Silver Cross 3D Pram System User manual

3D
IMPORTANT: KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE

2
3
silvercrossbaby.com
These instructions are important.
Read these instructions carefully before use
and keep them for future reference. Your
child’s safety may be affected if you do not
follow these instructions.
Your 3D Pram System is a high quality Silver
Cross product. It meets current British and
European safety standards and care and
regular light maintenance will ensure
long service.
This vehicle is intended for children from birth
and up to 15kg.
If somebody unfamiliar is using your 3D
always ensure that they read these instructions
carefully so that they understand how the
product works best.
The 3D Pram System is designed and tested
to accept the Ventura Plus Car Seat.
Always read all the instructions provided
carefully and remember, the safety of your
child is your responsibility.
Contents
First check all your parts have been supplied.
Your 3D Pram System includes:
1.1 3D Pram System body and chassis
1.2 Pram system liner
1.3 Hood
1.4 Apron
1.5 Footmuff
1.6 Raincover
1.3
1.1 1.2
1.4
1.5 1.6
Preparation for use
Remove all packaging material from your 3D
Pram System.
2.1 To unfold your 3D release the folding
lock by pulling up on each of the
handle catches (marked with a number
1) on both sides of the chassis
simultaneously.
2.2 Whilst holding each of the handle
catches (marked with a number 1), pull
upwards on the main handles. The
pushchair may lift off the floor during
this action.
2.3 As the 3D begins to unfold, release the
handle catches and immediately push
down with your foot on the centre of the
main lock to errect your pushchair.
2.4 Ensure that the secondary locks have
engaged on both sides, if not then
gently push down to engage them.
2.5 Your 3D is now erected. If you wish to
use your pushchair as a pram continue,
if you wish to use your 3D as a pushchair
proceed to point 4.1.
WARNING: Ensure that all
locking devices are engaged
before use.
2.1
2.2
2.3
2.4
2.5

4
5
silvercrossbaby.com
Using your 3D as a pram
3.1 Lift the leg supports to the upper
position, so that they touch the bumper
bar (see point 9.1).
3.2 Recline the seat to the lie flat position by
releasing the mechanism at the back of
the seat.
3.3 Remove the head support by releasing
the zip and then releasing the harness
(see point 6.2). Feed the harness
through the harness button holes.
Using your 3D as a pram (cont.)
3.4 Flip the head support over so that it is
upside down and place over the buckle
so that the head support is now laying
in the ‘seat’ of the pushchair (under the
head of the pram liner)
3.5 Pull the fabrics over and under at the
handle end of the seat. Ensuring that the
recline mechanism can pass through the
opening in the liner.
3.6 Now pull the liner over the bumper bar,
and under the leg support. The liner will
attach with velcro underneath the leg
support.
3.1
3.2
3.3
3.4
3.5
3.6

6
7
silvercrossbaby.com
Using your 3D as a pram (cont.)
3.7 Now fit your hood facing towards the
handles. The hood catches should easily
‘click’ onto the 3D. To lock, put the catch
down. Position the rear elasticated hood
skirt under the leg support joint.
3.8 Slip the apron cover over the bumper
bar end of the pram. Now slide the clips
on your apron on to the attachment
points inside the hood to enclose the
pram.
3.9 Your 3D Pram System is now ready for
use
WARNING: Do not add a
separate mattress.
Using your 3D as a pushchair
4.1 Attach your hood facing towards the
bumper bar. The hood catches should
easily ‘click’ into position. Lock them in
place by pushing the securing
catch down.
4.2 Select the position you require for the
seat back (see point 7.2) and the leg
support (see point 9.2).
Your 3D Pushchair is ready for use.
3.7
3.8
3.9
4.1
4.2

8
9
silvercrossbaby.com
Using the brake
5.1 To engage the brake, press down on
either pedal.
5.2 A ‘click’ will be heard.
Note: Always check that your brake
is fully engaged by gently rocking
the pushchair.
5.3 To disengage the brake, simply push the
brake pedal upwards, this will disengage
both sides simultaneously.
Using the harness
6.1 WARNING: Always use the
crotch strap in combination
with the waist belt.
To fasten the harness insert both buckle
clips into each side of the buckle.
Listen for the ‘click’.
6.2 WARNING: Use a harness
as soon as your child can sit
unaided.
To release the harness press the centre
and pull apart. The shoulder straps
can be unhooked from the buckle if
required.
6.3 Your harness is fully adjustable by
moving the slides (A), to make fitting
easy. ‘D’ rings are provided for fitting
a separate harness if required (B). Any
additional harness used must comply
with BS 6684. Your child should always
be harnessed in and should never be
left unattended, even for short periods
of time.
5.1
5.2
5.3
6.1
6.2
6.3
A
B
B
A

10
11
silvercrossbaby.com
Adjusting the seat position
7.1 Your 3D has 4 seat positions
7.2 To lower the seat, release the
mechanism on the rear top of the seat,
and gently lower to the desired position.
7.3 To raise the seat place your hand in the
middle of the rear of the seat and gently
lift to the desired position ensuring both
sides are level.
Operating your height
adjustable handles
8.1 The handles on your 3D have 2
positions. Press the button on the
underside and raise or lower to the
desired position.
Operating your leg support
9.1 Your 3D has a two position leg support
for your child.
9.2 Press the buttons simultaneously
underneath both sides of the leg
support and raise or lower to the
desired position.
7.1
7.2
7.3
8.1
9.2
9.1

