T/U
EN
I ≤ 2, but ≤ 2.1 I
EN
Input transducer
Alternating current
Standard rated currents IEN
See ordering table
Measuring range in rated value IEN 0 to IEN
Continuous overload capacity
2 IEN
Surge overload capacity
for IEN = 1 A; 1.2 A; 1.5 A; 2 A; 2.4 A; 2.5 A
for IEN = 5 A; 6 A; 7.5 A; 10 A
100 A for 1s
200 A for 1s
Input transducer
Alternating voltage
Standard voltage U
EN
See ordering table
Special rated voltage UEN
in the range from 40 to 500 V
Measuring range rated value U
EN
0 to U
EN
0 to 0.9 to 1.1 UEN
0 to 0.85 to 1.15 UEN
0 to 0.8 to 1.2 UEN
Continuous overload capacity
1.5x UEN but max. 600 V
Surge overload capacity
≤ 2x UEN (5 surges 1s, in intervals of 5s)
Output
Output signal bipolar, short-circuit proof and resistant to no-load operation, optionally load-
independent direct current or load-independent direct voltage
Standard rated current I
AN
2.5 mA; 5 mA; 10 mA; 20 mA
Special rated current IAN
in the range from 1 to 20 mA
Rated modulation range
0 to IAN or 4-20 mA
Permissible modulation range
0 to 1.2 IAN
max. possible modulation at RB 15 V/IAN and UH =
80% UHN
0 to 1.05 IAN
Zero offset
In the range from 0 to IAN
No-load voltage U
AL
≤ 30 V
Rated load RBIN
7.5 V/IAN
Operating load RB0 to 15 V/IAN
Standard rated voltage UAN
1 V, 10 V
Rated modulation range
0 to U
AN
Permissible modulation range
0 to 1.2 UAN
Zero offset
In the range from 0 to U
AN
Short-circuit current
≤ 20 mA
Rated load RBUN
UAN/1 mA
Load current IB
≤ 2 mA
Residual ripple I
SS
/U
SS
≤ 0.5% SS of I
AN
or U
AN
Setting time tgg
≤ 350 ms

SIMEAS-T - Transducer with auxiliary power
11
Auxiliary power U
H
Rated input voltage UHN
– Direct voltage
– Alternating voltage
24-60 V; 110-220 V 
100; 115; 230 V ~; 50/60 Hz
Input range
– Direct voltage
– Alternating voltage
± 20%
± 20%
Power consumption
– Direct voltage
– Alternating voltage
with U
H
= U
HN
; typical value
3 W
3 VA
Errors and influencing effects
The relative error information with signs "+" and "-"
Errors in reference conditions
0.3% relative to A
N
Reference conditions
– Input current IE
– Input voltage UE
– Frequency fE
– Curve form
– Auxiliary alternating voltage UH
– Auxiliary direct voltage UA
– Load RB
– Ambient temperature TU
– Warm-up period
– Interfering fields
0 to IEN
0 to UEN
fEN ± 0.5%
Sine, THD ≤ 5%
UHN ± 1%, THD ≤ 5%
UHN ± 1%, alternating component ± 2%
RBIN ± 1%, RBUN ± 1%
23 °C ± 1 °C
≥ 15 min.
None
Influencing effects
– of the ambient temperature
– of the frequency (45 to 65 Hz)
– of the curve form
– of the load with current output for RB = 15 V/IAN
– of the load with voltage output for RB = ∞ to
UAN / 1mA
– of the auxiliary power UH = 0.8 to 1.2
– of self-heating
During interference according to
IEC 801-3 and IEC 801-6, an additional error of
max. 2.5% may occur at certain frequencies.
≤ 0.2% / 10K
≤ 0.04% / Hz
≤ 0.02% per 10% THD (crest factor ≤ 2)
≤ 0.1%
≤ 10 m V
≤ 0.1%
≤ 0.3%
Other technical specifications
Surge voltage UDE 0435, Part 303 with type test
– input relative to output
– input relative to auxiliary power
– output relative to auxiliary power
– on input, output and auxiliary power as normal
mode voltage.
T = 5 kV, 1.2/50 µsec Ri = 500 Ω
T = 5 kV, 1.2/50 µsec Ri = 500 Ω
T = 5 kV, 1.2/50 µsec Ri = 500 Ω
T = 5 kV, 1.2/50 µsec Ri = 500 Ω
In each case, 3 surges in both directions of
polarity
Permissible ambient temperature according to
IEC 68-2 / 1-3
– operating temperature range
– functional temperature range
– storage temperature range
- 10 °C to + 60 °C
- 15 °C to + 70 °C
- 40 °C to + 85 °C
Max. permissible humidity
90% rel. humidity, non-condensing
Mechanical strength in accordance with DIN EN 61010 Part 1,
Interference immunity class IK06 (1 J)
Max. operating altitude
2000 m above sea level

