Sirius Satellite Radio SV1C One Manual

SV1C SIRIUS One
SIRIUS Satellite Radio Plug and Play
User and Installation Guide

SV1C Receiver User and Installation Guide
2
CONGRATULATIONS! Your new SV1C SIRIUS One SIRIUS®Satellite Radio Plug and Play Receiver lets
you enjoy SIRIUS Satellite Radio’s digital entertainment in your vehicle, home, or boat. Use this guide to
familiarize yourself with all of SV1’s features and capabilities. For the latest information about this and other
SIRIUSproducts,pleasevisithttp://www.siriusradio.com.
Table of Contents
Safety Precautions .......................................................... 4
FCCWarning .................................................................... 5
Cleaning the Receiver...................................................... 5
Package Contents............................................................ 6
Installation ..................................................................... 7
Location....................................................................... 7
Mounting the Receiver................................................ 7
Installing the MagneticAntenna ................................. 8
Connecting the Receiver .......................................... 10
Activating your SIRIUS Subscription ....................... 11
SV1C SIRIUS One Receiver Basic Operation ........ 13
RemoteControl.......................................................... 14
Installing Batteries in the Remote .......................... 14
Changing Channels................................................... 15
Display Button (DISP) ............................................... 15
Selecting Channels Directly ..................................... 16
Advanced Features ................................................... 17
Channel Presets (BAND).......................................... 17
Storing Channel Presets ........................................ 17
Using Channel Presets .......................................... 17
Searching for a Channel Preset (P.TUNE Mode)..... 18
FM Preset Button ...................................................... 18
Menu Options ............................................................. 19
FM Transmitter .......................................................... 20
FM Presets ............................................................. 20
FM On/Off............................................................... 21
Display Options......................................................... 21
Parental Control ........................................................ 22
Lock/Unlock ............................................................ 22
EditCode ................................................................ 23

SV1C Receiver User and Installation Guide 3
Table of Contents (continued)
©2005 SIRIUS Satellite Radio Inc.
® “SIRIUS,” the SIRIUS dog logo, channel names and logos
are trademarks of SIRIUS Satellite Radio Inc. “NFL” and the
NFL Shield logo, and the NFL Sunday Drive name and logo
are registered trademarks of the National Football League.
“NHL” and the NHL Shield are registered trademarks of the
National Hockey League. “NBA” and the NBA silhouette logo
are registered trademarks of NBA Properties Inc. Velcro is a
registered trademark of Velcro Industries B.V. All other
trademarks, service marks and logos are the property of their
respective owners. All Rights Reserved.
Audio Level ............................................................... 25
Signal Indicator ......................................................... 25
Factory Default ......................................................... 26
Troubleshooting ............................................................. 28
Specifications................................................................. 29
12MONTHLIMITEDWARRANTY .................................. 30

SV1C Receiver User and Installation Guide
4
• Ifthe LCDdisplay ontheReceiver becomes
damagedorbroken,donottouchtheliquidcrystal
fluid.Thefluidcanbe dangerousto yourhealth. If
theliquid crystalfluid contactsyour bodyor
clothing,immediately washit offwith soapand
water.
Caution
Takethe following precautions to keep the Receiver
inproperworkingorder:
• DonotopentheReceiver.
• Whenreplacing a fuse,use only anewone with
the proper rating. Using a fuse with the wrong
ratingmay causethe Receiverto malfunction.
• Topreventashort circuitwhenreplacing afuse,
first disconnect the wiring harness.
Note:
If the Receiver doesn’t seem to be working properly,
turn the Receiver’s power off, wait 5 – 10 seconds,
thenturnthepoweronagain.
Safety Precautions
Warning
Takethe following precautions to prevent fire and
avoid personal injury:
• Besurethe Receiver is installed as described in
theInstallationGuide.
• Theuse suggestionscontained inthis UserGuide
aresubject toany restrictionsorlimitations that
maybe imposedby applicablelaw—the purchaser
shouldcheck applicablelaw forany restrictionsor
limitationsbeforeinstalling and/oroperating this
Receiver.
• Failureto followthese safetyinstructions and
warnings may result in a serious accident.
• To avoid short circuits, never put or leave any
metallicobjects (coins, tools, etc.) inside the
Receiver.
• Ifthe Receiveremits smokeorunusual odors,turn
thepoweroffimmediately.
• Donot drop the Receiver,or subject it to strong
shocks.

