DRAWER BASE BED
Assembly Instructions
Please retain these instructions for future reference
Please read through these assembly instructions carefully to ensure that you can assemble your new purchase
without stress. These detailed instructions will guide you on how to prepare and assemble your bedroom suite.
DIFFICULTY
WE ADVISE YOU DO NOT USE POWERED DRILLS TO ASSEMBLE ANY BOLTS ON THIS BED
EQUIPMENT PROVIDED
Thank you for purchasing a Silverlynx product
As one of Australia’s leading bedroom furniture manufacturers, we have long established partnerships with
Australia’s most successful retailers.
Customers who buy our products recognise our commitment to quality and customer satisfaction.
Silverlynx is a value’s based business. Our commitment to quality, evolving design leadership, customer
service and exceeding customer expectations - is unsurpassed in the industry.
Enjoy your Silverlynx product.
Not Provided: Phillips head screwdriver
Hardware Pack - attached to Siderails: containing - 12x (M6) 10mm button head bolts; 2x 15mm
phillips head screws; 2x 38mm screws; 2x 30mm bolts; 2x washers; 1x allen key
Note: These instructions will also guide you on how to use the additional hardware pre-fitted to your bed components
Bed Frame Parts:
*Please note, your bed head may
look different, however the following
instructions will still apply
Slat System: See the attached document “Amendment to instructions for all SilverLynx beds”

Bomi Furniture P/L trading as Silver Lynx ABN 99 006 489 541 11-17 Sages Road Glenroy Victoria 3046 Australia
T:[phone] F:[phone] E:[e-mail] W:www.silverlynx.com.au
STEP 1 –Position Bed Head and Side
Rails approximately where your bed is to
be set up. NOTE the cleat is installed on
the Side Rail closer to the head end as
shown. Connect the Side Rails to the
Bed Head by hooking the Side Rail
brackets onto the Head brackets.
STEP 2 –Screw three button head
bolts (M6) into the position shown to
connect the Side Rails to the Bed Head
and tighten (finger tight only).
Having trouble? See *Helpful Tips* at
the end of this document.
STEP 3 –Optional angle brackets
located near the bottom of the head
end of your Side Rails can be fixed to
keep the Side Rails parallel with the
bedhead. Use the 15mm screws
provided to screw through the angle
bracket (you will need a Phillips head
screwdriver).
STEP 4 –Complete the above
process on the other Side Rail.
STEP 5 –Fitting the Underbed Drawer
Remove the drawers from the Drawer
Box –to do this, open the drawer all
the way out. There is plastic clip along
the side of the drawer runners.
Standing in front of your open drawer,
push the clip on your left up, while
simultaneously pushing the clip on the
right down. This will release the
drawer runner and you should be able
to completely remove the drawer so
that you can access the inside of the
box.
STEP 6 –Remove the other drawer -
making sure not to swap them when re-
installing. (Note, King Single and Single
beds will only have one drawer)
STEP 7 –Gently move the Drawer
Box into place so that it lines up with
the Side Rails (use the cut-outs on top
of the Drawer Box as handles). There
is a slot on the side of the drawer box
that will line up with the bolt holes near
the foot end of the Side Rails.
STEP 1 - 3
STEP 5 & 6
STEP 7

Bomi Furniture P/L trading as Silver Lynx ABN 99 006 489 541 11-17 Sages Road Glenroy Victoria 3046 Australia
T:[phone] F:[phone] E:[e-mail] W:www.silverlynx.com.au
STEP 8 –From the inside of the
Drawer Box, use the 2x 30mm bolts
and 2x washers to secure the Drawer
Box to the Side Rail (1 each side)
STEP 9 –Ensure the bed is square
and then tighten all bolts using the allen
key provided. Once snug, tighten only
with ¼ turn of the Allen Key. DO NOT
USE cordless drivers or power drills as
over-tightening can cause damage to
some components.
STEP 10 –Re-install the drawers by
lining up the runner components on
each drawer with the components in
the Drawer Box. Ensure your drawers
have not swapped position or they will
not fit. NOTE: you do not need to press
the plastic clips, but must make sure
the drawer goes in straight and evenly.
If the drawer does not go all the way to
the closed position, pull it open a few
centimetres and then push closed
again. Having trouble? See *Helpful
Tips* at the end of this document
STEP 11 –To set up the slat and
spine system, proceed to the
instructions titles “Amendment to
instructions for all SilverLynx beds”.
Note the 2x 38mm screws provided in
the hardware pack can be used in this
section of the assembly
STEP 10
STEP 9
STEP 8

Bomi Furniture P/L trading as Silver Lynx ABN 99 006 489 541 11-17 Sages Road Glenroy Victoria 3046 Australia
T:[phone] F:[phone] E:[e-mail] W:www.silverlynx.com.au
NOTES
•Button head bolts should be regularly inspected and may need to be retightened periodically
•Never drag or move assembled furniture as this may cause damage
CARE & MAINTENANCE
Your SilverLynx product is crafted with care, properly maintained, it will mature over time developing a rich
deep patina enhancing its appearance. To get the best performance from your SilverLynx product, please
follow the simple care instructions listed below.
•Do not use silicone based polishes/cleaners at any time.
•Dust surfaces gently with a feather duster then wipe gently with a slightly damp cloth/chamois.
•Do not allow liquids, damp clothes to remain in contact with lacquered surface for extended periods.
•Never place furniture in close proximity to heating outlets.
•Exposure to direct sunlight will cause colour fading to fabrics, leathers and timber finishes.
•Do not allow solvents, abrasives or heated objects to come in contact with the product.
•Do not use cordless drivers or power drills to tighten any bolts, as over-tightening can cause components to
bow, and can cause damage to the bolts.
Contact your retailer or our sales office for further information
*Helpful Tips*
STEP 2 & 3
The button head bolts that connect the Siderails to the Bed Head & Foot can sometimes be tricky to align. If you
are having trouble, try supporting the bottom edge of the Siderail near the bracket and lift it up while you
connect the bolts. This can help line up the holes in both brackets so that the bolt can connect easily.
STEP 10
Make sure the runners are aligned on both sides before pushing the drawer closed. You may find it easier to
slide the ‘arms’ of the runners all the way out from the drawer box –OR, you may find it easier if you push the
‘arms’ all the way in before trying to align the drawer. When properly aligned the drawer should close halfway
without resistance. At the halfway point, if resistance is felt, pull the drawer back out a few centimetres then
push closed again. Repeat until drawer closes fully.
GENERAL
Make sure not to tighten bolts before attaching all components and making sure they sit square. Once you are
ready, make sure all bolts are snug, then tighten only with ¼ turn of the Allen Key. DO NOT USE powered drills
as over-tightening can cause components to bow.