SIMEAS-T - Transducer with auxiliary power
12
Safety
in accordance with DIN EN 61010 Part 1
Overvoltage category
III
Degree of pollution
2
Fire resistance class
V-0
electrically isolated
Dielectric strength (test voltage)
with type test
– input relative to output
– input relative to auxiliary power
– output relative to auxiliary power
Ueff = 5.5 kV, 50 Hz, sine
Ueff = 5.5 kV, 50 Hz, sine
Ueff = 3.7 kV, 50 Hz, sine
Electromagnetic compatibility
Emitted interference according to EN 50081-1
– Radio interference field strength according to
EN 55022
– RFI voltage according to EN 55022
Cl. B
Cl. B
Interference immunity according to EN 50082-2
– Immunity against electromagnetic fields
according to EN61000-4-3 (IEC 801-3)
– Discharge of static electricity ESD according to
EN61000-4-2 (IEC 801-2)
– Fast transients, asymmetric burst according to
EN61000-4-4 (IEC 801-4)
Inputs and outputs
Power supply
– Surge according to IEC 801-5
– RFI current according to IEC 801-6
10 V/m
8 kV
2 kV
4 kV
10 V rms
7 Rating plate symbols
C
EU conformity marking
TR Customs Union Certification of EAC
Notice – Observe warning information
Input
Output
~
Alternating voltage or current

Direct voltage or current

SIMEAS-T - Transducer with auxiliary power
13
8 Description
The transducers in the enclosure are permanently wired and tested functional units.
They have a snap-on mounting for a 35 mm standard mounting rail according to
DIN EN 50022. Inputs and outputs can be safely connected to the screw terminals.
The devices are silicone-free, halogen-free and flame-resistant. Balancing
potentiometers are accessible after the modules have been removed from the
enclosure.
Weight:
approx. 0.33 kg
Degree of protection:
Enclosure:
Terminals:
DIN VDE 0470 T.1 / EN 60529
IP40
IP20
Connection:
Screw terminals
Input:
Output:
Auxiliary power supply:
4 mm²
2.5 mm²
2.5 mm²

SIMEAS-T - Transducer with auxiliary power
14
9 Ordering data
Ordering data for alternating voltage (G) MUU
Name
Order no.
Code
Device 7KG
6
1
0
6
-
-
B
↑
↑
↑
↑
Input signal EN
│
│
│
│
Rated frequency fEN
50 Hz
2
│
│
│
60 Hz
3
│
│
│
│
│
│
Rated input voltage
U
EN
│
│
│
40 V
K
│
│
100 / √3 V
A
│
│
60 V
L
│
│
110 / √3 V
B
│
│
120 / √3 V
C
│
│
132 / √3 V
D
│
│
100 V
E
│
│
110 V
F
│
│
120 V
J
│
│
132 V
N
│
│
150 V
P
│
│
220 V
G
│
│
230 V
W
│
│
240 V
V
│
│
250 V
Q
│
│
300 V
U
│
│
380 V
H
│
│
400 V
R
│
│
500 V
S
│
│
│
│
Output signal range
I
AN
/ U
AN
│
│
0 to 2.5 mA DC
G
│
0 to 5 mA DC
H
│
0 to 10 mA DC
J
│
0 to 20 mA DC
K
│
(Live Zero)
4 to 20 mA DC
N
2
0 to 1 V DC
L
│
0 to 10 V DC
M
│
│
Zero point position
│
Measuring range zero = zero signal
1