SV1C Receiver User and Installation Guide 5
FCC Warning
This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless
the modifications are expressly approved in this
User Guide. The user could lose the authority to
operate this equipment if an unauthorized change or
modification is made.
Note:
This equipment has been tested and found to
comply with Part 15 of the FCC Rules. These
rules are designed to provide reasonable
protection against harmful interference. This
equipment may cause harmful interference to
radio communications if it is not installed and
used in accordance with these instructions.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio reception, which can be determined by
turning the equipment off and on, the user is
encouragedto try to correct theinterferenceby one of
moreof the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the other
equipmentandthe Receiver.
• Connectthe otherequipment toa differentcircuit
fromthat to which theReceiver is connected.
• Consultthedealeroran experiencedradio
technician for help.
Warning
Do not operate the Receiver in a way that might
divertyourattentionfrom driving safely.As a driver,
youaloneareresponsibleforsafely operating your
vehicle in accordance with traffic safety laws at all
times.
Cleaning the Receiver
If the Receiver becomes dirty, turn its power off and
wipe it clean with a soft dry cloth. Do not use hard
cloths,paintthinner,alcohol, or other volatile
solvents to clean the Receiver. These may cause
damage to the plastic or remove indicator
characters.

SV1C Receiver User and Installation Guide
6
Package Contents
SurfacePreparation
CleaningKit
(Toclean a surface of any
known / unknown emulsions
prior to applying adhesives.)
SV1C SIRIUS
One Receiver
MagneticAntenna
SIRIUSOne
Remote Control
RubberAntenna
CableCover/Tail
&Adhesive Strip
AlcoholSwaband
Velcro®Strips
SuctionCup Mount
Visor/DashMount
CigaretteLighter
Power Cord
UserGuide
The following items are packaged with the SV1C SIRIUS One. Check the package to be all of the items
are included. If any of the items are missing, please contact the retailer where you purchased the
product.
UserandInstallationGuide
SV1SIRIUSOne
SIRIUSSatellite Radio PlugandPlay
1
4
7
2
5
8
BAND DISP
MUTE CH
SEL
CH
MENU
CAT CAT
0
3
6
9
BAND DISP
1 2 3 4 5

SV1C Receiver User and Installation Guide 7
Installation
Installation of your SV1C SIRIUS One is easy:
1.Choose a location in your vehicle where you
will mount the Receiver, either on the visor,
the dash, or the windshield.
2.Mount the Receiver on the visor using the
visor/dash mount, or on the dash using the
visor/dash mount and the velcro strips, or on
the windshield using the suction cup mount.
3.Install the magnetic antenna on the roof of the
vehicle,androutetheantennacabletothe
Receiver.
4. Connect the power cord for the Receiver to your
vehicle’scigarette lighter.
5.Subscribe to the SIRIUS service and begin
enjoyingthe SIRIUS entertainment!
Location
Choose a location in your vehicle where the
Receiver will not block your vision, interfere with the
vehicle controls, or obstruct the air bag. If you are
using the suction cup mount, the location should be
suitable for using the suction cup mount, such as
the windshield or other flat, smooth surface.
Thelocationshouldbeeasily reachable and provide
goodvisibilityofthe Receiver.
Mounting the Receiver
Attach the desired mounting device, suction cup
mount or visor/dash mount, to the Receiver by
sliding the flat portion of the mount into the slot on
the back top edge of the Receiver. Gently slide the
mounting device in until it snaps into place.
S
N
A
P
S
N
A
P

