Siemens SITRANS TF280 WirelessHART User manual

SITRANS TF280 WirelessHART
_
_________________
_
_
_________________
_
_
____________
_
_____
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
SITRANS
Temperature transmitter
SITRANS TF280 WirelessHART
Operating Instructions
7MP1110-0AC
7MP1110-0AD
10/2010
A5E02619566-02
Introduction 1
General safety instructions
2
Description
3
Commissioning (hardware)
4
Operation
5
Installing/mounting
6
Connecting
7
Alarm, error, and system
messages
8
Troubleshooting/FAQs
9
Appendix
A

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
order number: A5E02619566
Ⓟ 10/2010
Copyright © Siemens AG 2010.
Technical data subject to change

SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 3
Table of contents
1 Introduction................................................................................................................................................ 7
1.1 Purpose of this documentation ......................................................................................................7
1.2 History............................................................................................................................................7
1.3 Notes on warranty..........................................................................................................................7
1.4 Environmental protection ...............................................................................................................8
2 General safety instructions ........................................................................................................................ 9
2.1 General information .......................................................................................................................9
2.2 Correct usage.................................................................................................................................9
2.3 Qualified Personnel........................................................................................................................9
2.4 Transport/Storage ..........................................................................................................................9
3 Description............................................................................................................................................... 11
3.1 Applications..................................................................................................................................11
3.2 Product features...........................................................................................................................12
3.3 Design of SITRANS TF280 WirelessHART .................................................................................13
3.4 Mode of operation ........................................................................................................................15
3.5 Sensor..........................................................................................................................................15
3.6 Battery..........................................................................................................................................16
3.7 WirelessHART..............................................................................................................................17
3.7.1 Overview ......................................................................................................................................17
3.7.2 WirelessHART..............................................................................................................................17
3.8 HART maintenance port ..............................................................................................................19
4 Commissioning (hardware)...................................................................................................................... 21
4.1 Commissioning overview .............................................................................................................21
4.2 Identify device ..............................................................................................................................22
4.3 Assignment/determination of network access parameters ..........................................................24
4.4 Temperature sensor: connection of pins .....................................................................................25
4.4.1 Overview ......................................................................................................................................25
4.4.2 Connection of temperature sensor ..............................................................................................26
4.5 Inserting / removing the battery ...................................................................................................28
4.6 Quick Start ...................................................................................................................................31

Table of contents
SITRANS TF280 WirelessHART
4 Operating Instructions, 10/2010, A5E02619566-02
5 Operation................................................................................................................................................. 33
5.1 Overview ..................................................................................................................................... 33
5.2 Keypad ........................................................................................................................................ 34
5.3 Digital display .............................................................................................................................. 35
5.4 Menu structure ............................................................................................................................ 36
5.5 Use of local user interface........................................................................................................... 38
5.5.1 Input of alphanumeric string (input example).............................................................................. 38
5.5.2 Input of numeric string (input example)....................................................................................... 39
5.5.3 Increase/decrease parameter value (input example) ................................................................. 40
5.5.4 Set list values .............................................................................................................................. 41
5.5.4.1 Single selection ........................................................................................................................... 41
5.5.4.2 Multiple selection......................................................................................................................... 42
5.5.5 Use of key combinations............................................................................................................. 43
5.6 Parameter descriptions ............................................................................................................... 44
5.6.1 "1 Quick start".............................................................................................................................. 44
5.6.1.1 "1.1 Network ID".......................................................................................................................... 44
5.6.1.2 "1.2 Network key"........................................................................................................................ 44
5.6.1.3 "1.3 Device name"....................................................................................................................... 44
5.6.1.4 "1.4 Transmission rate" ............................................................................................................... 44
5.6.1.5 "1.5 HART modem"..................................................................................................................... 45
5.6.1.6 "1.6 Connect network"................................................................................................................. 45
5.6.2 "2 Settings".................................................................................................................................. 46
5.6.2.1 "2.1 Display"................................................................................................................................ 46
5.6.2.2 "2.2 Device name"....................................................................................................................... 47
5.6.2.3 "2.3 Temp. settings" .................................................................................................................... 48
5.6.2.4 "2.4 Cold restart" ......................................................................................................................... 50
5.6.2.5 "2.5 Reset device"....................................................................................................................... 51
5.6.3 "3 Diagnostics" ............................................................................................................................ 52
5.6.3.1 "3.1 Identification" ....................................................................................................................... 52
5.6.3.2 "3.2 Connection info"................................................................................................................... 52
5.6.3.3 "3.3 Network info"........................................................................................................................ 52
5.6.3.4 "3.4 Device status" ...................................................................................................................... 52
5.6.3.5 "3.5 Version"................................................................................................................................ 53
5.6.4 "4 Communication"...................................................................................................................... 54
5.6.4.1 "4.1 Wireless".............................................................................................................................. 54
5.6.4.2 "4.2 Maintenance port"................................................................................................................ 56
5.6.5 "5 Security".................................................................................................................................. 57
5.6.5.1 "5.1 Active / inactive"................................................................................................................... 57
5.6.5.2 "5.2 PIN input"............................................................................................................................. 57
5.6.5.3 "5.3 Change PIN" ........................................................................................................................ 57
5.6.5.4 "5.4 Set level 0"........................................................................................................................... 58
5.6.5.5 "5.5 Timeout"............................................................................................................................... 58
5.6.6 "6 Language"............................................................................................................................... 59

