Siemens REV23.03RF User manual

Symbole 24-hour mode 2 heating
periods
“Time” menu Heating active Comfort
setpoint 3 heating periods
T “Temperature”
menu Cooling active Economy setpoint
Current weekday
“Heating
periods” menu Automatic operation Setpoint frost protection
Weekday group
“Absence”
menu Continuously comfort mode Absence setpoint
Weekend group
Commissioning and quick start Battery
change Continuously
economy
mode
Not used with
this unit
Entire week
Absence Frost
protection 1 heating period
Time schedule
Functions of the roller selector
1. Receiver (REV-R.03/1)
Switch on power and press “RESET” button for
about 4 seconds: Orange LED_2 flashes briefly.
Then, press “SET” button for about 4 seconds:
Orange LED_2 flashes slowly; learning mode is
active.
Within 25 minutes press “ESC” button on
REV23.03RF for about 4 seconds: Orange LED_2
flashes fast and briefly; LED_1 changes from red to
flashing green.
After commissioning, the unit will operate
automatically. CLICK
Press:
•You access the menu
level
•You activate the menu
•You save the inputs
•You switch to the next
menu item
•You accept the menu
item
+
Roll:
•You go from one menu to the
next
•You change the setting
variables (temperature in
increments of 0.2 °C, time in
increments of hours and
minutes)
•You select predefined functions
2. Transmitter (REV23.03RF) Escape button
1. 2.
Press the Esc button to return to the menu level previously activated or to leave
the menu level in a number of steps until you reach the initial display
(the settings currently displayed will be accepted).
(Press button approximately for 4 seconds to transmit learning telegram.)
Setting the time of day and the weekday
•Adjustable in operating modes , , and
1. Remove controller from its base and open cover
of the battery compartment.
2. Remove the black battery transit tab. The
controller will switch itself on.
3. Close the battery compartment and replace the
controller.
Selecting the operating mode
The operating mode selector enables you
to select 5 different operating modes:
•Automatic operation with a maximum of 3
heating / cooling periods
•Continuously comfort mode
•Continuously economy mode
•Continuously frost protection mode
•24-hour mode with 1 comfort period
CLICK Ö
hÖhÖ
ÖÖ
If no button is pressed for a short time, the setting
displayed will be accepted and the initial display will
appear again.
1. Press: You access the menu level;
the clock flashes.
2. Press: You accept the menu;
the hours flash.
3. Roll: Set the current hour.
4. Press: You save the input;
the minutes flash.
5. Roll: Set the current minute.
6. Press: You save the input;
the weekday flashes.
7. Roll: Select the current weekday.
8. Press the Esc button to return to the menu level:
the Tmenu flashes.
(Change not necessarily required; press
the Esc button again to return to the
initial display.)
Changing temporarily the current
setpoint temperature Changing temperatures long-term
•Adjustable in operating modes , , and
° C
The change is
maintained until
the next switching
point is reached!
1. When pressing the or button for the
first time, the currently valid setpoint temperature
will be displayed. It can be readjusted in
increments of 0.2 °C (max. +/-4 °C).
2. After a short time, the initial display will
automatically appear again.
Changing temporarily the
temperature setpoint (savings tip)
CLICK ÖÖ
Ö° C Ö
Ö° C ÖÖ
° C ÖÖ
If no button is pressed for a short time, the setting
displayed will be accepted and the initial display will
appear again.
1. Press: You access the menu level;
the clock flashes.
2. Roll: Toward the display to the T menu.
3. Press: You accept the menu;
symbol
flashes.
4. Press: You accept ;
the setpoint flashes.
5. Roll: Set the comfort temperature
6. Press: You save the input;
symbol flashes.
7. Press: You accept ; the setpoint flashes.
8. Roll: Set the economy temperature.
9. Press: You save the input;
symbol
flashes.
10. Press: You accept ; the setpoint flashes.
11. Roll: Set the frost protection temperature.
12. Press: You save the input, symbol
flashes.
Adjustment not required; not used
with this unit.
13. Press the Esc button to return to the menu level:
The heating periods
menu flashes.
(Change not necessarily required; press
the Esc button again to return to the
initial dis
p
la
y
.
)
In operating modes and , this
button can be pressed to make a manual
change from comfort to economy mode,
or vice versa. The change will
automatically be cancelled when
reaching the next switching point or when
selecting another operating mode.
(Press button approximately for
4 seconds to transmit test telegrams.)
Siemens SBT / HVAC Products CE1B2265en 28.10.2005
en
Operating Instructions
REV23.03RF

Settings for automatic operation with 2 heating periods 24-hour operation
•Adjustable in operating modes , , and •Adjustable in operating mode
24-hour mode with one comfort period only.