SV1C Receiver User and Installation Guide
8
Depending upon your mounting choice, clip the
Receiver to the visor, or, use the velcro strips to
mount the Receiver to the dash, or, if you are using
the suction cup mount, lightly moisten the surface of
the suction cups which face the windshield (or other
surface) and press the suction cups to the mounting
surface.
Installing the MagneticAntenna
The optimum mounting location for the antenna is
on the roof of the vehicle, with a minimum
unobstructed area of 12 inches by 12 inches, and
exactly 6½ inches from the rear roof edge of the
vehicle(thelengthoftherubberantennacable
cover/tail). It is important to avoid any obstructions
that will block the SIRIUS signal, obstructions such
as a roof rack, a sunroof, roof mounted cargo
containers,orotherantennas.
The following illustrations show the recommended
mounting locations of the antenna for several types
of vehicles. Follow these recommendations for best
performance from the antenna.
Sedan/Coupe: Mount the antenna along the rear
centerline of the vehicle roof, located at the rear of
the roof near the rear window.
SUV/Mini-Van:Mount the antenna along the rear
centerline of the vehicle roof, located at the rear of
the roof near the rear door/hatch.
Pickup Truck: Mount the antenna along the rear
centerline of the cab roof, located at the rear of the
roof near the rear window.

SV1C Receiver User and Installation Guide 9
Convertible:Mounttheantenna along the centerline
of the trunk lid, with the rubber antenna cable cover/
tail directed toward the rear window.
Cleantheareawheretheantennaandrubber
antenna cable cover/tail will be mounted with the
supplied alcohol swab.
Connect the rubber antenna cable cover/tail to the
antenna cable, making sure that the strain-relief on
the antenna seats into the rubber antenna cable
cover/tailgroove.Route the antenna cable through
the wire channel in the rubber antenna cable cover/
tail. Do not yet attach the adhesive strip.
Temporarilyposition the antenna and rubber
antennacablecover/tailintheselectedmounting
area and route the cable from the antenna to the
vehicle’sinteriorbytucking it underneath the rubber
molding around rear window, as shown.
Route the cable from the lowest point of the rear
windowintothetrunk. Take advantageof any
existing cable channels or wiring conduits. For
SUVs, mini-vans & 5-door vehicles, bring the cable
into the vehicle under the rubber molding for the
tailgate,andcontinueundertheinteriortrim.
From the trunk, or rear of the vehicle, route the cable
around the passenger compartment and to the front
of the vehicle, to the receiver. Take care not pull the
cable across sharp edges that could damage it, and
keep it away from areas where it might entangle
feet. Coil any excess antenna cable in a location
where it can be hidden.
Once the antenna cable is routed through the
vehicle, and you are satisfied with the cable routing,

SV1C Receiver User and Installation Guide
10
peel the yellow protective material from the
adhesive strip and adhere the adhesive strip to the
rubberantennacover/tail.Next peel the red
protective material from the adhesive strip and
press the rubber antenna cable cover/tail firmly into
placeonthevehicle.
Double check that the location of the antenna and
rubber antenna cable cover/tail are correct, and
continue to press firmly down on rubber antenna
cable cover/tail for another 30 seconds.
Note: At room temperature (68 degrees), maximum
adhesion usually occurs within 72 hours. During this
period, avoid car washes and other contact with
the antenna and rubber antenna cable cover/tail.
Connecting the Receiver
Connect the antenna and cigarette lighter power
adapter to the Receiver to complete the installation.
The illustration below shows the location of the
antenna and power connectors on the Receiver.
Plug the cigarette lighter power adapter cord into
yourvehicle’scigarette lighter,and turn the Receiver
On by pressing the power button. Once you have
verified that Receiver has powered on, you can
RUBBERANTENNA
CABLECOVER/TAIL
VEHICLE
MOUNTINGSURFACE
RUBBERANTENNA
CABLECOVER/TAIL
ADHESIVE
STRIP
ANTENNA
CABLE
ANTENNA
(UNDERSIDE)
PROTECTIVE MATERIAL
(REDSIDE)