Table of contents
SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 5
5.7 Setting language ..........................................................................................................................60
5.8 Canceling the password protection..............................................................................................61
5.9 Quick start....................................................................................................................................62
5.10 Connect/disconnect .....................................................................................................................64
5.11 Measure temperature...................................................................................................................66
5.12 Increase service life .....................................................................................................................67
5.13 Protected from unauthorized access ...........................................................................................68
5.14 Set HART functions of the HART maintenance port....................................................................70
6 Installing/mounting................................................................................................................................... 71
6.1 Safety guidelines..........................................................................................................................71
6.2 Mounting and connection guidelines ...........................................................................................72
6.3 Mounting positions .......................................................................................................................72
6.4 Mounting of device using bracket ................................................................................................73
6.5 Changing the display orientation..................................................................................................75
7 Connecting .............................................................................................................................................. 77
7.1 Connect external devices to the HART maintenance port...........................................................77
8 Alarm, error, and system messages ........................................................................................................ 79
8.1 Overview of messages and symbols ...........................................................................................79
9 Troubleshooting/FAQs............................................................................................................................. 81
9.1 Password forgotten? ....................................................................................................................81
9.2 Returning of battery .....................................................................................................................82
9.3 Return process for battery-operated devices...............................................................................83
9.4 Technical support.........................................................................................................................84
A Appendix.................................................................................................................................................. 85
A.1 Technical data..............................................................................................................................85
A.1.1 General technical specifications ..................................................................................................85
A.1.2 Input .............................................................................................................................................85
A.1.3 Output ..........................................................................................................................................86
A.1.4 Measuring accuracy.....................................................................................................................86
A.1.5 Ambient conditions.......................................................................................................................86
A.1.6 Mechanical design .......................................................................................................................86
A.1.7 Communication ............................................................................................................................87
A.1.8 Power supply................................................................................................................................87
A.1.9 Certificates and approvals ...........................................................................................................87
A.2 Dimension drawings.....................................................................................................................88
A.2.1 Dimensions of SITRANS TF280 with cable gland .......................................................................88
A.2.2 Dimensions of SITRANS TF280 with Pt100 ................................................................................89
A.3 Spare parts/accessories ..............................................................................................................90
Index........................................................................................................................................................ 91

Table of contents
SITRANS TF280 WirelessHART
6 Operating Instructions, 10/2010, A5E02619566-02

SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 7
Introduction 1
1.1 Purpose of this documentation
Read these instructions carefully prior to installation and commissioning. The instructions
contain all the information you need for commissioning and using the device. In order to use
the device correctly, first make yourself acquainted with its principle of operation.
It is aimed both at persons mechanically installing the device, connecting it electronically,
configuring the parameters and commissioning it as well as service and maintenance
engineers.
1.2 History
The following table shows the most important changes in the documentation compared to
each previous edition.
Edition Comment
01
10/2009
First edition
02
10/2010
Enhanced options for positioning the antenna.
Range of settings for transmission rate increased.
1.3 Notes on warranty
The contents of this programming manual shall not become part of or modify any prior or
existing agreement, commitment or legal relationship. All obligations on the part of Siemens
AG are contained in the respective sales contract, which also contains the complete and
solely applicable warranty conditions. Any statements on the device versions described in
the programming manual do not create new warranties or modify the existing warranty.
The content reflects the technical status at the time of printing. We reserve the right to make
technical changes in the course of further development.

Introduction
1.4 Environmental protection
SITRANS TF280 WirelessHART
8 Operating Instructions, 10/2010, A5E02619566-02
1.4 Environmental protection
Recycling
Devices described in this programming manual can be recycled owing to the low content of
noxious substances in their version. Please contact a certified waste disposal company for
eco-friendly recycling and to dispose of your old devices.
Energy consumption
The devices are battery-operated, and have a very low power consumption. Depending on
use, the battery life is several years.
Disposal of battery
Additional information is available under Returning of battery (Page 82).

SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 9
General safety instructions 2
2.1 General information
This device left the factory free from safety problems. In order to maintain this status and to
ensure safe operation of the device, please observe the safety information and warnings
contained in these instructions.
Safety information and symbols must be observed without exception. They must not be
removed and must be maintained in legible condition at all times.
2.2 Correct usage
The device may only be used for the purposes specified in these instructions.
Insofar as they are not expressly stated in these instructions, all changes to the device are
the sole responsibility of the user.
2.3 Qualified Personnel
Qualified personnel are people who are familiar with the installation, mounting,
commissioning, and operation of the product. These people have the following qualifications:
● They are authorized, trained or instructed in operating and maintaining devices and
systems according to the safety regulations for electrical circuits, high pressures and
aggressive as well as hazardous media.
● For explosion-proof devices: They are authorized, trained, or instructed in carrying out
work on electrical circuits for hazardous systems.
● They are trained or instructed in maintenance and use of appropriate safety equipment
according to the safety regulations.
2.4 Transport/Storage
Make sure that transport damages are prevented through proper packaging!
Devices/replacement parts should be returned in their original packaging. If the original
packaging is no longer available, please ensure that all shipments are properly packaged to
provide sufficient protection during transport.
We cannot assume any costs for additional expenses resulting from transport damages.

General safety instructions
2.4 Transport/Storage
SITRANS TF280 WirelessHART
10 Operating Instructions, 10/2010, A5E02619566-02

SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 11
Description 3
3.1 Applications
Temperature measurement
SITRANS TF280 WirelessHART is a battery-operated temperature transmitter for field use. It
is used to measure the temperature under industrial conditions in the following sectors:
● Chemical industry
● Energy management
● District heating
● Water supply and treatment
● Food industry
● Iron & steel and cement industries
● Pharmaceuticals
● Biotechnology
Communication
The device communicates with other wireless HART devices by means of radio technology.
The basis is application of the HART protocol V7.1. SITRANS TF280 WirelessHART
therefore complies with the following requirements:
● Design of self-organizing, wireless sensor networks
● Data exchange with other wireless HART devices at distances of up to 250 m
● Subsequent installation without cabling
● Overcoming of structural hindrances along the signal path.

Description
3.2 Product features
SITRANS TF280 WirelessHART
12 Operating Instructions, 10/2010, A5E02619566-02
3.2 Product features
The device has the following features:
● Absence of all cabling:
– Wireless communication via wireless HART
– Battery operation
● Local user interface with display and keys for efficient on-site operation
● Energy saving functions
● Display with backlight
● Rotatable display: flexible selection of mounting position
Changing the display orientation (Page 75)
● Integral HART maintenance port
● Antenna can be folded by 90°. Range of rotation: approx. 360°.
● Simple configuration with SIMATIC PDM
● Housing complies with IP65.

Description
3.3 Design of SITRANS TF280 WirelessHART
SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 13
3.3 Design of SITRANS TF280 WirelessHART
Overview
The device is available in the following basic versions:


① SITRANS TF280 with cable gland ② SITRANS TF280 with fixed Pt100 sensor
Figure 3-1 SITRANS TF280 basic versions

Description
3.3 Design of SITRANS TF280 WirelessHART
SITRANS TF280 WirelessHART
14 Operating Instructions, 10/2010, A5E02619566-02
External design (example)










① Antenna ⑥ Dummy plug
② Control panel cover (local user interface) ⑦ Screw-on housing cover, front
③ Cable gland (sensor element) ⑧ Digital display (90° rotatable) (local user
interface)
④ Reference to the manual ⑨ Locking screws for control panel cover
⑤ Nameplate ⑩ Screw-on housing cover, rear
Figure 3-2 SITRANS TF280 WirelessHART: Device with cable gland
Antenna
The device antenna can be folded to an angle of 90°. In addition, the antenna can be rotated
approx. 360°. Two stops limit the range of adjustment.

Description
3.4 Mode of operation
SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 15
3.4 Mode of operation
Measuring principle
The device contains a Pt100 sensor element (resistance thermometer) in accordance with
IEC 751/DIN EN 60751. The temperature is measured as a change in resistance. This signal
is amplified by the measuring amplifier and digitized in an analog-to-digital converter.
The digital signal is analyzed in a microcontroller and corrected with regard to linearity.
The measured value is then available to a HART master via HART FSK as well as wireless
HART.
The sensor-specific calibration data are stored in an EEPROM.
3.5 Sensor
Properties
SITRANS TF280 WirelessHART applies Pt100 resistance thermometers of Class A or B.
The sensor elements used correspond to IEC 60751 and exhibit the following properties:
● Exchangeable sense element: The terminal is located in the device housing next to the
battery clips.
● Maximum length of sensor cable: 3 m with 2-, 3- or 4-wire connection.
● Software-based detection of sensor breaks.
● Measurement in temperature range -200 °C to +850 °C.
You can find additional information on the sensor elements under Technical data (Page 85).