12
13
silvercrossbaby.com
Operating the swivel wheels
10.1 Your 3D has lockable swivel wheels. By
pressing the locking catch down the
wheels will lock in the fixed position. By
lifting this up the wheels will freely swivel
for easier steering.
You should always lock the wheels on
uneven surfaces, and before folding.
Using your hood
11.1 Your 3D hood fits on the 3D facing both
directions, rearwards for the pram mode
and forwards for pushchair mode. Press
down on the hood arms to tension the
hood.
Using your liner
12.1 Your 3D liner has a Soft Wrap™ to
help provide your child with a safe and
comfortable position. Open the wrap
completely, place your child in the
centre of the Soft Wrap™ and close the
waist and crotch pads, securing with the
velcro tabs.
12.2 If you wish to attach a separate harness
D-rings can be accessed at the sides of
liner.
WARNING: Use a harness
as soon as your child can sit
unaided.
NOTE: Always use the
harness provided when in
pushchair mode
Your pram system liner can be washed
(please refer to washcare labels), it is
recommended that the mattress and
side supports are removed by accessing
from the base of the liner.
Using your raincover
13.1 To attach the raincover, first slide over
the 3D Pram System handles and pass
over the hood. Then fasten the velcro
flap at the rear.
13.2 Pull the raincover over the 3D at both
ends. Loop the velcro straps at the front
around the 3D leg, just below the foot
plate, and fasten. The raincover is now
fitted.
13.3 Your 3D Pram System raincover is
designed to fit the 3D in either pram or
pushchair mode. The raincover however
is not designed to fit when the Ventura
Plus car seat is fitted to the 3D. A
separate raincover can be purchased for
this purpose.
10.1
11.1
12.1
12.2
13.1
13.2
13.3

14
15
silvercrossbaby.com
Folding your 3D
Your 3D will fold with and without the
pram system liner fitted. It is easier
without the liner in position, and we
would therefore recommend removing it
before folding.
Note: To ensure your 3D folds
correctly remove all items from the
shopping basket before attempting
to fold.
Note: If the liner is left in place and
folded for a long period, then the
foam mattress will curve upwards.
This will then regain its normal flat
shape once a baby is placed in the
liner.
Note: If using as a travel system
please ensure that the Ventura Plus
car seat is removed before folding.
14.1 Before commencing the fold apply the
brake. Then lift the seat back into the
upright position (if in pram system make
sure you push the apron part upright)
lock the swivel wheels and ensure the
hood is fully folded back.
This is very important.
14.2 Next, gently Pull the 2 finger catches
simultaneously upwards (numbered 1)
until you hear the click and reveal the
red exclamation marks. Now press
down gently on the main pushchair
handles to disengage the main front
locks.
Folding your 3D
14.3 Rotate the red rotation lever (numbered
2) so it’s horizontal. Pull gently upwards
and the 3D will begin to fold. This lever
is not a carry handle.
Note: Do not force or over rotate
the red rotation lever, this may
cause damage to your pushchair.
14.4 Pushing on the handle and lifting the
red rotation lever will help your 3D to
fold easily.
14.5 Rock the pushchair onto the front wheels
and push downwards. Your 3D will lock
together.
14.6 From time to time it may be necessary
to lock your 3D by pressing the legs
together until the 3D locks. This is
perfectly normal.
NOTE: When folding your 3D in pram
mode, please ensure that the apron (seat
back) has been raised to the upright
position (see point 7.3), then proceed
with points 14.1 - 14.5.
NOTE: Silver Cross advises that the
apron is removed before folding in pram
mode.
14.1
14.2
14.3
14.4
14.5 14.6
Lock

16
17
silvercrossbaby.com
Unfolding your 3D
15.1 To unfold your 3D release the folding
lock by pulling up on each of the handle
catches (marked with a number 1) on
both sides of the chassis simultaneously.
15.2 Whilst holding each of the handle
catches (marked with a number 1), pull
upwards on the main handles. The
pushchair may lift off the floor during
this action.
15.3 As the 3D begins to unfold, release the
handle catches and immediately push
down with your foot on the centre of the
main lock to erect your pushchair.
NOTE: It is essential to ensure the
main lock is engaged. Failure to do
so could result in damage to your
pushchair.
Unfolding your 3D
15.4 Push the main pushchair handles
upwards to engage the secondary lock.
15.5 Check the secondary lock has engaged
on both sides. If not push down on the
tube to lock.
15.6 Your 3D is ready for use.
15.1
15.2
15.3
15.4
15.5
15.6

18
19
silvercrossbaby.com
Attaching your Ventura Plus
Car Seat
16.1 To attach your Ventura Plus, unfasten
the fabric cover on the 3D arms. Lift the
catches inside the arms until they reach
the stop point.
16.2 Position the Ventura Plus in the 3D seat,
do this by firstly positioning the large
opening on the Ventura Plus base over
the bumper bar.
16.3 Lock the handle down towards the
bumper bar, by pressing and holding
down both buttons simultaneously, then
rotating the handle. An audible ‘click’
will be heard. Your 3D Travel System is
now ready.
WARNING: Check that
the seat unit attachment
is correctly engaged by
checking both catches
are vertical and locked in
position with the car seat
Detaching your Ventura Plus
Car Seat
17.1 To detach your Ventura Plus,
simultaneously press the buttons on
both sides of the car seat handle at the
same time and hold down.
17. 2 Rotate the handle to the upright carry
position and lift the car seat out of the
3D.
17. 3 Push the car seat locks back into the 3D
arms and re-attach the fabrics back onto
the arms.
16.1
16.3
16.2
17.1
17. 2
17. 3