SV1C Receiver User and Installation Guide 11
proceed with activating your SIRIUS subscription.
Activating your SIRIUS Subscription
Before you can listen to the SIRIUS service, you
need to subscribe to the SIRIUS Satellite Radio
service.
1.Be sure that the Receiver is correctly installed
and that the antenna is oriented to receive the
SIRIUS signal.
2.Press the power button to turn Receiver On.
After displaying the SIRIUS logo, the Receiver
will update the SIRIUS channel line up. The
display will show, “UPDATING CHANNELS”
and show the status of the update.
HCDP %U X Xs
Wait until the channel updates have
completed before pressing any buttons on the
Receiver.
3. Once the channels have been updated, the
displaywillchange to “Call 1-888-539-SIRIUS to
Subscribe”andwillplaceyouin SIRIUS Satellite
Radio’sPreviewChannel, channel 184.
You will not be able to tune to any other
channelsuntilyou activate your SIRIUS
subscription.
1l 8a 8 5C 8 -l-
4. To listen tothe audiofrom yourReceiver,you will
needtotunetheFMradioin yourvehicle andthe
FMtransmitter inthe Receiverto thesame FM
frequency.The FMtransmitter inthe Receiver
defaultsto88.1MHz, soyou canbegin bytuning
yourFMradioto88.1 MHz.If thereis anFM station
ANT FM OUTAUDIO OUT DC IN
ANTENNA FM
OUT
AUDIO
OUT
DC
IN

SV1C Receiver User and Installation Guide
12
broadcasting on that frequency, you will have to
search for a quiet frequency to use. Refer to
the section titled, FM Transmitter in this User
Manual for instructions on how to tune the FM
transmitter to other FM frequencies.
5.Using the channel up and down buttons, tune
the Receiver to channel 000 to display the
Receiver’s unique 12-digit SIRIUS ID Number
(SID). You can also tune to channel 000 by
using the remote: Press the Select button,
then the 0 (zero) button, and then the Select
button again. (This SID number is also
available on the SV1C packaging.) Write the
SID number down in the space provided at
the end of this manual.
332 41 5 61 5 624
6.Haveyour credit card handy and contact SIRIUS
onthe Internet at:
https://activate.siriusradio.com/
and follow the prompts to activate your
subscription. You can also call SIRIUS toll-
free at:
1-888-539-SIRIUS (1-888-539-7474)
7.When you have successfully subscribed to
the SIRIUS service, and the Receiver has
been updated with your subscription
information, “UPDATED” will be followed by
“PRESSAKEY”.
ETDPU AD
SER KP E YSA
To continue, press any key on the Receiver.
The installation of your Receiver is now complete,
andyou are ready to begin enjoying SIRIUSSatellite
Radio’sdigitalentertainment!

SV1C Receiver User and Installation Guide 13
SV1C SIRIUS One Receiver Basic Operation
3
4
7
6
5
BAND DISP
1 2 3 4 5
1 8
9
2
1. POWER Button : Turns the Receiver’s power
On and Off.
2. ChannelUp/DownButtons: Navigates through
channelsand displayscreens.
3. BANDButton (P.Tune): Pressingand releasing
switchesbetween the five preset banks (A,B, C, D
andE), whichholdfive presetseach.Pressing and
holdingenables“PresetTuneMode”,which allows
forviewing andlistening ofstored presetswith the
channelup/downbuttons.
4. Preset Number Buttons (1-5): Sets and selects
presetchannels.Also usedto directlytune
channelsbyentering thechannel number.
5. DISP(Display)Button:Togglesdisplay between
thechannel numberand name,channel number
andcategory,channelnumber andartist name,
andchannelnumber andsong title.Holding the
DISPbutton downflips thedisplay screen180
degreestoenablemountingthe Receiverupside
downon avehicle visor.
6. CategoryPrevious/NextButtons: Navigates
throughthe category(genre) listscreen which
displaysSIRIUSchannel categories.
7. Select Button: Selects items displayed on the
screen and accesses the setup menu.
8. FM Preset Button: Selects between preset FM
frequenciesused forthe built-inwireless
transmitter.Pressingand holdingthe FMPreset
buttonwill access the listof FM presets whereyou
canchange them.
9. Mounting Release Button: Thisbutton releases
themount whichis connected tothe Receiver.