Description
3.6 Battery
SITRANS TF280 WirelessHART
16 Operating Instructions, 10/2010, A5E02619566-02
3.6 Battery
The very low energy consumption of the device means that a battery service life of up to
5 years is possible. The current charging level of the battery is shown in the device's digital
display. If a critical charging level is reached, the device also sends this condition as part of
the "Extended Status Byte" to the host control system.
Other repair or maintenance measures are not required on the device. You can find
supplementary information on this under Inserting / removing the battery (Page 28) and
Alarm, error, and system messages (Page 79).



① Lithium thionyl chloride battery D-cell ② Connector
③ Positive pole
Figure 3-3 High-capacity battery

Description
3.7 WirelessHART
SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 17
3.7 WirelessHART
3.7.1 Overview
WirelessHART
Wireless standard IEEE 802.15.4-2006 @ 250 kbps
Frequency band 2.4 GHz
Data transmission Frequency spread procedure (per packet basis)
Transmission range Up to 250 m (visual connection)
Power supply Battery
Network topologies Meshed network
Star topology
Combination of both topologies
HART specification HART protocol V7.1
HART - IEC 61158 E DDL - IEC 61804-3
3.7.2 WirelessHART
Fundamentals
Wireless HART is a fieldbus standard of the HART Communication Foundation and permits
radio-based networking of field devices.
The radio transmission is based on the wireless communication standard
IEEE 802.15.4-2006 (ISM band, 2.4 GHz).
The data transmission is appropriately encrypted using the
Advanced Encryption Standard (AES 128). Data transmission as well as parameterization of
the field devices involved is thus protected.
The data transmission is coordinated by the TDMA procedure
(Time Division Multiplex Access). Signals from different transmitters are then only
transmitted on the common bus within specific time slots, or the radio stations are
synchronized with a sampling rate of 10 ms.
Interferences from other radio stations also using the 2.4 GHz band are minimized by
application of a frequency spread procedure.

Description
3.7 WirelessHART
SITRANS TF280 WirelessHART
18 Operating Instructions, 10/2010, A5E02619566-02
Properties
Field devices communicating using wireless HART can be connected into a meshed
network:
● The wireless HART gateway obtains information from each field device involved in the
wireless HART network concerning the respective adjacent devices.
● The network manager in the wireless HART gateway organizes the network on the basis
of this information.
The field devices present on the network are both signal sources and repeaters. A message
is passed on from the transmitting field device via the connected fields devices until the
wireless HART gateway is reached. If a network station fails or if a hindrance prevents a
message from being passed on, the data is automatically transmitted via alternative routes.
If an additional field device is integrated into an existing network, it must be authenticated.



① Wireless HART gateway: SIMATIC NET IE/WSN-PA Link
② SITRANS P280 WirelessHART pressure transmitter
③ SITRANS TF280 WirelessHART temperature transmitter
Figure 3-4 Meshed wireless HART network (example)
The transmission distance from station to station without barriers (line-of-sight) is up to
250 m. Significantly longer distances can be covered it the field devices of a network are
spatially positioned in sequence.

Description
3.8 HART maintenance port
SITRANS TF280 WirelessHART
Operating Instructions, 10/2010, A5E02619566-02 19
3.8 HART maintenance port
The HART maintenance port is a HART communications interface via which the device can
be parameterized and adjusted. You will need the following hardware and software:
● A HART communicator. Or:
● A PG / PC with HART modem, an appropriate parameterization tool (e.g. SIMATIC PDM)
and the corresponding EDD.
● Appropriate cables
Note
Scope of supply
The accessories required for operation via the HART maintenance port are not included
in the scope of supply of the device. Further information on SIMATIC PDM can be found
on the Internet at:
SIMATIC PDM (http://www.automation.siemens.com/w2/automation-technology-process-
device-manager-pdm-3695.htm)
Further information
Information on connecting/operating external devices and additional parameterization
tools can be found in the respective documentation.
The following photo shows the contacts of the HART maintenance port for connecting a
HART modem or HART communicator:


① Electronics area ② HART maintenance port
Figure 3-5 HART maintenance port

Description
3.8 HART maintenance port
SITRANS TF280 WirelessHART
20 Operating Instructions, 10/2010, A5E02619566-02
See also
Overview (Page 33)
Connect external devices to the HART maintenance port (Page 77)
