Silver Cross SURF User manual

Surf
Pushchair and Bassinet

2
Warranty
All Silver Cross products are guaranteed for a
period of 36 months against manufacturing
faults, when the product is used correctly
according to the instruction manual.
Garantie
Tous les produits Silver Cross sont garantis
pour une période de 36 mois contre tout
défaut de fabrication, si le produit est utilisé
conformément au manuel d’instructions.
Garantía
Todos los productos de Silver Cross incluyen
una garantía de 36 meses contra defectos
de fabricación, siempre que el producto se
utilice correctamente de acuerdo con el
manual de instrucciones.
Garanzia
Tutti i prodotti Silver Cross sono garantiti
per un periodo di 36 mesi contro difetti di
fabbricazione, purché il prodotto venga
utilizzato correttamente, in conformità al
manuale delle istruzioni.
Garantie
Für alle Produkte von Silver Cross besteht
für den Fall von Herstellungsmängeln eine
Garantie von 36 Monaten, sofern das Produkt
sachgemäß wie in der Bedienungsanleitung
angegeben gebraucht wurde.
Garanti
Alla Silver Cross-produkter har 36 månaders
garanti som gäller tillverkningsfel förutsatt
att produkten har använts korrekt i enlighet
med bruksanvisningen.
Гарантия
На всю продукцию Silver Cross
действует гарантия сроком 36 месяцев,
покрывающая случаи производственного
брака, при условии использования
изделия в соответствии с инструкциями.
保修
在依据说明书正确使用产品的情况下，所有
Silver Cross产品对工艺质量问题保修期为36
个月。
保養期
所有 Silver Cross 產品均可享有36個月保養
期，提供在按照指引說明書正確使用下的工
藝缺憾保養。

Silver Cross


3
silvercross.com.au
These instructions are
important.
Read these instructions before use and keep
them for future reference. Your child’s safety
may be aected if you do not follow these
instructions.
Your Surf Pushchair and Bassinet is a
high quality Silver Cross product. It meets
current Australian, British and European
safety standards and care and regular light
maintenance will ensure long service.
This pushchair is suitable from birth up to
9kg with the Bassinet and from 6 months up
to 15 kg using the Seat Unit.
If somebody unfamiliar is using your Surf
Pushchair always ensure that they read
these instructions carefully so that they
understand how the product works best.
The Surf Pushchair is designed and tested
to be used with the Surf seat unit, Surf
Bassinet and the Surf Essentials pack, all sold
separately.
Always read all the instructions provided
carefully and remember, the safety of your
child is your responsibility.
WARNING
It may be dangerous to leave
your child unattended.
Contents
First check all your parts have been
supplied. Your Surf Pushchair includes:
1.1 Surf seat unit with harness
1.2 Chassis
1.3 Bumper bar
1.4 Rain cover
1.5 Rear wheels
1.6 Front wheels
1.7Cup holder
1.8Shopping basket
1.9Bassinet mattress and cover
1.10Bassinet outer
1.11 Bassinet liner
1.1
1.3
1.2
1.5
1.6
1.8
1.7
1.111.10
1.9
1.4

4
Preparation for use
Remove all packaging material from your
Surf Pushchair. To use your Surf Pushchair
from birth you must use the Silver Cross
Bassinet (included).
WARNING
Check that the Bassinet or seat
unit is correctly engaged before
use.
Surf chassis
2.1 Attach the front and back wheels by
inserting the axles into the Surf frame
until they ‘click’ into position.
2.2 Release the folding lock and lift the
handle to waist height.
2.1
2.2

5
silvercross.com.au
Surf chassis (continued)
2.3 Lift the handle upwards and ick
forwards, while holding the handle
tightly, the frame ‘clicks’ and locks
into position. Always check that the
frame is secure.
2.4 Apply the brake (see point 23.1) and
adjust the handle height by pushing
the adjustment button in. Slide the
handle up or down and release the
adjustment button. The handle will
lock and ‘click’ into position.
Your Surf chassis is now ready for use.
2.3
2.4

