Sirius Satellite Radio ALFRESCO SL80 User manual

1
SL80 ALFRESCO RANGEHOOD
ONBOARD INSTALLATION INSTRUCTIONS
Congratulations on your purchase!
Thank you for choosing a Sirius product.
SL80FRESCO900 EAN# 9351116000950
SL80BBQ1200M EAN# 9351116001032
SL80BBQ1200B EAN# 9351116002732
www.siriusbrand.com

2

3
BEFORE YOU INSTALL
INSTALLING THE RANGEHOOD
OPERATION
MAINTENANCE
SL80 WIRING DIAGRAM
BRACKET TEMPLATE
WARRANTY
4
6
8
8
9
10
11

4
The symbol on the product or on its packaging indicates that this product
may not be treated as house-hold waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the
product. This appliance is marked according to the European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory
such as flexible ducting, Sirius will only warrant the rangehood and motor. If installation is found to be
the cause of failure or issue then charges will apply for service and parts.
Flexible ducting is not permitted under any circumstances. Flexible ducting has been found to
increase noise levels, increase vibration and reduce airflow. Sirius Semi-rigid or solid ducting can be
used in lieu. There is a range available to suit any application.
Ducting available at www.siriusbrand.com
6 Year Warranty when Sirius Ducting is used. Full replacement warranty on parts and labour.
See website for terms & conditions.
A reduction in the duct diameter from stated ducting size will void warranty.
If you are in doubt about the ducting, please contact Sirius on 1300 762 219 prior to installation
WARNING
The appliance must be installed and
connected to the power supply only by a
qualified technician.
• There should be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the
room)
• The details concerning the method and frequency of cleaning
• There is a fire risk if cleaning is not carried out in accordance with the instructions;
• Do not flambé under the range hood;
• CAUTION: Accessible parts may become hot when used with cooking appliances.
BEFORE YOU INSTALL - DUCTING INFORMATION

5
Min. 1200mm - Max. 1600mm distance for
barbecues.
If the rangehood is positioned above the max height
recommended, warranty may be compromised
as performance of the rangehood will be affected.
Measurement is taken from the top of the grills to the
underside of the hood. (Fig.1)
• The air being drawn can’t be conveyed through
or into a duct used to let out fumes from
appliances fed by energy other than electric
power (eg. centralized heating, radiators, water
heaters, etc.).
• Attention: remove any possible PVC film from the
stainless steel, including the filters.
• To externally vent, please comply with the
pertaining rules given by competent authorities.
• Provide the room with an adequate ventilation
when a rangehood and appliances fed by energy
other than electric power (gas, oil, or coal stoves,
etc.) are used simultaneously. The rangehood,
when evacuating the air, could generate a
negative pressure in the room which can’t exceed
the limit of 0.04 mbar, in order to avoid the
suck of exhausts deriving from the heat source.
Therefore the room should be provided with air
intakes to allow a constant flow of fresh air.
If the rating label in the rangehood shows the symbol
, the appliance is built in class II° and it does not
need any earth connection.
If the rating label in the rangehood does not show
the symbol , the appliance is built in class I° and it
needs the earth connection.
When performing the electrical connections on the
appliance, please make sure that the current-tap
is provided with earth connection and that voltage
values correspond to those indicated on the label
placed inside the appliance itself.
Before carrying out any cleaning or maintaining
operations, the appliance needs to be switched off.
If the appliance is not provided with a non-separable
When ducting rangehood, options are as follows:
Roof vent - EASYROOF 200T/M
*Kit includes roof flashing
Download installation guide
Eave vent - EASYEAVE 200
Download installation guide
Wall vent - EASYWALL 200
Download installation guide
flexible cable and plug, or with another device
ensuring omnipolar disconnections from the grid,
with an opening distance between the contacts of at
least 3mm, then such disconnecting devices must be
supplied within the fixed installation.
If the fixed appliance is endowed with a supply cord
and a plug, the appliance has to be put in a place
where the plug can be reached easily.
The use of materials which can burst into flames
should be avoided in close proximity of the appliance.
When frying, please pay particular attention to fire
risk due to oil grease. Being highly flammable, fried
oil is especially dangerous. Do not use uncovered
electric grills. In order to avoid possible fire risk, all
instructions for grease-filter cleaning and for removing
eventual grease deposits should be strictly followed.
WARNING
Min. 1200 - Max. 1600
(Fig. 1)
(Fig. 2a)
(Fig. 2b)
(Fig. 2c)
Dome
featured on
200mm kit
only
FRONT VIEW