SIMEAS-T - Transducer with auxiliary power
15
Continued: Ordering data for alternating voltage (G) MUU
Name
Order no.
Code
Device 7KG
6
1
0
6
-
-
B
↑
↑
│
│
Auxiliary power
│
│
24 to 60 V DC
1
│
110 to 220 V DC
4
│
100 V AC, 50/60 Hz
5
│
115 V AC, 50/60 Hz
6
│
230 V AC, 50/60 Hz
7
│
│
Measuring range
│
Measuring range linear
0 to U
EN
0
expanded start range
0 to 0.05 to U
EN
≙0 to 0.8 to I
AN
/ U
AN
1
0 to 0.1 to U
EN
≙0 to 0.8 to I
AN
/ U
AN
2
expanded end range
0 to 0.9 to 1.1 U
EN
≙0 to 0.2 to I
AN
/ U
AN
3
0 to 0.85 to 1.15 U
EN
≙0 to 0.2 to I
AN
/ U
AN
4
0 to 0.8 to 1.2 U
EN
≙0 to 0.2 to I
AN
/ U
AN
5
Suppressed start range
0 to 0.9 to 1.1 U
EN
≙0 to 0 to I
AN
/ U
AN
6
0 to 0.85 to 1.15 U
EN
≙0 to 0 to I
AN
/ U
AN
7
0 to 0.8 to 1.2 UEN
≙
0 to 0 to IAN / UAN
8
Notice
Not all possible combinations are available

SIMEAS-T - Transducer with auxiliary power
16
Ordering data for alternating current (G) MUI
Name
Order no.
Code
Device 7KG
6
1
1
3
-
-
0
B
↑
↑
↑
↑
↑
↑
Input signal E
N
│
│
│
│
│
│
Rated frequency f
EN
50 Hz
2
│
│
│
│
│
60 Hz
3
│
│
│
│
│
HiY
│
│
│
│
│
Rated input current
IEN
│
│
│
│
│
1.0 A
A
│
│
│
│
1.2 A
B
│
│
│
│
1.5 A
K
│
│
│
│
2.0 A
C
│
│
│
│
2.4 A
D
│
│
│
│
2.5 A
L
│
│
│
│
5.0 A
E
│
│
│
│
6.0 A
F
│
│
│
│
7.5 A
G
│
│
│
│
10 A
J
│
│
│
│
│
│
│
│
Output signal range
I
AN
/ U
AN
│
│
│
│
0 to 2.5 mA DC
G
│
│
│
0 to 5 mA DC
H
│
│
│
0 to 10 mA DC
J
│
│
│
0 to 20 mA DC
K
│
│
│
(Live Zero)
4 to 20 mA DC
N
2
│
│
0 to 1 V DC
L
│
│
│
0 to 10 V DC
M
│
│
│
│
│
│
Zero point position
│
│
│
Measuring range zero = zero signal
1
│
│
│
│
Auxiliary power
│
│
19.2 to 72 V DC
1
│
88 to 264 V DC
4
│
100 V AC, 50/60 Hz
5
│
115 V AC, 50/60 Hz
6
│
230 V AC, 50/60 Hz
7
│
│
Measuring range
│
Measuring range linear
0 to U
EN
0
Notice
Not all possible combinations are available

SIMEAS-T - Transducer with auxiliary power
17
10 Mounting and operation
WARNING!
When electrical devices are operated, certain parts necessarily conduct dangerous
voltages. Failure to heed the operating notices can therefore lead to serious injury or
property damage.
The device should only be mounted and electrically connected by appropriately
qualified personnel. In particular, all warning notices must be observed.
10.1 Installation
•Before installing the device, check for external damage. In case of damage, the
device may not be installed, connected and operated.
•The installation location must be as free of vibrations as possible. The
permissible ambient temperature (operating or functional temperature) must
be observed (see technical specifications).
•Operation outside the functional temperature range can lead to erroneous
measurements and failure of the transducer.
•Plastic enclosure, overvoltage category III in accordance with DIN EN 61010
Part 1.
•Screw terminals for maximum 2.5 mm2or 4 mm2.
•The transducer must be mounted on a 35 mm DIN rail (in accordance with
DIN EN 50022). The DIN rail must be mounted horizontally.
10.2 Connection
The regulations for the construction of high voltage installations must be observed
when carrying out the electrical installation.
•If multiple receivers are used, for example recorders, displays, remote terminal
units, computers or controllers, these devices must be connected in series with
the current output of the transducer (ensure correct polarity). For transducers
with voltage output, the receivers are connected in parallel to this.
•A switch or circuit breaker must be installed in the building installation, this
must be suitably arranged and easily accessible for the user and labeled as the
disconnecting mechanism for the device. This disconnecting mechanism has
to meet the requirements of IEC 60947-1 and IEC 60947-3.
•The total load, including the cables, must not exceed the value stated in the
technical specifications.
•The pin assignment is shown in the section 8 Description.
•The performed installation must be tested according to EN 61439.