6
Using your Surf from birth with
the Bassinet.
Remove all packaging material from your
Surf Bassinet.
3.1 First erect the Bassinet outer. Lay the
Bassinet outer down with frame upper
most. Press the 2 x metal bars into the
locators on internal base of Bassinet.
A small groove in the locator holds the
frame in position.
3.2 Attach the Bassinet liner to the
Bassinet outer. Fasten each inner zip.
There is one at each end of the liner.
3.3 Pass the two D-shaped parts of the
liner between the liner and the outer
and fasten the velcro patches to secure
the liner in place.
3.4 Place the mattress into the base of
the liner.
3.5 Zip your Surf hood to the zip on the
Bassinet outer.
3.6 Attach the hood to the frame by
pressing down on the hood attachment
clips on each side of frame.
3.7 To t the apron, place the apron over
the top of the Bassinet. Secure in place
by sliding the apron clips over the
attachment points inside the
Bassinet frame.
NOTE: The Apron comes in 2 parts. To use
the apron with the Bassinet, the lower
part of the apron will need to be zipped
o rst. Please keep the lower part in a
safe place.
WARNING
ONLY USE ON A FIRM,
HORIZONTAL LEVEL AND DRY
SURFACE.
3.1
3.4
3.5 3.6
3.7
3.2
3.3

7
silvercross.com.au
Using your Surf from birth with
the Bassinet. (continued)
3.8 Slide the apron ap clips over the
attachment points on the inside of
the Bassinet frame.
3.9 Attach the bumper bar by pressing
the ends of the bumper bar into the
attachment points of the Bassinet
frame. Wait to hear them ‘click’
into place. Lift gently to ensure the
bumper bar is locked in place. Fold
the apron ap over the bumper bar,
the magnets hidden inside the ap
will hold it in place.
NOTE: The bumper is to be used on the Surf
Pushchair and the Surf Bassinet
WARNING
Please ensure the bumper bar is
fully locked in place whenever
lifting your child in the Bassinet.
Your child’s safety is your
responsibility.
WARNING
Ensure all locking devices are
engaged before use.
Your Surf Bassinet is ready to use.
3.8
3.9
CAUTION: The head of the child
in the Bassinet should never
be lower than the body of the
child.

8
Attaching the Bassinet to your
chassis
4.1 To attach your Surf Bassinet to
the Surf chassis hold the Bassinet
above the chassis. Locate the
Bassinet chassis connector onto
the attachment post of the chassis.
Ensure the Bassinet ‘clicks‘ into
place. The Bassinet should be tted
rearward facing. Lift the Bassinet
gently by the bumper bar to check it
has locked into place.
WARNING
Do not add a mattress other
than the one provided.
Detaching the Bassinet from
your chassis
4.2 With the Surf Bassinet facing you
press the red release button rst
located on the side of the Bassinet
until it clicks into place.
WARNING
This button is now unlocked. It
will re-lock automatically when
the Bassinet is re-attached to
the chassis.
Then while pressing and holding the other
black release button on the opposite side
of the Bassinet, lift the Bassinet from the
chassis using the bumper bar.
The Bassinet will now lift clear of the chassis.
WARNING
Always ensure your bumper bar
is attached when your child is in
the Bassinet.
4.1
4.2

