Skil PWRCORE 20 HT4222E-00 User manual
WARNING: To reduce the risk of injury, the user must read and understand the
Owner’s Manual before using this product. Save these instructions for future reference.
For Customer Service
Cordless Hedge Trimmer
Model: HT4222E-00
TM
1300-017-545 OR www.skil.com.au
2
1
4
6 7
Rear handle switch
Lock o knob
Ventilation slots
Cutting blades
Storage rail
53
Front handle switch
Protective guard Storage hook
Blade cover
Blade tip protector
XXdB
8
2SPECIFICATIONS
Rated Voltage 20V max d.c.
Weight 3.0 kg (with 2.5 Ah battery pack attached)
Weight 3.3 kg (with 5.0 Ah battery pack attached)
Cutting Length 55cm
Max Cutting Diameter 20mm
No-Load Speed 2800 SPM (stroke per minute)
3
10 cm
100 cm
Rear handle switch
Front handle switch
Lock o knob
Battery
level
indicator
9 q
w
e r
Storage
rail
Storage hook
9
9
9
a
b
c
2
2
1
4
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the o-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and o. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may aect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
INTRODUCTION
• This tool has been designed for trimming hedges and
bushes and is intended for domestic use only
• This tool is not intended for professional use
• Read this instruction manual carefully before use
and save it for future reference 3
• Pay special attention to the safety instructions
and warnings; failure to follow these may result in
serious injury
• Check whether the packaging contains all parts as
illustrated in drawing 1
• When parts are missing or damaged, please contact your
dealer
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
-WARNING Read all safety warnings, instructions,
illustrations and specications provided with this
power tool. Failure to follow all instructions listed below may
result in electric shock, re and/or serious injury. Save all
warnings and instructions for future reference. The term
“power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power
tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
5
b) Carry the hedge trimmer by the handle with the
blade stopped and taking care not to operate any
power switch. Proper carrying of the hedge trimmer will
decrease the risk of inadvertent starting and resultant
personal injury from the blades.
c) When transporting or storing the hedge trimmer,
always t the blade cover. Proper handling of the
hedge trimmer will decrease the risk of personal injury
from the blades.
d) When clearing jammed material or servicing the
unit, make sure all power switches are o and
the battery pack is removed or disconnected.
Unexpected actuation of the hedge trimmer while
clearing jammed material or servicing may result in
serious personal injury.
e) Hold the hedge trimmer by insulated gripping
surfaces only, because the blade may contact
hidden wiring. Blades contacting a "live" wire may make
exposed metal parts of the hedge trimmer "live" and
could give the operator an electric shock.
f) Keep all power cords and cables away from cutting
area. Power cords or cables may be hidden in hedges or
bushes and can be accidentally cut by the blade.
g) Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of
lightning. This decreases the risk of being struck by
lightning.
BEFORE USE
• This tool is not intended for use by children and
persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge
• Ensure that children do not play with the tool
• Do not leave the tool unattended
• Only use the tool in daylight or with appropriate articial
lighting
• Do not trim hedges when they are wet
• Never use the tool with a defective protective guard
• Check the functioning of the tool before each use and,
in case of a defect, have it repaired immediately by a
qualied person; never open the tool yourself
• Before use, thoroughly inspect the cutting area and
remove all foreign objects that could be entangled in the
cutting blades (such as stones, nails, wire fences, metal
plant supports)
DURING USE
• Wear protective gloves, a dust mask, close-tting clothes
and sturdy shoes
• Do not operate the tool when barefoot or wearing open
sandals
• Always wear long trousers and long sleeves when
operating the tool
• Keep other persons and animals at a distance of 5
metres when using the tool
• Take a secure stance when working (do not overreach,
especially when using steps or a ladder)
• In case of electrical or mechanical malfunction,
immediately switch o the tool and remove battery
AFTER USE
• Store the tool indoors in a dry and locked-up place, out
of reach of children
-store the battery pack separately from the tool
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations dierent
from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
b) Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
c) When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a re.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
f) Do not expose a battery pack or tool to re or
excessive temperature. Exposure to re or temperature
above 130°C may cause explosion.
g) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging
improperly or at temperatures outside the specied range
may damage the battery and increase the risk of re.