6
1. The rangehood is quite heavy, so two people
will be needed for installation.
2. Before connecting any ducting to the motor,
make sure the non-return valves - which are on
the air outlet of the motor - can swing open.
3. Using the supplied bracket template (pg. 8), mark
the location of the holes that need to be drilled
in the wall, being careful to make sure that the
wall behind is clear of electrical wiring, plumbing,
pipes etc. Note: Be sure to set the height of the
rangehood between the minimum and maximum
height requirements as per diagram Fig. 1( Pg. 3).
This can be done by measuring from the lowest
point of the rangehood to the horizontal support
bar. (Fig. 4)
SL80 FRESCO RANGEHOOD
INSTALLATION - ONBOARD MOTOR
Before installing the appliance, make sure that
none of the parts are damaged in any way. In
case of damaged parts, contact your retailer
and do not proceed with installation. Read all
of the following instructions with care before
installing the appliance.
• Use ducting within the min/max specifications
• Limit the number of ducting bends.
• Do not make any changes in ducting diameter:
Must be Ø 200 mm or equal surface area).
Before installing the appliance - in order not to
damage the appliance itself - the metal grease filter
should be removed. These filters could be removed
by pushing the handles towards the back side of the
rangehood and pulling it downwards to unfasten it
from its slot. (Fig.3).
NOTE
CAUTION
WARNING
(Fig. 4)
WARNING: Failure to install the screws or fixing
device in accordance with these instructions
may result in electrical hazards.
To install the appliance please follow these
instructions:
• The appliance must be installed by qualified
technicians, or where possible use a Sirius
recommended installer. See siriusbrand.com. In
order to avoid damage to the electronic parts
of the appliance, please do not use additional
screws.
1. Prepare the power supply - 240 volts.
2. Prepare a 210mm hole for the exhaust.
• Maximum length of ducting should not exceed 7
metres.
• Do not use screws to fix the ducting to the
rangehoods as they will prevent the movement of
non-return valves.
• Limit the number of elbows in the ducting, since
each elbow reduces the duct efficiency by 1
metre. (i.e. if you use two 90° elbows, the length
of ducting must not exceed 5 metres.)
• Avoid abrupt direction changes.
• Use 200mm constant diameter ducting for the
whole length for this twin motor rangehood.
• The use of Sirius ducting will increase the
warranty of the unit to 6 years.
(Fig. 3a)
(Fig. 3b)

7
(Fig. 6)
NOTE: Model measurements will vary.
Please check specific model specs.
4. Using an 8mm drill bit, pre-drill the holes that
will hold the bracket to the wall. (Using bracket
template)
5. Insert the supplied plastic dowels to the
pre-drilled holes and fix bracket to the wall with
the supplied screws. (Note: Please use a spirit
level to make sure the bracket is perfectly level.)
6. Once the bracket is secure, using two people,
lift the hood and drop the horizontal support bar
onto the fixed bracket (Fig. 5).
(Note: There are additional holes on the inside of
the hood to secure the rangehood flush to the wall
and completely stable. (Hole locations will vary per
model.)
7. Connect your Sirius ducting
(see www.siriusbrand.com for approved
ducting) to the outlet collar on the rangehood and
secure in place with a ring clamp if you are using
semi rigid ducting. If you are using solid/rigid
ducting, an external duct connector is required.
(Note: do not fix the ducting in place with screws
as they will prevent the movement of the non-
return valves). (See Fig. 2 for ducting options).
Complete all of the duct work to the atmosphere
before fixing the flue covers in place to ensure the
ducting has not come free.
(Fig. 5)
8. Insert the upper flue cover into the lower flue
cover and mount into the channel on the top of
the rangehood. There are two spring loaded clips
that need to be on the inside of the lower flue
cover to secure in place. (Fig 6.)
9. Telescope the upper flue cover to the ceiling and
mark with a pencil the outer line of the cover, this
will give you the exact location of where the top
fixing bracket needs to be fitter to the ceiling.
10. Fix the top fixing bracket into place using the
supplied 30mm screws (Fig.7).
(Fig. 7)
30mm
NOTE
Please do not fix shroud permanently.
Must be removable for servicing purposes.

8
• Accurate maintenance guarantees good
functioning and long-lasting performance.
• Particular care is due to the grease filters.
They can be removed by pushing its handle
toward the back side of the rangehood and
pulling the filter downwards so to unfasten it from
its slot (Fig.3).
To insert the filter just perform the opposite
operation.
• After 30 hours of operation, the push button
control panel will flash, signaling the filters are due
for cleaning. Press the timer button to reset.
The grease filter needs cleaning by regular
handwashing or in dishwashers every two
months at least, depending on its use.
• Filters may require cleaning sooner if
frequent heavy cooking is done.
• To clean the appliance itself, water and detergent
are recommended, while abrasive products
should be avoided. For steel appliances
specialized detergents are recommended (please
follow the instructions indicated on the product
itself to obtain the desired results).
MAINTENANCE
Manual control buttons:
SL80FRESCO900
SL80BBQ1200M
SL80BBQ1200B
A: Light switch on/off
B: Motor switch on speed 1/off - (low/simmer)
C: Motor switch on speed 2 - (general cooking)
D: Motor switch on speed 3 - (high power)
E: Motor switch on speed 4 - (booster)
F: 10 minute shut-off timer
OPERATION
11. Telescope the upper flue cover over the bracket
and secure in place with the very small 10mm
supplied screws. (Fig 8.)
(Fig. 8)
10mm

9
SL80 WIRING DIAGRAM

10
BRACKET TEMPLATE