9
silvercross.com.au
Using your bumper bar on the
Bassinet
Your Surf Bassinet uses the same Surf
bumper bar as your seat unit. It can be
fully or partly removed.
5.1 To attach, simply press both ends of
the bumper bar into the connector
points on the seat unit. Wait for it to
‘click’ in place.
5.2 To detach, press the bumper bar
release button on the Bassinet frame
with one hand and pull the bumper
bar away from the connector point
with the other hand. The bumper bar
will rotate.
To detach both sides repeat point (5.2)
above. With one side of the bumper
bar removed the Bassinet is easily
accessible.
WARNING
The bumper bar must be
securely connected at all times
when in use. The safety of your
child is your responsibility.
Using your hood on the Bassinet
6.1 Zip the back of the Surf hood to the
top of the Surf Bassinet frame taking
care to engage the zip properly.
6.2 Your Surf hood ts to the Bassinet
frame by pressing the hood clips
down onto the frame below the round
black plastic locator.
6.3 Your Surf hood can be used in 4
positions. Fully open, semi-open,
semi-open with viewing window, and
fully covered.
5.25.1
6.1 6.2
6.3

10
7.1
7. 2
8.1
Using your apron on the
Bassinet
7.1 First detached the Surf apron lower
section using the zip on the front of
the apron and place over the top of
the Bassinet.
NOTE: Please ensure you keep
the apron lower section in a safe
place, as you will need it when
using the Surf as a pushchair.
7. 2 Secure in place by sliding the apron
clips over the attachment points
inside the Bassinet frame and fold
the apron ap over the bumper bar
using the hidden magnets to secure
in place.
Using your Bassinet liner &
mattress
8.1 Your Surf Bassinet mattress is
removable. Simply lift it out of the
liner. The mattress cover can be hand
washed. Remove the foam mattress
insert prior to washing by opening
the ap on the back of the mattress
cover and removing the foam
mattress.
The Surf Bassinet has a removable
liner. Simply unzip each end and
release the Velcro fastenings to
remove it.
To t the liner and mattress see
preparation for use points (3.1-3.4).
The liner can be hand washed. (The
boards should be removed using the
zip on the back prior to washing)

11
silvercross.com.au
Using your raincover on the
Bassinet
9.1 Your Surf raincover should be used
when the Surf hood is attached to
the Bassinet. First slide over the hood
and down towards the foot of the
Bassinet and over the apron.
NOTE:This raincover can be used on
both the Bassinet and the Seat Unit.
A zip gives easy access to your child.
Using your Surf as a pushchair
10.1 Your Surf seat unit can be tted
to the chassis in rearward facing
position (infant facing you) or
forward facing position (infant facing
away from you). Follow point (4.1) to
attach the seat unit to the chassis
Adjust the seat unit to the desired
position. See point (20.1). Secure
the apron see point (17.1). Your Surf
Pushchair is ready to use.
10.1
9.1

12
Preparing the seat unit
11.1 First, zip the hood to the back of the
seat frame taking care to engage
the zip properly. Attach the hood by
pressing down on the hood clips on
either side of the seat frame below
the round black plastic locator.
11.2 Thread the harness through the
buttonholes, slide the chest and
buckle pads over the harness and
secure the harness buckle (see point
15.1).
11.1
11.2

13
silvercross.com.au
Preparing the seat unit
(continued)
12.3 Fit the bumper bar to the seat unit by
placing the metal ends of the bumper
bar into the xing points on the seat
unit. Wait to hear the bumper bar
‘click’ into place.
WARNING
Always ensure your bumper bar is
attached when your child is in the
seat unit.
NOTE: The apron comes in 2 parts.
To use the apron with the seat
unit, the lower part of the apron
will be needed and should be
zipped to the front section.
12.4 Slide the apron ap clips onto the
attachment points on the inside of
the seat frame. Fold the apron ap
over the bumper bar to enclose and
secure your child. To secure, release
and adjust the harness see points
(15.1-15.5)
12.3
12.4