SIMEAS-T - Transducer with auxiliary power
18
Notes for the fuses to be used:
For devices that are supplied with AC auxiliary energy, a 100 mA time-lag fuse
according to IEC 60127-2 must be connected upstream in the control cabinet
installation.
Appropriate protection must be provided for the measuring circuits during the
installation:
•Current measuring circuits: the fuse must prevent the values presented in the
table 6 Technical specifications from being exceeded.
•Voltage measuring circuits: the fuse must limit the current to 100 mA,
be suitably arranged and be easily accessible to the user.
10.3 Installation material
Measuring circuits: The connection of the measuring circuit must be made with
cables that have demonstrated double isolation for the highest voltage occurring in
the measuring circuit.
Secondary circuits: For devices in which the highest voltage of the measuring circuit
is 500 V, cables with basic isolation in relation to the maximum voltage in each
secondary circuit suffice.
For devices with voltages that exceed 500 V in the measuring circuit, the isolation of
the cable in the secondary circuits must correspond to a basic isolation for the
highest voltage occurring in the measuring circuit.
11 Commissioning
First ensure that the operating data matches the values on the rating plate. No
changes may be made on the transducer. After a warm-up time of 15 minutes, the
transducer is ready for operation and keeps within the error limits.
•Measurement option for the output current and load voltage. Before
connecting an ammeter to the output side of the transducer, the auxiliary
power should be switched off because the voltage at terminals 31 and 32 rises
to a maximum of 30 V DC during the interruption of the output current IA .
•Measurement of the output current (output signal IA): Disconnect the line
from terminal 31(+) or 32(-), and connect the ammeter in series there.
Measurement of the load voltage (output signal IA), or the output signal UA:
Connect voltmeter to terminals 31(+) and 32(-).
12 Maintenance
The output signal can be tested in a laboratory six months after commissioning and
subsequently every two years (section "Calibrating and testing"). The device has to be
opened for this. Apart from that, the transducer requires no maintenance.
WARNING!
The device contains no fuses to be changed by the user.

SIMEAS-T - Transducer with auxiliary power
19
13 Calibrating and testing
WARNING!
The work must be done in accordance with the specifications and performance instructions
of accident prevention regulation VBG 4.0. in particular 8. "Permissible discrepancies while
working on active parts". A suitable electrical tool must be used.
The transducer has to be opened and the modules removed for calibration. After
disconnecting the external electrical power cables, the enclosure cover is removed
and the modules pulled out. The circuit from the following modules:
•Measuring module G34932-F1800-H2
•Connection module G34932-F1801-H2
•Power supply module G34932-F1802-H2
The trim potentiometers are located on the measuring module.
Greater care is required when working on open modules because there may be
dangerous voltages on the rear of the measuring and power supply modules.
The rear sides of the modules should therefore be covered by suitable means.

SIMEAS-T - Transducer with auxiliary power
20
Test circuit for voltage and current transducers
(example for current output).
1
Alternating voltage encoder (THD ≤ 1%) 0 to 600 V or
Alternating current encoder (THD ≤ 1%) range 0 to 10 A
2
Voltmeter, class 0.01 (for voltage input)
3
Ammeter, class 0.01, Ri ≤ 0.1 Ω(for current input)
4
Test specimen, voltage or current transducer
5
Decade resistor 0 to 20 kΩ
6
Ammeter, class 0.01, Ri ≤ 10 Ω
7
Alternating and direct voltage encoder
8
Voltmeter