6) SERVICE
a) Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
SPECIFIC SAFETY INSTRUCTIONS FOR HEDGE
CUTTERS
a) Keep all parts of the body away from the blade. Do
not remove cut material or hold material to be cut
when blades are moving. Blades continue to move
after the switch is turned o. A moment of inattention
while operating the hedge trimmer may result in serious
personal injury.
6
-trim the side of a hedge in such a way that it will be
slightly narrower at the top
-use a hand saw or pruning shears to cut thicker
branches
• Holding and guiding the tool e
-hold the tool rmly with both hands and take a secure
stance
! while working, always hold the tool at the grey-
coloured grip area(s)
-guide the tool ahead of you
APPLICATION ADVICE
• For trimming a hedge at a uniform height level
-fasten a piece of string along the length of the hedge at
the desired height
-trim the hedge just above this string
MAINTENANCE / SERVICE
• This tool is not intended for professional use
• Keep tool and cutting blades clean
! remove battery from tool before cleaning
-clean the tool with a damp cloth (do not use cleaning
agents or solvents)
-clean ventilation slots 1 regularly with a brush or
compressed air
-after use, always carefully clean and lightly lubricate the
cutting blades
! wear gloves when handling or cleaning the cutting
blades
• Regularly check the condition of the cutting blades and
the tightness of the blade bolts
• Regularly check for worn or damaged components and
have them repaired/replaced when necessary
• Sharpening the cutting blades
! remove battery from tool
-sharpen the cutting blades with a small and smooth le,
in case a solid object damaged them
-we advise you, however, to have the blades sharpened
by a specialist
-lubricate the cutting blades after sharpening
• Storage r
-securely mount storage rail on the wall with 2 screws
(not supplied) and horizontally leveled
-use blade cover when storing the tool
-before storing the tool, wipe o the cutting blades with
an oil-soaked rag to prevent corrosion
TROUBLESHOOTING
• The following listing shows problem symptoms, possible
causes and corrective actions (if these do not identify
and correct the problem, contact your dealer or service
station)
! in case of electrical or mechanical malfunction,
immediately switch o the tool and remove battery
Motor does not start or stops suddenly
-empty battery -> charge battery
-hot battery -> let battery cool down
-cutting blades jammed -> clear jammed material
-internal fault -> contact dealer/service station
Tool operates intermittently
-on/o switch defective -> contact dealer/service station
-internal wiring defective -> contact dealer/service
station
• Only use the following batteries and chargers with
this tool
-SKIL battery: BY5197E-03 BY5196E-03
-SKIL charger: SC5358E-01 QC5360E-01 QC5359E-00
• Do not use the battery when damaged; it should be
replaced
• Do not disassemble the battery
• Do not expose tool/battery to rain
• Permitted ambient temperature (tool/charger/battery):
-when charging 4...40°C
-during operation –20...+50°C
-during storage –20...+50°C
EXPLANATION OF SYMBOLS ON TOOL/BATTERY
3 Read the instruction manual before use
4 DANGER - Keep hands away from the blade
5Wear protective glasses and hearing protection
6Do not expose tool to rain
7 Do not dispose of electric tools and batteries together
with household waste material
8Guaranteed sound power level
USE
• Charging battery
! read the safety warnings and instructions
provided with the charger
• Battery protection
The tool is suddenly being switched o or prevented from
being switched on, when
-the load is too high --> remove load and restart
-the battery temperature is not within the allowable
operating temperature range of -20 to +50°C --> 2
levels of the battery level indicator start ashing when
pressing button 9c; wait until battery has returned
within the allowable operating temperature range
-the battery is nearly empty (to protect against
deep discharge) --> a low battery level or ashing low
battery level 9b is shown by the battery level indicator
when pressing button; charge battery
! do not continue to press the on/o switch after the
tool is switched o automatically; battery may be
damaged
• Two-hand safety switch q
Prevents the tool from being switched on accidentally
-rst unlock by pressing knob