SV1C Receiver User and Installation Guide
14
Remote Control 1. Power Button : Turns the Receiver power On and
Off.
2. NumberButtons(0-9): Usedfor directlyselecting
channelsand forpresets.
3. BANDButton: Switches betweenpreset bandsA,B,
C, D, and E.
4. MUTEButton:Mutes theaudio.
5. CategoryPrevious/NextButtons: Navigatesthrough
categories(genres).
6. ChannelUp/DownButtons: Navigates through
channelsand displayscreens.
7. Select Button: Selects items on the display screen.
8. MENU Button: Used to access menu options to make
setupandfeaturechanges.
9. DISPButton:Togglesdisplaybetween thechannel
numberandname,channelnumberandcategory,
channelnumber andartist name,and channelnumber
andsongtitle.HoldingtheDISPbuttondownflips the
displayscreen 180degrees toenable mountingthe
Receiverupsidedown ona vehiclevisor.
10.FM Preset Button: Selects between preset FM
frequenciesused forthe built-inwireless transmitter.
Installing Batteries in the Remote
1.Remove thebattery cover.
2.InstallCR2032 battery.(+positive sideis up)
3.Replace thebattery cover.
1
4
7
2
5
8
BAND DISP
MUTE CH
SEL
CH
MENU
CAT CAT
0
3
6
9
1
3
2
6
4
5
10
9
7
8
5

SV1C Receiver User and Installation Guide 15
51POP []
Pressing the category previous or next button will
cause the Receiver to display a listing of the
previousornextchannelcategory.
Use the channel up/down buttons to display a
channel within a category and press the select
button to tune to the channel. When a new channel
is selected, the display will revert to the default
display screen for the new channel.
Display Button (DISP)
Momentarily pressing and releasing the DISP
(Display) button while the default screen is
displayed causes the Receiver to sequence the
displaybetweenthechannel number and channel
name, channel number and category name, channel
number and artist name, and channel number and
songtitle.
Afteryouhave successfully activated your SIRIUS
subscription, and the Receiver has received the
subscriptioninformationfromtheSIRIUSsignal,the
default display screen will be displayed.
rP4 v8 i1 e we
When the Receiver is powered On, the previously
selectedchannelwill automatically begin playing,
and the channel name of the current channel will be
displayed.
Changing Channels
Pressing the channel up or down button will cause
the Receiver to immediately tune to the next or
previouschannel.
Pressing the category previous or next button will
cause the receiver to display a list of the channels in
the current category. Use the channel up and down
buttonstonavigatethrough the list.

SV1C Receiver User and Installation Guide
16
lC4 V1 i l0 n ys
oR4 k10 c
lA4 c1 e o0 Ci
cS4 o1 o s0 l 'h
Note: If you are viewing a sports category channel
list (NFL®, NBA®, NHL®, or College), pressing and
releasingtheDISP buttonwillinsteadtoggle
between the team names and the current score of
anylive play-by-play game.
Use the category previous and next buttons to scroll
through the music and entertainment categories,
and the channel up and down buttons to scroll
throughtheavailablechannelsineachcategoryto
find the channel to which you want to listen.
When you have found the channel you wish to listen
to, press the select buttonto tune to the channel.
Thenewchannelwillbegin playing and the display
will revert to the default display screen for the new
channel.
Pressing and holding the DISP button for 1 second
will cause the Receiver to flip the display screen 180
degreestoenablemountingtheReceiver upside
down on a vehicle visor.
Selecting Channels Directly
Achannelmaybedirectlyselectedbyenteringthe
channel number using 0-9 buttons on the remote
control.
To enter a channel number, momentarily press and
release the select button.At the display prompt,
enterthethreedigitchannelnumber.
:# _H _C _

SV1C Receiver User and Installation Guide 17
Advanced Features
Channel Presets (BAND)
You canstore upto 30 of yourfavorite channelsas
presets for quick recall access. The preset channels
are stored in 5 bands,A, B, C, D, E, and F each
containing5channel presets, and are numbered 1
to 5. The 5 channel presets in each band are
accessed by pressing the appropriate number (1 to
5) on the Receiver.A momentary press and release
of the BAND button cycles through the 5 preset
bands (A, B, C, D, E, and F).
Storing Channel Presets
To store a favorite channel as a preset, do the
following:
1. Momentarily press and release the BAND
button until the desired preset band,A, B, C, D,
E, or F, is displayed.
2. Tune the Receiver to the channel you wish to
store as a preset. (See the section, Basic
Operation for specific instructions for tuning to a
channel.)
3. Press and hold for 1 second the numbered
preset button in which you wish to store your
favoritechannel.Thebandandpresetnumber
will then be displayed to confirm that the
channel has been stored.
1A4 S1 a d0 v e
Note: If the preset button already has a channel
stored in it, the preset will be replaced by the newly
stored channel.
Using Channel Presets
Press and release the BAND button to cycle
between the preset bands until the preset band you
wantisdisplayed.
The 5 preset channels in the active band can then
be selected by momentarily pressing and releasing
the 1 through 5 buttons.
When you have chosen a preset channel, the band
and preset number will be displayed.
A 1