Start of comfort period, end of comfort period and
temperature setpoint can be set individually by roller
selector.
Retrieving the default values
Press the button behind the small opening for at
least one second, thus resetting the user-specific
settings to their default values (the heating engineer
settings will remain unchanged).
The clock starts at 12:00.
When making a reset, all display fields will light up.
Default values
Factory settings for heating
Operating mode
Start of continuous operation 00:00 00:00 00:00
End of continuous operations 24:00 24:00 24:00
Setpoint of comfort mode 19 °C
Setpoint of economy mode 16 °C
Setpoint frost protection 5 °C
Setpoint
absence 12 °C
Operating mode
Selected periods
Start of period 1 07:00 06:00 06:00
End of period 1 23:00 08:00 08:00
Start of period 2 17:00 11:00
End of period 2 22:00 13:00
Start of period 3 17:00
CLICK Ö
ÖÖ
ÖÖ
hÖ
hÖ
° C Ö
Ö
hÖ
hÖ
° C Ö
ÖÖ
/Ö
If no button is pressed for a short time, the setting
displayed will be accepted and the initial display
restored.
1. Press: You access the menu level;
the clock flashes.
2. Roll: Twice toward the display;
menu
flashes.
3. Press: You accept the menu;
the day selection symbol
flashes.
4. Roll: Select the days, the working days, the
weekend or the week.
5. Press: You accept the selection made;
heating period flashes.
6. Press: Accept ; heating period 1 flashes.
7. Press: You accept heating period 1;
start time of heating period 1 flashes.
8. Roll: Set the start time of heating period 1.
9. Press: You save the input;
end time of heating period 1 flashes.
10. Roll: Set the end time of heating period 1.
11. Press: You save the input;
setpoint of heating period 1 flashes.
12. Roll: Set the setpoint of heating period 1.
13. Press: You save the input;
heating period 2 flashes.
14. Press: You accept heating period 2;
start time of heating period 2 flashes.
15. Roll: Set the start time of heating period 2.
16. Press: You save the input;
end time of heating period 2 flashes.
17. Roll: Set the end time of heating period 2.
18. Press: You save the input;
setpoint of heating period 2 flashes.
19. Roll: Set the setpoint of heating period 2.
20. Press the Esc button to return to the heating
periods menu:
Menu item heating periods
flashes.
21. Roll: Toward the display or away from it to
menu item or heating periods
(Change not necessarily required; press
the Esc button several times to leave
the menu level in several steps, thus
returning to the initial display.)
End of period 3 22:00
Setpoint of period 1 19 °C 19 °C 19 °C
Settings for automatic operation with 1 or 3 heating periods Setpoint of period 2 20 °C 20 °C
Setpoint of period 3 21 °C
•Adjustable in operating modes , , and
The procedure to be followed is the same as that for automatic operation with 2 heating periods the only
difference bein
g
that, in addition, a set
p
oint for heatin
g
p
eriod 3 can be entered
(
standard settin
g
21 °C
)
.Setpoint
absence 12 °C
Absence / holida
y
s
•Adjustable in operating modes , , and Default values
Factory settings for cooling
Operating mode
Setpoint 23 °C 23 °C 29 °C 35 °C
Setpoint
absence 30 °C
Changing the batteries
2 Alkaline batteries type AA 1.5 V
CLICK Ö
ÖÖ
Ö° C
ÖÖ
If no button is pressed for a short time, the setting
displayed will be accepted and the initial display will
appear again.
1. Press: You access the menu level;
the clock flashes.
2. Roll: Away from the display,
menu flashes.
3. Press: Accept ;
symbol flashes.
4. Roll: Set the start (weekday) of your absence.
5. Press: You save the input;
the number of days flash.
6. Roll: Set the duration of your absence;
number of days (max. 99)
7. Press: You save the input;
setpoint flashes.
8. Roll: Set the temperature.
9. Press the Esc button to return to the menu level;
the clock flashes.
(Change not necessarily required; press
the Esc button again to return to the
initial display.)
Remote operation ( for reason of mobility, there is no connection facility)
•Adjustable in operating modes , , and
Setpoint can be adjusted, but is not used with this unit.
When this symbol appears, the batteries must be
replaced within 3 months.
1. Remove controller from its base.
2. Open battery compartment at the rear and
replace the batteries.
3. Close battery compartment and replace the
controller.
Caution:
When changing the batteries, the current data are
maintained for a maximum of one minute.
Siemens SBT / HVAC Products CE1B2265en 28.10.2005