-switch on the tool by pressing both switch and switch
-switch o the tool by releasing either switch or switch
• Operating the tool
! start trimming only when motor is running
! do not cut groundcovering plants in order to
prevent earth/sand from damaging cutting blades
! do not overload the tool by cutting stems larger
than 20 mm in thickness
-move tool away from cutting area before switching o
! after switching o the tool the blades continue to
move for a few seconds
• Blade tip protector 1
-prevents kickback of the tool when solid objects (such
as fence posts or house walls) are touched
-protects the end blades from damage
• Trimming hedges w
-trim the sides of the hedge rst (from the bottom
upwards), then cut the top
7
-impeller blocked by foreign object -> remove blockage
Motor runs but blades remain stationary
-internal fault -> contact dealer/service station
Cutting blades hot
-cutting blades blunt -> have blades sharpened
-cutting blades have dents -> have blades inspected
-too much friction due to lack of lubricant -> lubricate
blades
ENVIRONMENT
• Do not dispose of electric tools, batteries,
accessories and packaging together with household
waste material. The electric tools, accessories and
packaging should be sorted for environmental-friendly
recycling
! prior to disposal protect battery terminals with
heavy tape to prevent short-circuit
8
WARRANTY
SKIL WARRANTY POLICY
For all SKIL warranty & enquiries, please contact 1300 01
SKIL (1300 01 7545) Monday to Friday 9:00am to 5:00pm
EST
Chervon Australia Pty Ltd ABN 36 165 077 501 (“Chervon”)
warrants to the original domestic purchaser that this product
will be free from defects in materials and workmanship for
5 years from date of purchase, and any battery or charger
will be free from defects in materials and workmanship for 3
years from date of purchase. Consumables will be covered
by a 3-month warranty and a complete list can be found
inside the manual.
Notwithstanding the foregoing, if a SKIL consumer Power
Tool is used for industrial, professional or commercial
purposes, the foregoing warranty will apply for a duration
of ninety days from the date of purchase. This ninety-day
commercial warranty pertains to the SKIL Power Tool range
only.
This SKIL product warranty is only applicable to purchases
from authorised SKIL retailers. This warranty will not apply to
SKIL products that are purchased from Amazon, eBay and
any other non-authorised online retailer. This SKIL product
warranty does not apply to any parallel imported product and
does not apply to any SKIL products that are not purchased
from an authorised SKIL retailer.To make a claim, return
the faulty item together with proof of purchase directly to
your closest service agent or to the place of purchase. Any
handling and transportation costs (and other expenses
incurred in claiming this warranty) are not covered by this
warranty and will not be borne by Chervon. The replacement
product or part or repaired product will be made available
for your collection at an address nominated by Chervon.
Where a valid warranty claim is made, Chervon will replace
the defective product or repair the fault. Where the product is
repaired, Chervon may use refurbished parts. This warranty
does not cover normal wear and tear, misuse or abuse. This
warranty may also be further limited or voided as specically
detailed in the product manual. Chervon has no other liability
under this warranty. The benets to you given by this warranty
are in addition to other rights and remedies imposed by State
and Federal legislation that cannot be excluded. Our goods
come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to
a major failure. Chervon Australia Pty Ltd, Unit 14, 5 Kelletts
Road, Rowville, VIC. 3178.
Ph; 1300 01 SKIL (1300 01 7545).
Email: [email protected]
The following accessories and consumables have a 3-month
warranty period:
Chucks Allen keys
Brushes Angle grinder anges
Collets Dust canisters
Industry leading battery
technology wraps each
cell with cooling material
to keep the battery
powering on for 25%
longer run time compare
to general battery
technology.
SKIL’s patented technology
extends the battery life 2X
longer compare to general
battery technology.
LONGER
RUN TIME
PWRCORE 20™
LITHIUM
*
2X
BATTERY LIFE
PWRCORE 20™
LITHIUM
*
*
Table of contents
Other Skil Trimmer manuals