14
Attaching the seat unit to your
chassis
WARNING
Ensure all locking devices are
engaged before use.
13.1 To attach your Surf seat unit to the Surf
chassis hold the seat unit above the
chassis. Locate the seat unit chassis
connector onto the seat attachment post
of the chassis. Ensure the seat unit ‘clicks’
into place. The seat unit can be tted
forward or rearward facing. Lift the seat
unit gently by the bumper bar to check
the seat has locked into place.
To adjust the seat position (see point
20.1).
Detaching the seat unit from your
chassis
14.1 With the seat unit facing you press the
red release button rst located on the
side of the seat unit until it clicks into
place.
WARNING
This button is now unlocked. It will
re-lock automatically when the
seat is re-attached to the chassis.
Then while pressing and holding the other
black release button on the opposite side
of the seat unit, lift the seat unit from the
chassis using the bumper bar.
WARNING
Always ensure your bumper bar is
attached when your child is in the
seat unit.
The seat unit will now lift clear of the
chassis.
NOTE: Remove the child from the
seat unit before detaching from
your chassis.
14.1
13.1

15
silvercross.com.au
A
BB
A
A
BB
A
A
BB
A
A
BB
A
Using the harness
WARNING
Always use the crotch strap in
combination with the waist and
shoulder straps
15.1 To fasten the harness insert both
buckle clips into each side of the
buckle. Listen for the ‘click’.
15.2 To release the harness press the
button at the centre of the buckle
and pull apart. The shoulder straps
can be unhooked from the buckle if
required.
15.3 Your harness is fully adjustable by
moving the slides (A), to make tting
easy. ‘D’ rings are provided for tting
a separate harness if required (B).
Any additional harness must comply
with BS 6684. Your child should
always be harnessed in and should
never be left unattended, even for
short periods of time.
Your Surf harness can be adjusted for
the size of your child.
15.1
15.3
15.2

16
Using the harness (continued)
15.4 The shoulder straps have 2 height
positions. To adjust, rst lift the ap
on the back of the seat unit. Thread
the harness from the back of the seat
unit through to the front of the seat
unit and allow the restraint clip to
lay at behind the seat securing the
shoulder strap in place.
15.5 The waist straps can be reduced to
t a smaller child by threading them
through the loops on the seat.
15.5
15.4

17
silvercross.com.au
Using your hood on the Seat
16.1 Zip the hood to the back of the seat
frame taking care to engage the zip
properly. Attach the hood by pressing
down on the hood clips on either side
of the seat frame below the round
black plastic locator.
16.2 Your Surf hood can be used in 4
positions. Fully open, semi-open,
semi-open with viewing window, and
fully covered.
16.1
16.2

18
Using your apron on the Seat
17.1 Slide the apron ap clips on your
apron to the attachment points on
the inside of the seat frame and fold
the apron ap over the bumper bar to
enclose and secure your child.
17.1

19
silvercross.com.au
Using your raincover on the Seat
18.1 Your Surf raincover should be used
when the Surf hood is attached to
the seat unit. First slide over the hood
and down towards the toe of the seat
unit. Velcro fastening secures the
raincover under the foot of the seat
unit.
18.2 A zip gives easy access to your child.
18.1
18.2

20
Using your bumper bar on the
Seat Unit
Your Surf seat unit has a bumper bar that
can be fully or partly removed.
WARNING
Always ensure your bumper bar
is attached when your child is in
the seat unit.
19.1 Fit the bumper bar to the seat unit by
placing the metal ends of the bumper
bar into the xing points on the seat
unit. Wait to hear the bumper bar ‘click’
into place.
19.2 To detach, press the bumper bar release
button on the seat unit with one hand
and pull the bumper bar away from
the xing point with the other hand.
The bumper bar will rotate allowing
easy access to your child, if the bumper
needs to be fully removed then repeat
on the opposite side.
WARNING
Always remove your child from
the seat before attempting to lift
and remove the seat unit.
Adjusting the seat position
Your Surf has 3 forward facing and 3
rearward facing seat positions
20.1 To adjust the seat position in either
forward or rearward facing mode, grip
the outside of the seat unit with both
hands. Place your ngers against the
large, circular seat adjustment buttons.
Press rmly inwards moving the seat
unit forwards or backwards to upright,
semi-recline or full recline. Release the
button and wait to hear the ‘click’ for
each position to lock into place.
19.1
19.2
20.1