SV1C Receiver User and Installation Guide
18
presets are not displayed.
3. To exit the P.TUNE mode, press and hold the
BANDbuttonfor approximately 1 second, until
the default display screen is displayed.
FM Preset Button
The Receiver has a special button called the FM
Preset button, which is identified by the icon.
When the FM Preset button is pressed, the
Receiver turns on the built-in FM transmitter and
begins transmitting on the next frequency from the
FM frequency preset list.A screen will be displayed
for 3 seconds showing the currently selected FM
frequency. When the FM transmitter is turned on, an
FMradiotunedtothesameFMfrequencywill
receivethecurrently tuned SIRIUS broadcast.
-M 8 1F 8 .1
Each subsequent press of the FM Preset button
advances to the next preset in the FM frequency
preset list. By using the FM Preset button, a quiet
FMfrequencymay be quickly tuned.
Searching for a Channel Preset (P.TUNE Mode)
To quickly search through all of your presets in the
P.TUNE mode, do the following:
1. Press and hold the BAND button for
approximately1secondtoentertheP.TUNE
mode.“PresetTuningMode” will momentarily be
displayed and the preset number will be
displayed to indicate the Receiver is in the
PresetTuneMode.
enT M. oP d eu
sl i1 nA y lCV
2. Use the channel up and down buttons to move
up or down through your channel presets and
immediatelytunetoeachchannel.Channel
presetsaregroupedanddisplayedbybank and
preset number, i.e., A1,A2...B1, B2, etc. Empty

SV1C Receiver User and Installation Guide 19
If no FM frequencies have been preset when the
FM Preset button is pressed, the Receiver will
default to a frequency of 88.1 MHz.
Pressing and holding the FM Preset button will
display the list of FM presets. Use the channel up
and down buttons to browse through the list.
-M 8 1F 8 .1
-M 9 5F 1 .2
- 1M 0 9F 3 .5
If you want to change the FM frequency of a preset,
press the select button to choose the preset when it
is displayed. Use the channel up and down buttons
to select an FM frequency and press the select
button. The preset will now display the new FM
frequency. To select the preset, press the MENU
button.
You may also change the FM presets by using the
FM Presets menu option of the Receiver. (Refer to
the FM Transmitter section in the Menu Options
section of this manual for instructions on
programming the FM presets list.)
Menu Options
To enter the Menu Options page of the Receiver,
press and hold the select button, or press the
MENU button on the remote control. The menu
options will be then displayed.
To select a menu option, use the channel up and
down buttons to display the option you wish to
adjust, and press the select button. If a selection is
not made within 10 seconds, the Receiver will exit
the menu options mode, and revert to the last active
display mode.
AR SM MF I TTN

SV1C Receiver User and Installation Guide
20
FM Presets
To create or add to a list of FM preset frequencies,
do the following:
1.Using the channel up and down buttons,
display the “FM PRESETS” menu item and
press the select button. You will then enter a
list of FM presets. (You may also enter this list
by pressing and holding the FM Preset
button.)
-M 8 1F 8 .1
2.Using the channel up and down buttons, display
the FM preset you wish to set (or change) and
press the select button. You will then enter a
list of FM frequencies, beginning with the
currently selected FM frequency for the preset.
18 H8 z.M
3.Use your FM radio to locate quiet FM
frequencies where there is no interference
To exit menu options, or any of the other menu
option screens, repeatedly press and release the
MENU key on the remote control until you are
returned to the default display screen.
The following sections explain each of the menu
options in the order in which they are displayed on
the Menu Options screen.
FM Transmitter
The FM Transmitter feature allows you to create a
preset list of 5 suitable FM frequencies which can
then be accessed by using the FM Preset button.
This option also allows you to turn the FM
transmitter On and Off.
ER EM TF SPS
/n fM fF OO
