Siemens SITRANS TH100 User manual

SITRANS T
Temperature transmitter
SITRANS TH100/TH320/TH420/
TR320/TR420/TF320/TF420 with 4
to 20 mA/HART
Operating Instructions
7NG0.1. / 7NG0.2. (TH/TR320/420 mA/HART)
7NG0.4. (TF320/420 single chamber housing mA/HART)
7NG0.5. (TF320/420 dual chamber housing mA/HART)
7NG3211-0. / 7NG3150-0NN00 (TH100/TH100 slim)
7MF7902-1AD (Display)
7NG3092-8KN (USB modem and SIPROM T)
05/2020
A5E41864807-AB
Getting started 1
Introduction 2
Safety notes 3
Description 4
Installing/mounting 5
Connecting 6
Operating (SITRANS TF) 7
Commissioning 8
Parameter assignment 9
Service and maintenance 10
Diagnostics and
troubleshooting 11
Technical data 12
Dimension drawings 13
Product documentation and
support A
Remote operation B
Calibration examples C
Accessory part sealing
plug / thread adapter D

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E41864807
Ⓟ 07/2020 Subject to change
Copyright © Siemens AG 2018 - 2020.
All rights reserved
